DIN-1TSTAT8
8-Zone Radiant Heat Thermostat, DIN Rail Mount
Installation Guide
Description
Control up to eight radiant heating zones using one DIN-TSTAT8 thermostat. The
thermostat mounts remotely allowing low-prole remote temperature sensors to be
installed in each zone. Easily adjust the temperature setting in each heat zone with a
Crestron®touchscreen, handheld remote, or mobile app.
The thermostat controls up to eight SPDT heat zone valves and one SPDT main control
valve. Use normally closed (NC) or normally open (NO) control valves that are rated at
1/2 HP at 240 VAC, 50/60 Hz.
Failsafe mode maintains the temperature in each zone to provide comfort and to prevent
frozen pipes if the user setpoint is temporarily lost.
Additional Resources
Visit the product page on the Crestron website (www.crestron.com) for
additional information and the latest rmware updates. Click the QR
code or use a QR reader application on your mobile device to scan the
QR image.
Install the DIN-1TSTAT8
NOTE: Observe the following points when installing the DIN-1TSTAT8.
• Use the DIN-1TSTAT8 in an electrical panel with DIN rail mounting provisions.
• Mount the DIN-1TSTAT8 in a well-ventilated area.
• Do not block the venting holes.
• Certain third-party DIN cabinets provide space for an informational label
between each DIN rail row. Crestron’s Engraver software (version 4.0 or later)
can generate appropriate labels for all Crestron DIN rail products.
Mount the DIN-1TSTAT8 to the DIN rail (not included):
1. Hang the DIN-1TSTAT8 on the top of the DIN rail.
2. Press the bottom toward the DIN rail and snap it into place.
DIN-1TSTAT8
DIN Rail
(not included)
DIN rail release
Remove the DIN-1TSTAT8 from the DIN rail:
1. Turn off power to the thermostat and the heating system.
2. Remove all connections from the DIN-1TSTAT8.
3. Use a small, at-head screwdriver to pull the DIN rail release tab down.
4. Tilt the bottom of the DIN-1TSTAT8 away from the bottom of the DIN rail and then
remove the thermostat.
Wire the DIN-1TSTAT8
Make the following connections to the thermostat.
NET:
Cresnet control from a control system
and to daisy-chained Cresnet device
1-8:
C (common), NC (normally closed), and
NO (normally open) to relays 1-8
MAIN:
C (common), NC (normally closed), and
NO (normally open) to the main valve
TEMP SENSE:
Temperature sensor (TS) input from
remote temperature sensors
MAIN
Zone Valve and Main Valve Connections (1-8, MAIN)
1. Wire the eight zone valves to the 1-8 terminals on the thermostat. Connect one zone
valve per heat zone. Each zone valve must have a corresponding temperature sensor
connected.
2. Wire the main control valve to the MAIN terminal on the thermostat. Do not connect
a zone valve to the MAIN port.
• For 2-wire, normally open valves, connect the NO terminal on the thermostat to
the OPEN terminal on the valve.
• For 3-wire valves, connect the NO terminal on the thermostat to the OPEN
terminal on the valve and then connect the NC terminal on the thermostat to the
CLOSE terminal on the valve.
For zone valve specications and wiring, refer to the documentation provided by the valve
manufacturer.
MAIN
Valve
Close
Open
Com M
230 VAC
Wiring is typical for
the zone valves
and the main valve.
LN
Temperature Sensor Connections (TEMP SENSE)
Wire the eight temperature sensors to the TEMP SENSE terminals. Connecting a
temperature sensor input enables the use of the corresponding zone valve. Connect one
temperature sensor per heat zone. Crestron recommends using CAT3 (up to 76 meters
(250 feet)) or CAT5 up to 152 meters (500 feet)) network cable. If other wire is used, the
total capacitance must be less than 7,000 pF (up to 152 meters (500 feet).
NOTE: When wiring the temperature sensors:
• Use a separate run of wire for each sensor. If using multi-conductor cable, use
only one pair per cable.
• Do not run temperature sensor lines parallel to any other wiring. Cross cables at
right angles.
• In situations where ordinary two-conductor thermostat wire (18 to 20 gauge) has
been installed, it may be used for runs up to 30 meters (100 feet). This is not a
preferred method of installation.
Cresnet Connections (NET)
Wire the Crestron control system, and other daisy-chained Cresnet devices, to the NET
terminals on the thermostat.

Operation
Bootup
The DIN-1TSTAT8 turns off all heat zones before starting up.
Main Valve Delay
When a heat call is made, a delay from 0 to 5 minutes can be set. The default delay is
5 minutes. For information regarding the main valve delay, refer to the documentation
provided by the valve manufacturer.
1-8 Buttons and LEDs
Press the 1-8 buttons to toggle the heat zone on and off.
The 1-8 LED:
• Flashes during a heat call.
• Lights when the heat is enabled, but there is no call for heat.
• Extinguishes when heat is disabled.
MAIN Button and LED
Press and hold the MAIN button for 10 seconds to toggle the main valve on and off.
The MAIN LED:
• Flashes during a heat call for one or more zone valves.
• Lights when heat is on for one or more zone valves.
• Extinguishes when all zone valves are off.
Temperature Sensors
The temperature sensors operate as follows:
• The temperature sensor reads the temperature of the room once per second.
• If a temperature sensor is not connected, the corresponding zone valve turns off and
stays off until a temperature sensor is connected.
• If a temperature sensor does not send a valid value, or does not functioning for 10
minutes, the corresponding zone valve turns off and stays off.
Failsafe Mode
Failsafe mode ensures that an appropriate heat level is maintained in each zone if
the stored setpoint becomes corrupt or if no control system is connected. When the
thermostat enters Failsafe mode, the temperature setpoint for all zones is set to the
failsafe setpoint.
Establish the failsafe setpoint in the control system program. The failsafe setpoint can
range from 5 ºC (41 ºF) to 20 ºC (68 ºF); the default failsafe setpoint is 20 ºC (68 ºF).
Temperate zones can use a lower failsafe setpoint and cold climates may use a higher
value.
The thermostat exits Failsafe mode after it reestablishes communication with the control
system or if stored setpoint is restored. The thermostat resumes normal operation
according to its last known state.
Verify System Operation
After the thermostat is installed and programmed, enter Test mode to verify that each
heating zone is operating correctly. During Test mode, the thermostat performs a heat call
on that zone.
To test the zone valve:
NOTE: To exit Test mode, press and hold the desired zone button for 10 seconds.
1. Press and hold the 1-8 button for 10 seconds to enter Test mode on the associated
zone.
2. Verify that the zone valve operates as expected. The DIN-1TSTAT8 performs a
5-minute heat call on that zone. If the valve is programmed to have a time delay, the
delay is initiated and added to the test call for heat. The zone LED ashes for the
duration of Test mode. The zone valve, main valve, and DIN-1TSTAT8 return to their
previous states when Test mode has been completed.
NOTE:
• The time delay is set per the manufacturers specications.
• The run-time for Test mode is determined by the time of the delay plus the
5-minute heat call. Test mode can take up to 10 minutes to complete.
Troubleshooting
The following table provides corrective action for possible trouble situations. If further
assistance is required, please contact a Crestron customer service representative.
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION
The thermostat is not
receiving a signal.
There is an improper
connection between the
sensor and the thermostat.
Check the connection
between the sensor and
thermostat.
An incomplete (open) circuit
exists in wiring.
Check the connection
between the sensor and
thermostat.
