Crestron HD-XSP How to use

Crestron HD-XSP
7.1 High-Definition Professional Surround
Sound Processor
Operations & Installation Guide

Important Safety Instructions
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•
Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
•Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
•Only use attachments/accessories specified by the
manufacturer.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED
TO DRIPPING OR SPLASHING. OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED
ON THE APPARATUS.
WARNING:
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. ONLY QUALIFIED SERVICE PERSONNEL
SHOULD PERFORM SERVICE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product's enclosure t hat may be of sufficient magnitude
to constitute a risk of electric shock to persons.
•Use only with the cart, stand, tripod, bracket or
table specified by the manufacturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
THIS IS AN APPARATUS WITH CLASS I
CONSTRUCTION. IT SHALL BE CONNECTED TO AN
ELECTRICAL OUTLET WITH AN EARTHING GROUND
TERMINAL.
IMPORTANT:
This device can be used with Class 2 output wiring.
•Unplug this apparatus during lightning storms or when
unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•Disconnect power prior to connecting or disconnecting
equipment.
•Do not install in direct sunlight.
•
The apparatus must be installed in a way that the power cord
can be removed either from the wall outlet or from the
device itself in order to disconnect the mains power.
•
Prevent foreign objects from entering the device.

The specific patents that cover Crestron products are listed at patents.crestron.com.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other
U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are registered trademarks & DTS-HD
Master Audio is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.
Manufactured under license from Dolby Laboratories.
Crestron, the Crestron logo, Cresnet, Crestron Studio, Crestron Toolbox, DigitalMedia, DM, PROCISE, QuickSwitch HD, and Sonnex are either
trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Blu-ray Disc is either a trademark or
registered trademark of the Blu-ray Disc Association (BDA) in the United States and/or other countries. Dolby, Pro Logic, the Double-D symbol, and
Dolby Digital are either trademarks or registered trademarks of Dolby Laboratories in the United States and/or other countries. DTS-HD Master Audio
and the DTS-HD Master Audio logo are either trademarks or registered trademarks of DTS in the United States and/or other countries. HDMI, the
HDMI logo and High Definition Multimedia Interface are either trademarks or registered trademarks of HDMI Licensing LLC in the United States
and/or other countries. Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for
errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2013 Crestron Electronics, Inc.
Regulatory Compliance
As of the date of manufacture, the HD-XSP has been tested and found to comply with specifications for CE
marking and standards per EMC and Radiocommunications Compliance Labelling.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A Contents •i
Contents
7.1 High-Definition Professional Surround Sound Processor: HD-XSP 1
Introduction ............................................................................................................................... 1
Features and Functions ................................................................................................ 1
Applications................................................................................................................. 5
Internal Block Diagram ...............................................................................................7
Specifications ..............................................................................................................7
Physical Description.................................................................................................. 11
Setup ........................................................................................................................................ 15
Network Wiring......................................................................................................... 15
Identity Code ............................................................................................................. 15
Installation ................................................................................................................. 15
Hardware Hookup ..................................................................................................... 18
Uploading and Upgrading........................................................................................................ 20
Establishing Communication..................................................................................... 20
Programs and Firmware ............................................................................................ 21
Program Checks ........................................................................................................ 21
Configuration........................................................................................................................... 23
“Installer” Menu ........................................................................................................ 23
Configure Inputs........................................................................................................ 24
Configure Outputs ..................................................................................................... 25
Configure Network.................................................................................................... 28
Configure Front Panel ............................................................................................... 33
Operation ................................................................................................................................. 35
Select a Source or Decoding Mode ........................................................................... 35
Volume Control and Mute (Theater Output Only) .................................................... 37
Additional Functions ................................................................................................. 37
Problem Solving ...................................................................................................................... 43
Troubleshooting......................................................................................................... 43
Reference Documents................................................................................................ 43
Further Inquiries ........................................................................................................ 43
Future Updates .......................................................................................................... 43
Return and Warranty Policies .................................................................................................. 45
Merchandise Returns / Repair Service ...................................................................... 45
Crestron Limited Warranty........................................................................................ 45

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •1
•True 7.1 surround sound processing for commercial and residential
applications
•All of the needed features and performance — none of the complexity
or cost
•DTS-HD Master Audio™, Dolby®TrueHD, and Dolby Digital®Plus
decoding
•HDMI®, S/PDIF (optical and coaxial), and stereo analog inputs
•Source input compensation and 80 ms lip sync adjustment per input
•Balanced analog 7.1 surround sound line outputs
•DSP with 9-band graphic or parametric EQ, delay, crossover and
compression
•Support for systems without a center speaker or subwoofer
•High-definition 3D video pass-through via HDMI
•Balanced stereo or mono downmix output
•
Balanced stereo mix input
7.1 High-Definition Professional
Surround Sound Processor:
HD-XSP
Introduction
Modern boardrooms and auditoriums are more than just places to meet and speak to
an audience — they are high-tech presentation environments where groups gather to
share ideas, inspire thought, and motivate action through the use of dynamic,
interactive multimedia. In an age where the televisions in our homes are commonly
supplemented by some kind of surround sound enhancement, it is only logical that
the same aural experience should be found in any corporate, government, hospitality
or educational presentation space. But, while specifying a large screen display has
become as simple as choosing paint, adding high-quality surround sound still relies
on wedging consumer grade components into an otherwise professional system. The
result is typically complicated, expensive, and ultimately unsatisfactory.
Features and Functions
(Continued on following page)

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
2•7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
•Built-in noise generator
•Advanced HDCP management for trouble-free handling of all digital
content
•QuickSwitch HD®technology for fast, reliable switching
•CEC pass-through from a control system enables control of display and
source devices over HDMI
•Color LCD front panel for setup and basic operation
•Native Crestron®system integration
•10/100 Ethernet communications
•Front panel USB port for installer setup
•Simplified setup via front panel or software
•Single-space rack mountable
Features and Functions
(Continued)
The HD-XSP from Crestron answers the call for a truly professional surround sound
solution that is simple and affordable to implement. The HD-XSP provides the
features and performance necessary to enable high-definition 7.1 channel audio for
virtually any commercial environment. It fits easily in a crowded equipment rack and
integrates cleanly with other AV and control equipment. It supports the latest 7.1
digital formats including Dolby TrueHD, Dolby Digital Plus and DTS-HD Master
Audio, with advanced HDCP management for trouble-free handling of all digital HD
content. Professional DSP and input/output mixing is even built in to streamline
integration as part of a complete multimedia presentation system.
The HD-XSP is also useful for many residential applications, providing a
cost-effective, compact surround sound processor that is well suited for integration
as part of a total home automation and entertainment system.
Complete Connectivity
The HD-XSP includes full input connectivity for all types of digital and analog
sources including Blu-ray Disc®players, HDTV receivers, game consoles,
computers, media servers and mobile devices. Additional specialized inputs and
outputs are provided to facilitate integration with system switchers, matrix routers,
microphone mixers, and teleconferencing codecs.
•HDMI Input – The HDMI input provides the essential interface for handling
high-definition 7.1 digital surround sound and HDCP protected content. It
can also handle DisplayPort Multimode signals using an appropriate
adapter. Easy HDMI input expansion is possible using a Crestron
HD-MD8X1 switcher*. CEC signals can even be passed through from a
control system to control the source device right through the HDMI
connection.
•S/PDIF Inputs – A combination of one optical and two coaxial S/PDIF
digital audio inputs provides connectivity for digital sources without HDMI.
•Stereo Analog Inputs – Two stereo audio inputs are included to handle
analog signals from line level sources such as laptop computers, media
players, and mobile devices.
* Items sold separately.

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •3
•Surround Sound Outputs – A total of eight balanced line level outputs are
provided to drive a multichannel power amplifier feeding up to seven
speakers and a subwoofer. The HD-XSP can be configured to work with
systems up to 7.1 channels, including those without a discrete center
speaker or subwoofer. Each output channel includes a discrete 9-band
graphic or parametric EQ plus trim, delay, and crossover adjustments.
Additional controls are provided for main volume, bass, treble, loudness,
compression, and LFE.
•Downmix Output – This balanced output provides a stereo or mono
downmix of the surround sound signal to feed a separate speaker zone,
assistive listening system, codec, or recording device. It includes controls
for volume, bass, treble, loudness, and balance.
•Mix Input – This balanced stereo input is designed to connect to the output
of a microphone mixer or teleconferencing codec. This input bypasses all
internal signal processing and surround sound decoding, mixing with the
main program signal at the Front Left/Right and/or Downmix outputs.
•HDMI Output – An HDMI output is included to pass the HDMI input signal
through to a display device. The HDMI output passes Full HD 1080p60
video and WUXGA computer signals with HDCP, Deep Color, and 3D. It
also passes audio with the option to select either a straight pass-through
from the HDMI input or a stereo downmix of the main surround signal. It
can even pass CEC signals from a control system to control the display
device.
Each HDMI, S/PDIF, and stereo input includes an input compensation adjustment to
match the average level between sources. Each of these inputs also includes up to
80 ms of lip-sync delay.
Easy Integration
By design, the HD-XSP fits seamlessly into just about any AV presentation or
distribution system. It is rack-mountable and occupies just one rack space. It contains
no fans, ensuring silent operation. Via Ethernet, it can communicate with a Crestron
control system, allowing simplified operation using a touch screen, handheld remote,
or mobile device.
Via its HDMI input and output, the HD-XSP provides an ideal solution for adding
surround sound processing to a Crestron DMPS Series DigitalMedia™ Presentation
System or any DM®Switcher (all sold separately). It can even be located remotely
and interfaced using a DM transmitter and/or receiver. Or, via its S/PDIF or analog
inputs, it can be added to a Sonnex™ Multiroom Audio System to provide surround
sound processing for a single room zone.
Via its Mix input and Downmix output, the HD-XSP solves a lot of problems that
other processors do not address. The Mix input allows the signal from a microphone
mixer to be passed through unprocessed and mixed with the program signal at the
output. This allows live speech and surround sound signals to coexist and function
simultaneously through the same speaker system. The Downmix output converts the
full audio presentation into a stereo or mono signal, perfect for feeding a remote
listening zone, an assistive listening system, or a recording device.
For teleconferencing and Web streaming applications, the HD-XSP serves as a
cost-effective surround sound downmixer to allow participants at the far end to
experience the full audio presentation. Simultaneously, it mixes the incoming signal
from the far end with the local surround sound audio and sends it to the local room
speakers.

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
4•7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
To drive all the room speakers, Crestron AMP Series Commercial Power
Amplifiers* offer a high-performance, custom-configurable multichannel amplifier
solution for boardrooms, auditoriums, and custom theaters of any configuration —
even systems using 70 or 100 Volt ceiling speakers. Or, for the ultimate in
performance, choose a PROCISE®High-Definition Professional Surround Sound
Amplifier.*
* Items sold separately.

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •5
Applications
The following diagrams show a HD-XSP in a residential and a commercial
application.
HD-XSP in a Residential Application

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
6•7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
HD-XSP in a Commercial Application

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •7
Internal Block Diagram
The following diagram represents the switching abilities of the HD-XSP.
Internal Block Diagram of the HD-XSP
HDMI
Optical
S/PDIF 1
S/PDIF 2
Unbalanced 1
Unbalanced 2
Mix
Switch
7.1 Audio
Video
HDMI Out
Surround
Processing
Downmix Downmix Out
7.1 Out
Specifications
Specifications for the HD-XSP are listed in the following table.
HD-XSP Specifications
SPECIFICATION DETAILS
Audio – General
Features Six selectable source inputs plus built-in
noise generator, 7.1 Dolby Digital/DTS®
surround sound decoder, 7.1 multichannel
signal processing and steering, 9-band
graphic or parametric EQ, 80 ms lip-sync
delay, 20 ms speaker delay, unprocessed
Direct mode, stereo or mono downmix
output, stereo mix input (post surround
decoder/processor), HDCP management,
QuickSwitch HD
Input Signal Types HDMI supporting HD lossless multichannel
up to 7.1 with HDCP, DisplayPort
Multimode*, S/PDIF (coaxial and optical),
analog 2-channel
Output Signal Types Analog 7.1 channel, analog 2-channel
downmix, HDMI with 2-channel downmix
(Continued on following page)

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
8•7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
HD-XSP Specifications (Continued)
SPECIFICATION DETAILS
Audio – General (continued)
Analog-To-Digital Conversion 24-bit 96 kHz
Digital-To-Analog Conversion 24-bit 96 kHz (192 kHz in Direct mode)
Audio – Surround Sound Output
Frequency Response 20 Hz to 20 kHz ±0.5 dB
Total Harmonic Distortion +
Noise (THD + N)
< 0.002% digital in, < 0.003% balanced in,
< 0.003% unbalanced in (at 1 kHz across
balanced analog out)
Signal-to-Noise (S/N) Ratio > 108 dB digital in, > 103 dB balanced in,
> 103 dB unbalanced in (A-Weighted at full
output across balanced analog out)
Decoding Modes None, Stereo, Dolby Pro Logic IIx Movie,
Dolby Pro Logic IIx Music, DTS Neo:6
Cinema, DTS Neo:6 Music, Two Channel
Steering – Surround, Two Channel Steering
– Rear, Multichannel Stereo (Party), Dolby
Digital, Dolby Digital EX, Dolby Digital Plus,
Dolby TrueHD, DTS, DTS-ES Matrix,
DTS-ES Discrete, DTS 96/24, DTS-HD
Master Audio, PCM Multichannel
Speaker Trims ±12 dB per output (Front L/R, Surround
L/R, Back L/R, Center, Sub)
Speaker Delay 0 to 20 ms per output
Crossover Frequency Large (full range), 40, 50, 60, 70, 80, 90,
100, 120, 150, or 200 Hz per output
(excluding sub)
Low Frequency Effects (LFE) -10.0 to 0.0 dB
Main Volume Level -80 to +20 dB, adjustable from 0% to 100%,
plus mute
Bass Control ±12.0 dB
Treble Control ±12.0 dB
EQ Modes 9-band graphic (per output) or 9-band
parametric (per output)
GEQ Center Frequencies 63, 125, 250, 500, 1k, 2k, 4k, 8k, 16k Hz
GEQ Gain ±12.0 dB per band
PEQ Center Frequency 10 to 20,000 Hz per band
PEQ Gain ±12.0 dB per band
PEQ Bandwidth 0.1 to 3.5 octaves per band
Loudness Compensation On/off
Compression None, Crestron DRC (Heavy, Medium,
Light), Dolby/DTS DRC (Heavy, Medium,
Light), Dolby TrueHD Auto
DTS Neo:6 Music Settings Center Gain 0.0 to 1.0, Standard or Wide
mode
Dolby Pro Logic IIx Music
Settings
Dimension ±3, Center Width 0 to 7,
Standard or Panorama
(Continued on following page)

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •9
HD-XSP Specifications (Continued)
SPECIFICATION DETAILS
Audio – Downmix Output
Frequency Response 20 Hz to 20 kHz ±0.5 dB
Total Harmonic Distortion +
Noise (THD + N)
< 0.002% digital in, < 0.004% balanced in,
< 0.004% unbalanced in (at 1 kHz across
balanced analog out)
Signal-to-Noise (S/N) Ratio > 107 dB digital in, > 103 dB balanced in,
> 102 dB unbalanced in (A-Weighted at full
output across balanced analog out)
Downmix Volume Level -80 dB to +20 dB, adjustable from 0% to
100%, plus mute
Bass Control ±12.0 dB
Treble Control ±12.0 dB
Loudness Compensation On/off
Balance ±50%
Summing Stereo or mono selectable
Audio – Program Inputs
Input Compensation ±10.0 dB per input
Lip-Sync Delay 0.0 to 80.0 ms per input
Audio – Mix Input
Main Volume -80.0 to 0.0 dB plus mute, feeds front
left/right outputs
Downmix Volume -80.0 to 0.0 dB plus mute, feeds downmix
outputs
(Continued on following page)

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
10 •7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
HD-XSP Specifications (Continued)
SPECIFICATION DETAILS
Video
Features Audio breakaway, HDCP management,
resolution management, Crestron
QuickSwitch HD
Input Signal Types HDMI, DisplayPort Multimode*
Output Signal Type HDMI
Formats HDMI with Deep Color & 3D, HDCP content
protection support
Input Resolutions,
Progressive
640 x 480 @ 60 Hz,
720 x 480 @ 60 Hz (480p),
720 x 576 @ 50 Hz (576p),
800 x 600 @ 60 Hz, 848 x 480 @ 60 Hz,
852 x 480 @ 60 Hz, 854 x 480 @ 60 Hz,
1024 x 768 @ 60 Hz, 1024 x 852 @ 60 Hz,
1024 x 1024 @ 60 Hz, 1280 x 720 @ 50 Hz
(720p50), 1280 x 720 @ 60 Hz (720p60),
1280 x 768 @ 60 Hz, 1280 x 800 @ 60 Hz,
1280 x 960 @ 60 Hz,
1280 x 1024 @ 60 Hz,
1360 x 768 @ 60 Hz,
1365 x 1024 @ 60 Hz,
1366 x 768 @ 60 Hz,
1400 x 1050 @ 60 Hz,
1440 x 900 @ 60 Hz,
1600 x 900 @ 60 Hz,
1600 x 1200 @ 60 Hz,
1680 x 1050 @ 60 Hz,
1920 x 1080 @ 24 Hz (1080p24),
1920 x 1080 @ 25 Hz (1080p25),
1920 x 1080 @ 50 Hz (1080p50),
1920 x 1080 @ 60 Hz (1080p60),
1920 x 1200 @ 60 Hz,
2048 x 1080 @ 24 Hz,
2048 x 1152 @ 60 Hz, plus any other
resolution allowed by HDMI up to 165 MHz
pixel clock
Input Resolutions, Interlaced 720 x 480 @ 30 Hz (480i),
720 x 576 @ 25 Hz (576i),
1920 x 1080 @ 25 Hz (1080i25),
1920 x 1080 @ 30 Hz (1080i30), plus any
other resolution allowed by HDMI up to 165
MHz pixel clock
Output Resolutions Matched to inputs
Communications
Ethernet For control & setup; 10/100 Mbps,
auto-switching, auto-negotiating,
auto-discovery, full/half duplex, DHCP
USB USB client for setup
HDMI Passes CEC and EDID, CEC control
system pass-through to HDMI input and
output, supports HDCP, provides HDCP
key management
(Continued on following page)

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •11
HD-XSP Specifications (Continued)
SPECIFICATION DETAILS
Power Requirements
Power Pack 2.0 A @ 24 Vdc,100-240 Vac,
50/60 Hz power pack included
Environmental
Temperature 41º to 104º F (5º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 65 Btu/h
Enclosure
Chassis Metal with black finish, vented sides
Front Panel Metal with black finish and polycarbonate
label overlay
Mounting Freestanding or 1U 19-inch rack-mountable
(feet and rack ears included)
Dimensions
Height 1.72 in (44 mm) without feet
Width 19 in (483 mm) with rack ears
Depth 10.23 in (260 mm)
Weight 4.2 lbs (1.9 kg)
Included Accessory
Power Pack 24 Vdc, Universal
Available Accessories
AMP Series Commercial Power Amplifiers
CBL Series Crestron Certified Interface Cables
HD-MD8X1 QuickSwitch HD 8x1 HDMI Switcher
PROAMP Series PROCISE High-Definition Surround Sound
Amplifiers
* HDMI requires an appropriate adapter or interface cable to accommodate a DisplayPort Multimode
signal.
Physical Description
This section provides information on the connections, controls and indicators
available on the HD-XSP.
HD-XSP Physical View

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
12 •7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
HD-XSP Overall Dimensions
17.17 in
(436 mm) 17.32 in
(440 mm)
9.93 in
(253 mm)
9.72 in
(247 mm)
0.30 in
(7 mm)
19.00 in
(483 mm)
1.72 in
(44 mm)
IN OUT
HDMI
OUTPUT
LAN
INPUT
DIGITAL BAL ANCED
2
5 6
MIX
3
4LR
+ - + -G
FRONT
LR
+ - + -G G
SURROUND
LR
+ - + -G G
BACK
LRCS
+ - + -G G
CENTER - SUB
+ - + -G G
DOW NMIX
LR
+ - + -G G
2.0A
24V
—
--- G
L
R
MAC ID LABEL SERIAL LABEL
123567 & 8 910
11 15 17 19 20 21
4
12 13 14 16 18
Connectors, Controls & Indicators
# CONNECTORS*,
CONTROLS &
INDICATORS
DESCRIPTION
1 COMPUTER
Pin 3 Pin 4
Pin 2 Pin 1
(1) USB Type B female;
USB computer console port (cable included);
For setup only
PIN DESCRIPTION
1
+5 Vdc
2
Data -
3
Data +
4
Ground
(Continued on following page)

Crestron HD-XSP 7.1 High-Definition Professional Surround Processor
Operations & Installation Guide – DOC. 7446A 7.1 High-Definition Surround Processor: HD-XSP •13
Connectors, Controls & Indicators (Continued)
# CONNECTORS*,
CONTROLS &
INDICATORS
DESCRIPTION
2 PWR LED (1) Green LED, indicates operating power
supplied via power pack
3 RESET (1) Recessed push button for hardware reset
4 MUTE (1) Push button for audio mute
5 VOL ∧, VOL ∨(2) Push buttons for volume adjustment
6 Display Display Type: TFT active matrix color LCD
Size: 1.8 inch (45 mm) diagonal
Resolution: 220 x 176 pixels
Functions: Displays audio settings and setup
parameters
7 ∧, ∨, <, >(4) Push buttons, for 4-way LCD menu
navigation and parameter adjustment
8 SELECT (1) Push button, used to select or execute the
highlighted menu item or value
9 BACK (1) Push button, steps menu back one level
10 HOME (1) Push button, returns to the home menu
11 HDMI IN (1) 19-pin Type A HDMI female;
HDMI digital audio/video input
12 HDMI OUT (1) 19-pin Type A HDMI female;
HDMI digital audio/video output
13 INPUT, DIGITAL 2 (1) JIS F05 female (TOSLINK) optical fiber
connector;
S/PDIF optical digital audio input
14 INPUT, DIGITAL 3 – 4 (2) RCA female;
S/PDIF coaxial digital audio inputs;
Input Impedance: 75 Ωnominal
15 INPUT, L/R 5 – 6
L
R
(4) RCA female comprising (2) unbalanced
stereo line level audio inputs;
Input Impedance: 10 kΩ
Maximum Input: 2 Vrms;
16 INPUT, MIX L/R
BALANCED
LR
+ - + -G
(1) 5-pin 3.5 mm detachable terminal block;
Balanced/unbalanced stereo line level audio
input;
Input Impedance: 24 kΩbalanced, 12 kΩ
unbalanced;
Maximum Input Level: 4 Vrms balanced,
2 Vrms unbalanced
(Continued on following page)

7.1 High-Definition Professional Surround Processor Crestron HD-XSP
14 •7.1 High-Definition Surround Processor: HD-XSP Operations & Installation Guide – DOC. 7446A
Connectors, Controls & Indicators (Continued)
# CONNECTORS*,
CONTROLS &
INDICATORS
DESCRIPTION
17 OUTPUT, FRONT L/R,
SURROUND L/R,
BACK L/R, CENTER C,
SUB S
FRONT
LR
+ - + -G G
SURROUND
LR
+ - + -G G
BACK
LRCS
+ - + -G G
CENTER - SUB
+ - + -G G
(4) 6-pin 3.5 mm detachable terminal block;
Balanced/unbalanced line level 7.1 surround
sound audio output;
Output Impedance: 200 Ωbalanced, 100 Ω
unbalanced;
Maximum Output Level (FRONT,
SURROUND, BACK, CENTER): 4 Vrms
balanced, 2 Vrms unbalanced;
Maximum Output Level (SUB): 12.6 Vrms
balanced, 6.3 Vrms unbalanced
18 OUTPUT, DOWNMIX
L/R
DOWNMIX
LR
+ - + -G G
(1) 6-pin 3.5 mm detachable terminal block;
Balanced/unbalanced line level stereo audio
output;
Output Impedance: 200 Ωbalanced, 100 Ω
unbalanced;
Maximum Output Level: 4 Vrms balanced,
2 Vrms unbalanced
19 LAN
Green
LED
Yellow
LED
Pin 8 Pin 1
(1) 8-wire RJ-45 female (8P8C modular jack);
10BASE-T/100BASE-TX Ethernet port;
Green LED indicates link status;
Yellow LED indicates Ethernet activity
PIN
SIGNALS
1
TX +
2
TX -
3
RX +
4
Connected to pin 5
5
Connected to pin 4
6
RX -
7
Connected to pin 8
8
Connected to pin 7
20 24VDC
2.0A
(1) 2.1 x 5.5 mm DC power connector
24 Vdc power input;
Power pack included
21 G (1) 6–32 screw, chassis ground lug
* Interface connectors for MIX, FRONT, SURROUND, BACK, CENTER-SUB and DOWNMIX
ports are provided with the unit.
