Crestron ULTIMATE IWS82-AW-W-T-EACH User manual

The Crestron® Ultimate In-Wall Subwoofer ULTIMATE IWS82-AW-W-T-
EACH made by Origin Acoustics delivers the pinnacle of performance for
demanding residential installations. The ULTIMATE IWS82-AW-W-T-
EACH is an in-wall subwoofer designed to produce deep, gratifying bass
in any room.
In the Box
1 ULTIMATE IWS82-AW-W-T-EACH
 
Additional Items
1 Grille
1 Cutout Template
Installation
Prepare the Mounting Hole
Before finalizing the speaker location, check to make sure there are no
fixtures, pipes, air ducts, joists, or other possible obstructions. If
applicable, use a good quality stud finder to locate joists.
To identify obstructions, do the following:
lUse a drywall saw to cut a small hole at a 45° angle. An angle cut
simplifies repair since the removed piece can be reinserted to help
plug the hole.
lUse a piece of stiff wire, bent into an L shape, with one end long
enough to explore an area equal to the size of the speaker with the
toggle clamps extended. Insert the wire into the hole, make sure it
rotates freely in a complete circle and that there is sufficient depth.
If there are no obstructions, use the supplied template to trace an
outline of the mounting hole on the wall. Cut the final mounting hole at
a 90° angle to the wall.
ULTIMATE IWS82-AW-W-T-EACH QuickStart
Ultimate In-Wall Dual 8 in. Subwoofer, All Weather, White Textured, Single
1

Paint the Speaker Grille
Painting the speaker grille should be done prior to mounting.
1. Carefully remove the thin cloth on the underside of the grille, and set
it aside for reinstallation.
2. Lightly spray paint the front of the grille from a distance. Be careful
not to plug any of the holes.
3. Once the paint is dry, put the cloth back on the underside of the grille.
Install the Speaker Cable
Run the speaker cable (not included) from the audio source to the
speaker location, observing all appropriate local codes. Strip the ends of
the speaker cable approximately 0.25 in. to 0.50 in. (~6 mm to ~12 mm)
and twist the strands.
Connect the Speaker Cable
Connect the speaker cable (not included) to the spring terminals by
pressing the top of the terminals down and inserting the exposed
strands into the hole. Make sure that the positive wire is attached to the
red connection, and the negative wire is attached to the black
connection.
Mount/Remove the Speaker
On the speaker, make sure all the Toggle clamps are in the unlocked
position.
1. Fit the speaker into the hole, and using a screwdriver (not included)
turn the screws clockwise.
2. Tighten the screws until the speaker is secured to the wall; do not
overtighten.
3. To remove the speaker, turn the screws counterclockwise until the
toggle clamps rotate inward. Remove the speaker carefully from the
hole.
2
ULTIMATE IWS82-AW-W-T-EACH QuickStart
Ultimate In-Wall Dual 8 in. Subwoofer, All Weather, White Textured, Single

Visit the Product Page
Scan the QR code to visit the product page.
ULTIMATE IWS82-AW-W-T-EACH
https://www.crestron.com/model/6511859

Additional Information

Original Instructions
The U.S. English version of this document is the original instructions.
All other languages are a translation of the original instructions.
Regulatory Model: M202046008
Crestron product development software is licensed to Crestron dealers and Crestron
Service Providers (CSPs) under a limited nonexclusive, nontransferable Software
Development Tools License Agreement. Crestron product operating system software is
licensed to Crestron dealers, CSPs, and end-users under a separate End-User License
Agreement. Both of these Agreements can be found on the Crestron website at
www.crestron.com/legal/software_license_agreement.
The product warranty can be found at www.crestron.com/warranty.
The specific patents that cover Crestron products are listed at
www.crestron.com/legal/patents.
Certain Crestron products contain open source software. For specific information, visit
www.crestron.com/opensource.
Crestron and the Crestron logo are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Origin Acoustics is
either a trademark or registered trademark of Origin Acoustics, Inc. in the United States
and/or other countries. Other trademarks, registered trademarks, and trade names may
be used in this document to refer to either the entities claiming the marks and names or
their products. Crestron disclaims any proprietary interest in the marks and names of
others. Crestron is not responsible for errors in typography or photography.

©2021 Crestron Electronics, Inc.
Doc. 9038A
07/23/21
