Culligan Good Water Machine User manual

Culligan®
Good Water
Machine®
Drinking
Water
System
Owners
Guide

NOTICE: Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after the system.
For installations in Massachusetts, Massachusetts Plumbing Code 248 CMR
shall be adhered to. Consult your licensed plumber for installation of this
system. The use of piercing valves is not permitted in Massachusetts.
Check with your public works department for applicable local plumbing and sanitation
codes. Follow your local codes if they differ from the standards used in this manual.
Operational, maintenance and replacement requirements are essential for this product
to perform properly. The Good Water Machine®contains replaceable particulate and
activated carbon filters. It also includes a replaceable reverse osmosis membrane filter which
is critical for the effective reduction of Total Dissolved Solids. The filtered water should be
tested periodically to verify that the system is performing properly.
Culligan International Company
9399 W. Higgins Road, Suite 1100
Rosemont, Illinois USA 60018
847/430-2800
www.culligan.com
Products manufactured and marketed by Culligan International Company (Culligan) and its affiliates are protected
by patents issued or pending in the United States and other countries. Culligan reserves the right to change the
specifications referred to in this literature at any time, without prior notice. Culligan, Good Water Machine, Aqua
Cleer, Culligan Man and www.culligan.com are trademarks of Culligan International Company or its affiliates.
i

Safety/Warnings ..........................................ii
System Specifications .....................................2
Introduction
About Your System ...................................3
Component Description...............................3
Certified Performance.................................4
How to Use Your System ..............................5
Performance Check ...................................5
Installation
Application Guidelines ................................6
Servicing Your System
Service Schedule......................................8
Filter Replacement ....................................8
Parts List..............................................12
Service Log ...............................................13
Performance Data Sheet...................................14
California Certificates......................................18
Warranty..................................................21
Table of
Contents
1

System
Specifications
Dimensions - Filter Assembly .............7.5”W x 3”D x 16.5”H
- Storage Tank - Std ..........9” Diameter x 14”H
- Medium ....................11” Diameter x 14”H
- Large .......................15.5” Diameter x 24”H
Storage Capacity - Standard Tank ..............2 gallons
- Medium Tank ...............3 gallons
- Large Tank..................9 gallons
System Flow Sequence ........................Particle Filter, Activated Carbon Filter,
..............................Reverse Osmosis Membrane Filter, Storage
Tank,
..............................Polishing Filter, Dispensing Faucet
Particle Filter ..............................5 Micron Spun Polypropylene
Activated Carbon Filter ........................Solid Carbon Block
Reverse Osmosis Membrane Filter .............Culligan Aqua-Cleer®Thin Film Composite
Polishing Filter ..............................Cullar G Activated Carbon
Dispensing Faucet. . . . . . . . . . . . . . . . . . . . . . . . . . . . .Culligan Aqua-Cleer Faucet Rotary Operation,
Stainless Steel and Resin Flow Passages, with
Built-in Siphon Break
Colors ..................................... Polished Chrome or White
Model 2 Gallon 3 Gallon 9 Gallon
System DPR* to Storage
Tank 14.5 (54.88 L) 14.5 (54.88 L) 14.5 (54.88 L)
Efficiency Rating3 17.9% 17.9% 17.9%
Recovery Rating4 30.8% 30.8% 30.8%
* DPR - Daily Production Rate
Product Production Rate without storage tank to atmosphere1
- AC-30 Models...............30 gpd (114 L/day)
Ratio of Product to Flush Flow2
Soft Water Applications ......2:3
Hard Water Applications......1:3 - 1:5
1 Rating at 50 psi, 77°F, 500 mg/L TDS Influent, Without Storage Tank to atmosphere. This is a factory
specification for membrane production. Actual production rate and TDS rejection will depend on temperature,
water pressure, TDS level, membrane variation and usage pattern.
2 May vary with pressure. See Technical Manual for all hard water applications and applications where TDS
exceeds 1000 mg/L (ppm).
3 Efficiency rating means the percentage of the influent water to the system that is available to the user as reverse
osmosis treated water under operating conditions that approximate typical daily usage.
4 Recovery rating means the percentage of the influent water to the membrane portion of the system that is
available to the user as reverse osmosis treated water when the system is operated without a storage tank or
when the storage tank is bypassed.
2

Thank you for choosing a Culligan Good Water Machine®drinking water system. Your
new system is designed to bring you years of deliciously crystal-clear Culligan®water. With
its special faucet installed on your sink, it’s like getting bottled water straight from your
kitchen tap.
With three separate filter technologies and its unique space-saving design, the Good Water
Machine is the most advanced drinking water system available today from Culligan.
About Your System
The reverse osmosis method of water treatment has long been regarded as one of the most
efficient and effective ways to reduce impurities. It’s the technology we’ve used to build your
new Culligan Good Water Machine. In addition, we’ve incorporated activated carbon and
fine particle filtration to bring you one of the most effective systems available today.
Good Water Machine System Components
Refer to Figure 1, page 7
Particle Filter
The particle filter reduces dirt, sand, rust, and other microscopic particles 15 times smaller
than a grain of sand.
Activated Carbon Filter
The activated carbon filter reduces elements that cause water to taste and smell unpleasant,
including the taste and odor of chlorine, if present in your untreated water supply.
Reverse Osmosis Membrane Filter
The reverse osmosis (RO) membrane filter reduces dissolved substances, including radium,
lead, and many others. These substances may not be in your water. See Performance Data
Sheet for list of substances and removal percentages.
Manifold Assembly
The manifold serves as the functional hub of the system, directing and regulating the flow
through each of the system’s components. It makes the Good Water Machine extremely
space efficient and simplifies filter changes.
Storage Tank
The storage tank holds up to 2 gallons of triple-filtered Culligan water under pressure for
rapid delivery. Optional three and nine-gallon tanks are available.
Polishing Filter
The Good Water Machine includes a second activated carbon filter as added assurance
that your water will be crystal clear.
Introduction
3

Introduction
(cont.)
Faucet
The special drinking water faucet mounts conveniently on your kitchen sink. A simple twist of
the handle is all it takes to enjoy refreshing Culligan drinking water.
Certified Performance
The Culligan Good Water Machine Model AC-30, AC-30M, AC-30L, AC-30 Plus,
AC-30M Plus and AC-30L Plus Drinking Water Systems have been tested and
certified by WQA to NSF/ANSI 372, and CSA B483.1, and NSF/ANSI Standard 58
for the effective reduction of TDS, Barium, Cadmium, Hexavalent and Trivalent
Chromium, Lead, Radium 226/228, Copper and Selenium as verified and
substantiated by test data.
Average removal percentages are as follows:
AC-30 (M,L) & AC-30 Plus (M,L)
Barium..............97.90% Radium 226/228 ................... 80.00%
Cadmium ...........99.20% Selenium ............................ 97.50%
Chromium III ........96.70% TDS/Sodium Chloride... ............... 87.3% (2 Gallon Tank)
Chromium VI........88.50% ..................................... 87.3% (3 Gallon Tank)
Copper .............95.30% ...................................... 87.3% (9 Gallon Tank)
Lead ...............98.40%
The substances removed by this system are not necessarily in your untreated water. See
Performance Data Sheet for exact percentages of contaminant removal.
4

     
       
       
      
     

     
 
       
    
       
 
  
    
      
How To Use Your System
With the Good Water Machine, you’ll get a continuous supply of clear, refreshing water for
drinking and cooking. But Culligan improves a lot more than just water. Crystal clear Culligan
water is ideal for:
•coffee •recipes •pasta
•tea •baby formula •ice cubes
•soup •house plants •steam irons
•juice •pets •drink mixes
•everything you make with water
Performance Check
This system contains a replaceable treatment component, critical for the effective reduction of
Total Dissolved Solids, and that product water shall be tested periodically to verify that the
system is performing properly.
“This reverse osmosis treatment system contains a replaceable component critical to the
efficiency of the system. Replacement of the reverse osmosis component should be with one
of identical specification, as defined by the manufacturer, to assure the same efficiency and
contaminant reduction performance.”
To check the performance of your Good Water Machine, it is necessary to measure the total
dissolved solids (TDS) level of the filtered water. This simple test can be done quickly by your
dealer.
The Good Water Sentry™Water Quality Monitor is another way to keep track of your
system’s performance. This optional accessory checks your drinking water each time you
use the special faucet, and signals when the membrane filter may need to be replaced.
AC-30 Plus, AC-30L Plus, and AC-30M Plus come with the Good Sentry Water Quality
Monitor.
The Good Water Machine® Models are supplied with a nitrate test kit. Product water must
be tested frequently according to the instructions provided with the kit.
If the water quality of your system seems to have declined, drain the storage tank and allow
the system to refill. If the problem persists, call your Culligan Man™ for service.
Suggested Installation Equipment
Tools
Sink Cutting Tools
•Screwdriver, blade and Phillips (#1)
•Porcelain Cutter Kit, 1-1/4 inch diameter,
PN 00591625 •1/8 inch diameter pilot drill for #10 screws
•Greenlee Hole Punch, 1-1/4 inch diameter •Center Punch
•Plumbers Putty •Razor Blade Knife
•Heavy Duty Drill with speed control to •Faucet Installation Tool, PN 00-4033-75
400 rpm •Aqua-Cleer HSeries or “System” series
filter housing
Introduction
(cont.)
5

           
       
        
Installation This Owner’s Guide provides visual assembly reference only. Since specialized skills are
required in the assembly of the drinking water system, we recommend that you contact your
local independently operated Culligan dealer to complete this installation.
Please refer to the Aqua-Cleer/Good Water Machine Drinking Water Systems Technical
Manual (01018587) for installation guidelines on the following topics:
•Faucet Installation •Flushing Procedure for Pre-Filters
•Storage Tank Settings •Post Installation Performance Measurements
Application Guidelines
The Good Water Machine is designed for use on potable water supplies meeting the
guidelines outlined in Table 1. The system should be installed on your home’s cold water
line. The flushing stream should discharge through an approved siphon break as illustrated
in Figure 1. Installation of this system must comply with state and local laws and regulations.
The Good Water Machine may also be used to provide crystal-clear Culligan water to
other drinking water using appliances such as an icemaker or refrigerator. Installing the
unit to supply filtered water to other appliances may be complicated and require additional
components for proper use. We again recommend that you contact your local independently
operated Culligan dealer to complete this type of installation. Use of the Good Water
Machine with these and other appliances must follow the guidelines set forth in the Aqua-
Cleer/Good Water Machine Drinking Water Systems Technical Manual ( 01018587).
Installations that do not follow these guidelines run the risk of working improperly or even
causing damage to the appliances.
Table 1 – Influent Water Characteristic
Pressure 40 - 120 psi (280 - 827 kPa)
Temperature 33 - 100°F (1 - 38°C)
Total Dissolved Solids (TDS)1 0 - 2500 ppm ( 0 - 2500 mg/L)
pH 5 - 10
Chlorine2 0 - 3 ppm ( 0 - 3 mg/L)
Chloramine 0 - 3 ppm ( 0 - 3 mg/L)
Turbidity 0 - 10 NTU
Hardness3 0 - 10 gpg
Iron 0 - 1 ppm (0 - 1 mg/L)
Bacterial Quality Potable
1 See the Technical Manual for all applications where TDS exceeds 1000 ppm (1000
mg/L). A booster pump is strongly recommended.
2 The reverse osmosis membrane filter used in this system may be damaged by chlorine.
This system includes activated carbon which protects this element by reducing chlorine.
Influent chlorine should not exceed 3 mg/L.
3 A softener is strongly recommended for water over 10 gpg.
6

The exact placement of the components will vary by installation. Although shown beneath a Installation
sink, it may be installed in a basement, crawl space, or in an adjacent cabinet. Regardless of
where the system is installed, the flow sequence described by (Figure 1) must be observed.
The Aqua-Cleer®/Good Water Machine®drinking water system is designed to be mounted
near a sink for easy access to cold water and drain lines. Lengths of 1/4-inch and 3/8-
inch OD plastic tubing will be required to make this installation. A length of Culligan®drain
tubing is required to install the air gap siphon break.
Evaluate the installation site to determine the easiest path for the plumbing to follow. Take
care to make the installation as neat as possible.
Aqua-Cleer
Faucet
Monitor
Sensor Drain
Cold Water
Supply
Tubing From Faucet
Air Gap - 3/8” Tubing
Monitor Feed Line
Post 1/4" Tubing
Filter 1/4" Tubing
to Faucet
3/8" Tubing Air Gap AC-30
to Faucet Manifold
Product
Port
Ball Valve
3/8" Tubing to Faucet Product Port
Tank
Figure 1
Notice: Install the drain line so that it runs downward with no loops or low spots.
Otherwise the unit will overflow at the air gap siphon break built into the faucet, or make
irritating gurgling sounds. The concentrate line that leads to the faucet should be installed
in a straight vertical path to avoid making a gurgling noise. 7

  
   
  
   
 
 
Servicing
Your System
Service Schedule
When properly maintained, your Good Water Machine will give you years of dependable
service. Use the following as a guide to get the most out of your system. Service frequency
may vary depending on your local water conditions. High sediment, chlorine, turbidity, or
hardness levels may require more frequent service. Refer to Figures 3 & 4.
At Least Once Per Year
Replace:
•Particle Filter (1)
•Activated Carbon Filter (2)
•Polishing Filter (4)
Check:
•RO Membrane Filter (3)
- TDS Reduction Performance
- Flow Rates
•Capillary Assembly
Sanitize the System.
Use the convenient chart inside the back cover of this booklet to keep track of your system’s
maintenance.
Filter Replacement
Culligan recommends that you have your Good Water Machine serviced by your local
Culligan Man. You can rely on his or her experience and expertise to keep your system in
top operating condition.
If you wish to service your system, the filters are available from your Culligan dealer.
For replacement components, or to measure the Total Dissolved Solid (TDS) Reduction
Performance please contact your local Culligan Dealer or 1-800-CULLIGAN (1-800-285-
5442) for the dealer near you. See the Parts List at the end of this section for replacement
numbers.
Cartridge Conditioning
The activated carbon, reverse osmosis, polishing filter, and particle filter cartridges must be
conditioned as follows prior to installation into the Good Water Machine. Your Culligan Man can
do these important procedures at the time of purchase.
Activated Carbon Cartridge—10-minute flush to remove carbon dust
RO Membrane Filter—Minimum 24-hour flush to remove preservative solution
Polishing Filter—2-gallon flush to remove carbon dust
Particle Filter—10-minute flush
8

   
   
Tubing Connectors
The Good Water Machine features easy-to-use push-in
tubing connectors (Fig. 2) on the manifold assembly
and the polishing filter.
To disconnect the connector, hold the collar against
the fitting body and pull the tube from the fitting.
To assemble lubricate the tubing end with water and
push the tubing into the connector until it bottoms out.
Be sure the tubing is smooth and free of abrasions,
otherwise a leak may result. Figure 2
Figure 3
Flow
Fittings
Figure 4
Filter Replacement and Sanitizing Procedure
Use the following procedure and the reference in Figure 3 when servicing the Good Water
Machine.
Notice: Cleanliness is essential in the filter replacement procedure. Be sure to wash
your hands thoroughly before handling filters. The use of protective gloves is strongly
recommended.
Servicing
Your System
(cont.)
Materials:
Pre-flushed activated carbon cartridge and polishing filter cartridge
Particle filter
Household (5.25%) bleach—hydrogen peroxide is not recommended
Clean 1-gallon plastic container with cap
100-ml graduated cylinder
Plastic pan to hold manifold assembly
Tubing connector, 3/8” tube x 3/8” tube
Flat-blade and #2 Phillips screwdrivers
Paper towels
Disposable plastic gloves (like those used in the food service industry)
9

    
               
          
Servicing
Your System
(cont.)
Preparation
1. Locate the system’s supply valve and turn off the system’s water supply.
2. Using the graduated cylinder, add 5 ml (about 1 teaspoon) of bleach to the 1-gallon
container. Open the dispenser faucet and fill with one gallon of product water. If there
is not enough RO water, fill the container the rest of the way with soft water. Cap the
container and shake to mix.
Notice: If any RO water remains after filling the container, you may want to fill a
pitcher with the drinking water as it will take several hours for the system to refill after
servicing. In any case, leave the faucet open until the storage tank is empty and then,
close the faucet.
3. Remove the polishing filter (Fig. 4) and discard. Connect the tubing ends together with
the tubing connector.
4. Lift the filter assembly from the mounting bracket and place it in the plastic pan to catch
any dripping water.
5. Using the flat-blade screwdriver, pull the u-clips from all three housings. Insert the u-clip
into the two square holes at the bottom rear of the manifold and push up to release the
filter housings. Remove the housings with a downward twisting pull.
6. Remove the particle filter cartridge and the activated carbon cartridge and discard. If the
RO membrane filter will be reused, clean the outside with a wet paper towel and place
the membrane filter in a clean, unused plastic bag.
7. Wet some paper towels with the diluted bleach solution. Clean the inside of the housings
and the underside of the manifold with the paper towels.
Sanitizing the Storage Tank and Faucet
1. Add 15 ml (about one tablespoon) of bleach to the particle filter housing (#1, Figure 3).
Replace all three housings on the manifold and insert the u-clips.
Notice: The weight of the storage tank will increase by 8 to 16 pounds. Turn off the
water supply valve.
2. Turn on the supply valve and fill the storage tank with 1 to 2 gallons of water.
3. Wait ten minutes before opening the faucet and draining the storage tank. Do not rinse
any remaining solution from the tank.
Notice: During this time, proceed to the “Sanitizing the Manifold Assembly” section.
Wait to do step 4 until indicated.
4. Remove the temporary tubing connector and replace it with a new polishing filter. Make
sure the flow arrow on the polishing filter points to the faucet (Figure 4).
10

  
    
              
              
            
            
          
Sanitizing the Manifold Assembly
1. Using the flat-blade screwdriver, pull the u-clips from all three housings. Insert the u-clip
into the two square holes at the bottom rear of the manifold and push up to release the
filter housings. Remove the housings with a downward twisting pull. Discard any solution
remaining in the housings.
2. Open the particle filter cartridge bag half way, being careful not to touch the filter
element. Lubricate the particle filter cartridge o-rings with water and insert the cartridge
into position #1 in the manifold.
3. Fill housing #1 about 2/3 full of the diluted bleach solution from the 1-gallon container.
Assemble the housing to the manifold and replace the u-clip.
4. Repeat steps 2and 3for housing #2 (activated carbon cartridge) and housing #3 (RO
membrane filter).
Notice: For RO membrane filters that have a single open-end, pour diluted bleach
solution into the center tube.
Caution! The solution should remain in contact with the RO membrane filter
for at least five (5) but no longer than ten (10) minutes. Longer contact time
will shorten the life of the membrane.
Notice: While waiting for the filters to be sanitized, complete step 4of the
“Sanitizing the Storage Tank and Faucet” section. Then complete step 5below.
5. Using the #2 Phillips screwdriver, loosen the capillary assembly retaining screws, then
twist and remove the assembly. Inspect the tubing for plugging and kinks and replace
the tubing as needed. Reinstall the capillary assembly, but leave the screws 1/4 turn
loose.
6. In this step, you will need to observe water flowing to the drain. If the drain flow is not
visible with the current tubing connections, install a temporary drain tube in the waste
port of the manifold. Turn on the supply valve. When water is seen flowing to the drain,
carefully loosen the capillary tube assembly retaining screws until the flow to the drain
increases.
Notice: When the assembly is about 3/16” out of the manifold, the o-ring seal for
the capillary tube is bypassed, but there should be no external leaks.
Servicing
Your System
(cont.)
7. Rinse the manifold assembly for five minutes or until no chlorine is detected in the water
passing to the drain. Tighten the capillary assembly retaining screws.
8. Check the performance of the system according to the procedure outlined in the
“Performance and Technical Information” section of this manual. Replace the RO
membrane if necessary.
9. Instruct the customer to discard the first glassful of water from the system to flush out any
residual chlorine that might remain in the polishing filter tubing and faucet. The polishing
filter will remove any chlorine remaining in the storage tank.
10. Record your service on the chart at the end of the Owner’s Guide.
11

Parts List
2
10
96
8
11
7
4
1
5
3
Item Description Part Number
1 Mounting Bracket 01-0040-81
2 Faucet - Chrome 01-0184-01
Faucet - White 01-0184-02
Faucet - Chrome w/ Light 01-0184-68
Faucet - White w/ Light 01-0184-69
3 Polishing Filter 01-0042-91
4 Plastic Ball Valve 01-0045-50
5 Storage Tank - Std. 01-0050-95
Storage Tank - Medium 01-0047-76
Storage Tank - Large 01-0047-65
6 Screw,#10.9x.625”PanHeadPhil. 00-4010-16
7 Particle Filter Element 00-4015-38
8 Capillary Assembly 01-0090-25
9 Reverse Osmosis Membrane Element AC-30 Non-Nitrate 01-0074-02 or
01-0167-31
10 Drain Adapter 01-0040-80
11 Activated Carbon Element 01-0125-80
* Icemaker Tee -3/8 x 3/8 x 1/4 01-0047-28
* Tubing, Blue - 1/4” O.D. 00-4021-84
* Tubing, Blue - 3/8” O.D. 01-0002-87
* Good Water Sentry Monitor 01-0047-12
* Aqua-Cleer Booster Pump 01-0093-34
* Not Illustrated
12

Model Serial No.
Date Installed
For Service Call Culligan At: (_______)
Date Serviced Filter(s) Changed Sanitized
Particulate Filter Activated Carbon
Filter
RO Membrane
Filter Polishing Filter
Culligan®
Good Water
Machine®
Service Log
13

     
    
    
    
       
   
             
            
 
  
  

             
            
               
Performance
Data Sheet
Important Notice: Read this Performance Data Sheet and compare the capabilities of the unit with
your actual water treatment needs. Culligan recommends that you have your water supply tested to
determine these needs before purchasing a water treatment unit.
Culligan knows the more informed you are about your water treatment systems, the more confident
you will be about its performance. It’s because of this and more than seventy years of commitment to
customer satisfaction that Culligan is providing this Performance Data Sheet to its customers.
Manufacturer: Culligan International Company,
9399 W. Higgins Rd, Suite 1100, Rosemont, IL 60018 USA
[phone]
Product: Culligan Good Water Machine Reverse Osmosis Drinking Water System
MODELS: •AC-30 •AC-30 Plus
•AC-30M •AC-30M Plus
•AC-30L •AC-30L Plus
Use Guidelines
• Working Pressure: 40-120 psig (280-827 kPa)
• Do not allow exposure to temperatures below 33°F (1°C)
• Maximum operating temperature: 100°F (38°C)
• This system must be installed according to local plumbing codes on the cold water line.
• This system requires regular replacement of all filters to maintain proper operation. Depending
on usage and influent water quality, the carbon and particulate filters should be changed at least
annually and the reverse osmosis membrane should be replaced every 3-5 years. Varying chlorine,
sediment or TDS levels may affect replacement frequency.
MSRP
• Particulate Prefilter Element........................00-4015-38................................. 30.00
• Activated Carbon Prefilter Element .................01-0125-80................................. 40.00
• Activated Carbon Postfilter Element................01-0042-91................................. 20.00
• RO membrane .....................................01-0074-02................................. 95.00
• If water production decreases or anoticeable taste change occurs, contact your local Culligan
Dealer. A Culligan professional can determine if your drinking water system requires servicing.
Optional water quality monitors are also available to monitor the performance of the reverse
osmosis membrane.
• Caution! Do not use with water that is microbiologically unsafe or of unknown
quality without adequate disinfection before or after the system.
• The Good Water Sentry Water Quality Monitor is another way to keep track of your systems
performance. This optional accessory checks your drinking water each time you use the special
faucet, and signals when the membrane filter may need to be replaced.
14

These systems have been tested and certified by WQA according to NSF/
ANSI 372, and CSA B483.1, and NSF/ANSI Standard 58 for the reduction of the
substances listed below. The concentration of the indicated substances in
water entering the system was reduced to a concentration less than or equal
to the permissible limit for water leaving the system, as specified in NSF/ANSI
58.
Substance Removal1
Substance Influent
Challenge
Concentration
(mg/L)
Max.
Permissible
Product Water
Concentration
(mg/L)
Minimum
Percent
Removal
Average
Percent
Removal
Barium 10.0 +/- 10% 2.0 88.40% 97.90%
Cadmium 0.03 +/- 10% 0.005 92.20% 99.20%
Hexavalent Chromium 0.30 +/- 10% 0.1 83.00% 88.50%
Trivalent Chromium 0.30 +/- 10% 0.1 92.50% 96.70%
Chromium (Hexavalent
& Trivalent)
0.3 +/- 10% 0.05 (Hex.)
& 0.05 (Tri.)
Copper 3.00 +/- 10% 1.3 95.30% 95.30%
Lead 0.15 +/- 10% 0.010 93.50% 98.40%
Radium 226/2284 25 pCi/L +/- 10% 5 pCi/L 80.00% 80.00%
Selenium 0.10 +-/10% 0.05 93.90% 97.50%
1 While testing was performed under standard laboratory conditions, actual performance may vary depending on water
pressures, temperatures, and other substances which may be found in your water.
2 Based upon testing methods using Barium as a surrogate. All concentrations in pCi/L: Pico curies per liter.
Performance
Data Sheet
(cont.)
15


        
Performance
Data Sheet
(cont.)
Output (Total Dissolved Solids (TDS) Reduction and Output Production)1
Tank Size 2 Gallon 3 Gallon 9 Gallon
Product system daily prod. rate to pressurized storage tank 14.5 gpd (54.8 L) 14.5 gpd (54.8 L) 14.5 gpd (54.8 L)
Prod. rate w/o storage tank to atmosphere 30 gpd 30 gpd 30 gpd
Efficiency rating2 17.9% 17.9% 17.9%
Recovery rating3 30.8% 30.8% 30.8%
Influent challenge concentration (mg/L) 750 +/- 40 mg/L 750 +/- 40 mg/L 750 +/- 40 mg/L
Max. permissible product water concentration (mg/L) 187 187 187
Minimum percent removal 76.6% 76.6% 76.6%
Average percent removal 81.6% 81.6% 81.6%
1 This is a factory specification for membrane production. Actual production rate and TDS rejection will depend on temperature,
water pressure, TDS level, membrane variation and usage pattern.
2 Efficiency rating means the percentage of the influent water to the system that is available to the user as reverse osmosis treated
water under operating conditions that approximate typical daily usage.
3 Recovery rating means the percentage of the influent water to the membrane portion of the system that is available to the user
as reverse osmosis treated water when the system is operated without a storage tank or when the storage tank is bypassed.
Testing Conditions (Complete Systems)
Temperature: 77° F ± 2° F pH: 7.5 ± 0.5
Pressure: 50 psi Turbidity: < 1 NTU
This system has been tested and shown to operate at its calculated recovery rating under
standard test conditions.
Dimensions
Filter Assembly 7.5” W x 3” D x 16.5” H (20 cm W x 8 cm D x 42 cm H)
Storage Tank Standard 9” Diameter x 15” H (23 cm Diameter x 38 cm H)
Medium 11” Diameter x 15” H (28 cm Diameter x 38 cm H)
Large 15.5” Diameter x 22” H (40 cm Diameter x 56 cm H)
The Good Water Machine models listed above have been tested and
certified by WQA according to NSF/ANSI 372, and CSA B483.1, and NSF/ANSI
Standard 58 for the effective reduction of TDS, Barium, Cadmium, Hexavalent
and Trivalent Chromium, Lead, Radium 226/228, Copper and Selenium as
verified and substantiated by test data. The concentration of the indicated
substances in water entering the system was reduced to a concentration
less than or equal to the permissible limit for water leaving the system as
specified in NSF/ANSI 58.
Refer to your Installation and Operating Instructions and printed limited Warranties for
more specific product information. To avoid contamination from improper handling and
installation, your system should only be installed and serviced by your Culligan Man.
Performance will vary based on local water conditions. The substances reduced by this
system are not necessarily in your water.
16

Table 1 – Influent Water Characteristic
Pressure 40 - 120 psi (280 - 827 kPa)
Temperature 33 - 100°F (1 - 38°C)
Total Dissolved Solids (TDS)1 0 - 2500 ppm ( 0 - 2500 mg/L)
pH 5 - 10
Chlorine2 0 - 3 ppm ( 0 - 3 mg/L)
Chloramine 0 - 3 ppm ( 0 - 3 mg/L)
Turbidity 0 - 10 NTU
Hardness3 0 - 10 gpg
Iron 0 - 1 ppm (0 - 1 mg/L)
Bacterial Quality Potable
1 See the Technical Manual for all applications where TDS exceeds 1000 ppm (1000 mg/
L). A booster pump is strongly recommended.
2 The reverse osmosis membrane filter used in this system may be damaged by chlorine.
This system includes activated carbon which protects this element by reducing chlorine.
Influent chlorine should not exceed 3 mg/L.
3 A softener is strongly recommended for water over 10 gpg.
Application Guidelines
The Good Water Machine is designed for use on potable water supplies meeting the
guidelines outlined in Table 1. The system should be installed on your home’s cold water
line. The flushing stream should discharge through an approved siphon break as illustrated in
Figure 1. Installation of this system must comply with state and local laws and regulations.
Performance
Data Sheet
(cont.)
17

California
Certications
State of California
Department of Public Health
Water Treatment Device
Certificate Number
08- 1900
Date Issued: August 13, 2008
Trademark/Model Designation
Good Water Machine AC-30
Good Water Machine AC-30 PLUS
Replacement Elements: Particulate Prefilter: 00-4015-38
GAC Prefilter: 01-0125-80
RO Module: 01-0074-02 or 01-0167-31
GAC Postfilter: 01-0042-91
Manufacturer: Culligan International
The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section
116830 of the Health and Safety Code for the following health related contaminants:
Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants
None Barium
Cadmium
Chromium (hexavalent)
Chromium (trivalent)
Copper
Lead
Organic Contaminants Radium 226/228
None Selenium
Rated Service Capacity: n/a Rated Service Flow: 1.7 gpd
Do not use with water that is microbiologically unsafe or of unknown quality, without adequate disinfection
before or after the system.
18
