LOCKING LADDER PULL
ASSEM BLY

CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
2crlaurence.com | usalum.com
ABOUT THIS MANUAL
The procedures covered in this manual are not needed for regular installations. This manual covers the
procedures needed to paint Ladder Pull Handles. Please store screws and internal mechanisms in a safe
place until you are ready to reassemble. Refer to the 11M0189 Locking Ladder Pull Installation Manual to
install the reassembled handles onto your door.
NOTE: LLPA shown. LLUPA and DLLPA similar
TABLE OF CONTENTS
ABOUT THIS MANUAL 2
DISASSEMBLE HANDLE 3 - 5
Separate Interior and Exterior Handles 3
DISASSEMBLE INTERIOR HANDLE 4
Remove Cam and Thumb Turn 4
Remove Bottom Mounting Post, Internal Housing and Transmission Cover 4
DISASSEMBLE EXTERIOR HANDLE 5
Remove Bottom Mounting Post 5
Remove Lock Cylinder 5
ASSEMBLE INTERNAL HANDLE 6 - 9
Install Internal Housing 6
Test and Adjust Internal Housing 7
Install Thumb Turn 8
Secure Internal Housing to Tube 9
Install Bottom Mounting Post 9
Install Cam 9
ASSEMBLE EXTERNAL HANDLE 10
Install Lock Cylinder 10
Install Bottom Mounting Post 10

1A
1B
Internal
Handle
Bottom
Mounting Post
Top Mounting
Post
External
Handle
A
2
2C
Nylon
Sleeves
Internal
Handle
External
Handle
B
2
Lock Housing
Screw
Remove Interior Handle Lock Housing Screw and separate handles.
2
Remove Set Screws at Interior Top and Bottom Mounting Posts.
1
NOTE: Handle in unlocked position.
1A
Remove Set Screws
Store in safe place.
Bottom
Mounting Post
Internal
Handle
A
2
B
2
Remove Lock Housing
Screw and Store.
Internal
Handle
2C
Separate Handles.
Remove Nylon Sleeves
and store in safe place.
Nylon
Sleeves
Internal
Handle
External
Handle
1B
Remove
Set Screws
and store.
Top
Mounting Post
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
3crlaurence.com | usalum.com
DISASSEMBLE HANDLE
Separate Interior and Exterior Handles

1A
Remove Screws and Set Screws
from Transmission Cover and store in safe place.
B
2
3D
A
4
3Remove Strike Pin Sleeve and Internal Housing
Remove Bottom Mounting Post.
Remove Cam and Thumb Turn.
2
Remove Transmission Cover.
1
3D
Remove Internal
Housing and store parts.
Remove Strike
Pin Sleeve
and store.
C
3
B
3
Remove
Screw and Store.
A
3
Remove
Screw and Store.
Bottom Mounting
Post
Remove Screw. Store in safe place.
B
2
A
2
1B
Cam
Thumb
Turn
Transmission
Cover
Remove Cam and Thumb Turn
from Transmission Cover and store in safe place.
A
4
4
B
4
Slide
Transmission
Cover from bottom tube.
NOTE: Store Screws, Strike Pin Sleeve and Internal
Housing Parts in a safe place until Handle Installation.
Internal Housing Parts
Internal Housing
Transmission
Cover
Bottom Mounting
Post
NOTE: Handle shown from side.
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
4crlaurence.com | usalum.com
DISASSEMBLE INTERIOR HANDLE
Remove Cam and Thumb Turn
Remove Bottom Mounting Post, Internal
Housing and Transmission Cover

External Housing
Bottom Mounting
Post
A
3
1C
3
Spacers
Rubber
Washer
Rubber
Washer
Metal
Washer
Connecting
Grommet
Screw
1B
Remove Lock Cylinder from External Housing.
2
1A
Loosen screw to
remove Bottom Mounting
Post Fittings.
Exterior Handle
Remove Bottom Mounting Post.
Slide External Housing to tube and remove.
1
B
3
Slide External Housing
from bottom tube.
NOTE: Handle shown from side.
NOTE: Store Mounting Post Fittings
in safe place until Handle Installation.
1C
Use 6 mm
Allen Wrench
to remove.
Bottom Mounting
Post
Lock
Cylinder
EXTERIOR
2C
Housing
Adaptor
Remove Lock Cylinder and Housing Adaptor
from External Housing and
store in safe place.
External
Housing
B
2
A
2
Locknuts
and Screws
Remove fasteners holding
Housing Adaptor and store in safe place.
Remove Set Screw Holding
Exterior Housing. Store in safe place.
A
3
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
5crlaurence.com | usalum.com
DISASSEMBLE EXTERIOR HANDLE
Remove Bottom Mounting Post
Remove Lock Cylinder

Align Rack teeth
and insert Gear
from bottom.
Gear
1B
Gear
Assemble Internal Housing.
Temporarily hold Internal Housing at bottom tube with Bottom Mounting Post Screw.
Hold Gear in Base and push
Internal Housing into bottom of tube.
NOTE: When Gear reaches cutout, hold Gear
from bottom until housing is aligned and secured.
Connecting Rod
Fixed Rack
Rack
Gear Base
1A
1
Connecting Rod
Bar Guide
Post
1
2
3
1A
Gear Base
Fixed Rack
Rack
3
Align hole in Bar Guide Sleeve
with hole for Bottom Mounting Post.
Bottom Mounting
Post Screw
A
2
B
2
Hold Gear from bottom until
Thumb Turn is installed.
1B
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
6crlaurence.com | usalum.com
ASSEMBLE INTERNAL HANDLE
Install Internal Housing

To make adjustments, remove the Gear and move the Fixed Rack. Insert the Gear and repeat Step 1
above to test again. When Internal Housng is properly set, proceed with next step.
2
3/4”
(19 mm)
Turn Gear 180 degrees to move Strike Pin from
flush to 3/4” (19 mm) past bottom of tube.
1
Strike Pin
flush
to bottom
of tube.
Strike Pin 3/4”
past bottom of tube.
Internal Housing in open
position with Strike Pin flush
to bottom of tube.
Internal Housing in locked
position with Strike Pin extended
3/4” past bottom of tube.
NOTE: Strike Pin should extend 3/4”
past bottom of tube when Gear turns.
NOTE: Strike Pin should retract flush
to bottom of tube when Gear turns.
NOTE: Use a flat head screwdriver to test.
Hold gear from bottom so it doesn’t fall.
1A
Turn Gear 180
Degrees to extend
Strike Pin.
1BTurn Gear back
to retract
Strike Pin to flush.
A
22C
NOTE: For small
adjustments, turn
Strike Pin clockwise
or counter clockwise
into Connecting Stud.
Move Fixed Rack so
Strike Pin is in correct position.
B
2
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
7crlaurence.com | usalum.com
ASSEMBLE INTERNAL HANDLE (CONTINUED)
Test and Adjust Internal Housing

1C
2
Strike Pin flush to bottom
tube in unlocked position.
Bottom Mounting
Post Screw
Thumb
Turn
Unlocked
C
3
Secure Thumb Turn to Transmission
Cover with Screws and Set Screw.
Turn Handle over and center Internal Housing
over cutout in tube. With Internal Housing and
Thumb Turn in unlocked position align with Gear.
2
11A
1B
Transmission
Cover
Bottom Mounting
Post Screw
NOTE: Hold gear from bottom so it doesn’t fall.
Remove Bottom Mounting Post Screw to slide
Transmission Cover onto tube and then reinstall.
1C
Replace Bottom
Mounting
Post Screw
Hold in position and test mechanism.
NOTE: If it doesn’t turn easily, go back to previous steps and adjust.
3
A
3
Turn Thumb Turn up to locked position.
Ensure Strike Pin is extended past
bottom tube.
B
3
Turn Thumb Turn down again
to unlocked position.
2
Align
ThumbTurn
with slot in Gear.
Gear
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
8crlaurence.com | usalum.com
ASSEMBLE INTERNAL HANDLE (CONTINUED)
Install Thumb Turn

1
B
2
B
3
3
Install Strike Pin Sleeve at bottom tube.
Remove Bottom Mounting Post Screw
and use it to install Bottom Mounting Post.
Fit Cam into Transmission Cover and Gear Holder. Secure with set screw.
2
Install Screw at top of Internal Housing.
1
1
NOTE: Handle shown from side.
Strike Pin
Sleeve
A
2
B
2
Align holes and secure.
Bottom Mounting
Post Screw
A
3
Bottom Mounting Post Screw
Bottom Mounting
Post
B
3
4
B
4
Set Screw
Cam
Transmission Cover
A
4
CRL LOCKING LADDER PULL ASSEMBLY
ALUMINUM
9crlaurence.com | usalum.com
ASSEMBLE INTERNAL HANDLE (CONTINUED)
Secure Internal Housing to Tube
Install Bottom Mounting Post
Install Cam

3
Install Lock Cylinder at exterior and Housing Adaptor at interior.
Align Bottom Mounting Post and secure.
2
Slide Exterior Housing onto tube from bottom and align at cutout.
Secure External Housing to tube.
1
1
Exterior
Housing
Bottom Tube
NOTE: Handle shown from side.
4
A
4
3
B
4
A
2
Lock Cylinder
Tail Piece
EXTERIOR Housing
Adaptor
Lock Cylinder Tail Piece fits inside
hole in Housing Adaptor.
B
2
2C 2D
Secure Cylinder to
Housing Adaptor.
Align screws to holes in
Cylinder Plate.
Secure Housing Adaptor
to Exterior Housing.
Fit locknuts
on screws.
3
Insert Set Screw through hole in
Exterior Housing. Tighten to secure.
B
4
Use 6 mm
Allen Wrench
to secure.
4C
Spacers
Rubber
Washer
NOTE: Mounting Post fittings assembly shown as
handle is originally shipped. Spacers fit through holes
in glass door. Refer to 11M0189 Locking Ladder Pull
Installation Manual to install handle on door.
Rubber
Washer Metal
Washer
Connecting
Grommet
Screw
A
4
Insert Bottom Mounting Post
in hole in bottom tube.
CRL LOCKING LADDER PULL ASSEMBLY
