CRU DataPort LP SAS/SATA User manual

Rugged, Reliable, Mobile, SecureTM
1-800-260-9800 www.CRU-DataPort.com
Package Contents
1 - DataPort LP SAS/SATA Carrier
1 - DataPort LP SAS/SATA Frame
4 - 6 x 32 x 3/8” flat-head screws for hard drive mounting
4 - M3 x 10mm Phillips pan-head screws for frame mounting
Installation Instructions
To install the DataPort LP, remove the carrier from the frame. To
remove the carrier, press the release button on the left corner
of the carrier. This will release the ejection lever to remove the
carrier (see figure 1). Extend the ejection lever fully to release the
carrier. Use the lever to pull the carrier out of the frame.
Install the Frame Into the Enclosure
1. Slide the frame into the enclosure and, using the screw holes
provided, secure the frame into the enclosure. For installations
requiring mounting rails, attach the mounting rails and then
slide the frame into the enclosure.
2. Connect the data cable and the power cable to the back of
the frame. For SATA support connect the HBA to JP4. For SAS
support use JP5 or JP4 (see figure #2). For dual host support
each data connector must be connected to a different host.
Install the Hard Disk Drive Into the Carrier
1. Slide the SAS or SATA hard drive into the carrier and secure it
with the provided screws.
2. Make sure the lever is fully extended before inserting the
carrier into the frame. Insert the carrier and then close the
lever by pushing it back in to complete the insertion and secure
the carrier. Power up the enclosure; the drive should spin up
and be operational. The green LED indicates that the drive is
powered up and the amber LED indicates drive activity.
Figure 1: Front View
DataPort LP SAS/SATA Install Guide
The DataPort LP is designed to mount via top, bottom, or
side mounts. This allows the maximum number of options
to mount the DataPort LP into any enclosure.
release
button

Rugged, Reliable, Mobile, SecureTM
1-800-260-9800 www.CRU-DataPort.com
IMPORTANT: Read the following before removing the carrier!
Removing the DataPort LP carrier while it is operational is not
recommended. The DataPort LP supports hot-swapping, but does
not enable it. Your Host Bus Adapter must provide hot-swapping.
If it does and you need to remove the carrier, observe the follow-
ing precautions:
Wait until the drive has stopped writing and there is no•
read/write activity
If using a disk caching program, ensure all drive activity•
has completed
After drive activity has concluded remove the carrier from•
the frame
The DataPort LP provides a front panel green LED indicating
Power On to the hard disk drive. The DataPort LP ships with the
drive activity LED always on and the drive feature Delayed Spin
up disabled. To enable drive activity and Delayed Spin up remove
the jumper from JP5. Please note many SAS drives support the
drive ready LED feature during normal operation the LED will be
on when the drive is ready and flash when the drive is in use.
For SAS/SATA Host Bus Adapter and RAID controller LED sup-
port, the DataPort LP activity LED can be externally driven. To en-
able this feature on JP7 jumper pins 1 & 2. Remove the jumper
from JP5 and connect the host activity cable to JP5, where Pin 1
supports the activity signal and Pin 2 is ground.
Limited Product Warranty
CRU-DataPort warrants the DataPort LP to be free of significant
defects in material and workmanship for a period of one (1) year
from the original date of purchase. CRU-DataPort’s warranty is
nontransferable and is limited to the original purchaser.
Product Remedies
CRU-DataPort’s entire liability and the original purchaser’s
exclusive remedy for any breach of warranty shall be, at CRU-
DataPort’s option, either (a) return of the price paid, or (b) repair
or replacement of the hardware, provided that the hardware is
returned to CRU-DataPort with a copy of the sales receipt or
applicable documentation. Any replacement hardware will be
warranted for the remainder of the original warranty period.
These remedies are void if the hardware fails because of acci-
dent, abuse, misapplication, or modification (this will be deter-
mined by CRU-DataPort).
Limitation of Liability
The warranties set forth in this agreement replace all other war-
ranties. CRU-DataPort expressly disclaims all other warranties,
including but not limited to the implied warranties of merchant-
ability and fitness for a particular purpose and noninfringement of
third-party rights with respect to the documentation and hard-
ware. No CRU-DataPort dealer, agent, or employee is authorized
to make any modification, extension, or addition to this warranty.
In no event will CRU-DataPort or its suppliers be liable for any
costs of procurement of substitute products or services, lost
profits, loss of information or data, computer malfunction, or any
other special, indirect, consequential, or incidental damages aris-
ing in any way out of the sale of, use of, or inability to use any
CRU-DataPort product or service, even if CRU-DataPort has been
advised of the possibility of such damages. In no case shall CRU-
DataPort’s liability exceed the actual money paid for the products
at issue.
CRU-DataPort reserves the right to make modifications and
additions to this product without notice or taking on additional
liability.
Register your product at www.CRU-DataPort.com.
A5-001-0004 Rev. 1.0
