Cub Cadet CC-3040PS User manual

READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT
6004281 - REV A9/18
CC-3040PS
10 cu ft POLY SWIVEL DUMP CART
*PATENT PENDING

This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
Read and understand all safety rules and operating instructions before using this
tractor attachment.
Follow all safety rules and operating instructions provided by your vehicle's
manufacturer when using attachment.
Never allow children or untrained persons to operate vehicle or attachment.
Do not exceed the vehicle manufacturer's towed weight limit.
Reduce vehicle speed and allow extra stopping distance when towing heavy
loads.
Reduce vehicle speed and towed weight when operating on slopes.
Operate up and down slopes, never across the face of slopes.
Do not carry passengers on vehicle or attachment.
Avoid sudden turns or maneuvers.
Do not tow attachment on public roadways.
Do not remove warning decals from product.
Check product for worn, loose, or damaged parts before each use. If any damage
is present, repair the product before using.
Check product for loose or missing fasteners before each use. Tighten or replace
fasteners as needed before using.
Do not exceed vehicle speed of 6 miles per hour when towing Dump Cart.
Do not exceed Dump Cart rated weight capacity of 600 pounds.
1
Safety Rules

If this product fails due to a defect in material or workmanship within THREE
YEARS from the date of purchase, we will at our option repair or replace it free of
charge. This warranty excludes tires and wheels which are expendable and
become worn during normal use.
This warranty does not cover:
Repairs necessary because of operator abuse or negligence. •
Equipment used for commercial or rental purposes. •
Paint that is worn or faded due to normal use or exposure. •
To arrange for product repair visit ohiosteel.com/partsstore and fill out the
warranty repair form. You can also call 1-800-652-2321 to speak to our Customer
Service Team, or return this product to place of purchase for replacement.
This warranty gives you specific legal rights, and you may also have other rights
which may vary from state to state. This warranty applies only while this product
is in use in the United States.
In the space below record the purchase date of your Lawn Sweeper.
Model Number CC-3040PS
Purchase Date
Retailer/Dealer
Purchase Price
Keep this Owner's Manual and your receipt in a safe place for future reference.
After the three year warranty period all replacement parts may be ordered at
ohiosteel.com/partsstore or by calling 1-800-652-2321 .
When ordering replacement parts, always give the following information:
Product 10 cu ft POLY SWIVEL DUMP CART •
Model Number CC-3040PS •
Part Number •
Part Description •
2
Warranty

23 (x12)
TOOLS REQUIRED FOR ASSEMBLY:
1/2" Wrench or Socket •
Grease Gun •
Large Flat Screwdriver •
5 (x1)
1 (x1)
2 (x1)
29 (x2)
4 (x1)
26 (x2)
25 (x4)
24 (x12)
22 (x12)
3 (x1)
27 (x1)
28 (x2)
3
Carton Contents

22
24
1
2
24
22
3
23
27
4
Attach Undercarriage to Poly Body and tighten with hardware as shown.
Attach Front Support loosely to Poly Body as shown.
Insert Axle into Undercarriage halfway as shown. Center Spacer inside Swivel
Clevis and align with Axle.
DO NOT
TIGHTEN
HARDWARE
AT THIS TIME
4
Assembly Instructions
1
3
2

Tighten Bolts
on Front Support
after Latching
to Drawbar
28
29
25
26
MAKE SURE
VALVE STEM
IS FACING OUT
25
Slide Axle completely through Undercarriage; Swivel Clevis and Spacer must
be captured by Axle. Align Drawbar with Front Support and press down to
latch.
Slide Washers and Wheels onto Axle and secure with Hairpins as shown.
5
Assembly Instructions
4
5

Periodic Maintenance:
Tighten fasteners as needed before each use •
Check tire pressure before each use •
Gease wheels annually •
How to Use Dump Cart:
Attach Dump Cart to your tractor using the installed spring loaded hitch pin. 1.
Do not exceed 600 pounds when loading material into the cart body. 2.
Distribute the weight of the load as evenly as possible in the cart body for 3.
best handling.
When hauling heavy loads, verify that your vehicle has adequate towing and 4.
braking capacity.
Do not exceed 6 miles per hour when towing Dump Cart. 5.
Before Using Dump Cart:
Apply grease to wheels using grease gun until grease can be seen 1.
squeezing out from both sides of the wheel.
Check tire pressure and inflate to 30 psi if needed. 2.
Read all Safety Rules found on page 1. 3.
How to Empty Dump Cart:
Step down the foot pedal to release the latch mechanism. 1.
Lift the body and swivel as desired to guide the material to preferred 2.
location.
Lift the body entirely and empty material. 3.
Lower the body and guide the latch into the drawbar and relatch. 4.
6
Operating Instructions

REPLACEMENT PARTS ORDERING 1-800-652-2321
22
24
1
23
2
28
4
27
29
25
9
8
7
12
11
10
16
18
17
10
19
20
10
14 13
23
23
5
26
3
15
21
6
ITEM PART NO DESCRIPTION QTY ITEM PART NO DESCRIPTION QTY
1 6000667 BODY, POLY, 10 CU FT 1 16 300055 HEX BOLT, 3/8-16 X 3" 1
2 411061 UNDERCARRIAGE 1 17 6000309 LATCH 1
3 6000668 FRONT SUPPORT 1 18 6000325 SPRING, LATCH 2
4 300001 AXLE 1 19 300052 HEX BOLT, 3/8-16 X 3/4" 2
5 6002535-BY DRAWBAR ASSEMBLY (incl 10-20) 1 20 6000612 SPRING LOADED HITCH PIN 1
6 6000383 DRAWBAR, WELDED 1 21 6003362 HARDWARE, BOLT BAG 1
7 6000548 CLEVIS, SWIVEL 1 22 300054 SLOTTED TRUSS BOLT, 5/16-18 X 3/4" 12
8 6000368 WASHER, SPRING 1 23 6000418 SPINNER GRIP NUT, 5/16-18 12
9 6000369 SHOULDER BOLT, 1/2" X 3/8" 1 24 3000711 WASHER, 5/16" USS 12
10 300061 HEX NUT, 3/8-16 C-LOCK 6 25 3000721 WASHER, 3/4" SAE 4
11 3000720 WASHER, 3/8" USS 1 26 300084 HAIRPIN COTTER 2
12 300075 WASHER, 1/2" USS 1 27 6000463 SPACER,1" X 3.125" 1
13 6000305-Y FOOT PEDAL 1 28 6000105 SPACER, 3/4" X 1.250 2
14 6000324 BUSHING 2 29 6002415-C WHEEL (incl bushings) 2
15 6000370 HEX BOLT, 3/8-16 X 3-1/2" 2 - 6000809 KIT, 3/4" WHEEL BUSHINGS -
7
Repair Parts

10
Notes

[phone]
MODEL # CC-3040PS
[phone]
Designed And Tested In Columbus, Ohio
Manufactured In The U.S.A. From Domestic
And Imported Components
