Crestron TPMC-CH-IMC User manual

Crestron TPMC-CH-IMC
Interface Module
Operations Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2005 Crestron Electronics, Inc.

Crestron TPMC-CH-IMC Interface Module
Contents
Interface Module: TPMC-CH-IMC 1
Introduction......................................................................................1
Features & Functions.............................................................1
Specifications.........................................................................3
Physical Description ..............................................................4
Industry Compliance..............................................................8
Setup.................................................................................................8
Network Wiring.....................................................................8
CAT5 Wiring .......................................................................10
Hardware Hookup................................................................11
Problem Solving.............................................................................13
Troubleshooting...................................................................13
Further Inquiries ..................................................................14
Future Updates.....................................................................14
Return and Warranty Policies ........................................................15
Merchandise Returns / Repair Service ................................15
CRESTRON Limited Warranty ..........................................15
Operations Guide - DOC. 6345 Contents •i

Crestron TPMC-CH-IMC Interface Module
Interface Module: TPMC-CH-IMC
Introduction
Features & Functions
The TPMC-CH-IMC is an interface module designed for, and included
with the Crestron TPMC-15-CH and TPMC-17-CH tilt touchpanel media
centers. The interface module expands the configuration possibilities of
the TPMC-15-CH and the TPMC-17-CH by allowing unbalanced video
signals (via BNC) and balanced/unbalanced audio signals to be
connected to the touchpanel’s CAT5 inputs and outputs. This device can
also be used to convert sources to CAT5 for use with other Crestron
CAT5 devices such as the CNXRMCLV Enhanced Room Solution Box.
Operations Guide - DOC. 6345 Interface Module: TPMC-CH-IMC •1

Interface Module Crestron TPMC-CH-IMC
The following block diagram illustrates the function of the
TPMC-CH-IMC.
Block Diagram of the TPMC-CH-IMC
2 •Interface Module: TPMC-CH-IMC Operations Guide - DOC. 6345

Crestron TPMC-CH-IMC Interface Module
Specifications
The following table provides a summary of specifications for the
TPMC-CH-IMC.
Specifications of the TPMC-CH-IMC
SPECIFICATION DETAILS
Cresnet Power Usage 2 Watts (0.08 Amp @ 24 VDC)
Video Input
Connector Type
Input Impedance
Input Level
Maximum DC Offset
BNC (x3)
75 Ω(internally terminated)
1 Vpp Nominal, 1.5 Vpp Maximum
1.5 V
Video To Panel
Connector Type
Output Impedance
Bandwidth
RJ-45
100 Ω(balanced)
100 MHz
Audio Input
Connector Type
Input Impedance
Max Input Level
5 position, mini-terminal block
10k Ωunbalanced, 20k Ωbalanced
2 VRMS unbalanced, 4 VRMS balanced
Audio Output
Connector Type
Output Impedance
Max Output Level
5 position, mini-terminal block
600 Ωbalanced when connected to
touchpanel
2 VRMS when connected to touchpanel
Audio To Panel (RJ-45)
Connector Type
Output Impedance
Max Output Level
RJ-45
100 Ωbalanced
2 VRMS balanced
Operating Temperature
and Humidity
41º to 122º F (5º to 50º C),
10 to 90% Relative Humidity,
non-condensing
Dimensions & Weight Height: 1.29 in (3.26 cm)
Width: 7.30 in (18.54 cm)
Depth: 3.95 in (10.02 cm)
Weight: 9.7 oz (0.28 kg)
Operations Guide - DOC. 6345 Interface Module: TPMC-CH-IMC •3

Interface Module Crestron TPMC-CH-IMC
Physical Description
The TPMC-CH-IMC, shown in the following diagram, is supplied with
the TPMC-15-CH and TPMC-17-CH tilt touchpanel media centers. The
module is housed in a black enclosure with a silk-screened top panel. A
Light Emitting Diode (LED) indicating power, a network connector, and
connectors for video input, audio input, and audio output are located on
one side of the unit. The opposite side provides an RJ-45 video output
connector, an RJ-45 audio input/output connector and a network
connector to the touchpanel. The TPMC-CH-IMC also has a mounting
flange to secure the unit to a mounting surface or the rear of a rack. A
15-foot (4.6 meter) “triamese” cable with connections for network
communications and CAT5 audio and video to the touchpanel is included
with the TPMC-15-CH and TPMC-17-CH touchpanels.
TPMC-CH-IMC
4 •Interface Module: TPMC-CH-IMC Operations Guide - DOC. 6345

Crestron TPMC-CH-IMC Interface Module
Physical Views of the TPMC-CH-IMC
Ø 0.23 in (0.58 cm) 4 PLACES FOR RACK MOUNTING
1.75 in
(4.45 cm)
3.95 in
(10.02 cm
)
1.29 in
(3.26 cm)
6.83 in
(17.35 cm)
7.30 in
(18.54 cm)
VIDEO (RED) LABEL AUDIO (BLUE) LABEL
Ports
There are seven ports that serve various functions on the
TPMC-CH-IMC. Refer to the following diagrams and descriptions of
each port.
NET
This 4-position mini-terminal block connector is used to connect to other
Cresnet peripherals in a system. Another NET connector is located on the
other side of the module. Data and power for the TPMC-CH-IMC are
provided via either connection.
If making network connections to a control system or Cresnet
peripherals, refer to “Network Wiring” on page 8.
Operations Guide - DOC. 6345 Interface Module: TPMC-CH-IMC •5

Interface Module Crestron TPMC-CH-IMC
VIDEO
The video input consists of three BNC connectors for unbalanced video
signals. The component, composite or S-video input signal from an
external video source is connected to these ports.
AUDIO IN
The 5-position mini-terminal block connector mates with the included
connector which is wired to an external audio source and provides
balanced and/or unbalanced audio input. Description of the pinouts is
shown in the following table.
AUDIO IN Pinouts
PIN DESCRIPTION
L + Left Positive
L- Left Negative
G Ground
R + Right Positive
R - Right Negative
AUDIO OUT
The 5-position mini-terminal block connector mates with the included
connector and provides balanced and/or unbalanced microphone output.
Description of the pinouts is shown in the following table.
AUDIO OUT Pinouts
PIN DESCRIPTION
L + Left Positive
L- Left Negative
G Ground
R + Right Positive
R - Right Negative
6 •Interface Module: TPMC-CH-IMC Operations Guide - DOC. 6345
