NuIPC® cPCI-6760D series
6U CompactPCI Highly Integrated Single Slot
Dual Bridge Low Power Pentium-III CPU Module
and Rear I/O Transition Module
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Copyright 2005 ADLINK TECHNOLOGY INC.
All Rights Reserved.
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Trademarks
NuIPC® is a registered trademark of ADLINK Technology Inc.
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Service from ADLINK
Customer Satisfaction is top priority for ADLINK Technology Inc.
Please contact us should you require any service or assistance.
ADLINK TECHNOLOGY INC.
Web Site: http://www.adlinktech.com
Sales & Service: [email protected]
TEL: [phone]
FAX: [phone]
Address: 9F, No. 166, Jian Yi Road, Chungho City,
Taipei, 235 Taiwan
Please email or FAX this completed service form for prompt and
satisfactory service.
Company Information
Company/Organization
Contact Person
E-mail Address
Address
Country
TEL FAX:
Web Site
Product Information
Product Model
Environment
OS:
M/B: CPU:
Chipset: BIOS:
Please give a detailed description of the problem(s):
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents i
Table of Contents
List of Tables........................................................................... v
List of Figures ...................................................................... viii
1 Introduction ........................................................................ 1
1.1 Checklist ............................................................................ 1
Front Board ..................................................................... 1
Rear Board ..................................................................... 2
1.2 Description........................................................................... 3
1.3 Features............................................................................... 8
1.4 Specifications....................................................................... 9
Specifications of the front board (cPCI-6760D series) .... 9
Safety Certificate and Test ........................................... 15
Power Consumption ..................................................... 15
Specifications of rear board cPCI-R6760D ................... 16
Specifications of rear board cPCI-R6760S ................... 17
Peripheral Connectivity for Front and Rear Board ........ 20
1.5 Functional Block Diagram.................................................. 23
1.6 Mechanical outline drawing ............................................... 24
2 Jumpers and Connectors................................................ 25
Jumpers and connectors map of cPCI-6760D series
front board .................................................................... 26
Jumpers and connectors map of cPCI-R6760D board . 28
Jumpers and connectors map of cPCI-R6760S
series board .................................................................. 29
2.1 Jumpers, Connectors, and LED Indicators on cPCI-6760D 30
JP1 on cPCI-6760D ...................................................... 31
Keyboard and Mouse Combo Connector (CN4) on
cPCI-6760D .................................................................. 31
Ethernet Connectors (CN6, 7) ...................................... 32
Serial Port COM1 Connector (CN1) ............................. 32
VGA Connector (CN3) .................................................. 33
SB (Port A) Connector (CN5) ....................................... 33
DE Connectors (44-pin, CN2) ....................................... 34
Micro-Switch Connector (CN8) ..................................... 35
CompactPCI J1 Pin Assignments ................................. 36
CompactPCI J2 Pin Assignments ................................. 37
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ii Table of Contents
CompactPCI J3 Pin Assignments ................................. 38
CompactPCI J4 Pin Assignments ................................. 39
CompactPCI J5 Pin Assignments ................................. 40
PMC Slot Pin Assignments J11 .................................... 42
PMC Slot Pin Assignments J12 .................................... 43
LAN Port Indicators (Integrated in LAN1 (CN6) and
LAN2 (CN7)) ................................................................. 44
IDE Activity LED Indication ........................................... 45
Power LED Indication ................................................... 46
WDT LED Indication ..................................................... 46
Self-Hot-Swap LED Indication ...................................... 46
LAN1, LAN2 Front and Rear I/O Connecting Selection 47
S1, S2: LAN1 Connecting Selection ............................. 47
S3, S4: LAN2 Connecting Selection ............................. 48
2.2 Jumpers, Connectors and LED Indicators on the
cPCI-R6760D ..................................................................... 49
JP2-5 COM2 Mode Selection on cPCI-R6760D
Rear Board ................................................................... 50
Keyboard Connector (CN13) ........................................ 51
Mouse Connector (CN12) ............................................. 51
Ethernet Connectors (CN7, CN8) ................................. 51
Serial Port COM2 Connector (CN10) ........................... 52
Serial Port COM1 Pin Headers (CN5) .......................... 52
Parallel Port Connector (CN11) .................................... 53
VGA Connector (CN6) .................................................. 53
USB (Port B) Connector (CN9) ..................................... 54
IDE Interface (40-pin, CN2, CN4) ................................. 54
FDD Interface (34-pin, CN3) ......................................... 55
CompactPCI rJ3 Pin Assignments ................................ 56
CompactPCI rJ5 Pin Assignments (AB type connector) 57
LAN Port Indicators (Integrated in LAN1 (CN7)
and LAN2 (CN8)) .......................................................... 58
2.3 Jumpers, Connectors and LED Indicators on cPCI-R6760 59
JP2 cPCI-R6760S LAN3 Enable/Disable ..................... 60
JP3 cPCI-R6760S LAN4 Enable/Disable ..................... 60
JP4-7 COM2 Mode Selection on cPCI-R6760S
Rear Board ................................................................... 61
Keyboard Connector (CN22) ........................................ 62
Mouse Connector (CN21) ............................................. 62
Ethernet Connectors (CN14-17) ................................... 63
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents iii
Serial Port COM2 Connector (CN19) ........................... 63
Serial Port COM2 Pin Headers (Reserved, CN13) ....... 64
Serial Port COM1 Pin Headers (Reserved, CN8) ......... 64
Parallel Port Pin Headers (Reserved, CN1) ................. 65
VGA Pin Headers (Reserved, CN5) ............................. 66
USB (Port B) Connector (CN18) ................................... 66
IDE Interface (40-pin, CN2, CN3) ................................. 67
FDD Interface (34-pin, CN4) ......................................... 68
External Ultra-160 SCSI Interface (CN20) .................... 69
CompactPCI rJ3 Pin Assignments (cPCI-R6760S) ...... 70
CompactPCI rJ4 Pin Assignments (cPCI-R6760S) ...... 71
CompactPCI rJ5 Pin Assignments (cPCI-R6760S) ...... 72
LAN Port Indicators (Integrated in LAN1 to LAN4) ....... 73
3 Getting Started ................................................................. 75
3.1 CPU Installation ................................................................. 75
3.2 Memory Installation............................................................ 76
3.3 CF Installation.................................................................... 76
DB-6760CF Outline, Jumper and Connectors .............. 77
DB-6760CF Installation for cPCI-6760D and
CF card notice .............................................................. 78
Removing DB-6760CF from cPCI-6760D ..................... 78
3.4 HDD Installation................................................................. 79
HDD/FFD Installation for cPCI-6760D .......................... 79
Removing HDD/FFD from cPCI-6760D ........................ 80
3.5 Device Connection for OS Installation ............................... 80
Using cPCI-6760D on ADLINK’s cBP-6108, 6105,
6515, and 6402 series backplane ................................. 80
Using cPCI-6760D on other backplanes ....................... 81
3.6 Notice for Rear I/O Connection.......................................... 82
The I/O implementation is only supported by
rear I/O board ............................................................... 82
The I/O implementation is supported by both
rear I/O and front I/O ..................................................... 82
LAN1, LAN2 Front and Rear I/O Connecting Selection 83
4 Driver Installation............................................................. 87
4.1 VGA Drivers Installation..................................................... 88
Driver Installation on Windows 2000 ............................ 89
Driver Installation on Windows 98 ................................ 90
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iv Table of Contents
Driver Installation on Windows NT ................................ 91
4.2 LAN Drivers Installation ..................................................... 92
Software and Drivers Support ....................................... 92
Driver Installation on Windows 2000 ............................ 93
Driver Installation on Windows 98 ................................ 94
Driver Installation on Windows NT ................................ 95
4.3 SCSI Drivers Installation.................................................... 96
Software and Drivers Support ....................................... 96
Driver Installation on Windows 2000 ............................ 97
Driver Installation on Windows 98 ................................ 98
Driver Installation on Windows NT ................................ 99
5 Watchdog and Utilities ................................................... 101
5.1 Watchdog Timer Configuration ........................................ 101
WDT Programming ..................................................... 101
How to Test the WDT? ............................................... 102
5.2 Hardware Doctor Utility .................................................... 103
5.3 Intel Preboot Execution Environment (PXE) .................... 103
5.4 Intel Adapter Teaming...................................................... 104
5.5 PICMG 2.1 Hot Swap Support......................................... 105
Insertion process: ....................................................... 106
Extraction Process: ..................................................... 107
5.6 Self Hot Swap Support..................................................... 108
BIOS Setting Process ................................................. 108
Windows 98 and 2000 Setting Process ...................... 109
Insertion Process ........................................................ 110
Extraction Process ...................................................... 111
Warranty Policy ................................................................... 113
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

List of Tables v
List of Tables
Table 1-1: cPCI-6760D Model Variations Comparison Table .... 5
Table 1-2: cPCI-R6760D and cPCI-R6760S comparison table . 6
Table 1-3: Power Consumption ............................................... 15
Table 1-4: Peripheral Connectivity for cPCI-6760D with cPCI-
R6760D .................................................................. 20
Table 1-5: Peripheral Connectivity for cPCI-6760D with cPCI-
R6760S ................................................................... 21
Table 2-1: JP1 Clear CMOS content ....................................... 31
Table 2-2: Keyboard/Mouse Combo Connector (CN4) on cPCI-
6760D front board ................................................... 31
Table 2-3: Ethernet Connector LAN1 (CN6) and LAN2 (CN7) on
cPCI-6760D front board .......................................... 32
Table 2-4: Serial Port COM1 (CN1) on cPCI-6760D
front board .............................................................. 32
Table 2-5: VGA Connector (CN3) on cPCI-6760D front board 33
Table 2-6: USB Connector (CN5) on cPCI-6760D front board 33
Table 2-7: Secondary IDE channel (CN2) on cPCI-6760D front
board ...................................................................... 34
Table 2-8: Micro-Switch Connector CN8 on cPCI-6760D ........ 35
Table 2-9: CompactPCI J1 pin assignments ........................... 36
Table 2-10: CompactPCI J2 Pin Assignments ........................... 37
Table 2-11: CompactPCI J3 pin assignments ........................... 38
Table 2-12: ComapctPCI J4 pin assignments ........................... 39
Table 2-13: CompactPCI J5 pin assignments ........................... 40
Table 2-14: PMC Slot Pin Assignments J11 .............................. 42
Table 2-15: PMC Slot Pin Assignments J12 .............................. 43
Table 2-16: Amber LED indication in LAN port .......................... 44
Table 2-17: Green LED indication in LAN port .......................... 45
Table 2-18: IDE Activity LED indication ..................................... 46
Table 2-19: Power LED indication ............................................. 46
Table 2-20: WDT LED indication ............................................... 46
Table 2-21: Self-hot-swap LED indication ................................. 46
Table 2-22: LAN1 Connecting Selection .................................... 47
Table 2-23: LAN2 Connecting Selection .................................... 48
Table 2-24: JP2-5 COM2 Mode Selection on cPCI-R6760D
rear board ............................................................... 50
Table 2-25: Keyboard Connector (CN13) on cPCI-R6760D
rear board ............................................................... 51
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

vi List of Tables
Table 2-26: Mouse Connector (CN12) on cPCI-R6760D
rear board ............................................................... 51
Table 2-27: Ethernet Connector LAN1 (CN7) and LAN2 (CN8)
on cPCI-R6760D rear board ................................... 51
Table 2-28: Serial Ports COM2 (CN10) on cPCI-R6760D
rear board faceplate ................................................ 52
Table 2-29: Serial Ports COM1 (CN5) pin headers on
cPCI-R6760D rear board ........................................ 52
Table 2-30: Parallel Ports LPT1 (CN11) on cPCI-R6760D
rear board faceplate ................................................ 53
Table 2-31: VGA Connector (CN6) on cPCI-6760D front board 53
Table 2-32: USB Connector (CN9) on cPCI-R6760D
rear board faceplate ................................................ 54
Table 2-33: Primary IDE channel (CN2) and secondary
IDE channel (CN4) on cPCI-R6760D rear board .... 54
Table 2-34: FDD Interface (CN3) on cPCI-R6760D ................... 55
Table 2-35: CompactPCI rJ3 pin assignments on
cPCI-R6760D rear board ........................................ 56
Table 2-36: CompactPCI J5 pin assignments on
cPCI-R6760D rear board ........................................ 57
Table 2-37: Amber LED indication in LAN port on
cPCI-R6760D rear board ........................................ 58
Table 2-38: Green LED indication in LAN port on
cPCI-R6760D rear board ........................................ 58
Table 2-39: JP2 cPCI-R6760S LAN3 Enable/Disable ............... 60
Table 2-40: JP3 cPCI-R6760S LAN4 Enable/Disable ............... 60
Table 2-41: JP4-7 COM2 Mode Selection on cPCI-R6760S
rear board ............................................................... 61
Table 2-42: Keyboard Connector on cPCI-R6760S rear board . 62
Table 2-43: Mouse Connector on cPCI-R6760S rear board ...... 62
Table 2-44: Ethernet Connector LAN1 to LAN4 on
cPCI-R6760S rear board ........................................ 63
Table 2-45: Serial Ports COM2 (CN19) on cPCI-R6760S
rear board faceplate ................................................ 63
Table 2-46: Serial Ports COM2 pin headers (CN13) on
cPCI-R6760S rear board ........................................ 64
Table 2-47: Serial Ports COM1 pin headers (CN8) on
cPCI-R6760S rear board ........................................ 64
Table 2-48: Parallel Ports Pin Headers (CN1) on
cPCI-R6760S rear board ........................................ 65
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

List of Tables vii
Table 2-49: VGA pin headers (CN5) on cPCI-R6760S
rear board ............................................................... 66
Table 2-50: USB Connector (CN18) on cPCI-R6760S
rear board faceplate ............................................... 66
Table 2-51: Primary IDE channel (CN3) and secondary
IDE channel (CN2) on cPCI-R6760S rear board .... 67
Table 2-52: FDD Interface (CN4) on cPCI-R6760S ................... 68
Table 2-53: External Ultra-160 SCSI Interface (CN20) on cPCI-
R6760S faceplate ................................................... 69
Table 2-54: CompactPCI rJ3 pin assignments on
cPCI-R6760S rear board ........................................ 70
Table 2-55: CompactPCI rJ4 pin assignments on
cPCI-R6760S rear board ........................................ 71
Table 2-56: CompactPCI rJ5 pin assignments on
cPCI-R6760S rear board ........................................ 72
Table 2-57: Amber LED indication in LAN port .......................... 73
Table 2-58: Green LED indication in LAN port .......................... 73
Table 3-1: JP1 DB-6760CF Master/Slave Setting ................... 77
Table 3-2: LAN1 Connecting Selection .................................... 84
Table 3-3: LAN2 Connecting Selection .................................... 84
Table 5-1: BIOS and OS setting for self Hot Swap ................ 108
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

viii List of Figures
List of Figures
Figure 1-1: Functional Block Diagram........................................ 23
Figure 1-2: Outline drawing for cPCI-6760D series front board. 24
Figure 2-1: Front View................................................................ 26
Figure 2-2: Bottom and Front Panel View .................................. 27
Figure 2-3: Jumpers and connectors map of
cPCI-R6760D board ................................................ 28
Figure 2-4: Jumpers and connectors map of
cPCI-R6760S series board ...................................... 29
Figure 2-5: IDE Activity LED Indication...................................... 45
Figure 3-1: DB-6760CF Outline ................................................. 77
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction 1
1 Introduction
This manual contains information on the cPCI-6760D series CPU
module and its related rear I/O transition modules, including cPCI-
R6760D - basic rear I/O transition module for cPCI-6760D and
cPCI-R6760S - super rear I/O transition module (super RTM).
Topics covered in this chapter include:
XChecklist
XDescriptions
XFeatures
XSpecifications
XFunctional block diagram
XMechanical outline drawing
1.1 Checklist
The cPCI-6760D series comply with the PICMG 2.0 Rev. 3.0
CompactPCI specification with 6U single-slot (4 TE/HP) form
factor. The cPCI-6760D series support both front panel I/O and
rear panel I/O. It is not necessary to use the rear board if the
application requires only front panel I/O wiring or special
backplane wiring. The front board (the CPU module) and the rear
board (the rear I/O transition module, RTM) are sold separately.
The standard models: cPCI-6760D/P7 and cPCI-6760D/P8 are
front boards, and the standard models: cPCI-R6760D and cPCI-
R6760S are rear boards.
Front Board
Front board is the CPU module. There are two standard versions
available for cPCI-6760D series module (see section 1.2 for the
model variations comparison table). The default version does not
include any RAM or HDD. However, the CPU module may be
equipped with different capacity of RAM or HDD by request.
Please check your configurations with your dealer and check that
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2Introduction
your package is complete with the items listed below. If there are
any damaged or missing items, please contact your dealer.
XThe cPCI-6760D CPU module (may be equipped with
different capacity of RAM or HDD. Those items may vary
according to various configuration requests. The CPU is
pre-soldered and the CPU heatsink is pre-mounted.)
XOne 2.5” ATA HDD accessory pack (P/N: 58-00023-000)
including a specially designed 44-wire connection cable and
screws kit. (This accessory pack will not be available if the
2.5” ATA HDD is pre-mounted by request.)
XOne DB-6760CF removable CompactFlash socket adaptor
(which is pre-mounted on the CPU module for the standard
configuration delivery. The DB-6760CF may not be included
if customer requests the pre-configuration of 2.5” ATA HDD
or by OEM project request.)
XY cable for PS/2 keyboard and mouse connection. (P/N: 30-
01016-000)
XThis User’s Manual
XADLINK CD
Rear Board
The rear board is a rear I/O transition module (RTM). Different rear
boards provide different I/O function combinations or extensions.
Two models are available for use with the cPCI-6760D series
module: cPCI-R6760D and cPCI-R6760S. The cPCI-R6760D is
designed for the standard rear panel I/O for cPCI-6760D. And the
cPCI-R6760S is designed for the extra rear panel I/O functionality
expansion for cPCI-6760D. Please see section 1.2 and the model
variations comparison table. Check that your package is complete
Note: The delivery package of cPCI-6760D OEM version
(non-standard configuration, functionality, customized
logo, modified faceplate or package) may vary accord-
ing to various customization requests.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction 3
with the items below. If you find any damaged or missing items,
please contact your dealer.
XThe cPCI-R6760D or R6760S rear I/O transition module
XOne 40-wires EIDE cable and one 34-wires FDD cable (P/
N: 58-00009-000)
XThis User’s Manual
XADLINK CD
1.2 Description
ADLINK cPCI-6760D is a powerful and flexible CompactPCI host
slot processor board based on Intel BGA2 Mobile (or Low Voltage/
Ultra Low Voltage) Pentium III processor. This board is specially
designed to add total system functional density to ADLINK’s 6U
CompactPCI platform for CTI and Telecom applications. It is also
suitable for clustering high-availability, high-density, and high-
reliability embedded applications where performance and a rich
feature set are mandatory.
The CPU module uses the Intel® 440BX AGPset chipset which
supports processor front side bus (FSB) running at 100MHz and
PC-100 SDRAM up to 512MB with optional ECC capacity. The
highly integrated design allows the cPCI-6760D to provide full
functionality within a single slot space. Users can access the RS-
232, AGP-VGA, USB, keyboard, mouse, Dual Ethernet ports and
one PMC expansion slot on the front panel. There are two
standard models available for cPCI-6760D numbering as cPCI-
6760D/P7 and cPCI-6760D/P8 that provide different CPU speed
for customized applications.
cPCI-R6760D rear I/O transition module provides the rear panel I/
O extension features for cPCI-6760D. It provides the I/O access of
Note: The delivery package of cPCI-R6760 OEM version
(non-standard configuration, functionality, customized
logo, modified faceplate or package) may vary accord-
ing to the different customization request.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4Introduction
printer port, dual Ethernet ports, keyboard, mouse, USB, RS-232/
422/485, and AGP-VGA on rear panel as well as providing
interfaces for inner chassis connection of storage devices such as
EIDE and FDD.
cPCI-R6760S rear I/O transition module, the super RTM, provides
the extra functionality expansion for cPCI-6760D. It provides the I/
O access of Ultra-160 SCSI, four Ethernet ports, keyboard,
mouse, COM2 (RS-232/422/485), and one USB on rear panel.
The module also provides the interfaces for inner chassis
connection of EIDE and FDD. Reserved pin headers of printer
port, COM1, and VGA port are used for customized applications.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction 5
cPCI-6760D Model Variations Comparison Table
Model cPCI-6760D/P7 cPCI-6760D/P8
Processor Intel BGA2 Pentium-III
700MHz
Intel BGA2 Pentium-III
850MHz
Processor
FSB 100 MHz 100 MHz
Chipset Intel® 440BX AGPset Intel® 440BX AGPset
Memory Size Up to 512MB Up to 512MB
Memory
Type
PC-100 SDRAM in 144-pin SO-
DIMM
PC-100 SDRAM in 144-pin
SO-DIMM
Graphic SMI SM721 SMI SM721
Video Mem-
ory Build-in SM721 4MB VRAM Build-in SM721 4MB VRAM
Serial Port 2 (one RS-232/422/485)* 2 (one RS-232/422/485)*
Parallel Port 1* 1*
USB 2* 2*
Ethernet Port 2 Ports (Intel® 82599 Fast
Ethernet Controller)
2 Ports (Intel® 82599 Fast
Ethernet Controller)
EIDE 2 UDMA-33 channels* 2 UDMA-33 channels*
FDD I/F Yes* Yes*
Flash Stor-
age
Removable CompactFlash
Socket or 2.5” Flash Drive
Removable CompactFlash
Socket or 2.5” Flash Drive
PMC Socket Single, 32-bit Single, 32-bit
cPCI Slots
Support 14 slots, all bus mastering 14 slots, all bus mastering
Table 1-1: cPCI-6760D Model Variations Comparison Table
Note: Some functional interfaces should be collocated with
cPCI-R6760D or cPCI-R6760S. Please refer to the
specification and peripheral connectivity table for more
information.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6Introduction
cPCI-R6760D and cPCI-R6760S Comparison Table
Model cPCI-R6760D cPCI-R6760S
SCSI None External Ultra-160 SCSI Interface
(HD-68)
Ethernet Ports
(RJ-45)
Two ports support front
and rear I/O
Two ports support front and rear I/
O; two extra ports support rear I/O
VGA DB-15 on faceplate Reserved pin headers on board
COM1 Reserved pin headers on
board (RS-232)
Reserved pin headers on board
(RS-232)
COM2 DB-9 on faceplate (RS-
232/422/485)
Reserved pin headers on board
and DB-9 on faceplate (RS-232/
422/485)
Parallel Port DB-25 on faceplate Reserved pin headers on board
USB One connector on face-
plate One connector on faceplate
EIDE Two 40-pin interfaces on
board Two 40-pin interfaces on board
FDD I/F One 34-pin interface on
board One 34-pin interface on board
Keyboard PS/2 on faceplate PS/2 on faceplate
Mouse PS/2 on faceplate PS/2 on faceplate
14-slot support Yes No *
Table 1-2: cPCI-R6760D and cPCI-R6760S comparison table
Note: *Please refer to the specification and peripheral
connectivity table for more information.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction 7
CAUTION: When collocating cPCI-R6760S with cPCI-6760D, do
not apply this combination in the 14-slot support
backplane such as cBP-6515R or cBP-6014R. The
cPCI-R6760S utilizes the PCI bus from secondary
bridge on J4 and J5. Using cPCI-R6760S with a 14-
slot support backplane may cause conflict between the
add-on card’s PCI bus mastering devices and the
onboard PCI bus mastering devices such as Ultra-160
SCSI and fast Ethernet controller. It may also result in
malfunctions in some add-on cards or onboard
devices.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
