Custom Dynamics PROBEAM PB-KIT-BCM-1156-T User manual

Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
We thank you for purchasing the Custom Dynamics® ProBEAM® LED Turn Signals! Our LEDs oer maintenance free
service and higher visibility. Our ProBEAM® product line ulizes the latest technology and automove grade compo-
nents to ensure the highest level of reliable service. Custom Dynamics® oers one of the best warranty programs
and customer support in the industry. If you have any quesons during the installaon of this product please call us
at 1(800) 382-1388.
CD #: PB-KIT-BCM-1156-T
Package Contents:
- Choice of Front 1157 ProBEAM® Amber/White Dynamic
Ringz ™ Lenses with Smoke Lenses or ProBEAM® Amber
LED Turn Signals with Amber Lenses
- Choice of Rear 1156 ProBEAM® Red LED Turn Signals with
Red Lenses Inserts or ProBEAM® Amber LED Turn Signals
with Amber Lenses
US Patent: 830597, 830595, D851,817, D851,327
Chinese Patent: ZL201830045649.4, ZL201830409095.1,
ZL201830409102.8, ZL201830409095.1
Fitment: 2011-2017 Harley-Davidson® Heritage Classic
(FLSTC) and 2014-2021 Road King® (FLHR) with OEM Flat
(Pancake) Style (2-screw) lens and rear 1156 single con-
tact bulb bases (models with center taillight). Does not t
CVO™ models or Internaonal (HDI) Harley-Davison® Mo-
torcycles.
Part Number: PB-KIT-BCM-1156-T
Note:
• Use care in removing the OEM lens and bulbs from the
housing, so as not to scratch or mar the chrome housing.
Custom Dynamics® is not liable for damage to chrome
housing during installaon.
• Dielectric grease does not need to be used with this LED
product, it can actually prevent them from working. Re-
move any excess grease from your turn signal sockets be-
fore inserng.
***IMPORTANT***
CAN Bus Models: 2011-Present Soail, 2012-Present Dyna, 2014
-Present Touring, 2014-Present Sportster
This LED product is BCM compliant. However, you must run the
4 way hazard ashers for 3 minutes with the ignion in the OFF
posion to allow the BCM to sync the new LED turn signals load
aer they are installed.
ATTENTION
Please read all Informaon below before Installaon
02-2021
Installaon:
1. Remove the exisng lens from turn signal housing by
removing the two screws.
2. Remove exisng bulb from turn signal housing.
3. Remove any corrosion or dielectric grease from the
socket to insure the socket contacts are clean.
4. Conrm the proper orientaon of the socket base and
insert the base into the socket. If it seems hard to
twist the base in the socket or hard to remove, it is
probably orientated the wrong way.
5. Twist the LED turn signal a few rotaons to coil wire
from the turn signal to the socket base ( Figure 1).
1

Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
Installaon Connued:
6. Align the adapter to the housing and press
slightly to get started, do not press into place
( Figure 2).
7. Use the Lens to push the adapter into place
and fully seat into housing (Figure 3).
8. Remove the lens and check that adapter is se-
cure, if not remove and adjust tabs and repeat
steps 6 and 7. Adapter should be snug but not
ght.
Installation Instructions - Page 2
2
3
02-2021
Installaon Connued:
9. Install the provided O-rings on the lens and the two
mounng screws removed in Step 1 ( Figure 4).
10. Install the lens and rmly ghten the two screws
(over-ghtening the screws will crack the lens).
11. Check operaon of turn signals in all modes.
4
