Crestron CEN-IDOCV User manual

CrestronCEN-IDOCV
InterfaceforApple®iPod®withVideo
Operations Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
Industry Compliance
Federal Communications Commission (FCC) Compliance Statement
Reorient or relocate the receiving antenna
Increase separation between the equipment and the receiver
Connect the equipment inot an outlet on a circuit different from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:
(1) this device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
The PWE-4803RU is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.
As of the date of manufacture, the CEN-IDOCV and PWE-4803RU have been tested and found to comply with
specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling.
(E300305)
All brand names, product names and trademarks are the property of their respective owners.
©2009 Crestron Electronics, Inc.

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Contents
CEN-IDOCV Quick Start iii
Introduction ..............................................................................................................................iii
Required Equipment...................................................................................................iii
Installation..................................................................................................................iii
Interface for Apple®iPod®with Video: CEN-IDOCV 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Applications.................................................................................................................3
Specifications ..............................................................................................................4
Physical Description....................................................................................................5
Setup..........................................................................................................................................9
Network Wiring...........................................................................................................9
CAT5 Wiring...............................................................................................................9
Identity Code...............................................................................................................9
Installation.................................................................................................................10
Hardware Hookup .....................................................................................................10
Programming Software............................................................................................................15
Earliest Version Software Requirements for the PC .................................................15
Programming with Crestron SystemBuilder..............................................................15
Programming with SIMPL Windows........................................................................15
Example Program......................................................................................................17
Uploading and Upgrading........................................................................................................18
Establishing Communication.....................................................................................18
Programs and Firmware ............................................................................................19
Program Checks ........................................................................................................19
Problem Solving ......................................................................................................................20
Troubleshooting.........................................................................................................20
Reference Documents................................................................................................21
Further Inquiries........................................................................................................21
Future Updates ..........................................................................................................21
Appendix: PoE Injector – PWE-4803RU ................................................................................22
Specifications ............................................................................................................22
Physical Description..................................................................................................23
Setup..........................................................................................................................25
Return and Warranty Policies..................................................................................................26
Merchandise Returns / Repair Service ......................................................................26
CRESTRON Limited Warranty.................................................................................26
Operations Guide – DOC. 6761B Contents •i

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
CEN-IDOCV Quick Start
Introduction
The following steps are designed to guide you through the basic hookup,
configuration and use of a CEN-IDOCV. For detailed instructions on installation and
usage, please refer to “Interface for AppleiPod with Video: CEN-IDOCV” on
page 1.
Required Equipment
The following equipment is required to load and run the demo program.
•Power over Ethernet injector such as the Crestron PWE-4803RU.
•CEN-IDOCV Interface for Apple®iPod®with Video.
•2-Series control system with CUZ file version 3.155 or later.
•Apple iPod®.1, 2, 3
•USB cable for connecting CEN-IDOCV to PC.
•Optional: ABAR-1 or ABVR-1.
1. For a complete list of supported products, refer to Crestron Online Help Answer ID 4837,
or contact Crestron True Blue Support at www.crestron.com/true_blue_support.
2. Except where noted, this document uses the term “iPod” as a general reference to the
various versions of iPod produced by Apple Computer, Inc.
3. iPod device not included.
Installation
Refer to the following diagrams and connect the CEN-IDOCV in the following
order.
1. Connect AUDIO OUT to a device capable of receiving Crestron Home®
(CH) audio (i.e. ABAR-1).
AUDIO OUT Port
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV ¥iii
®®

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
2. If video is to be delivered from the CEN-IDOCV, connect VIDEO OUT to
a device capable of receiving CH video (i.e. ABVR-1).
VIDEO OUT Port
3. Connect the LAN PoE port to a PoE Injector or other PoE source.
LAN PoE Port
4. Connect the CEN-IDOCV to an iPod or to a CEN-IDOCV-DS.
Connect CEN-IDOCV Directly to iPod
Connect CEN-IDOCV to CEN-IDOCV-DS
5. Verify PWR and DEVICE LEDs are illuminated.
iv ¥Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
6. Program the Crestron®system using either:
•Standard programming methods such as creating a custom program in
SIMPL™ Windows or Crestron SystemBuilder™.
•Use the example program available from the Crestron website
(www.crestron.com/exampleprograms) as the foundation for a program
containing a CEN-IDOCV.
7. Establish communications with the CEN-IDOCV. Refer to “Establishing
Communication” on page 18 for details.
8. Configure the CEN-IDOCV to connect with the network control system.
a. DHCP is on by default.
b. Connect via USB as described on page 18.
c. Display the CEN-IDOCV’s “System Info” window (click the
icon) to view and note the IP address (to be used in step 10d below).
d. Configure the IP table (this enables communication with the control
system).
9. Upload and test the program created in step 6. Refer to “Programs and
Firmware” on page 19 for more information.
10. Install and configure Crestron Sync for iTunes on the PC or Mac hosting
iTunes®. Crestron Sync is available for download from the Crestron website
(www.crestron.com/crestronsync). Follow the instructions to download and
configure the software.
a. Setup all CEN-IDOCV addresses in Crestron Sync (this should not be
done by the end user). Refer to “Install & Configure Crestron Sync for
iTunes Software” on page 13 and the Crestron Sync help file for more
information.
b. If the “Add New Device” window is not automatically displayed after
starting Crestron Sync for the first time, right-click inside the “Crestron
Sync” window and click Add New Device.
c. Enter a name for the device, i.e., My iPod (This is not the name of the
iPod. It is a reference name to help the user identify the CEN-IDOCV).
d. Type the IP address of the CEN-IDOCV (from step 8 above).
e. Click OK to add the device to the “Crestron Sync” window.
f. Test a sync operation. If syncing a large library with an empty iPod, the
iPod should be removed from the CEN-IDOCV and directly connected
to the PC hosting iTunes. Subsequent minor updates can be done with
the iPod in the CEN-IDOCV using the Crestron Sync application.
11. Leave the latest version of theCrestron CEN-IDOCV Quickstart Guide
(Doc. 6794) with the end user.
This concludes the Quick Start section of the CEN-IDOCV Operations Guide.
Continue reading for more information on installing and operating the
CEN-IDOCV.
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV ¥v

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Interface for Apple®iPod®with
Video: CEN-IDOCV
Interface for Apple®iPod®with
Video: CEN-IDOCV
IntroductionIntroduction
The CEN-IDOCV is a Crestron interface and control solution for the popular Apple®
iPod®personal media player1, 2, 3. The compact and stylish docking station can be
placed anywhere on a counter, shelf, or other convenient location, while the interface
module gets mounted neatly out of site nearby. The interface module provides audio,
video, USB, and high-speed Ethernet connectivity for full integration with a Crestron
whole-house AV system4.
The CEN-IDOCV uses the latest Apple authentication chip, enabling high speed
music library browsing and compatibility with the latest Apple products and features.
The chip supports 6th generation (and later) iPod Classic, late model iPod Nano,
iPhone, and iPod Touch devices.
1. For a complete list of supported products, refer to Crestron Online Help Answer ID 4837, or contact
Crestron True Blue Support at www.crestron.com/true_blue_support.
2. Except where noted, this document uses the term “iPod” as a general reference to the various
versions of iPod produced by Apple Computer, Inc.
3. iPod device not included.
4. Audio/video signal output requires one or more Crestron Home®(CH) CAT5 balanced AV
compatible devices.
Features and Functions
•“Made for iPod” AV and control interface
•Connects to the iPod via multi-pin cable or stylish docking station
•Enables full 2-way touchpanel control of the iPod
•Plays audio throughout the home or office
•Allows viewing of video files on a video touchpanel or display
•Syncs to iTunes®over Ethernet
•Charges the iPod battery
•PoE "Power-over-Ethernet" compatible
•Includes Crestron Home®CAT5 Balanced AV connectivity
•Affords plug-and-play integration with Adagio®systems
The CEN-IDOCV is available in four different models.
Models
DESCRIPTION MODEL NUMBER COLOR
CEN-IDOCV-B-S BlackInterface for Apple iPod®
with Video CEN-IDOCV-W-S White
CEN-IDOCV-PWE-B-S BlackInterface for Apple iPod®
with Video, w/PoE Injector CEN-IDOCV-PWE-W-S White
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV •1

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
For simplicity within this guide, the color and packaged accessories are omitted and
CEN-IDOCV is used except where noted.
Easy Docking
Placing the iPod into the docking station (CEN-IDOCV-DS included) instantly
connects it for sharing with speakers and video monitors throughout the home or
office.
Touchpanel Control
Integrating the iPod with a Crestron system enables full control and navigation using
touchpanels, APADs, keypads, computers, and handheld remotes. From any
touchpanel, you can search the entire iPod library by genre, artist, album and track.
Sync to iTunes®over Ethernet
Using USB-over-IP technology, the CEN-IDOCV allows the iPod to connect with
any networked PC or Mac running Apple iTunes software right from the docking
station. Syncing the iPod to iTunes works the same as if it were hooked up with a
USB cable, affording full capabilities for organizing and transferring music and
video files, podcasts, audio books, and playlists anytime you want.
Audio and Video Distribution*
The CEN-IDOCV module features Crestron Home®CAT5 Balanced AV outputs to
enable audio and video signals to be fed from the iPod to your home theater or
multiroom distribution system. The video output supports composite and component
signal types for high-quality display of any video files loaded on the iPod.
* Audio/video signal output requires one or more Crestron Home®(CH) CAT5 balanced AV
compatible devices.
Crestron Home®CAT5 Balanced AV
Crestron Home (CH) CAT5 Balanced technology allows the CEN-IDOCV to be
located up to 500 feet from the central equipment, interfacing directly with other
CH-compatible devices like the Crestron CNX-BIPAD8 and CNX-PVID8 using
ordinary CAT5 type wire. Connecting the CEN-IDOCV to conventional AV
equipment, or to a Crestron Adagio®Home Entertainment system, is facilitated using
the ABAR-1 Balanced Audio Receiver and ABVR-1 Balanced Video Receiver (both
sold separately).
Adagio®Plug-and-Play
The CEN-IDOCV affords easy plug-and-play setup as part of a complete Adagio
system. Without any programming, Adagio delivers full access and control of the
docked iPod from every room.
Power over Ethernet
For operation and charging the iPod battery, the CEN-IDOCV gets its power right
through the LAN wiring using 802.3af Power over Ethernet (PoE) technology. PoE
eliminates the need for a separate wall-wart power supply or dedicated power wiring.
A PoE Injector (PWE-4803RU, included with CEN-IDOCV-PWE-B-S and
CEN-IDOCV-PWE-W-S) connects inline with the LAN cable, allowing for
installation at any convenient location. For applications with multiple CEN-IDOCVs
or other PoE-powered devices, a Crestron 5-port PoE switch (CEN-SW-POE-5, sold
separately) may be used, allowing up to four devices to be powered from a single
location.
2 •Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Applications
The following diagram shows a CEN-IDOCV in a residential application.
CEN-IDOCV in a Residential Application
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV •3

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
Specifications
SPECIFICATION DETAILS
Power Usage Power over Ethernet: IEEE 802.3af Class 2
PoE Powered Device; <135mA @ 48 Volts
DC;
Provided by a PoE device such as the
PWE-4803RU PoE Injector (Included with
CEN-IDOCV-PWE models only) or
CEN-SW-POE-5 5-Port Power over Ethernet
Switch (not included).
Compatible iPod Models For latest iPod device support information,
refer to Crestron True Blue Online Help
Answer ID 4837, or contact Crestron True
Blue Support; Website URL:
www.crestron.com/true_blue_support;
NOTE: Supports access to music and video
functions only; does not provide access to
photo, phone, game, or Web functions.
Signal Types:
Audio
Video
Analog stereo output via Crestron ‘CH’ CAT5
Balanced Audio port
Composite and Component (YPbPr) outputs
via Crestron ‘CH’ CAT5 Balanced Video port
Ethernet 10BaseT/100BaseTX, static IP or DHCP,
DNS, full duplex, auto-switching, auto-
negotiating, auto-discovery, TCP/IP, CIP,
IEEE 802.3u & 802.3af compliant
Minimum 2-Series Control
System Update File1,2 Version 3.155 or later
Environmental
Temperature
Humidity
Heat Dissipation
41º to 113º F (5º to 45 ºC)
10% to 90% RH (non-condensing)
14 BTU/Hr
Enclosure Metal with label overlay, freestanding or
surface mount with integral mounting flanges
Dimensions
Height
Width
Depth
1.42 in (3.61 cm)
4.56 in (11.58 cm)
5.79 in (14.71 cm)
Weight 1.0 lb (0.5 kg)
Available Accessories
ABAR-1
ABVR-1
CEN-SW-POE-5
PWE-4803RU
Balanced Audio Receiver
Balanced Video Receiver
5-Port Power over Ethernet Switch
PoE Injector (included with
CEN-IDOCV-PWE models only)
1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following
these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
NOTE: Crestron software and any files on the website are for authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
4 •Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Physical Description
This section provides information on the connections, controls and indicators
available on your CEN-IDOCV.
CEN-IDOCV Physical View
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV •5

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
CEN-IDOCV Overall Dimensions
5.79 in
(14.71 cm)
4.63 in
(11.76 cm)
4.00 in
(10.16 cm) 4.56 in
(11.58 cm)
1.42 in
(3.61 cm)
Connectors, Controls & Indicators
# CONNECTORS,
CONTROLS &
INDICATORS
DESCRIPTION
1 COMPUTER
(1) USB Type B female;
USB 2.0 port (cable included)
(Continued on following page)
6 •Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Connectors, Controls & Indicators (Continued)
# CONNECTORS,
CONTROLS &
INDICATORS
DESCRIPTION
2 DEVICE
(1) 30-pin female connects directly to the
iPod, or to the included CEN-IDOCV-DS
docking station. Provides two-way
communications, audio, video, and power link
to the iPod.
3 PWR LED (1) Green LED, indicates power supplied from
PoE.
4 SYNC LED (1) Yellow LED, indicates when internal iPod
is synced to iTunes
5 DEVICE LED (1) Green LED, indicates an iPod is
connected
6 SETUP
(LED and button) Used to setup unit’s IP ID in conjunction with Crestron Toolbox™.
7 LAN PoE1
GREEN
LED
YELLOW
LED
PIN
8
PIN
1
(1) 8-wire RJ45 with 2 LED indicators;
10BaseT/100BaseTX Ethernet port, 802.3af
Power over Ethernet compliant;
Green LED indicates link status;
Yellow LED indicates Ethernet activity.
8 CH-AUDIO OUT2
PIN
1
PIN
8
(1) 8-wire RJ-45 female, shielded; CAT5
balanced stereo audio output port;
Connects to any “CH” CAT5 audio input port
or bidirectional audio port;
Maximum Cable Length: 500 ft (152 m)
9 CH-VIDEO OUT3
PIN
1
PIN
8
(1) 8-pin RJ-45 female, shielded; CAT5
balanced video output port;
Formats: Composite, component (YPbPr);
Connects to any “CH” CAT5 video input port;
Maximum Cable Length: 500 ft (152 m)
1. Refer to the following table for connector pinouts. DC power applied by Ethernet power sourcing
equipment (PSE) can connect to either signal pins or N/C pins.
PIN SIGNAL PIN SIGNAL
1 TX + 5 N/C
2 TX - 6 RC -
3 RC+ 7 N/C
4 N/C 8 N/C
2. This eight-pin RJ-45 port provides connectivity to the CNX-BIPAD or a Crestron device with a
CAT5 audio input. This port provides stereo output over CAT5 wiring. Refer to the following table
for connector pinouts.
PIN WIRE COLORS
(568B) AUDIO I/O PIN WIRE COLORS
(568B) AUDIO I/O
1 WHITE/ORANGE + Audio Left Out 5 WHITE/BLUE N/A
2 ORANGE - Audio Left Out 6 GREEN - Audio Right Out
3 WHITE/GREEN + Audio Right Out 7 WHITE/BROWN N/A
4 BLUE N/A 8 BROWN N/A
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV •7

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
3. This eight-pin RJ-45 port provides connectivity to a device with a CH input port or a Crestron device
with a CAT5 video input. This port provides component or composite balanced output over CAT5
wiring. Refer to the following table for connector pinouts.
PIN WIRE COLORS (568B) COMPOSITE COMPONENT
1 WHITE/ORANGE + Composite + Y
2 ORANGE - Composite - Y
3 WHITE/GREEN N/A + Pb
4 BLUE N/A + Pr
5 WHITE/BLUE N/A - Pr
6 GREEN N/A - Pb
7 WHITE/BROWN N/A N/A
8 BROWN N/A N/A
8 •Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Setup
Network Wiring
When wiring the Ethernet network, consider the following:
•Use Crestron Certified Wire.
•Use Crestron power supplies for Crestron equipment.
•Provide sufficient power to the system.
Unlike other Crestron network devices, the CEN-IDOCV does not use Cresnet®for
communications between the device and the control system. The CEN-IDOCV
requires the use of a high-speed Ethernet connection for control system and PC
communications.
For information on connecting Ethernet devices in a Crestron system, refer to the
latest version of the Crestron e-Control®Reference Guide (Doc. 6052), which is
available for download from the Crestron website (www.crestron.com/manuals).
CAT5 Wiring
Category 5 (CAT5) wiring is a twisted pair cable designed for Ethernet networks.
These networks operate at speeds of up to 100 Megabits per second (Mbps) using the
100BASE-T standard. Crestron takes advantage of this specification for a variety of
audio and video applications.
Crestron recommends using CresCAT-IM (or CresCAT-D) wire for transmitting
video signals from the CH port.
When using a Crestron wiring solution, the CresCAT-IM (or CresCAT-D) wire can
carry audio and video signals up to 500 feet (152 m) (observe distance limitations
based upon power consumption for the device in use).
For more information, refer to the latest version of the Crestron CAT5 Wiring
Reference Guide (Doc. 6137), which is available for download from the Crestron
website.
Identity Code
The IP ID is set within the CEN-IDOCV’s IP table using Crestron Toolbox. For
information on setting an IP table, refer to the Crestron Toolbox help file. The IP IDs
of multiple CEN-IDOCV devices in the same system must be unique.
When setting the IP ID, consider the following:
•The IP ID of each unit must match an IP ID specified in the SIMPL™
Windows program.
•Each device using IP to communicate with a control system must have a
unique IP ID.
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV •9

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
Installation
Ventilation The CEN-IDOCV should be used in a well-ventilated area.
To prevent overheating, do not operate this product in an area that exceeds the
environmental temperature range listed in the table of specifications. Consider using
forced air ventilation to reduce overheating. Consideration must be given if installed
in a closed or multi-unit rack assembly since the operating ambient temperature of
the environment may be greater than the room ambient temperature. Contact with
thermal insulating materials should be avoided on all sides of the unit.
Mounting The CEN-IDOCV can be mounted in a rack or to any surface using the integral
mounting flanges. Mounting hardware is not provided.
Hardware Hookup
Connect the Device Make the necessary connections as called out in the illustration that follows this
paragraph. Refer to “Network Wiring” on page 9 before attaching the LAN cable.
Apply power after all connections have been made.
When making connections to the CEN-IDOCV, note the following:
•Use Crestron power supplies for Crestron equipment.
•The CEN-IDOCV-DS is the only docking station that can be used with the
CEN-IDOCV.
•The 6.5 foot (2 meter) cable (included with the CEN-IDOCV-DS) cannot be
extended.
10 •Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B

Crestron CEN-IDOCV Interface for Apple®iPod®with Video
Hardware Connections for the CEN-IDOCV
LAN PoE*:
TO 10BaseT/100BaseTX
802.3af-COMPLIANT
POWER SOURCE
CH (VIDEO):
TO DEVICE WITH
CH VIDEO INPUT
CH (AUDIO):
TO DEVICE WITH
CH AUDIO INPUT
COMPUTER :
TO USB PORT
ON PC
DEVICE:
TO CEN-IDOCV-DS
OR IPOD
* A PoE Injector (PWE-4803RU) is included with the CEN-IDOCV-PWE-B-S
and CEN-IDOCV-PWE-W-S. Refer to
“Appendix: PoE Injector – PWE-4803RU” on page 22 for details.
NOTE: For CAT5 connections use Crestron Certified Wire.
Operations Guide – DOC. 6761B Interface for Apple®iPod®with Video: CEN-IDOCV •11

Interface for Apple®iPod®with Video Crestron CEN-IDOCV
Connect the iPod NOTE: Due to the bandwidth limitations of a LAN, the CEN-IDOCV is not
recommended for loading an empty iPod with a large music/video library. A direct
USB connection between the iTunes PC and the iPod is highly recommended when
loading an empty iPod with a large music/video library. After the iPod is loaded, the
CEN-IDOCV should be used for regular syncing operations.
NOTE: Prior to connecting the iPod, the iPod’s TV Out setting must be set to On
the TV Screen setting must be set to the aspect ratio of the connected display (16:9
or 4:3), the TV Signal setting must be set (NTSC or PAL), and the Fit to Screen
setting must be set to Off. For instructions, refer to the iPod instruction manual.
After all the connections have been made to the CEN-IDOCV, the CEN-IDOCV can
be directly connected to an iPod or to a CEN-IDOCV-DS.
NOTE: The included cable cannot be extended.
To connect the CEN-IDOCV directly to an iPod:
To connect the CEN-IDOCV to a CEN-IDOCV-DS:
For information on using an iPod with the CEN-IDOCV-DS, refer to the latest
revision of the CEN-IDOCV-DS guide (Doc. 6762) which is available for download
from the Crestron website.
12 •Interface for Apple®iPod®with Video: CEN-IDOCV Operations Guide – DOC. 6761B
