INSTRUCTION MANUAL
BEVERAGE COOLER MODEL: RDACO - 160001-B2
- Please read these instructions carefully before operating this appliance.
- Check if local voltage corresponds to the unit label.
SAFETY
- This appliance is designed to operate on alternative current (A.C.) Only
- DO NOT CONNECT TO DIRECT CURRENT (D.C.).
- Care should be taken when operating this appliance, as HOT SURFACES may cause
burns.
- DO NOT SHAKE OR TURN UPSIDE DOWN because it can damage the refrigeration
system.
- When not in use for long period unplug the appliance.
OPERATION
- Install the equipment on a counter 50” (1.2m) height (at least).
- Find a place well ventilated, protected from solar rays and away from heat sources.
- Plug the equipment without the product container and turn on. After some minutes you will
see a thin ice layer on the evaporator (drawing nº 18) that will melt a short time later and this
cycle will repeat.
- Replace the product container and the equipment is ready to use.
- As a “tip” fill in the product container with a already cooled product to get a best
performance.
- Obs.: The temperature is controlled by a thermostat that keeps the liquid around 41ºF
(5ºC).
- Remember that when positioning the jet tube( nº 6), observe that the hole in the tube must
be directed to evaporator.
CLEANING
- For your safety unplug the equipment before any maintenance service.
Body: Use only a damp cloth or sponge dipped in soapy water.
Product Container: Use only water and neutral soap. Avoid abrasive materials.
Product Dispenser: Use only water and neutral soap after disassemble (see drawing nº
7 and 8).

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
6
32
46
43
44
35
36
37
39
41
42
24
14
29
40
48
47
31
21
17
1
23
4
5
18
19
10
14
11
20
27
26
30
25
28
15
38
34
16
33
13
12
45
24
21
45
14
24
7
7a
8
7b
10
14
500
5.5 (110V)
20 x 2 / 5.3 x 2
34.3 Kg/75.5
62/24.5x 65/25.6 x 57/22.5
Power (W)
Amperage (A)
Capacity (L/g)
Weight (Kg/lbs)
Dimension WxHxD (cm/in)
RDACO-160001-B2
Technical Data
DISASSEMBLY SEQUENCE
TO WASH THE DISPENSER
- Push the lever (7c).
- Hold the Tube (8) by the loop and
pull it.
- Unscrew the plastic Nut(7a) (The
dispenser body (7c)will be free).
- Wash the components using water
and neutral detergent.
- Reassembly it in reverse sequence.
CROYDON
CROYDON DOUBLE BEVERAGE COOLER (RDAÇO) DOUBLE BEVERAGE COOLER (RDAÇO)
Item Code Description
1.242-3
1.060-3
1.055-3
1.275-3
1.057-3
1.238-3
1.469-3
1.474-3
594
635
1.236-3
481
331
642
531
1.432-3
1.206-3
1.290-3
1.109-3
1.416-3
643
604
641
601
1.410-3
1.444-3
1.407-3
1.266-3
1.426-3
1.270-3
2.085-3
1.431-3
3.021-3
271
2.088-3
1.232-3
1.434-3
1.430-3
1.291-3
1.204-3
1.234-3
1.233-3
1.447-3
1.433-3
597
14.033-3
332
333
Product Container Cover
Latex Ring
Pump Body
Rotor
Rotor Screw
Jet Tube
Dispenser Assembly (Complete)
Dispenser Tube
Lock Washer (3/16”)
Nut (M6)
Product Container
Screw (3/16”)
Screw
Washer (1/4”)
Screw Hex Type
Front Panel
Insulation Tube
Evaporator
Insulation Tube
Product Container Seat
Washer (3/16")
Nut (3/16")
Washer (5/16")
Nut (1/4")
Thermostat Support
Driving Magnet
Jet Motor
Jet Motor Support
Fan Motor Assembly
Thermostat
Wiring Connector
Cabinet
Rubber Protection
On/Off Switch
Rubber Foot
Drip Pan Support
Left Cover
Metal Seat Base
Condenser
Gás Filter R-134a
Drip Pan Grate
Drip Pan
Compressor 220V / 60Hz
Cabinet Cover
Lock Washer (1/4")
Power Connection Cord
Screw (1/4”)
Screw (1/4”)
