Current Solutions SoundCare Plus User manual

TENSPros
SoundCare™ Plus Pain Relief Device
Operating instructions
Medical device for pain treatment
based on ultrasound
www.currentsolutionsnow.com
INSTRUCTION MANUAL

TENSPros
2
Contents
1. FOREWORD…………………………………………………..…...3
2. SAFETY PRECAUTIONS…………………………………………...3
3. INDICATIONS AND CONTRAINDICATIONS…………………...6
4. PRESENTATION…………………………………………………....7
5. SET UP……………………………………………………………... 9
6. OPERATION……………………………………………………...12
7. MAINTENANCE……………..…………………………………...14
8. DIAGNOSTICS………………………………….………………..15
9. SPECIFICATIONS AND TECHNICAL DATA…………..……….. 16
10.STORAGE ………………………………………………………...17
11.AND DISPOSAL……………………...…………………………..18
12.STANDARDS AND REQUIREMENTS………….………………...18
13.GUIDANCE AND MAUFACTUER’S DECLARATION…….….....18
14.WARRANTY…………………………………………………….… 22
15.NORMALZED SYMBOLS……………………………..………….23
SoundCare™ Plus Pain Relief Device

TENSPros
1.
FOREWORD
1.1
General This manual has been written for the users of the ultrasound therapy
SoundCare™ Plus. It contains general information on the operation,
precautionary practices, and maintenance information. In order to
maximize use, efficiency, and the life of the system, please read this
manual thoroughly and become familiar with the controls, as well as the
accessories before operating the system.
This user manual is published by
. does not guarantee its contents and reserves the
right to improve and amend it at any time without prior notice .Amendments
will however be published in a new edition of this manual .
Current Solutions™, LLC
Current Solutions™, LLC
1.2
Therapy
possibilities
The ultrasound therapy SoundCare™ Plus is an apparatus featuring an
ultrasound therapy unit. Pain affects the quality and enjoyment of life,
especially for those who suffer chronic pain. SoundCare™ Plus is ultrasound
therapy device for the treatment of chronic and acute muscular pain.
1.3
Treatment
head
The ultrasound treatment heads for the SoundCare™ Plus are so-called multi-
frequency heads. This treatment head can now supply both 1 and 3MHz
ultrasound. The head has excellent beam characteristics, fully meeting
the requirements of the existing standards. The excellent beam characteristics,
ergonomic design and effective contact control of the multi-frequency
treatment heads make an optimal treatment possible. Standard accessories
2
include a ultrasound head with 5cm er that can work at 1MHz and 3MHz.
User can also choose to purchase ultrasound head with 1cm2 er that can
also work at 1MHz and 3MHz.
A
A
1.4
Finally
You have made a wise choice in selecting the SoundCare™ Plus. We are
confident that your unit will continue to give satisfaction over many years
of use. Nevertheless, if you have any queries or suggestions, please
contact your authorized distributor.
2.
SAFETY
PRECAUTIONS
2.1
PRECAUTION-
ARY
DEFINITIONS
The precautionary instructions found in this section and throughout this
manual are indicated by specific symbols. Understand these symbols and
their definitions before operating this equipment. The definition of these
symbols is as follows.
3
SoundCare™ Plus Pain Relief Device

TENSPros
Caution: Text with a “CAUTION” indicator will explain possible
safety infractions that could have the potential to cause minor to
moderate injury or damage to equipment.
Warning: Text with a “WARNING” indicator will explain possible
safety infractions that will potentially cause serious injury and
equipment damage.
Danger: Text with a “DANGER” indicator will explain possible
safety infractions that are imminently hazardous situations that
would result in death or serious injury.
2.2
CAUTION Caution:
Read, understand, and practice the precautionary and operating
instructions. Know the limitations and hazards associated with using
any ultrasound device. Observe the precautionary and operational
decals placed on the unit.
Keep yourself informed of the contraindications.
Never leave the patient unattended during treatment.
Do not operate the device when connected to any other medical
devices.
Do not operate this unit in an environment where other devices are
used that intentionally radiates electromagnetic energy in an
unshielded manner.
Ultrasound should be routinely checked before each use to determine
that all controls function normally, especially that the intensity control
does properly adjust the intensity of the ultrasonic power output in
stable manner. Also, determine that the treatment time control does
actually terminate ultrasonic power output when the timer reaches zero.
Do not use sharp objects such as pencil point or ballpoint pen to
operate the buttons on the control panel.
Before each use, inspect Ultrasound Applicator for cracks, which may
allow the ingress of conductive fluid.
Inspect Applicator cables and associated connectors before each use.
The ultrasound therapy controls unit is not designed to prevent the
ingress of water or liquids. Ingress of water of liquids could cause
malfunction of internal components of system and therefore create
risk of injury to the patient.
Caution should be used for patients with suspected or diagnosed
epilepsy.
Refer to recent surgical procedures when muscle contraction may
disrupt the healing process.
Do not use over the menstruating or pregnant uterus, and over areas
of the skin which lack normal sensation.
4
SoundCare™ Plus Pain Relief Device

TENSPros
SoundCare™ Plus should not be used on driving, operating machinery,
or during any activity in which in voluntary muscle contractions may put
the user at under risk of injury.
2.3
WARNING Warning
Care must be taken when operating this equipment around other
equipment. Potential electromagnetic or other interference could
occur to this or to the other equipment. Try to minimize this
interference by not using other equipment in conjunction with it.
The apparatus may not be used in close proximity (i.e. less than 2
meters) to short-wave equipment.
The apparatus may not be used in so - called “ wet rooms ”
(hydrotherapy rooms)
The user must keep the device out of the reach of children.
Use of controls or adjustments or performance of procedures other
than those specified here in may result in hazardous exposure to
ultrasonic energy.
Before administering any treatment to a patient you should become
acquainted with the operating procedures for each mode of treatment
available, as well as the indications, contraindications, warnings,and
precautions. Consult other resources for additional information
regarding the application of Ultrasound.
Only use the device for the recommended applications. The device
should be used medical supervison.
Do not use solvents to clean the device.
A damaged device must no longer be used.
The device must only be serviced, repaired and opened by authorized
sales centre.
Dispose of the device in accordance with local regulations. Keep the
operating instructions with the device.
Pregnant and nursing women use the device cautiously.
The group of immaturity bone uses the device cautiously.
Continuous and effect treatment time is not over than 30min every day.
Don't use cell phone during using the device.
The use of sensitive coupling glue cautiously.
Always keep the sound head in constant motion.
2.4
Danger Danger
Patients with an implanted neuro-stimulation device must not be treated
with or be in close proximity to any shortwave diathermy, microwave
diathermy, therapeutic ultrasound diathermy, or laser diathermy anywhere
on their body. Energy from diathermy (shortwave, microwave, ultrasound,
and laser) can be transferred through the implanted neurostimulation
5
