Custom Audio Electronics FT190 User manual

FT190
Thermal panel printer
FT190 24/40
User’s manual
www.custom.it

FT190
Printer components
1- Print mechanism
2- Case
3- Paper outfeed
4- Paper loading label
5- Front panel
6- Paper roll compartment
7- Keypad
8- Feed connector
9- Paper winder connector
10- Interface connector
11- Outside “Print” key connector

FT190
All rights reserved. The reproduction of this manual, either totally or partially,
in any form whatsoever, whether it be on paper or through computer
processes, is strictly prohibited. Custom Engineering s.r.l. and the resource
teams employed in the making of this manual will not be held responsible for
any problems arising as a result of improper use of this manual, as they
guarantee that the information contained in it has been subjected to careful
inspection.
Any suggestions regarding errors in its contents or possible improvements
will, nonetheless, be greatly appreciated. The products are continuously
checked and improved. For this reason Custom Engineering s.r.l. reserves
the right to modify the information contained in this manual without prior
notice.
COD. DOME-FT190 Revision 1.20
Copyright 1998 Custom Engineering s.r.l. – Italy
Custom Engineering
Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy
Tel. : [phone] - Fax : [phone]
http: www.custom.it Email : [email protected]

FT190
ytimrofnoCfonoitaralceD"EC"ytimrofnoCfonoitaralceD"EC" ytimrofnoCfonoitaralceD"EC" ytimrofnoCfonoitaralceD"EC"ytimrofnoCfonoitaralceD"EC"
41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI 41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI 41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI :°N 8962030CD
:emans'rerutcafunaM.l.r.sgnireenignEmotsuC
s'rerutcafunaM :sserdda 2enittereBadartS )amraP(ovivetnoF ylatI
:tcudorpehttahtseralceD
:emantcudorPmsinahcemtnirplamrehthtiwretnirplenaP
:emanepyT091TF
:ledoMLTT091TF
:sevitceridgniwollofehthtiwytimrofnocnisi
86/39/CEE;13/29/CEE;633/98/CEEsevitceridytilibitapmoccitengamortcelE
:sdradnatsgniwollofehthtiwecnadroccanI
22055NE BssalC oidarfotnemerusaemfosdohtemdnastimiL noitamrofnifoscitsiretcarahcecnabrutsid tnempiuqeygolonhcet 5991
1-28005NE-ytilibitapmoccitengamortcelE lairtsudnI:2traP.dradnatsytinummilareneG .stnemnorivne 2991
2-4-00016NEstnemeriuqeregrahcsidcitatsortcelE egrahcsidriaVK8,egrahcsidtcatnocVK4 5991
4-4-00016NE.stnemeriuqertsrub/tneisnartlacirtceletsaF VK5.0sniamCD 5991
04105VNEcitengamortceleycneuqerf-oidardetaidaR .stsetytinummI.sdleif MAzHK1%08,zHM0001-zHM08,m/V3 3991
8991enuJ

TABLE OF CONTENTS
FT190i
INTRODUCTION
CONTENTS OF THE MANUAL......................................................................1
CONVENTIONS USED IN THE MANUAL .....................................................1
GENERAL INFORMATION REGARDING SAFETY .....................................1
UNPACKING THE PRINTER .........................................................................3
GENERAL FEATURES..................................................................................3
DESCRIPTION OF THE PRINTER...............................................................4
1. INSTALLATION AND USE
1.1 CONNECTIONS................................................................................... 1-1
1.1.1 Power supply ................................................................................. 1-1
1.1.2 Logic circuitry ................................................................................. 1-2
1.2 CONFIGURATION ............................................................................... 1-5
1.3 AUTOTEST .......................................................................................... 1-6
1.4 HEXADECIMAL DUMP ........................................................................ 1-6
1.5 MAINTENANCE.................................................................................... 1-7
1.5.1 Changing the paper roll.................................................................. 1-7
2. INTERFACES
2.1 TTL SERIAL......................................................................................... 2-1
2.2 TTL PARALLEL.................................................................................... 2-2
2.3 CALENDAR CLOCK (OPTIONAL)...................................................... 2-3
2.3.1 Adjusting the clock through the keypad ......................................... 2-3
3. PRINTER FUNCTIONS
3.1 PRINT DIRECTION ............................................................................. 3-1
3.2 CONTROL CHARACTERS ................................................................. 3-2
4. TECHNICAL SPECIFICATIONS
4.1 TECHNICAL SPECIFICATIONS......................................................... 4-1
4.2 DIMENSIONS....................................................................................... 4-2
5. CHARACTER SETS
5.1 CHARACTER SETS ............................................................................ 5-1

TABLE OF CONTENTS
FT190 ii
ATTACHMENT A - ACCESSORIES AND SPARE PARTS
A.1 ACCESSORIES................................................................................... A-1
A.1.1 PSM05 Power supply .................................................................... A-1
A.1.2 AV03 Rewinder.............................................................................. A-2
A.2 SPARE PARTS.................................................................................... A-3

INTRODUCTION
FT1901
CONTENTS OF THE MANUAL
In addition to the introduction which lists: the conventions used in the manual,
general information relative to safety, unpacking of the printer and a brief
description of the printer itself, highlighting its main features, the manual is
split up into the following chapters:
Chapter 1: Containing the information required for installing and using the
printer correctly
Chapter 2: Containing the specifications of the interfaces
Chapter 3: Containing the description of the printer command set
Chapter 4: Containing the technical specifications of the printer
Chapter 5: Containing the character sets (fonts) used by the printer
CONVENTIONS USED IN THE MANUAL
N.B.
Gives important information or suggestions relative to the use of the
printer
WARNING
The information marked with this symbol must be carefully heeded
to safeguard against damaging the printer
DANGER
The information marked with this symbol must be carefully heeded
to safeguard against injury to the operator
GENERAL INFORMATION REGARDING SAFETY
•Read and keep the following instructions.
•Observe all warnings and follow all instructions attached to the printer.
•Before cleaning the printer, disconnect the feed cable.
•Clean the printer with a damp cloth. Do not use liquid or spray products.
•Do not operate the printer near to water.

INTRODUCTION
FT190 2
•Do not place the printer on unsteady surfaces. It could fall and get
seriously damaged.
•Use the type of electricity supply marked on the printer label. In the event
of uncertainty, contact the seller.
•Position the printer in such a way as to ensure that the cables connected
to it will not be damaged.
•Ensure that the maximum absorbed current of the printer does not
exceed the maximum acceptable current for the type of feed cable used.
•Do not put objects of any kind inside the printer as they could cause a
short circuit or damage parts which could affect its performance.
•Do not spill liquids on the printer.
•Do not carry out technical operations on the printer with the exception of
the scheduled maintenance operations specifically indicated in the user’s
manual.
•Disconnect the printer from the electricity supply and have it repaired by a
specialized technician should any of the following conditions occur:
A. The feed connector has been damaged.
B. Liquid has penetrated to the inside of the printer;
C. The printer has been exposed to rain or water;
D. The printer is not operating normally despite the instructions in
the user’s manual having been followed.
E. The printer has been dropped and its case damaged.
F. The performance of the printer is poor.
G. The printer does not work.

INTRODUCTION
FT1903
UNPACKING THE PRINTER
Remove the printer from the box, taking care not to damage the packing
material, as it could be needed for future transportation of the machine.
Ensure that all the components illustrated are in fact present and that they
are in perfect condition. If this is not the case, contact the after-sales
assistance department immediately.
Printer
Manual (or Cdrom)
Paper roll (inside the printer)
Long screws
N.B.
Before using the long screws, read the note to paragraph 4.2.
GENERAL FEATURES
The FT190 is a printer which, in addition to having an innovative design,
guarantees high performance and is reliable and user-friendly.
For these reasons, it is the ideal solution for applications which require the
immediate printing of data on a ticket, whether they be of an industrial,
professional or laboratory nature. Typical fields of application are: weighing
systems, receipts (not for tax purposes) as well as for security, controlling
and diagnostics purposes.
It has a 200 dpi thermal print mechanism and uses 57.5mm paper rolls. It
can print 24 or 40 characters per line according to the selection made at the
setup stage through the software command.
The FT190 printer is so compact and lightweight that it can be installed
extremely easily on any type of equipment. It is supplied with TTL serial and
parallel interfaces and has a 1Kbyte reception buffer. It can also be
equipped with a Real Time Clock.
(Figure 1)

INTRODUCTION
FT190 4
DESCRIPTION OF THE PRINTER
The FT190 printer has an ABS casing (1) with a front cover (2) which opens
to allow access to the paper roll and print head.
The control panel is located on the front (3) and has a PRINT key, a FEED
key and two LEDs: Power and Status.
•PRINT key. When enabled it outputs, in parallel, the logic state “0” on
pin 4 of J1, while in serial it brings about the transmission of the control
character “$0D”, if this has been enabled at the printer setup stage. In
parallel on PRINT key there is a connector J6 used for the connection
to outside key (figure 1.1).
•FEED key. When this is pressed, the paper feeds forward manually. If
this key is pressed briefly, when the RTCK option is installed, the date
and time of day is printed.
•The POWER LED indicates that the the printer is receiving a digital
power supply.
•The STATUS LED, when flashing, signals that the paper is finished.
When lit steadily, it signals the presence of an error (head power supply
too high or too low or head temperature too high).
(Figure 2)

1. INSTALLATION AND USE
FT19011-
1.1 CONNECTIONS
1.1.1 Power supply
The FT190 printer is equipped with a standard 4-pin male AMPMODU1-type
connector (J7). The signals on the connector pins are as follows:
WARNING
Respect the polarity of the power supply.
It is possible to avoid connection with the feed connector (J7) by using the
logic circuitry’s flat 26-pin connector (J1) on request at the time of ordering,
thus connecting the printer’s power supply and signals with a single cable. In
this case, however, the flat cable must not exceed 30 cm in length because,
when electrical current runs inside small diameter wires, voltage failures can
occur, thus interfering with the correct operation of the printer.
For the pin pattern relative to feeding through the logic’s flat connector,
please refer to the following paragraph.
NIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGISSETONSETON SETON SETONSETON
11
1
11 DNG
22
2
22 DNG
33
3
33 cdV7otcdV5.4morf:TV+)ylppusrewopdaeh(
44
4
44 %7±cdV5:CDV+)ylppusrewopdraccigol(
(Table 1.1)
(Figure 1.1)

1. INSTALLATION AND USE
FT190 21-
1.1.2 Logic circuitry
In the 20-pin connector J1, the signals are arranged as follows:
In the 26-pin connector J1, the signals are arranged as follows:
NIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGISNIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGIS
11
1
11 TV+ 22
2
22 TV+
33
3
33 CDV+ 44
4
44 CDV+
55
5
55 DNG 66
6
66 DNG
77
7
77 DT 88
8
88 6D
99
9
99 5D 01010101014D
11111111113D 21212121212D
31313131311D 41414141410D
5151515151*7D 6161616161TESER
7171717171ESP 8181818181STR/YDAER
9191919191DEEF 0202020202DR/BTS
NIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGISNIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGIS
11
1
11 DNG 22
2
22 DNG
33
3
33 DNG 44
4
44 PT
55
5
55 TV+ 66
6
66 TV+
77
7
77 TV+ 88
8
88 TV+
99
9
99 CDV+ 0101010101CDV+
1111111111DNG 2121212121DNG
3131313131DT 41414141416D
51515151515D 61616161614D
71717171713D 81818181812D
91919191911D 02020202020D
(Table 1.2)

1. INSTALLATION AND USE
FT19031-
NIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGISNIPNIP NIP NIPNIPLANGISLANGIS LANGIS LANGISLANGIS
1212121212*7D 2222222222TESER
3232323232ESP 4242424242STR/YDAER
5252525252DEEF 6262626262DR/BTS
*The D7 signal is not taken into consideration in the event of 7-bit
programming of the parallel port. In order to configure the FT190 with the
extended character set, the parallel interface must be 8-bit programmed.
The signals indicated have the following functions:
GND: signal and power supply ground;
+VT: head power supply;
+VDC: logic card power supply;
PSE (input): serial/parallel interface selection. If shortcircuited to ground (0)
it enables serial communication; if free (1) it enables parallel reception;
D0, ..., D7 (inputs): data buses. In the parallel configuration, these
correspond to the printer input data bus (the high level indicates binary digit
1). In serial communication, if the serial parameter selection has been
chosen through the connector, these are used to determine communication
speed and reception protocol. Normally, the data bus is on logical level 1: to
obtain logical level 0, shortcircuit to ground (GND).
(Table 1.3)

1. INSTALLATION AND USE
FT190 41-
The serial baud rate is settable as shown in the table below:
D0 D1 D2 BAUD
001300
101600
1 1 1 1200
0 1 1 2400
0 0 0 4800
1 0 0 9600
All other combinations select the speed at 1200 baud.
D3 = 1: flag type transmission protocol. When the print buffer is full, the
printer sends a low level on the RTS signal, which interrupts transmission;
when the buffer is able to receive more data, the level of the RTS signal
changes to 1.
D3 = 0: XON/XOFF type transmission protocol. When the print buffer is full,
the printer sends a XOFF $13 (DC3) command, which interrupts
transmission; when the buffer is able to receive more data, the command
XON $11 (DC1) signal is transmitted.
D5, D6, D7: the selection of these bits causes the configuration of the serial
with the transmission format listed in the table below:
D7 D6 D5 Format
1 1 1 8 parity none bits and 1 stop bit
0 1 1 8 parity EVEN bits and 1 stop bit
0 1 0 8 parity ODD bits and 1 stop bit
1 1 0 7 parity none bits and 1 stop bit
1 0 1 7 parity EVEN bits and 1 stop bit
1 0 0 7 parity ODD bits and 1 stop bit
Remember that in order to configure the printer in serial mode, the signal
PSE must be shortcircuited to ground on connector J1.
RESET (input): reset card controller, active at low level. The reset initializes
the printer parameters, with the following effects:
• the line buffer and print buffer are erased;
• the print format is selected according to programming;
(Table 1.4)
(Table 1.5)

1. INSTALLATION AND USE
FT19051-
• the PSE pin of J1 is read for serial or parallel configuration;
• the autotest is printed, on pressing the FEED key;
• the functioning of any optional cards installed is checked.
READY/RTS (output): in the parallel configuration the high level indicates that
the printer is ready to receive data. A low level indicates that the printer is
busy. In serial communication, the high logic state (1) indicates that the
printer is ready to receive data; the low logic state (0) indicates that the print
buffer is full and cannot accept data.
FEED (input and output): paper feed key, active at low level. This signal is in
parallel to the contacts of the FEED key on the front of the printer.
STB/RD (input): in the parallel configuration, a low level indicates to the
printer that there is valid data on the data buses (D0, ..., D7). In the serial
configuration, it corresponds to the data reception pin.
TP (input and output): PRINT key, active at low level. This signal is in parallel
to the contacts of the PRINT key on the front of the printer.
1.1.3 Outside Print key
To the connector J6 (figure 1.1) can be related an outside Print key. The
polarity and the signal's function are as follows (table no. 1.6):
1.1.4 Rewinder
The connector J4 (1.1) is used to feed the outside rewinder. The position
and the signal's function are as follows (table no. 1.7):
niPniP niP niPniPlangiSlangiS langiS langiSlangiS
1TNIRP
2DNG
(Table 1.6)
niPniP niP niPniPlangiSlangiS langiS langiSlangiS
1+ROTOM
2-ROTOM
(Table 1.7)

1. INSTALLATION AND USE
FT190 61-
1.2 CONFIGURATION
The FT190 enables the configuration of the printer default parameters.This
procedure is enabled by holding down the PRINT and FEED keys while
switching on, with the jumper JP2 present on the printer card open.
After this, each time the PRINT key is pressed, the parameter is modified
and its current value is printed. Once the required value has been obtained,
press the FEED key to proceed to the next parameter, and so on. Once all
the parameters have been run through, the printing of a message signals the
end of the setting procedure.
The parameters affected during configuration are:
• Selection of the number of columns (24 or 40)
• Print direction (normal or reverse)
• Selection of the character dimensions (normal, double width, double
height, expanded)
• Selection of the font (font 1 or font 2)
• Enabling or disabling of the CR command
• AUTOFEED enabling or disabling : if the function is enabled when the
printer receives a characters number equal to the line buffer the next
character will place on the left margin in a new line
• Selection of the print speed in function of the absorption
• Selection of the red intensity : using two-colour thermal paper is
possible to set different red tonality
• Selection of the parameters for serial and parallel communication
• Enabling or disabling of the 1Kbyte buffer
• Enabling setting of the real time clock
• Enabling of seconds printing in the real time clock function.
The settings made are saved on the EEPROM (non volatile memory).
1.3 AUTOTEST
To run the autotest, hold down the FEED key, while switching on the printer.
The autotest causes the printing of the printer’s current setting data and the
printing of the complete ASCII character set.

1. INSTALLATION AND USE
FT19071-
1.4 HEXADECIMAL DUMP
If the PRINT key is held down during switching on, the printer enters
Hexadecimal Dump mode. This function is used for the diagnostics of
characters received in serial or parallel. In fact, these are printed in
hexademical code together with the corresponding Ascii code.
1.5 MAINTENANCE
1.5.1 Changing the paper roll
To change the paper roll, proceed as follows:
1) Open the printer cover and press down the swinging support of the print
mechanism at the point marked PUSH;
2) Insert the end of the paper roll in the slit of the print mechanism and
position the paper roll so that it rotates in the right direction, as shown in
the figure;
3) The paper is automatically pulled by the roller for 3 or 4 centimetres;
4) Tear off the paper and re-close the cover.
WARNING
Before inserting the paper, ensure
that it is cut evenly
(Figure 1.2)

2. INTERFACES
FT19012-
The selection of the standard interface, TTL serial and parallel, is given by
the status of the PSE pin of J1.
2.1 TTL SERIAL
In the serial protocol, the signals which distinguish the communication are
TD, RD, and RTS if the RTS/CTS protocol has been selected while, if the
XON/XOFF protocol has been selected, the signals are TD and RD.
Transmission
format
Protocol
RTS/CTS
Protocol
XON/XOFF
(Figure 2.1)

2. INTERFACES
FT190 22-
2.2 TTL PARALLEL
In the parallel communication the signals which can be used are:
1) 7 or 8 bit data buses;
2) STROBE signal indicating the validity of the data;
3) READY signal indicating that the printer is ready to receive data.
Transmission
format
Flow
diagram
(Figure 2.2)

2. INTERFACES
FT19032-
2.3 CALENDAR CLOCK (optional)
The Real Time Clock is available as an option.
Printing and adjustment of the clock are managed by a series of control
characters, described as follows.
N.B.
For the real time clock control characters, please refer to
description of the printer command sets in chapter 3
2.3.1 Adjusting the clock through the keypad
The time and date can be adjusted using the PRINT and FEED keys on the
printer’s front panel. To set, proceed as follows:
• While holding down the FEED key, press the PRINT key. The printer will
print the time and date with an arrow indicating the digit to be modified;
• Each time the PRINT key is pressed, the digit marked by the arrow will
increase and an updated version will be printed;
• To proceed to modify another digit, press the FEED key again. Each
time the printer will print the updated time and date, highlighting with an
arrow the currently selected digit;
• To terminate the setting procedure, press PRINT and FEED at the
same time.
