CrimeStopper cool start RS2-G3 User manual

RS2-G3
ONEBUTTON 2-WAYREMOTESTARTSYSTEM
OPERATINGINSTRUCTIONS
CONGRATULATIONS onyourchoiceofaCoolStart™RemoteEngineStarterandKeylessEntrywithDP
TechnologybyCrimestopper SecurityProductsInc. Thisbookletcontainsthe information necessaryfor
operatingyour system.Ifanyquestionsarise,contactyourinstallationdealeror CrimestopperSecurity
ProductsInc.
*IMPORTANTINFORMATION:PrimaryandOptionalFeatures
-PRIMARY: Thesearefeaturesthatmustbe connected inorder for thesystemtooperateproperlyi.e.
RemoteStartconnections,Flashinglights,and BrakeReset.Forprogramming,the programbutton mustbe
installed.
-OPTIONAL: Thesefeaturesare tobeconnectedonlyifdesiredor agreed upon bythe customer andthe
installing dealeri.e.Door Locks,Horn-Honk,Anti-Grind,etc.Thesefeaturesmayalsorequire additionalparts
and/orlaborfees.Consultwithyourinstallerbeforehandtobesureofwhatisgoingtobeinstalledwithyour
particularsystem.
CRIMESTOPPERSECURITYPRODUCTS, INC.
1770S. TAPO STREET, SIMI VALLEY, CA. 93063
REV 08.08.2014
ThisdevicecomplieswithFCC Rulespart15.Operation is
subjecttothe followingtwoconditions:1)Thisdevicemaynot
causeinterference,and (2)thisdevicemustacceptany
interferencethatmaybe received,includinginterferencethat
maycauseundesired operation.The manufacturerisnot
responsibleforanyradioorTVinterferencecaused by
unauthorized modificationtothisequipment. Suchmodification
couldvoidtheuser'sauthoritytooperatethe equipment.

2
TABLEOF CONTENTS
Operation Cautions&Warnings…….……………..….…………………………………….…………….….…………2
Using theRemoteTransmitter………………………………………………………………………….………....…….3
StatusLED……………………………………………………………………………………………….……….……….4
RemoteEngine Control…………….…..……………………………………………………………….…….……….4-6
Timed Self StartMode (optional)………………………………………………………………………………………..7
TurboTimerMode……………………………….……………………………………...……………….……………..…8
Convenienceand SafetyFeatures……………………………….………………………………….…...………….9-10
TransmitterProgramming….…………….…………………………………………….……………….…………....…11
NoFactoryKeylessEntryafterRemoteStart…………..…………………………………………………………….12
PanicMode……………..………………………………………………………………………………………………...12
RemoteStart Diagnostics……………………………………………………………………………………………….13
BatteryReplacement.…………………………………….………………...……………………..…………….………14
2-WayDataPort…………………………………………………………………………………………………………15
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPERSECURITYPRODUCTS,INC. and its VENDORS shallnotbeliablefor anyaccident
resultingfromtheuseofthisequipment. Thissystemisdesignedtobeprofessionallyinstalledintoacaror
vehicleinwhichall items,suchasparking brakeand all associated components,doorswitches,transmission
shift linkage,throttlelinkage,andall engine safetyfeatures,areinperfectworking condition.
ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO: A)Understandtheoperation ofthis
systemand itssafetyfeatures.B)Check forproper operationofthesystemprior toacceptingdeliveryofthe
vehiclefromtheinstallationfacility.C)Checkandmaintaintheconditionofthevehicleandallitemsrelativeto
the proper operation ofthissystemanditssafetyfeatures.D)Always leavethe doorsandwindowsclosed
andlocked toprotectagainst accidentsandtheft.
DONOTremote startthevehicleinaclosedgarage. Makesurethatthegaragedoorisopen orthereis
adequateventilation.Failuretoobservethisrulecouldresultin injuryordeath frompoisonousCarbon
Monoxidefumes.

3
USINGTHEREMOTETRANSMITTER
BASICREMOTEOPERATION
The transmitter suppliedwiththissystemisasinglebutton 2-Wayremotecontrol.Thisisamultifunction
remotecontrol.Itcanoperatepower door locks(ifequipped withpower locks)andRemoteStartthevehicle.
The 2-WayRemoteControlwill confirmoperationwithBeepsandLEDflashforlock, unlockandremotestart.
1.Press Once=LockorUnlock.
a.Lock=1beep &1green LEDflash.
b.Unlock=2beeps&2greenLEDflashes.
2.Press 3timeswithin2seconds=PanicMode –30second cycle(2 secondbeep andgreenLED).
3.Press andHold2seconds=RemoteStartor RemoteStop.
a.RemoteStart =1beep, red &greenLEDflashonce.
b.EngineRunning =4beeps,red&greenLEDflash4times.
c.StartFail=2beepsandredLEDflashes.
d.EngineStop/Shut Down=1beep &1red LEDflash.
2-WayRemote
Red&GreenLED
1-WayRemote
BlueLED

4
STATUSLED
VEHICLESTATUSLED:LocatedonWindowAntenna
The Statusled will flashwhenthedoorsarelocked.Itwill turn off whenthe doorsareunlocked.The LEDwill
remainsolidwhen thesystemisinValet Servicemode. Theremotestartfunction WILL NOToperatewhen in
ValetMode.
REMOTEENGINECONTROL
REMOTEENGINESTARTING -SUCCESSFULSTART:
1)Press theremotestartbuttonforatleast2seconds.Parking lightsflashonce,returnsolid,andthe
Ignition/Acccircuitsturnon. Theremotecontrolwill beepandtheLEDwill flashoncetoconfirm.
2)AfterafewsecondstheStarterMotorengages.TheparkinglightsandAcccircuitswillturnoffwhile
cranking.
3)EngineStartsandRuns. Parking LightsandAcc turnsbackon,and thedoorslock.
4)Enginewill remainrunningfor programmed run timeuntil resetwithBrakepedal.Ifneeded,theenginecan
be turnedoffwithremotetransmitterbypressingand releasing theStart button.
AFTER
IGN
3
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.
PRESS START

5
REMOTEENGINECONTROL
REMOTEENGINESTARTING -UNSUCCESSFULSTART
Intheeventthatthe enginedoesnotstarton thefirstattempt,thesystemshutsdownforafewsecondsand
thenattemptstorestarttheenginea2nd and 3rd time.For hard startingengines,theunitwill allowastarter
cranktimeofupto4secondsmaximum.Thisshouldprovideamplecranking timefordifficultstarts,butis
limited to4secondstohelppreventdamagetothestarterfromover cranking.IfThirdattemptfailstostart
engine,thesystemwill turnoff anddoorswill remainlocked.NOFURTHERATTEMPTSWILLBE MADE
AUTOMATICALLY
TURNING OFFAREMOTESTARTEDENGINE:
1)EngineisrunninginRemoteStart(Parking lightsON).
2)Press andholdtheremotestart button for 2seconds..
3)Engine&parking lightsOFF, Doorsre-lock.
ENTERINGYOUR REMOTESTARTEDVEHICLE:
1)Withengine running,unlocksystemwithremote(Ifequipped)oropendoorwithkey.
2)Entervehicleandbecarefulnottostep on brakepedal!(RemoteStart Reset)
3)Turn Ignition toON/RUNposition, thenpressbrakepedaltoresettheRemoteStarter &Shift outofpark.
4)Remotestarterwill reset instantlywhenthebrakeispressed.Parking lightswill turn offandtheignitionkey
isnowcontrollingyour vehicle.
IDLEDOWNMODE:
Thismode allowstheunittotakeoveroperation ofthe parked vehiclewhilethe ignitionkeyisremovedand
you exit thevehicle. The vehiclewill remainrunningfor theprogrammed time or untilcanceled. TheRunTime
choicesare:10, 20,30 minutesorInfinityRun. Default=20 minutes
Examples:
•You pulluptoaconveniencestoreforaquickstop, "IdleDown"modekeepsenginerunningwhenyouexit
the vehicle,(withkeysinhand). When you return, turnignitionON,stepon brakeanddriveaway.

6
REMOTEENGINECONTROL
IDLEDOWNMODE-EXITINGTHEVEHICLE:
1)Withvehicleenginerunningwithkey, press theRemoteStartbuttonfor2seconds.
2)Parking Lightswill turnON.
3)Doorswill unlock.
4)Turn OFFIgnition andremovekey.Engine shouldremainrunning.
5)Enginewill remainrunning forprogrammed run time oruntil youreturn(whichevercomesfirst).
IGN
SOLID
OFF
UNLOCK
PRESS START
IDLEDOWNINFINITYRUNMODE:
IdleDowncanbeprogrammedfor INFINITYRUN.Thisallowsthevehicleenginetoremainrunning
INDEFINITELY without theignitionkeyinthe switch.Theparking lightscontinuouslyflashinthismode.This
mode can bebeneficialtolawenforcementorcommercialtrucksthatneedtoremainrunningunattendedfor
long periodsof time. Talktoyour installer toselectoption.

7
OPTIONAL SELF START MODE(OPTION22)
SELECTABLEHOURLYCOLD-STARTMODE(2,3or4HOURS)Default=OFF
Thismode allowsthevehicletobe programmed toself-startevery2,3or 4hoursandrunfortheprogrammed
runtime.Thiscan behelpfulduring extremelycoldconditionswhereenginefluidfreeze-up isaconcern.This
optionisdisabledbydefault andmustbe activated.
TIMEDSELF-STARTMODE:
1)The ignitionmustbe off.
2)Press StartButton once,thenPress andHoldStart Buttonfor 2seconds(within3seconds).
3)The 2-Wayremotewill beep 3timesandtheRed&GreenLEDwill flash3timestoconfirm.
4)The parkinglightswill flash4timesandthehornwillchirpfor4timestoconfirmSelfStartMode
Activated.
RESETTINGTIMEDSELF-STARTMODE:
Toreset the timed self-start mode,startvehicleusingtheignitionkeyorthe remotecontrol. Thelightswill
flash3times.

8
TURBOTIMERMODE(OPTION#21)
The optionalTurboTimer modeallowsthe CoolStartsystemtokeepaTurbo orTurbo Dieselvehiclerunning
for 1,3or5minutes[selectively]after you removethekeyandexitthevehicle.Thisishandyfor turbo cool-
downwithouttheneedfor expensiveturbotimers.The Default=OFF.
To ActivateTurbomode:
Withthe engine running bykey, momentarilythepressRemoteStartButtonwithbrake pedaldepressed.
Releasethe brake after the Parking LightsandStatusLEDwill blinkthe number of minutesfortheTurbo
Timer. The doorsunlock.
REMOVE KEY
FLASH1-5X
EXITVEH.
PRESS
ANDHOLD
BRAKE
RUNNING RELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5MIN.
PRESS START

9
CONVENIENCEAND SAFETYFEATURES
KEYLESS ENTRY(PowerDoorLocks, mayrequireData Module-Optional)
The doorswill lockor unlockwithamomentarypressoftheStartbutton.
Toconfirmlock, theparkinglightswill flashonce, the StatusLED(onantenna)will start flashing andthehorn
will chirponce(selectableoption). The remotecontrolwill alsobeep oncetoconfirmlock.
Toconfirmunlock, theparking lightsflashtwice, the StatusLEDturnsoffandthe hornchirpstwice(selectable
option). The remotecontrolwill flashtwicetoconfirmunlock.
AUTOLOCK / UNLOCK (Option #2) Default=OFF
The AutoLockfeature controlswhetherthedoorswillautomaticallylock/unlockon yourvehiclewhendriving
or withturningtheIgnitionON/OFF. Thereare3choices:
1. DoorsLockandunlockwhenignition isturnedonoroff.
2. Lockwithignitionandbrakepedal,unlockwithignitionoff.
3. AutoLockonly, nounlock.
HORN CHIRPS(Option#16&17)
Ifvehiclehornsare connectedtothesystem, theywillprovideaudibleconfirmationchirpsforremotestart.The
chirpsound canbeprogrammedfrom shorttolongtoadjustfordifferentsoundinghorns.Note:Horn
honk/chirp featuremayrequire extralaborand/orpartstoinstall.
Option16=ChirpswithRemoteStartOn/Off.
Option17=Short, mediumorlong ChirpPulse(15,20or30milliseconds).
ANTI-GRIND(Optional, relaynotincluded)
ThisOptionalfeature preventstheuserfromaccidentallygrinding the starter ifthe Ignitionkeyisturned too far
tothe startpositionwhileengine isalreadyrunning fromtheremotestarter.The Anti-Grindrequirestheuseof
an externalrelay.

10
CONVENIENCEAND SAFETYFEATURES
VALETMODE(RequiresInstallationofValetSwitch)
Beforeservicingyourvehicleorhanding thekeysovertoaValetwerecommend puttingtheunitintoValet
Mode.TheremotestartfunctionWILLNOToperatewheninValetMode.Toenter Valetmode,turn the key
totheONposition,press and holdProgram/Valetswitchfor 5-6 seconds.The StatusLEDwill turn on solid
whenthesystemisinValetMode. Toexit ValetMode,performthisprocedureagain.
HOODOPENSAFETY(Requires hoodpinswitch)
Preventsthe engine frombeing RemoteStarted withthehood isopen.Thiseliminatesriskofinjuryto
someone working underthehoodofthevehicle.IfRemoteStartbutton ispressedwiththehoodopen,the
lightswill flashtwiceand theunitwillnot attemptastart. Thesystemwillabort RemoteStartanytimethehood
isopened. See RemoteStart Diagnostics onpage13.
BRAKEPEDALRESET:
Preventsstarting or shutsoff aremotestarted vehiclewhenthiscircuitisactive.Thispreventsunauthorized
drivingofaremotestartedvehicle.Thiscircuitshutsthesystemdownimmediatelywhen brakepedalis
pressed. Turnthe ignition keytothe “ON”positionbeforethebrakepedalispressed.
OEMALARMINTERFACE(Mayrequireoptional DatabusModule)
ThisfeatureisdesignedtoDisarmand Re-armFactoryequippedsecuritysystemsinconjunctionwithremote
start andkeylessentry(ifneededforyour vehicle).Thisfeaturewill maintainthe originalintegrityand security
ofyourvehicle’sfactoryequippedsystemsbefore,during,or afterremotestart. Somevehiclesrequire an
optionalDatabusmoduletooperateafactoryalarmor keylessentry.
LOCK withREMOTESTARTand AfterREMOTESTARTABORT:
Option#8controlswhetherthesystem will automaticallylockduringandafter aremoteStartabortortime-
out. Thereare4choicesfor thisoption:
1. Lock withRemote StartOnly-Default.
2.OFF.
3.LockwithRemoteStartandLockwithRemoteStart Abort.
4.LockwithRemoteStart Abort only.

11
TRANSMITTERPROGRAMMING
Note:All transmittercodesmustbelearnedattimeofprogramming!! Thesystemlearnsupto3
differenttransmittercodes.
1.Turn Ignition Keytothe ONposition.
2.Press Programmingbutton4times,thenafterafewsecondstheunit flashesthe parkinglights4times.
3.Press thestartbutton ofthefirsttransmitter.Youshouldget1lightflashconfirmingtheremoteiscoded,
thenpressthestartbuttonofasecondtransmitter,theunit willflash2timesconfirmingtheremoteiscoded
andsoon.Ifall 3codesarelearned, turnignitionkeyoff. Seediagrambelow.
IGN
OFF
WAITFOR
4FLASHES
PRESS4X's
FLASH1, 2,or3X's
IGN
OFF
PRESSSTARTBUTTON

12
NOFACTORYKEYLESS ENTRYAFTERREMOTESTART
MostnewcarsDoNotallowthefactoryRemoteKeyless EntrytofunctionwiththeIgnition ON.Thismeans
you can’tusethefactoryremotetolock or unlockthedoors.Afterremotestartyouhavetousethekeysto
unlockthe door.Also,manynewvehiclesunlockthedoorswhendisarming thefactoryalarm.Thisleavesthe
doorsunlockedwhileRemoteStarted.Toresolvethisproblem,haveyourinstallerconnectthedoorlocksto
the RemoteStart KeylessEntry. TheRemoteStarterwill Re-Lockthe doorsafter remotestarting.
POWERONMEMORY
Thissystemisequippedwithcircuitrythatwill allowthesystemtorememberitsstatusifthepowerislostand
thenreconnected.
PANICMODE
Thismode isused inan emergencysituationor youarehavingtroublefindingyourvehicleinaparking lot.
The vehiclehornsmustbe connectedfor thisoption.
To Activate: Press thestartbutton3timeswithin2seconds. Thehornsstarthonkingandparkinglightsflash
for 30 seconds.
To Deactivate: Press the startbutton againtostopthehornsandLights.

13
REMOTESTART DIAGNOSTICS
IfthesystemflashestheLEDandParkingLightsonetosixtimesanddoesn’tattemptremote.The
LEDwill continueflashingtheerrorcodeuntiltheignitionisturnedon, itmeansthefollowing:
1ParkingLightFlash(1LEDFlash)=ProblemwithBrakeSwitch.
2ParkingLightFlashes(2LEDFlashes) =ProblemwithHoodSwitch.
3ParkingLightFlashes(3LEDFlashes) =TachProblem.
4ParkingLightlashes (4 LEDFlashes) =VoltageSense Problem,batterynotcharging ortolow.
5ParkingLightFlashes(5LEDFlashes) =Problemwith(-) BrakeInput.
6ParkingLightFlashes(SolidLED)=ValetServiceMode.
Besure totell your installertheDiagnosticcode whentaking vehicleinfor service
SYSTEMISUNSUCCESSFULATREMOTESTARTDURINGEXTREMECOLDCONDITIONS:
Pleasebe aware thatduringsub-freezing conditionsyour remotestarter maytakemore thatone attemptto
startoritmaynotsuccessfullystartthevehicleafter3attempts.Duringtheseconditionsthevehiclemaynot
properlystarteven usingthe key;thereforetryingtostart bytheremotewouldalsobe unsuccessful.

14
BATTERYREPLACEMENT
Toreplace thebattery: Simplytakethe caseapartasshownbelow.Removethe twoCR-2016Lithium
batteriesand replace. Put casebacktogetherandtighten screw.
The 1-WayremoteneedstwoCR-2016 Lithiumbatteries.
The 2-WayremoteneedsoneCR-2032Lithiumbattery.
The 1-Wayremotehasalowbatteryindication; The BlueLEDwill flashonceevery5seconds
The 2-Wayremotehasalowbatteryindication; The Red LEDwill flashonceevery5seconds

15
2-WayDATAPORT
Somevehiclesrequire aDatabusModuletoBypass the factoryImmobilizerandoperatethekeylessentry.
Databusmodulesareused tocommunicatewiththevehiclescomputerat theOBD2Dataconnectoror
Canbuswires. Thisreducesinstallationerror. CrimestopperSystemswithDPSerieshaveadirectDataPort
Plug-Infor theDatabusbypass module. ThiseliminatesconventionalwiringbetweentheAlarm/Remote
Starter andthebypass interfacemodule.
Features Include:
•TransponderImmobilizer.
•PassLockImmobilizer.
•O.E.M.AlarmControl.
•R.A.P. Shutdown.
•PowerDoor Locks.
•PriorityUnlock.
•Parking Lights.
•CourtesyLights.
•Tachometer.
•Heated Seats.
•RearDefrost.
The actualfeaturescontrolleddepend on the vehicleandDatabusmodule.

16
FCC Statement
1. ThisdevicecomplieswithPart 15of theFCCRules.Operation issubject tothefollowing twoconditions:
(1)Thisdevicemaynot causeharmfulinterference.
(2)Thisdevicemust accept anyinterferencereceived,including interferencethat maycauseundesired operation.
2. Changesormodificationsnot expresslyapproved bythe partyresponsibleforcompliancecouldvoidthe user'sauthorityto
operatethe equipment.
NOTE:
Thisequipment hasbeentestedand found tocomplywiththe limitsforaClass Bdigitaldevice, pursuant toPart 15 of the FCC
Rules.Theselimitsaredesigned toprovide reasonableprotectionagainst harmfulinterferenceinaresidentialinstallation.
Thisequipment generatesusesand canradiateradiofrequency energyand,if notinstalled and used inaccordancewiththe
instructions, maycauseharmfulinterferencetoradiocommunications. However, thereisnoguarantee thatinterferencewillnot
occurinaparticularinstallation.
If thisequipment doescauseharmfulinterferencetoradioortelevision reception, whichcanbe determined byturning the
equipment off and on,the userisencouraged totrytocorrect the interferencebyone ormoreof the following measures:
Reorient orrelocatethereceivingantenna.
Increasethe separationbetween the equipment and receiver.
Connect theequipment intoan outlet onacircuitdifferent fromthat towhichthe receiverisconnected.
Consultthe dealeroranexperienced radio/TVtechnician forhelp.
www.crimestopper.com
[e-mail]
Phone [phone]
FAX [phone]
©2014 CrimestopperSecurityProducts
