Crux Sightline RVCAD-81H User manual

R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
PRODUCT FEATURES:
- Acvates Reverse camera input in Audi, Porsche and Volkswagen vehicles with 4G systems.
- Rear-view camera input with PDC seng.
- Front camera input with med acvaon/deacvaon seng.
- On-screen display and setup.
PARTS INCLUDED:
rev.051121
1 of 8
Power/CAN POWER Harness
REARFRONT
①ACC (Yellow)
②FRONT/REAR_POWER (Red)
③CAN -HIGH (Orange)
④CAN -LOW (Green)
⑤MMI (Blue)
⑥GND (Black)
① ② ③ ④ ⑤ ⑥
CONNECTOR PIN ASSIGNMENT:
RVCAD-81H Module RVCAD-81H Harness LVDS Cable Programming Keypad

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
2 of 8 rev.051121
R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
DIP SWITCH SETTINGS:
DIP# FUNCTION SETTING
1 NO FUNCTION SET TO OFF
2NO FUNCTION SET TO OFF
3NO FUNCTION SET TO OFF
4 NO FUNCTION SET TO OFF
5
VEHICLE SELECTION SEE CHART BELOW
6
7
8
NOTE on DIP Switches:
DOWN is ON
VEHICLE DIP# 5 DIP# 6 DIP#7 DIP# 8
Audi A3 with 5.8” screen OFF ON OFF OFF
Audi A3 with 7” screen OFF ON OFF ON
Audi A4/Q7 with 7” screen OFF ON ON ON
Audi A6 with 8” screen OFF ON ON OFF
Volkswagen Golf with 5.8” screen OFF OFF OFF OFF
Volkswagen Golf with 6.5” screen ON OFF ON OFF
Volkswagen Golf with 8” screen OFF OFF OFF ON
Porsche 2016 with 7” screen ON ON OFF ON

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.051121
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
WIRING DIAGRAM:
R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
ACC (Yellow)
Front/Rear Camera Power (Red)
Ground (Black)
To OE Monitor
Connect to GRAY Connector
(DO NOT connect to Blue or
Green Connector)
RVCAD-81H
To Rear Camera
To Front Camera
Manual Rear Camera
Detect Trigger
(Brown wire)
1. Unplug the Quadlock connector from the headunit. 2. Remove the GRAY connector insert from the Quadlock.
3. Plug the factory GRAY connector insert to the
RVCAD-81H harness
4. Plug the GRAY connector insert on the RVCAD-81H
harness to the Quadlock connector.
INSTALLATION INSTRUCTIONS:
3 of 8

R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.051121
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
4 of 8
ON SCREEN DISPLAY (OSD) SETTINGS:
Plug in the OSD Control Keypad to the module to adjust the sengs. Unplug and store when nished.
MENU OSD On/O
Return to previous menu
SEL Select Item
UP Move cursor Up
Increase selected value
DOWN Move cursor Down
Decrease selected value
MENU SEL UP DOWN
First Menu Second Menu Third Menu Descripon
Opon
RearCam-Type OEM OEM Camera
EXTDevice Aermarket Camera
RearCam-Power
ON Camera power connously ON
AUTO Camera power ON in reverse gear
OFF Camera Power OFF
RearCam-Det
PDC Detected by P >> buon (CAN)
GEAR Detected by Reverse Gear (CAN)
WIRE Not Used
FrontCam-Type OEM OEM Camera
ExtDevice Aermarket Camera
FrontCam-Power
ON Camera power connously ON
AUTO Camera power ON aer reverse gear
OFF Camera power OFF
FrontCam-Det CAN Detected by CAN
WIRE Not Used
RearCam-RcvOpt
ON Show front camera aer reverse process
Set me to show front camera (1 - 30 seconds)
OFF Do not show front camera
Steering Mode Not Used (set to OFF)
Reset Execute Reset to factory defaults
Front and Rear Camera Sengs:

R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.051121
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
First Menu Second Menu Descripon
Screen
Horizontal Horizontal screen movement
Vercal Verical screen movement
Scale X Up Reduce / Increase screen width
Scale X Down
Scale Y Up Reduce / Increase screen height
Scale Y Down
Reset Reset to factory defaults
Screen Posion Sengs:
First Menu Second Menu Third Menu Descripon
Parking
OPS Display ON Display OPS (Opcal Parking Sensors)
OFF OPS not displayed
Line Display ON Display parking guide lines
OFF Parking guide lines not displayed
Warnings Lang Set warning text language
Horizontal Move parking line horizontally
Vercal Move parking line vercally
Transparency Parking line transparency
Reset Reset to factory defaults
Park Assist System (PAS) Sengs:
Parking Line ON Parking Line OFF
5 of 8

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
6 of 8 rev.051121
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
R
INTERFACING SOLUTIONS
Sightline
REAR-VIEW INTEGRATION
PDC ON PDC OFF
Grid Type - Split Grid Type - Full
Press UP Buon
Press DOWN Buon
Press
MENU
Buon
Press
SEL
Buon
Use the OSD Control Keypad to make the
Vercal and Horizontal adjustments to
the parking guide lines. Set the screen
to show the reverse camera in order to
properly adjust the parking guide lines.
Image to the right shows which buons
to use on the keypad.

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.051121
RADIO REPLACEMENT
SWC RETENTION
+
R
INTERFACING SOLUTIONS
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
7 of 8
5.8” Screen 8” Screen
SELECTING THE AV SOURCES:
VW GOLF
MUTE = Change AV Source
(Press for 1 second)
AV1, AV2, HDMI
RADIO = Return to OEM Screen
NAV = Change AV Source
(Press for 1 second)
AV1, AV2, HDMI
RADIO = Return to OEM Screen
AUDI A6/A7 (4G)
NAV = Change AV Source
(Press for 1 second)
AV1, AV2, HDMI
RADIO = Return to OEM Screen

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.051121
RADIO REPLACEMENT
SWC RETENTION
+
R
INTERFACING SOLUTIONS
RVCAD-81H
Front & Rear View Integration Interface with AV Inputs for
AUDI, PORSCHE and VOLKSWAGEN with 4G MIB/MIB1 & PCM4/4.1 Systems
8 of 8
VEHICLE APPLICATIONS:
AUDI Screen Size/System VOLKSWAGEN Screen Size
2016 - 2017
2016 - 2017
2015 - 2017
2016 - 2017
A3
A4
A6/A7
Q7
5.8” & 7” / MIB/MIB1
7” / MIB/MIB1
8” / MIB/MIB1
7” / MIB/MIB1
2015 - 2017 Golf 7 5.8”/ 6.5” / 8”
MIB/MIB1
PORSCHE
2016 - 2019 All models 7” with PCM4/4.1
AUDI A3/A4/Q7 (2016)
NAV = Change AV Source
(Press for 1 second)
AV1, AV2, HDMI
RADIO = Return to OEM Screen
PORSCHE (2016)
NAV = Change AV Source
(Press for 1 second)
AV1, AV2, HDMI
HOME = Return to OEM Screen
