Cub VS-95A043 Installation and operating instructions

b


VS-95A043
For Passenger Cars
Blind Spot Detection I Lane Change Alert

1
1. Precautions ......................................................................................................... 2
2. Introduction ........................................................................................................ 5
2.1 System block ................................................................................................................ 5
2.2 Product specications ......................................................................................... 5
3. Installation Guide .................................................................................... 6
3.1 Installation diagram ............................................................................................... 6
3.2 Package contents ................................................................................................... 6
3.3 Installation steps ....................................................................................................... 7
3.4 Reinstallation ............................................................................................................... 9
4. User Manual ....................................................................................................... 10
4.1 System startup and shut o󰀨 .......................................................................... 10
4.1.1 System startup ........................................................................................................... 10
4.1.2 System shut o󰀨 .......................................................................................................... 10
4.2 Function ............................................................................................................................. 10
4.2.1 Detection zone ........................................................................................................... 11
4.2.2 Blind Spot Detection (BSD) .......................................................................... 11
4.2.3 Lane Change Alert (LCA) ..................................................................... 11
4.3 System abnormalities .......................................................................................... 12
4.3.1 Malfunction prompts ............................................................................................. 12
4.3.2 Troubleshooting ........................................................................................................ 12
Contents

2
1Blind Spot Detection System
Precautions
Before using this device, please read this instruction
manual carefully before installing or removing it to
ensure that the device is safe to use. The Company
shall not be liable for any damage arising from failure
to comply with the following matters.
Before installing
If you wish to laminate your car’s rear windshield with or it has
already laminated with a heat insulation film, please contact the
dealer to ensure that the heat insulation film does not technically
contain metal components. If it contains the metal components, it is
recommended not to install this device.
If your car has the following conditions, please consult a professional
technician to evaluate whether or not to install this device：
• If the angle between the rear windshield and the horizon is not
within 20 - 60 degrees, it is recommended not to install this device.
• If the third brake light is on top of the interior rear windshield, it
may a󰀨ect the radar installation position.
• If there is a rear spoiler, rear spare tire, or a bicycle, it may block
the radar and a󰀨ect the system performance.
Due to the highly sensitive detection performance of this device,
please ensure to follow the installation procedures and precautions
during installation to avoid affecting the device performance, and
please ensure to hide the wires properly according to the layout of
the car to avoid the wiring harness from a󰀨ecting driving safety, and
obstructing you from getting in and o󰀨 the car. It is recommended that
you consult a professional technician for installation.
Please follow the preparatory works before installation：
Please wear protective
goggles.
Please work with an
assistant.
Please tighten with
a specified torque.
wrench
(1)
(2)
(3)
(4)

3
If the connector is
dislocated, please
replace the connector
to its original position.
Please do not pull the
connector apart by
pulling the harness.
Please do not pull
the harness by force.
Connect the connector
and terminal tightly.
Cut o󰀨 the excessive
length of the cable tie.
RF Standard
(1)
(2)
NCC low-power radio waves radiated device management methods：
Companies, stores, or users are prohibited from changing
the frequency, increasing the power, or modifying the
characteristics and functions of the original design of the
certified low-power radio waves radiated device without
permission.
The use of low-power RF devices must not affect the
safety of aviation and interfere with legal communications.
If any interference occurs, they should be stopped
immediately and improved to the extent of no interference
before users can use the legal communications mentioned
in the previous paragraph, i.e., radio communications
under the provisions of the Telecommunications Act. Low-
power RF devices must endure interference from legal
communications or industrial, scientic, and medical radio
wave-radiated electrical equipment.
Article 12:
Article 14:
FCC regulations：
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including
interference that may cause undesired operation.

4
NOTE : This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o󰀨 and on,
the user is encouraged to try to correct the interference by one or more
of the following measures :
━Reorient or relocate the receiving antenna.
━Increase the separation between the equipment and receiver.
━Connect the equipment into an outlet on a circuit di󰀨erent from that to
which the receiver is connected.
━Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user΄s authority to operate the
equipment.
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 cm between the radiator and a
human body.
Although the device provides blind spot detection assistance
warning function, it might still be affected by multiple factors
such as road conditions, driver behaviors, driving environment
or weather which may result in occasional false alarm/no alarm.
Therefore, the device does not guarantee 100 % detection accuracy
rate. Do not over-rely on the device for avoidance of accidents, and
you shall at all times follow the traffic rules, pay attention to the
actual road conditions, stay alert, drive carefully.

5
2Introduction
Blind Spot Detection System
Thank you for purchasing this device. The device uses a 77 GHz
millimeter-wave radar to detect vehicles coming behind your car. When
there is a car getting in the detection zone, the device will provide visual
and audible warnings to remind you to pay attention to the car in order to
protect the safety of the driver and passengers. If you have any problems
while using it, please contact your dealer.
Radar frequency 76-77 GHz
Operating temperature -40℃~ +85℃
Storage temperature -40℃~ +95℃
Input voltage 9~16 V
Current consumption 6 W (Max.)
Left turn signal wiring
Right turn signal wiring
Cigarette lighter plug
Left indicator
Right indicator
Buzzer
2-1 system block
2-2 Product Specifications

6
3
No. Item Q'ty
Radar with its bracket 1 set
Indicator 2 pcs
Buzzer 1 pcs
Main power harness 1 set
Accessories
(including 2 iron plates, 2 indicator adhesive
tapes, 15 cable ties, 4 crab clips, 1 manual)
1 bag
Blind Spot Detection System
Left turn signal
Radar
Right turn signal
Cigarette lighter plug
/ IGN WIRING
Left indicator
Right indicator
Buzzer
3-1 Installation diagram
3-2 Package contents
Installation Guide

7
3-3 Installation steps
Note: Please ensure that the heat insulation lm on the rear windshield
does not contain metal components.
Please prepare a tape measure, a multimeter and an alcohol pad before
installing.
1
10cm10cm
Radar installation position diagram
Center of rear windshield
Radar
Find a position ±10 cm at the center of the rear windshield's upper edge
with a tape measure, and wipe it with an alcohol pad.
Note 1:
There must not be any no-original object such as driving recorder,
brake light and other devices within 5 cm left and right of the radar.
If the third brake light is located at the center of the rear
windshield's upper edge, it is recommended to install the radar
beneath it with the distance at least 2 cm.
Note 2:
2
Tear off the tape on the radar's bracket, face the surface printed with
the logo Cub outwards, and attach the bracket parallel and close to the
ceiling or align along the defog line. Be careful not to attach it to the
defog line.
3
Flip down radar's level, adjust the bracket until the bubble in the level is
at the center of the two vertical black lines, and then tighten the knob.

8
4
5
6
After connecting the radar and main power harness, hide the wires along
with the ceiling to the C-pillar on the driver side, and connect the left
and right turn signal wirings to the car's left and right turn signal trigger
wires(+) with crab clips.
Note: Please ensure the positive
electrode of the left and right
turn signals by a multimeter.
Note: If the turn signals are
not connected, the system will
alarm by illuminating indicators
only.
Continue to hide the main power harness along with the ceiling or down
the door frame's waterproof strip to the driver side's A-pillar, connect the
indicators and buzzer, and hide the two wire harnesses into the door
rubber strip.
If there is a risk of airbags'interference when hiding harness, please hide
harness down the door frame's waterproof strip to the driver side' s A-pillar.
Attach the left indicators directly to the A-pillar at an appropriate visible
height, or attach it to an iron plate, insert it between the A-pillar and the
instrument panel, and then adjust the best viewing angle. Attach the
alarm buzzer at a position near the instrument panel.
Note: If the surface of the
A-pillar has a velvet cover, the
indicators will be unable to x
firmly. It is recommended to
install it with an iron plate.

9
9
7
8
3-4 Reinstallation
Right indicator goes to right side A-pillar through the left side A-pillar and
then the ceiling. The installation height and method is the same with the
left one.
Please ensure to hide all the wires properly into the trims and frame's
waterproof strips to avoid the wiring harness from a󰀨ecting driving safety,
and obstructing you from getting in and o󰀨 the car. Besides please hide
the splitter into the trim under the instrument panel properly and use
cable ties to x with the car cables.
Plug into Cigarette lighter and hide the remaining wires properly. When
ACC ON, the indicators will light up for 3 seconds, and the buzzer will
chime once, indicating that the system has started normally.
If the bracket is incidentally attached wrongly, such as not at the center
of the rear windshield, not close to the upper edge of the rear windshield,
or not maintained at a horizontal level, etc., and you wish to remove
and reattach, spray alcohol around the bracket base in contact with
rear windshield. Then use a thin line such as a shing line to scrape the
edges of the bottom back and forth.

10
4Blind Spot Detection System
User Manual
4-1 System startup and shut off
4-2 Function
4.1.1 System startup
When ACC is ON, the indicator will illuminate for 3 seconds, and the
buzzer will chime once, indicating that the system starts normally.
The system self-tests within 10 seconds after power-on, and using
the turn signals or hazard warning lights in this period time would
lead to the indicators flashing, which means the system reads the
turn signals correctly. However, if the turn signals are not connected,
no response resulted.
4.1.2 System shut o󰀨
When you park the car and stop the ignition, the system will shut o󰀨.
Note:
When your speed achieves 5 km/h(3 mph), Blind Spot Detection(BSD)
and Lane Change Alert(LCA) functions will be activated. The radar will
detect the vehicle entering the detection zone with a relative speed less
than 40 km/h(25 mph), and the system will provide visual and audible
warnings to remind you to pay attention to driving safety until the vehicle
is not in the detection zone, if it meets other warning requirements.
(1)
(2)
(3)
(4)
If the vehicle is overtaking at a close distance from behind, or the
vehicle, with body length less than 4 m, coming from behind and
entering the second lane from the third lane, the device may fail to
provide a correct warning.
If the vehicle traveling from behind is driving at the similar speed with
your vehicle(relative speed below 5 km/h(3 mph)) and continuously
driving in the detection zone for a period of time, or your car starts
from a standstill and accelerates, and the vehicle initially staying
in the detection zone is also starting from a standstill and keep
staying in the detection zone, the device may fail to provide a correct
warning.
If a motorcycle rides too close(1 m or 3.2 feet) to your vehicle, the
device may fail to provide a correct warning.
If the motorcycle is ridding too close to the vehicle which is travelling
behind your vehicle at a close distance and therefore obstructed by
such vehicle, or if there is any vehicle behind your vehicle while your
vehicle is turning, the device may fail to provide a correct warning.
Note：

11
4.2.1 Detection zone
4.2.2 Blind Spot Detection (BSD)
When a vehicle approaches your car from behind and enters the
detection zone, extending rearward from the radar to approximately 7 m,
the corresponding indicator will illuminate.
If the corresponding turn signal is ON, the system not only light
up the indicator, but also sound an audible alert.
Note: If the turn signals are not connected, the system will alarm by
illuminating indicators only.
BSD
BSD
7m
7m
LCA 20m
LCA 20m
When a vehicle approaches your car from behind, if it enters the detection
zone, extending rearward from the radar to approximately 20 m, and
the collision time with your car is within 2 seconds, the corresponding
indicator will illuminate.
4.2.3 Lane Change Alert(LCA)
7m
BSD
LCA 20m

12
4.3.1 Malfunction prompts
If the system malfunctions, the buzzer will sound an audible alert for 3
seconds for every 10 minutes. and the two indicators will light up until the
system returns to normal.
4.3.2 Troubleshooting
When a malfunction occurs, please contact the dealer as soon as
possible or go to the service for repair. Shown below are some simple
troubleshooting methods for reference
4-3 System abnormalities
LCA 20m
Item Abnormal
Status Possible Causes Possible solution
Power-on
self-test
Not response after
ACC ON
Power
abnormality
Please check if pressing
the button on the
cigarette lighter plug or
there is poor connect.
If there is a breakage,
please contact the dealer.
If there is no abnormality,
please recheck the wire
harness
Wire harness
abnormality
Please check if the wire
harness is damaged or
there is a poor connect or
not. If there is a breakage,
please contact the dealer.
If there is no abnormality,
please recheck the power
supply
If the corresponding turn signal is ON, the system not only light
up the indicator, but also sound an audible alert.
Note: If the turn signals are not connected, the system will alarm by
illuminating indicators only.

13
Item Abnormal
Status Possible Causes Possible solution
power on
self -
inspection
The indicator
does not light
up.
Damaged
connector or
poor contact
Re-plug the connector
and check if the indicator
can light up or not. If
it still does not light
up, please contact the
dealer
No sound.
Damaged
connector or
poor contact
Re-plug the connector
and check if the buzzer
can sound or not. If it still
does not sound, contact
your dealer
System
The indicator
lights up
continuously,
and there is an
audible alert
Radar
abnormality Contact your dealer
Functions
The indicator
does not light up
It does not
meet the
warning
requirement
Please ensure that the
alarm has met the alarm
condition. If there is no
warning when the alarm
condition is met, please
contact the dealer
No second-level
warning
No turn
signals
Please connect the turn
signals correctly
It does not
meet the
warning
requirement
If there is no alarm when
the warning requirement
is met, please contact
the dealer
The buzzer
connector
is damaged
or there is a
poor connect
Re-plug the connector
to check if the buzzer
can sound, or ensure If
the warning requirement
is met. If the buzzer still
does not sound, contact
your dealer
Other
When the engine
stalls, the light
on the Cigarette
lighter plug is
still on
Cigarette
lighter
supplies
uninterrupted
power
Press the button on the
cigarette lighter plug
to turn o󰀨 the system
or unplug the cigarette
lighter plug, or please
consult a professional
technician to install this
product changing to IGN
power supply

14

www.cubelec.com.tw
E-mail: [email protected]
Address : NO.6, LANE 546, SEC.6, changlu RD., fuhsin
township, changhua county 50648, taiwan(R.O.C.)
