Curtis RCD725C User manual

Before operating this unit,
please read this Owners manual carefully.
INSTRUCTION MANUAL
COMPACT
DIGITALAUDIO
AUTO STOP
Compact Component System
MODEL NO.: RCD725C

TABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTS
This instruction manual is important to you. Please read it. In a short time it shows exactly how to conne-
ct, operate and adjust this unit for best performance.
It can save you money. It shows simple things to do and check before you call for help and save the cost
of unnecessary service and call out charge.
Please retain all packing material for future transportation of the unit or in the unlikely event that the unit
needs to be returned for service.
TABLE OF CONTENTS...............................................................................................................1
WARNINGS.................................................................................................................................2
LOCATION OF CONTROLS.......................................................................................................3
REMOTE CONTROL..................................................................................................................4
AM LOOP ANTENNA..................................................................................................................5
..
MAINTENANCE AND CARE.....................................................................................................15
Pack contents:
1 x main unit
1 x remote control
2 x speaker
1 x instruction manual
OPERATING INSTRUCTION..................................................................... ..........................6-14
1 x AM loop antenna

WARNINGS
DO NOT OPEN
RISK OF ELECTRICSHOCKRISK OF ELECTRICSHOCK
DO NOT OPENDO NOT OPEN
WARNING
TO Prevent fire or shock hazard, do not use this plug with an extension cord, receptacle or add other
outlet unless the blades can be can be fully inserted to prevent blade exposure. To prevent fire or shock
hazard, do not expose this appliance to rain or moisture.
The lightning flashwith arro-
whead symbol,within anequ-
ilateral triangle isintented to
alert the userto the presence
of uninsulated' dangerous vo-
ltage' within theproduct's en-
closure that maybe of suffici-
ent magnitude toconstitute a
risk of electricshock to perso-
ns.
CAUTION : TO REDUCE THE
RISK OF ELECTRICSHOCK
DO NOT REMOVE COVER (
OR BACK),NO USERSERV-
ICEABLE PARTS INSIDE R-
EFER SERVICING TO QUA-
LIFIED SERVICE PERSON-
NEL
The exclamation pointwithin
an equilateral triangleis int-
ended to alertthe user tothe
presence of importantopera-
ting and maintenance(servi-
cing) instructions inthe liter-
ature accompany-ing theap-
plicance
IMPORTANT SAFETY INSTRUCTIONS
1 Read these instruction.
2 keep these instructions.
3 heed all warnings.
4 Follow all instructions.
5 Do not use this product near water(swimming pool, beach, lake etc.).
6 Clean only with a dry cloth.
7 Do not block any of the ventilation openings.Install in accordance with the manufacturer's instructions .
8 Do not install near any heat sources such as radiators, heat registers . Stoves or other apparatus
(including amplifiers)that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug, A polarized plug has two
blades with one wider than the other. Agrounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly at receptacles and the point
where they exit from the stereo.
11 Only use attachments/accessories specified by the manufacturer.
12 Unplug this apparatus during lightning storms or when unused for long periods of time
13 Refer all servicing to qualified service personnel. Servicing is required when the system has been
damaged in any way, such as a damaged power-supply cord or plug . Has been exposed to rain or
moisture ,does not operate normally , or has been dropped.
14 This appliance should not be exposed to dripping water or splashing water and objects filled with
water, such as vases, should not be placed on this unit

LOCATION OF CONTROLS
COMPACT
DIGITALAUDIO
AUTO STOP
Compact Component System
1
2
3
4
5
6
7
8
9
12
13
14
15
16
17
19
10
20
11
18
21
COMPACT COMPONENT
SYSTEM
COMPACT
DIGITAL AUDIO
PUSH OPEN
22
1.Standby Indicator
2.Random button
3.Colour/mode button
4.CD button
5.Program/Memory button
6.Stop/Band button
7.Repeat/Memory up button
8.Play/Pause button
9.Skip FWD button
10.Cassette Door
11. Push Open
12.Skip REW button
13.Volume+ button
14.Volume- button
15.Tuner button
16.Tape button
17.Mute button
18.Standby/On button
19.LCD Display
20. Sensor
21. CD Door
22. Push open

REMOTE CONTROL
1 Functiceon Button 10
2
3
4
5
6
7
8
9
Program/Memory Button
Standby/On Button 11 Volume+ Button
Timer Button 12 Mute Button
Sleep Button 13 Volume- Button
Stop/Band Button 14 Preset EQ Button
Random Button 15 Track/Tune REW Button
Play/Pause Button 16 Intro Button
Track/Tune Forward Button 17 Display Button
M-Up/Repeat Button
1 2
3
4
5
6
7
8
9
10
11
13
14
15
16
17
12
INSTALLATION BATTERY
The remote control uses 1 power source, CELL BATTERY (CR 2025, 3V).
Simply pull out the insulation tag in the battery compartment. The remote control is now functional.
Be sure to observe the polarity makings which are engraved inside the battery compartment, then close
the cover.
BATTERY REPLACEMENT
When the battery become too weak, the operating distance of the remote controller is greatly reduced
and you will need to replace the battery
Open the battery compartment cover, use a screwdriver or other tool to push out the battery (follow the
exit direction in pushing out). Push in the new battery in the opposite direction (the+polarity is faced up.)
Put the cover back and secure.
Note:
To maintain the accuracy and long life of the transmitter,do not press two or more buttons simultaneously.
If the remote control is not used for a long time, remove the battery to prevent possible damage through
leaking battery.
USING THE REMOTE CONTROLLER CORRECTLY
Point the remote controller at the Remote Sensor.
The functions of the buttons on the remote control are the same as the corresponding controls on the
main unit.
When there is a strong ambient light source, the performance of the infrared Remote Sensor may be
degraded, causing unreliable operation.
The maximum effective distance for remote control operation is about 15 feet.

AM LOOP ANTENNA INDICATION

PREPARATION FOR USE
SETTING THE CLOCK
Remove the unit carefully from the box, retaining the packaging for future use.
Read these instructions carefully before use.
CONNECTIONS
Connect the speakers to the speaker sockets on the back of the unit.
Connect the right speaker to the right socket and the left speaker to the left socket.
Connect the AM loop antenna to its socket at the rear of the product.
Extend the FM antenna.
SPEAKER
Speaker may be placed away from the main unit by unwinding the speaker cable.
IMPORTANT
Since movement of the CD mechanism and the sensitive circuitry may cause interference to a radio tuner
nearby, switch this unit off while operating other radio devices.
This product utilizes a laser
Danger - Invisible laser radiation when opened and interlock failed or defeated. Avoid direct exposure to
the beam.
Caution - Use of controls, adjustments, or procedures not listed in this manual may result in hazardous
radiation exposure.
AC POWER OPERATION
Connect the power cord from the main supply having 120V/60Hz only if the unit will be used .
Then press the STANDBY/ON button to switch the unit on or off.
Disconnect the power cord from the mains supply if the unit is not going to be used for some Time.You
may need to reprogram any memory settings.
At STANDBY / ON mode ,press MEMORY / PROGRAM button for 3 seconds , the time systems
will flash onthe display .Press TUNING / SEARCH FORWARD or REW button to select your
dseired time system (12 / 24HRS.) and pressMEMORY / PROGRAM button to confirm the time
system .At this time, the hourdigits will flash,Press the TUNING /SEARCH FORWARD or REW
button to setyour local timefor HOURS ,thenpress MEMORY / PROGRAM button toconfirm . At
this time, theMINUTES will flashon display .Press the TUNING /SEARCH FORWARD or REW
button to setyour local timefor MINUTE.

LISTENING TO THE RADIO
OPERATION
Press the STANDBY/ON button to turn the unit on.
Select the Tuner function by pressing the TUNER button.
Select the desired frequency band that your station is on (FM, AM) with the BAND Selector button on
the unit .
Tune to the desired radio station by pressing the TUNING UP/DOWN buttons on the unit or on the
remote control.
If you hold the TUNING UP/DOWN button for more than half a second ,the unit will begin to automatic-
ally scan until a strong signal is found or until the TUNING UP/DOWN button is Pressed again.
To turn off the radio, press the STANDBY/ON button to switch the unit into standby mode.
STORING PRESET STATIONS
Tune either automatically or manually (as described in previous sections) to the station to be stored.
Press the PROGRAM/MEMORY button once; "MEMORY" will blink on the display. The display will
change for 5 seconds; during this time you must select the desired memory location by pressing the
MEMORY UP button.
Press the PROGRAM/MEMORY Button to store the station at that location.
The unit can store up to 10 FM stations, 10 AM Stations.
TUNING TO A PRESET STATION
Select the desired program number by pressing the MEMORY UP button
ANTENNA
There is a built-in one-meter FM Antenna wire at the rear of the unit.
Unravel the wire and move it around to obtain the best reception. For AM reception the signals are
picked up through the external frame antenna. You may have to move the frame amtenna to obtain the
best reception.
SELECTING A PRESET STATION
To select a preset station, press the M-UP Button (9) on the unit until the desired preset program is
displayed.

HANDLING COMPACT DISCS
To remove a disc from its storage case, press down on the center of the case and lift the disc out,holding
it carefully by the edges.
Fingerprints and dust should be carefully wiped off the disc's recorded surface with a soft cloth. Unlike
conventional records, compact discs have no grooves to collect dust and microscopic debris so gently
wiping with a soft cloth should remove most particles.Wipe in a straight line from the inside to the outside
of the disc. Small dust particles and light stains will have absolutely no effect on reproduction quality.
Never use chemicals such as record sprays antistatic sprays, benzene, or thinners to clean compact
discs. These chemicals can irreparably damage the disc's surface.
Discs should be returned to their cases after use. This avoids serious scratches that could cause the
Laser pickup to skip.
Do not expose discs to direct sunlight, high humidity, or high temperatures for extended periods. Long
exposure to high temperatures can warp the disc.
Do not stick paper or write anything with a ballpoint pen on the label side of the disc.
LOADING AND UNLOADING COMPACT DISCS
Press the STANDBY/ON button to turn the unit on.
Select the CD function by pressing the CD button.
Press the PUSH OPEN button on the CD door to open the CD compartment.
When the disc compartment has opened, remove a disc from its case and place it carefully in the disc
compartment with the label side facing up.
Close the disc compartment by pressing the PUSH OPEN button. When the compartment is fully
closed, the disc will start turning automatically. The total number of tracks will appear on the CD display.
CAUTION
Do not put anything except a compact disc into the compartment. Foreign objects can damage the mec-
hanism.
Keep the disc compartment closed when not in use to prevent dirt and dust from entering the mechanism.
Never place more than one disc into the disc compartment at any time. If the disc is correctly loaded, the
total number of tracks on the disc will be displayed.
Notes:after the disc compartment is fully closed, the disc information may not appear on the display. This
means that the disc is improperly loaded(most likely it is upside down). To check, open the disc compa-
rtment again and reload the disc.

DISC PLAY
Insert a CD as described in the previous section and close the disc compartment. The display will then
show the total number of tracks and total playtime.
Press the PLAY/PAUSE button. Disc play will begin from the start of the first track of the disc.A particular
track can be selected using either of the CD SKIPbuttons . If this is done before pressing the PLAY/
PAUSE button, disc play will start with the selected track when the PLAY/ PAUSE button is pressed.
At the end of the disc, the unit will switch to stop mode.
Notes:
If the disc is deeply scratched, or too dirty, disc play may not start. If an improperly centered disc is
played, noise can be heard in the mechanism. The use of such discs should be avoided.
If the disc is inserted incorrectly, or the disc is damaged the display will show No disc
DISC ERRORS
This compact disc player has built-in error compensation circuits to correct for minor defects in a disc.
There are limits, however, to the amount of correction available.
In some cases, the CD player may skip some tracks, or parts of tracks, on a disc during disc play. This
problem may be caused by defects (such as scratches) in the disc being played, which are too large for
the error compensation circuits to handle.If you encounter this problem, check the CD player's operation
as follows, before having the unit serviced:
Play a new disc. If the CD player operates normally, the skipping problem is probably due to a defective
disc.
TO STOP A CD PART WAY THROUGH
Press the Stop button. Disc play will stop, and the display will show the total number of tracks.
To temporarily stop disc play (pause mode), press the PLAY/PAUSE button. Disc play will stop at the
current play position. The track playing time will flash .
To resume disc play, press the PLAY/PAUSE button again.
TRACK SKIP
STARTING DISC PLAY FROM THE BEGINNING OF A PARTICULAR TRACK
Press the SKIP Forward or REW TRACK buttons to select the desired track. The number of the selected
track will be shown on the CDdisplay. Press the PLAY/PAUSE button to start play.
TO SKIP TO THE NEXT TRACK
For example, to skip ahead to the beginning of track 5 while track 4 is playing. . Press the SKIP FWD
TRACK button once. Disc play will resume at the beginning of track 5. The CD player will skip ahead
to the next track each time the SKIP FWD TRACK button is pressed.Repeatedly pressing the SKIP FWD
TRACK button makes the CD player skip ahead through the disc track by track. Once the beginning of
the last track is reached the CD player advance to the first track.

TO SKIP BACK TO THE PREVIOUS TRACK ON A DISC
For example to skip back to the beginning of track 3 while track 4 is playing. Press the SKIP REW
TRACK button twice. Disc play will resume at the beginning of track 3. The CD player will skip back one
track each time the Reverse Skip Track button is pressed. If this button is pressed in the middle of
a track, the CD player will skip back to the beginning of that track. To make it skip back to the previous
track press the SKIP REW TRACK button twice.
Repeatedly pressing the SKIP REW TRACK button makes the CD player skip back through the disc track
by track. Once the beginning of the first track is reached, the CD player will go to the last track.
Notes:
The SKIP Forward TRACK buttons can be used to select a desired track to play before disc play starts.
In this case the number of the selected track will be display until the PLAY/PAUSE button is pressed.
TRACK SEARCH
You can search through the track by holding SKIP FWD or REW button down; normal play will resume
when the button is released.
FOR REPEAT PLAY OF ALL THE TRACKS
Press the REPEAT button once. The REPEAT will be displayed .
Press the PLAY/PAUSE button.
The disc will then begin playing through to the end of the last track. At which point it will automatically
return to the beginning of the first track. This will continue until the Stop button is pressed.
FOR REPEAT DISC PLAY OF ONE OF THE TRACKS
Press the Repeat button twice. The REPEAT will flash.
Press the Play/Pause button.
The selected track will then begin playing through to its end. At which point it will automatically return to
the beginning of that track. This will continue until the Stop button is pressed.
If the Repeat button is pressed once more, the REPEAT will disappear, repeat play will end; normal disc
play will resume from that point.
When the last track has finished playing, the CD player will then stop.
RANDOM PLAY.
The CD player can play tracks in a randomly generated sequence.
Press the RANDOM Button. The RANDOM indicator will appear on the display.
Press the PLAY/PAUSE Button. The player will now select a track from the selected disc, at random, and
begin to play that track.
At the end of that track another track is chosen at random and played.
This continues until all the tracks have been played on that disk, the unit will then enter the STOP mode.

This continues until all the tracks have been played on that disk, the unit will then enter the
STOP mode.
It is possible to program, the tracks you wish to play in a sequence of your choice, it is not po-
ssible to enter programs during disc play. Press the STOP Button first, and then follow the inst-
ructions below.
ENTERING A PROGRAM
1.Press the PROGRAM Button. The information will be displayed on the display.
2.Select the desired track using the Forward and Reverse SKIP/SEARCH Buttons.
3.Press the PROGRAM Button.
The first program selection is now stored in program memory.
4.Select the next desired track using the Forward and Reverse SKIP/SEARCH Buttons.
5.Press the PROGRAM Button.
Continue entering tracks in this way until all the desired tracks are stored (up to 20).
Notes: If the PLAY/PAUSE Button is pressed before the PROGRAM Button is pressed to store a track,
the track will not be programmed, and the disc will start playing from the first selected track.
Any track can be programmed to play more than once.
Repeatedly pressing the PROGRAM button will enable you to check the program if required
LISTENING TO PROGRAMMED TRACKS
1. Enter all tracks you want to program into memory following the procedure above.
2. Press the PLAY/PAUSE Button.
3. Disc play will start at the beginning of the first programmed track.
TO CLEAR THE PROGRAM MEMORY
If the disc is playing, press the STOP Button. The MEMORY will disappears.
The program memory will also be cleared if the disc compartment is opened, if the function is changed,
or if the power is switched off.
SLEEP FUNCTION
When the disc is playing,press SLEEP button on the remote control.SLEEP and 90 indicators will appear.
Press and hold SLEEP button to select the time you want (max 90, min 10). Then the unit will resume
playing mode, but SLEEP will display on the screen. And the unit will change to standby mode at the
preset time. For example, you select 10 by SLEEP button; the unit will change to standby mode after 10
minutes.
TIMER ON FUNCTION
The unit incorporation a Timer function to allow it to be switched ON from standyby into either CD Tape
or Tuner Mode.
If CD mode is selected the unit will switch ON and start playback from the first track of the loaded disc.
If Tape mode is selected the play button on the tape must be remain pressed down for playback to start-
This mode is not recommended for long periods as damage to the tape may occur.
If Tuner mode is selected the last listened to station will be heard when the unit switches on.

LISTENING TO THE TAPE
Whilst using the Timer function please ensure the volume is set to a reasonable level before setting the
timer to avoid Audio shock damaging the speakers at switching on.
Once the timer has activated the unit will remain on for 60minute before switching off and when using
tape or CD Audio will be heard until the 60 minute switch off time is reached or the tape or CD ends
whichever is the sooner. Unless it is cancelled the Timer will repeat every day at the same time .
MUTE
Press the MUTE button on the remote control to switch off the sound The MUTE indicator lights up.
Press MUTE again to restore the sound to the previous level. Mute indicator will go off.
COLOUR/ MODE
Press STANDBY/ON button, seven colour( green white yellow cyan red purple blue) will cycle slowly on
the display. you can fix a colour that you like by press COLOUR/MODE button once. If need to change
another colour ,you need to press COLOUR/MODE again. The colour cycle anew .
PRESET EQUALIZER
This unit is equipped with a preset equalizer which has been added to enhance your listening
pleasure by altering the frequency response of the music to give it a different feel Press the
PRESET EQ button repeatedly to cycle through the following equalization modes.
FLAT(EQ OFF)
CLASSIC ROCK POP
INSERTION AND REMOVAL OF CASSETTES
Firstly you must press the PUSH OPEN button to open the cassette key door.
Press the STOP/EJECT button to open the Cassette Door.
Slip your cassette tape into the door, with the exposed section pointing down and the playback side
facing you.
Close the Cassette Door securely.
When finished, press the Stop/Eject button to open the Cassette Door, and retrieve your cassette tape.

PREPARATION FOR USE
RECORDING
123 4 5 6 123 4 5 6 123 4 5 6 123 4 5 6
1 RECORD
2 PLAY
3 FAST REW
4 FAST Forward
5 STOP/EJECT
6 PAUSE
PLAYBACK
Press the STANDBY/ON button to turn the unit on.
Select the TAPE function by pressing the TAPE button.
Insert your cassette tape as mentioned above
Press the PLAY button to activate playback.
Use the PAUSE button whenever you want to suspend playback.
Press the STOP/EJECT button when finished.
FAST FWD AND REW FUNCTIONS
Press the STOP/EJECT Key to open the Cassette Door.
Insert your cassette tape as mentioned above.
Press the FAST FWD key to forward wind the tape or REW button to rewind the tape.
Press the STOP/EJECT Key to stop the function.
Always press STOP/EJECT key at the end of the FAST FWD / REW function.
This unit has Automatic Level Control circuitry. This means that the recording level is set automatically.
The volume or EQ controls will not affect the recording.
RECORDING FROM THE RADIO
Press the STANDBY/ON button to turn the unit on.
Select the Tuner function by pressing the TUNER button and press BAND button to select AM or FM.
Tune in your station and put in your cassette tape.
Press the RECORD button and the PLAY button at the same time to start recording.
Press the STOP/EJECT button when finished.

RECORDING FROM CD
Press the STANDBY/ON button to turn the unit on.
Select the CD function by pressing the CD button and insert a disc.
Press the RECORD button and the PLAY button at the same time.
Press the CD PLAY/PAUSE button.
To stop recording, press the STOP button of the CD player.
Press the STOP/EJECT button of the cassette deck.
SOUND CONTROLS
ALC
This unit features ALC, Automatic Level Control, which means that whilst recording, the Changes you
make to EQ/Volume will not affect the recording.
COPYRIGHT NOTICE WARNING
Most records,compact discs, audio and videocassettes,radio and television broadcasts contain material,
which is the subject of copyright. It is unlawful to record such material in any form whatsoever, whether
on disc or tape, without the permission of the copyright owner concerned. Any person who makes a rec-
ording of such material without the consent of the copyright owner infringes copyright and may be liable,
to pay substantial damages to the copyright owner, and in some cases to criminal prosecution.
HEADPHONES
Headphones should have a 3.5mm diameter stereo plug and an impedance of 8-32 ohms. When head-
phones are connected, the speakers are automatically disconnected.
CASSETTE CARE
Two common causes of trouble experienced when using cassettes are:
(a) Tape jamming - Leading to uneven speed in playback,
(b) Tape tangling - Where the tape wraps itself around vital parts of the mechanism.
To reduce the likelihood of these problems occurring, the following precautions should be observed.
Check that there is no loose layers of tape visible through the cassette center window take up any loose
layers, using a pencil or hexagonal barreled ballpoint pen, before inserting the cassette into the machine.
If the cassette feels "tight" the tape may be jamming due to "ridges" formed in the winding of the tape
(visible through the center window). These may be removed, in most cases, by fast winding of the cass-
ette from one end to the other and back again.
Use only well-known brands of tape.
Avoid use of C-120 cassettes.
Furthermore, do not expose cassettes to direct sunlight, dust or oil, and do not touch the tape surfaces.
The tape heads, pinch roller and capstan require periodic cleaning.

MAINTENANCE AND CARE
This removes particles of the metal .
HEAD CLEANING
oxide coating that wear off the tape and accumulate on these parts and impair performance. Switch off
the power, press the Stop/Eject button to open the cassette door, and press the Play button. Clean the
tape heads, pinch roller and capstan with a soft cloth or cotton bud dampened in iso-propylalcohol or
special tape head cleaner.
PREVENTION OF ACCIDENTAL ERASURE
To prevent a recording on a cassette tape being erased accidentally, break off the tab on the rear of the
tape, as in the diagram. Now recording on this side is no longer possible. You can render this protection
ineffective by covering the hole with a piece of adhesive tape
Electronic products of this kind should never be subjected to extreme temperatures or high humidity. For
instance, this set should not be placed in bathing areas or around stoves and radiators.
Keep this unit away from radiators and other heat sources.
Keep this unit away from naked flame source, such as lighted candle.
Do not expose this unit to dropping or splashing and no objects filled with liquid, such as vase,shall be
placed on it the apparatus.
If necessary, clean the unit with a piece of cloth dampened with water only (Be sure the AC Power Cord
is disconnected from the Mains). Never use a polish or a strong detergent, as this will damage the finish
of the cabinet.
This equipment has been designed and manufactured to meet the highest international standards, but,
like any electrical apparatus, which is operated at mains voltage, care must be taken if you are to obtain
the best results and safety is to be assured. This is particularly important with audio equipment.
DO . . . read the operating instructions before you attempt to use the equipment.
DO . . . ensure that all electrical connections (including the mains plug, extension leads and interconne
ctions between pieces of equipment) are properly made and in accordance with the manufacturer's in
structions. Check that the mains fuse rating is correct.
DO . . . always consult your dealer if you are ever in doubt about the installation, operation or safety of
your equipment. He is the best person to advise you.
DO NOT. . . obstruct the necessary all-round ventilation -especially DON'T stand the set close to curtains
or on soft furnishing such as carpets. Overheating can cause unnecessary damage and shorten the life
of the set.
Remember that to obtain the best performance and lasting satisfaction from your equipment, have it reg-
ularly maintained by a reliable service organization. Ensure that all the family correctly uses it. ABOVE
ALL: Never let children push anything into holes or slots in the case - this could result in an electric sho-
ck; Meyer guess or take chances with electrical equipment of any kind - it is better to be safe than sorry!
