Crow 4 OUTPUTS RELAY EXPANDER BOARD OUTPUT MODULE... User manual

ELECTRONIC ENGINEERING LTD.
4 OUTPUTS RELAY EXPANDER BOARD OUTPUT MODULE 12V/1A
Installation Instruction
Before starting to install and work with this device
Please read the Safety Instructions.
1. Scope of delivery
RELAY Board
Plastic board holder (x4)
Installation Instruction
2. Introduction
The RELAY board has been designed for internal installation inside a plastic enclosure. The RELAY board
connects to the control panel main board via the 4 wire keypad buss.
The RELAY board provides four independent changeover relay contacts that can be used to interface to
other devices such as garage doors, automatic gates, etc.
P/N 7101750 Rev. A
X 4

3. Operation Instructions
The CROW control panel allows for up to 8 programmable alarm outputs. 4 of these outputs are available as
standard on-board on the control panel and the additional outputs can only be accessed via this optional
relay board.
The Relay unit has 8 Open Collector transistors' outputs and 4 Relays outputs. The Open Collectors switch
to 0V when the output is ON. Every control to this board activates one relay output and one Open Collector
Outputs.
4. Mount the RELAY board
Be sure that the Control Panel's AC plug and battery are unplugged before connecting the unit.
A. Insert the plastic holders to the 4 holes at the corners of the RELAY board.
B. Remove the cover from the glue side of the plastic holders.
C. Attach the board and glue it to a free area at the right side of the control panel base.
D. Connect the 4 Bus wires to the Terminal Block (Data, Clock, Neg, Pos).
Use only the supplied plastic holders.
5. Outputs Setting
There are 4 jumpers on the RELAY board labeled as "Learn" from 1 - 4. These jumpers are used to select
the control outputs and relate them to the output relays.
The first jumper labeled as "1", relates to Relay #1, through to the jumper labeled "4" that relates to Relay # 4.
If the jumper #1 is in OFF position then relay #1 will follow the programmed options for output # 1, if jumper
#1 is ON then relay #1 will follow the programmed options for output # 5.
If jumper #2 is OFF then relay # 2 follows output # 2, if jumper #2 is ON then relay #2 follows output # 6, etc,
up to jumper 4 making relay # 4 follow output #4 or #8.
Please refer to the following table for more details;
6. Control Panel setup
The following option must be turned ON in the Control Panel for the RELAY activation:
P25E10E OPTION 6 MUST BE ON
7. Technical Data
Data a Protocol CROW CONTROL PANEL BUS
Operation Voltage 11 to 16Vdc
Current Consumption Active: 20mA per active
Standby: 15mA
Relay Contacts 24VDC 1A
Open Collector Drive
Outputs 12VDC 50mA
LED Indicator Individual LED for each relay
Operating temperature -10 - +50 °C
Storage temperature -20 - +60 °C
Humidity (EN60721) < 85 % r.h., non condensing
EMI rejection up to 1 GHz > 10 V/m
JUMPER
RELAY
# 1
JUMPER
# 1
RELAY
# 2
JUMPER
# 2
RELAY
# 3
JUMPER
# 3
RELAY
# 4
JUMPER
# 4
OFF Output
#1 Output #2 Output #3 Output #4
ON Output
#5 Output #6 Output #7 Output #8
COMPILES WITH: EN 50130-4+A1+A2,
EN301489-3, EN300220-3, EN60950-1,
EN61000-6-3, EN55022 KL. B, EN50371
