KUBE II Lottery Printer
Setup Guide
Validation_Printer_Setup_01282014

2
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Date:
Monday, August 11, 2014
Notice of Rights:
Copyright © 2014 Amano McGann, Inc. All rights reserved. This document contains proprietary information and such information may not be
reproduced whole or in part without written permission from:
Amano McGann, Inc.
2699 Patton Road
Roseville, Minnesota 55113
Notice of Liability:
Amano makes no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically
disclaim all warranties, including without limitation warranties of fitness for a particular purpose. Amano reserves the right to make equipment
changes and improvements that may not be reflected in this document. Portions of this document may have been updated to include the latest
hardware or firmware version, if applicable.
We recommend that this document be read in its entirety before any attempt is made to operate the equipment.
Trademark Notice:
Amano is a registered trademark of Amano Inc. All other trademarks are the property of their respective owners.
Contact Information:
Every effort has been made to ensure the accuracy of this document. If you have comments, question, or ideas regarding this document
please send them to Amano via e‐mail to:
or, via postal mail to:
techwriter@am anomcgann.com
Amano McGann, Inc.
Technical Wr i ter
2699 Patton Road
Roseville, Minnesota 55113
For more information about Amano’s complete line of products, visit our web site at:
www.amanomcgann.com
Date
Monday, August 11, 2014
Product
KUBE II Lottery Printer
Build/Revision
Model
Validation Printer
Document Type
Setup Guide
Version
A1
Company Name ‐ Long
Amano McGann, Inc.
Company Name ‐ Short
Amano McGann
Street
2699 Patton Road
City/State/Postal Code
Roseville, Minnesota 55113
Telephone
(612) 331‐2020
Fax
(612) 331‐5187
Email
[email protected]
Website
www.amanomcgann.com
Copyright
Copyright © 2014 Amano McGann, Inc. All rights reserved.
File Name
Validation_Printer_Setup_01282014

3
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Contents
Chapter 1: Introduction 4
Specifications 4
Hardware Installation 5
Inventory 5
Components 6
Dimensions and Weight 7
Turning Printer On/Off 7
Chapter 2: Maintenance 10
Chapter 3: Driver Installation 16

4
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Chapter 1: Introduction
KUBE II POS thermal printer ideal for the retail and the hospitality industries. It is the perfect solution for shops thanks to its compact,
attract i ve and sturdy design and because it can be mounted either vertically or horizontally. KUBE II is powerful and fast: it prints on receipts
that are 80/82.5mm wide with an extraordinary print quality; the characters and graphics can be positioned in any direction. The 90mm large
paper size allows a high degree of printing autonomy. KUBE II is distinguished by unparalleled performance, robustness and reliability: it is
equipped with a very high quality long‐life print head (200km of printed paper), and the new cutter for automatic receipt cutting that ensures
maximum functionality for more than 2 million cuts. KUBE II prints logos and coupons at high resolution. KUBE II is completed with accessories
such as the "splash‐proof" protection and sides available in different colors (red, silver and beige). KUBE II is available with USB and RS232
serial interface or Ethernet interface, with drawer driver..
Specifications
Receipt/invoice/orders printer
RS232+USB/Ethernet
Powerful and fast: 250mm/sec
Prints high quality logo and coupon graphics
It prints 1D and 2D barcodes
80/82.5mm paper width
Paper thickness: 63 μm
Autonomy: paper diameter 90mm
Long lasting printing head (200Km printed paper)
Well‐built and reliable
Auto‐cutter 2.000.000 cuts
Size: 209mm (L)x140mm (W)x152mm (H)

5
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Hardware Installation
Inventory
1. User manual
2. Guarantee sheet
3. Upper foam packing shell
4. Power supply cable
5. RS232 serial cable
6. Printer
7. Additional feet for vertical use
8. Lower foam packing shell
9. Power supply
10. Box
11. Paper roll

6
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Components
1. Opening levers of paper compartment
2. Cover for paper compartment
3. Near paper end sensor
4. Blade for manual tear‐off
5. Paper presence sensor
6. Sensor of cover open
7. Status led
8. FEED key
9. ON/OFF key
10. Serial RS232 connector
11. USB connector
12. Drawer connector
13. Power supply connector

7
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Dimensions and Weight
Weight: 2.3 Kg without paper roll
Length: 209 mm
Height: 152 mm
Width: 140 mm

8
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Turning Printer On/Off
1. Switch printer ON pressing key ON/Off. The status led will turn on.
2. Switch printer OFF pressing key ON/OFF. The status led will turn off.

9
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
NOTE: During power up, do not hold down the ON/ OFF key because the printer enters in a test mode and it is
unusable by keys; in this case, tum the printer off and on again without pressing any key

10
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
Chapter 2: Maintenance
To change the paper roll, proceed as follows:
1. Lift the opening levers.
2. Open the printer cover

11
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
3. Place the paper roll in the paper compartment.
4. Pull out a few centimeters of the paper roll edge.

12
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
5. Close the printer cover
6. Wait for the paper to load and cut automatically.
NOTE: Inspect inside the printer every paper change, and
verify that there aren't paper off‐cuts on the cutter
compartment; if this event happens remove the paper
off‐cuts before execute any other operation with
tweezers.
WARNING: Remove the adapter guides, as shown, for
82,5mm paper roll only.
In case of cutter jam, proceed as follows:
1. Press slightly the left side of the cutter cover, so that it opens.
2. Lift the cover and remove it.
3. Rotate the mechanism in the direction that oppose less resistance, as shown in the label.
4. Press FEED key.
5. Reassemble the cover removed in advance.
If the cutter is unlocked, the led turns green. If the led remains blinked red, repeat the previous operation.
If the problem persists, please contact the customer service.

13
Validation_Pr i nter _Setup_01282014
KUBE II Lottery Printer Setup Guide
NOTE: Inspect inside the printer every paper change, and verify that there aren't paper off‐cuts on the cutter
compartment; if this event happens remove the paper off‐cuts before execute any other operation with tweezers.
1. Download the SW from the web site:
2. Use the following procedure to install the printer SW:
WINDOWS/OPOS: From the START menu, press Enter and key‐in the path where the SW was saved on your PC, then
click OK. Follow the instructions that appear on the screen to install the driver.

16
Validation_Printer_Setup_01282014
KUBE II Lottery Printer Setup Guide
Chapter 3: Driver Installation
The Kube II Printer Driver is either provided with the printer or is downloadable from the OEM's website: Custom.biz
1. Go to Gaming section
2. Multi‐Function Printer and Scanners
3. Click "Kube II Lottery"
4. Scroll down to drivers
5. Select self‐installing driver for Kube II Lottery (Xp‐8 Compatable)
6. Click Download
7. Create install directory
8. Save As into install directory (not the desktop)
9. Extract to folder
10. Click file exe to install
11. Run the install exe
12. Follow instructions on screen

17
Validation_Printer_Setup_01282014
KUBE II Lottery Printer Setup Guide

18
Validation_Printer_Setup_01282014
KUBE II Lottery Printer Setup Guide
13. Select paper size ‐ 82.5

19
Validation_Printer_Setup_01282014
KUBE II Lottery Printer Setup Guide
14. Select cable ‐USB port

20
Validation_Printer_Setup_01282014
KUBE II Lottery Printer Setup Guide

21
Validation_Printer_Setup_01282014
KUBE II Lottery Printer Setup Guide
WARNING: Don't set the printer as a default
