Custom Brackets Tilt Head CB User manual

Quick Release
push bar
Quick Release
push bar
Tilt lock knob
(rotate counter-clockwise
to tighten)
Tilt lock knob
(rotate counter-clockwise
to tighten)
Tilt drag knob
(rotate clockwise
to tighten)
Tilt drag knob
(rotate clockwise
to tighten)
Tilt Head CB Features Tilt Head CB Features
Custom Brackets
style quick release
Custom Brackets
style quick release
Attach the Tilt Head CB to the monopod’s ⅜”-16 mounting stud and tighten until rmly attached.
* * * * * Caution * * * * *
If you are using a monopod with a ¼”-20 mounting stud, you will need to purchase a ⅜” to ¼” reducer
bushing and install it in bottom of the Tilt Head’s base.
Attach the Tilt Head CB to the monopod’s ⅜”-16 mounting stud and tighten until rmly attached.
* * * * * Caution * * * * *
If you are using a monopod with a ¼”-20 mounting stud, you will need to purchase a ⅜” to ¼” reducer
bushing and install it in bottom of the Tilt Head’s base.
Attaching the Tilt Head CB to a monopod Attaching the Tilt Head CB to a monopod
Attaching the bracket to the tilt head quick release Attaching the bracket to the tilt head quick release
Figure #10 Figure #10
Figure #11 Figure #11
Attach the bracket to the quick release by pushing in the push bar, and while
holding the push bar in, slide the bracket into the quick release from the front.
Figure #2 shows the bracket in the quick release.
Attach the bracket to the quick release by pushing in the push bar, and while
holding the push bar in, slide the bracket into the quick release from the front.
Figure #2 shows the bracket in the quick release.
Tilt Head CB INSTRUCTIONS Tilt Head CB INSTRUCTIONS
32 Alpha Park
Cleveland, Ohio 44143
phone: [phone]
toll free: 800-530-2289
website: www.custombrackets.com
email: [email protected]
32 Alpha Park
Cleveland, Ohio 44143
phone: [phone]
toll free: 800-530-2289
website: www.custombrackets.com
email: [email protected]
Made in USA Made in USA
Innovative Camera Supports Innovative Camera Supports
Front View Front View
Quick Release
push bar
Quick Release
push bar
Custom Brackets
style quick release
Custom Brackets
style quick release
If you are attaching the Tilt Head CB to the Manfrotto 685B monopod and would like to prevent the
Tilt Head from twisting on the monopod, see the accessory ATP (Anti-twist Pins).
If you are attaching the Tilt Head CB to the Manfrotto 685B monopod and would like to prevent the
Tilt Head from twisting on the monopod, see the accessory ATP (Anti-twist Pins).

For a period of ve (5) years from date of purchase, Custom Brackets will repair or replace free of charge, any
defect in material or workmanship. Warranty does not cover repairs due to abuse, negligence, impact or any
modications made by the customer. Excessive force unscrewing knobs will void warranty. Warranty service is
available by returning the Tilt Head CB (shipping prepaid) to Custom Brackets. All returns must include a return
authorization (RA) number (contact Custom Brackets to obtain), letter explaining the problem, and a copy of
the sales receipt.
For a period of ve (5) years from date of purchase, Custom Brackets will repair or replace free of charge, any
defect in material or workmanship. Warranty does not cover repairs due to abuse, negligence, impact or any
modications made by the customer. Excessive force unscrewing knobs will void warranty. Warranty service is
available by returning the Tilt Head CB (shipping prepaid) to Custom Brackets. All returns must include a return
authorization (RA) number (contact Custom Brackets to obtain), letter explaining the problem, and a copy of
the sales receipt.
USA 5 Year Warranty USA 5 Year Warranty
Repair service is available by returning the Tilt Head CB (shipping prepaid) to Custom Brackets. All returns
must include a return authorization (RA) number (contact Custom Brackets to obtain), letter explaining the
problem, and a copy of the sales receipt. A repair cost will be issued and must be approved prior to any
repairs. Shipping charges are the responsibility of the customer.
Repair service is available by returning the Tilt Head CB (shipping prepaid) to Custom Brackets. All returns
must include a return authorization (RA) number (contact Custom Brackets to obtain), letter explaining the
problem, and a copy of the sales receipt. A repair cost will be issued and must be approved prior to any
repairs. Shipping charges are the responsibility of the customer.
Repair Repair
The Tilt Head CB is designed completely maintenance-free. The Tilt Head CB is designed completely maintenance-free.
Maintenance Maintenance
For a period of ve (5) years from date of purchase, Custom Brackets will repair or replace free of charge,
any defect in material or workmanship. Warranty does not cover repairs due to abuse, negligence, impact or
any modications made by the customer. Excessive force unscrewing knobs will void warranty. Limitation to
the warranty - after year one shipping charges are not covered. Warranty service is available by returning the
Tilt Head CB (shipping prepaid) to Custom Brackets. All returns must include a return authorization (RA) number
(email [email protected] to obtain), letter explaining the problem, and a copy of the sales receipt.
For a period of ve (5) years from date of purchase, Custom Brackets will repair or replace free of charge,
any defect in material or workmanship. Warranty does not cover repairs due to abuse, negligence, impact or
any modications made by the customer. Excessive force unscrewing knobs will void warranty. Limitation to
the warranty - after year one shipping charges are not covered. Warranty service is available by returning the
Tilt Head CB (shipping prepaid) to Custom Brackets. All returns must include a return authorization (RA) number
(email [email protected] to obtain), letter explaining the problem, and a copy of the sales receipt.
International 5 Year Limited Warranty International 5 Year Limited Warranty
The Tilt Head CB has many unique features. It is constructed from anodized aluminum for a lightweight
and scratch-resistent nish. The tilt head has separate lock and drag knobs for better control. All knobs
are captive to prevent loss. All of the fasteners are stainless steel to resist corrosion and black oxide for
appearance.
The Tilt Head CB has many unique features. It is constructed from anodized aluminum for a lightweight
and scratch-resistent nish. The tilt head has separate lock and drag knobs for better control. All knobs
are captive to prevent loss. All of the fasteners are stainless steel to resist corrosion and black oxide for
appearance.
Tilt Head CB Features Tilt Head CB Features
