OWNER’S MANUAL
Model Number: CM-ABDS-A18-WWM-U-S-AC-PLBS-DR-LM
COPYRIGHT® 2015 CUSTOMATIC ADJUSTABLE BEDZ
This produ t and all our bedding produ ts are overed by one or more of the following issued
and pending U.S. patents in luding Nos. 7448100, D657157, D663542, D657158, D657156,
8209801, 8209800, D663544, D663543 and other patents pending.
Exclusiv ly D sign d by
ADJUSTABLE BEDZ
CUSTOM SLEEP
TO FIT YOUR LIFE
®
TM
Serial Number: ___ __________ ______
(Pla e your serial number here for ready referen e)
World Class Adjustabl B d Bas !
Blu tooth Sp ak r Syst m
“Edg -to-Edg ” Lumbar Support
AC Pow r Outl ts
DreamStar
Th
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:57 PM Pag 1

ADJUSTABLE BEDZ
CUSTOM SLEEP
TO FIT YOUR LIFE
®
TM
Tabl of Cont nts
Safety Pre autions 1
Parts List 3
Installation Guide 4
Emergen y Power Down Operation Guide 6
Advan e Highlight Features 7
Wireless Hand Control Operation Guide 8
A tivating Bluetooth Sound System 11
Troubleshooting 12
Warranty & Registration 14
Model Number: CM-ABDS-A18-WWM-U-S-AC-PLBS-DR-LM
World Class Adjustable Bed Base!
Th
DreamStar
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:58 PM Pag 2

Saf ty Pr cautions
ATTENTION!
IMPORTANT SAFETY INSTRUCTIONS.
PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS PRODUCT.
Always unplug this adjustable bed frame from the ele tri al outlet before any leaning or maintenan e of the bed frame. To
safely dis onne t, make sure all ontrols are in the off position, then remove the plug from the outlet.
Keep ord away from heated surfa es. Keep air openings free of lint, hair and the like - never operate when air openings are
blo ked. Never drop or insert any obje t into any opening. Use only indoors.
Cease use of this bed frame and onta t the Adjustable Bed base enter for repair if: (1) it has a damaged ord or plug, (2) it is
not working properly, (3) it has been dropped or damaged, or (4) it has been dropped into water.
ELECTRICAL SAFETY
To redu e the risk of ele tri sho k, ele tri al fire, or faulty operation of this produ t, your Adjustable Bed features a polarized plug
meant to be used only with a grounded ele tri al outlet. If this plug does not fit into your outlet, onta t a qualified ele tri ian to
install a properly grounded outlet. Failure to use a properly grounded outlet for this produ t will ompromise this important
grounding safety feature. The use of adapters is not re ommended unless the outlet is he ked by a qualified ele tri ian to ensure
the proper grounding of the adapter. Please note: Unauthorized modifi ations to this produ t ould void the ele tri al portion of
your warranty.
This bed is spe ifi ally designed to require no maintenan e by you, the user. Any opening or tampering with the ontrol box,
motors or hand ontrols (with the ex eption of the battery ompartment if equipped) will result in a void of the warranty.
Only those authorized may ondu t repairs or part repla ement on your adjustable bed.
This Adjustable Bed is designed ex lusively for in-home use.
HOSPITAL DISCLAIMER: It is NOT designed for hospital use and is NOT designed to meet hospital standards.
Do not use this bed with TENT TYPE oxygen therapy equipment or use near explosive gases.
GROUNDING SAFETY
WARRANTY WARNING!
IN-HOME USE ONLY
IMPORTANT SAFETY FEATURES
FOR OPTIMAL SAFETY, YOUR ADJUSTABLE BED SHOULD BE PLUGGED INTO A SURGE PROTECTOR
(not supplied with this Adjustable Bed).
1
Exclusiv ly D sign d by
ADJUSTABLE BEDZ
CUSTOM SLEEP
TO FIT YOUR LIFE
®
TM
Weight fail safe feature: In the ase that an overload of weight is pla ed on the head or foot me hanism, the ontrol unit will
automati ally stop all fun tions. The ontrol unit will automati ally resume all fun tions 30 se onds after ex ess weight is removed.
Th
DreamStar
World Class Adjustable Bed Base!
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:58 PM Pag 3

Saf ty Pr cautions-cont’d
It is possible that the (optional) vibrating feature of this bed may be misinterpreted by some pa emakers as movement and/or
exer ise. This is ommon with any produ t that produ es a vibrating motion, and may or may not affe t your pa emaker. Please
onsult your physi ian with any on erns.
CONSUMERS WITH PACEMAKERS
FCC omplian e devi e omplies with part 15 of the FCC Rules. Operation is subje t to the following two onditions:
(1) This devi e may not ause harmful interferen e, and (2) this devi e must a ept any interferen e re eived,in luding
interferen e that may ause undesired operation.
Any hange to the antenna or the devi e ould result in the devi e ex eeding the RF exposure requirements and void user’s
right to operate the devi e.
The input transformer voltage is AC120V 60HZ; the output voltage is DC24V 3A. In the ase of a short- ir uit, a fuse on the
transformer will blow to prote t the ele tri al equipment of the devi e (Fuse: 1A~1.5A.). Should this o ur, you should seek
professional assistan e to fix the problem, and all Customer Care at: 1-877-826-8757
Immediately dispose of all pa king materials as it an pose a smother risk to small hildren and pets. Injury ould o ur also if
hildren or pets are permitted to play on or under the bed. Do not allow hildren to operate this bed without adult supervision.
RADIO FREQUENCY IS 433.92 MHZ.
PRODUCT RATINGS
SMALL CHILDREN AND PETS WARNING
2
Lift Motor Restri tions: The lift motors in this bed are NOT designed to operate ontinuously for more than three (3) minutes
over a thirty (30) minute time period, or approximately 10% duty y le. To ensure reliable fun tionality and full life of this
produ t, do not attempt to ex eed these limits.
NOTE: Att mpting to circumv nt or xc d this rating will short n th lif xp ctancy of th product and may void th warranty.
Weight Restri tions: The re ommended weight limits on our adjustable beds are:
Twin/TXL/Split QN/Split CA King: 575 Pounds, Full/FXL: 600 Pounds, Queen: 650 Pounds.
The stru ture of the bed will support the re ommended weight when distributed evenly a ross the bed.
The hea an foot sections are not esigne to in ivi ually support or lift this amount of weight.
For optimal performan e, entering and exiting the adjustable bed with the bed in the flat or level position is re ommended.
NOTE: Exc ding th r comm nd d w ight r strictions could damag your adjustabl b d and void your arranty.
SAVE THESE INSTRUCTIONS!
Proper operation of your Adjustable Bed is necessary to ensure the long life and
durability you expect from a high-quality product. The manufacturer has tested
and inspected this product prior to shipment.
Th
DreamStar
World Class Adjustable Bed Base!
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:58 PM Pag 4

NOTE: Before discarding any packing materials, check the adjustable bed frame
carton and verify all items in the parts list are included:
3
A. Wireless Remote Control (1)
C. 6.5”Brush Steel Leg Supports (4) D. Inner Headboard Bra ket (2)
E. Outer Headboard Bra ket (2) G. Headboard Bra ket Bolt (6) I. 5/16 In h Washer (12)
J. 5/16 In h Nut (6)
**Only in TXL, SCK, SQ models.
Parts List
L. Wren h (1)
M. Vel ro Leg Strap (1)**
K. Allen Key Wren h (1)
Th
DreamStar
World Class Adjustable Bed Base!
B. “Quick-Slide”
Mattress Retainer Bar (2)
N. Loop Retainer An hor (4)†
† Indi ates Part is atta hed to Base
O. AC Outlet (2) †
CAUTION: Ele tri Plug output AC 120V.
Do not ex eed Max Power: 500 W
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:58 PM Pag 5

STEP 1.
For safety reasons, the following should be performed by 2 people.
Carefully lift the bed frame unit out of the shipping arton with the
top side fa ing downward.
STEP 2. Assembling Be Legs
For this step, you will need 4 bed legs (C), whi h an be found in the
A essories box. Turn ea h bed leg (C) in a lo kwise dire tion into
the threaded holes on the frame as shown. Repeat the bed leg
assembly for all 4 legs (C) provided.
STEP 3.
Remove and extend the power ord from the frame.
STEP 4.
Take plasti wrapping off the base frame.
STEP 5.
Carefully rotate the base frame so the top side is fa ing upward. Be
areful not to rest the frame on its side. The weight may damage the legs.
STEP 6.
Plug the power ord into a grounded ele tri al outlet.
STEP 7.
Install batteries in hand unit.
Try all fun tions on the hand ontrol to ensure all features are
operational.
If the bed does not work, refer to Troubleshooting on p.1.
STEP 8.
Return bed to flat or level position.
STEP 9. Attaching the “Quick-Slide”
Mattress Retainer Bar
Fasten the “Qui k-Slide” mattress retainer bar (B) to the foot of
the bed base using the “Qui k-Slide” method illustrated below.
(No tools or s rews are required)
Simply position the open ends of the Retainer Bar dire tly
aligned with the “Loop” Retainer An hors already installed to the
foot of the base surfa e. Slide the Retainer Bar forward allowing
the open ends to glide into the loop.
Installation Guid
Important!
MAKE SURE POWER CORDS DO NOT OBSTRUCT
ANY ADJUSTABLE BED MECHANISMS.
NOTE:For optimal safety, a surge prote tor should be
used (not supplied with this Adjustable Bed).
If the adjustable frame is to be set up without a headboard,
simply install a mattress on the frame.Installation is now complete.
If a headboard is to be installed, proceed to step 10 on next page.
DO NOT OVERTIGHTEN
THE BED LEGS.
4
Th
DreamStar
World Class Adjustable Bed Base!
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:59 PM Pag 6

STEP 10. Assemble the Hea boar Bracket
i. Use the hand ontrol to elevate the head of the bed so
the bed base frame is rea hable.
iv. When headboard bra kets are assembled, make sure there is a spa e of 1.5 (38.1 mm) to 2 in hes (50.8 mm)
between the edge of the bed base and the headboard bra kets.
v. Se urely fasten the headboard bolts (not in luded with your adjustable bed) to the end of the headboard bra ket assembly.
vi. Measure the distan e from the enter of one mounting hole in the headboard to the enter of the other.
vii. Measure the distan e from the enter of one mounting hole in the headboard bra ket assembly to the enter of the other.
viii. If you need to adjust the headboard bra kets, uns rew the bolts holding the outer headboard bra kets and move them
the ne essary distan e. Reinstall the bolts and se urely tighten.
STEP 11.
Pla e your mattress on the adjustable bed frame surfa e. Your adjustable bed and headboard installation is now omplete.
If the bed omes with a programming option, turn to the Wireless Hand Control Operation Guide (lo ated on page 8) to pro eed.
ii. Slide the inner headboard bra ket (D) horizontally with the
“C” opening fa ing down under the Crossbar. Position the
Bra ket (D) in the guide peg on the bottom of the Crossbar.
Insert a headboard bolt (G) fitted with a 5/16 in h washer (I)
thru the pre-drilled hole in the Crossbar & into the pre-drilled
slotted hole in the “C” hannel Inner Headboard Bra ket.
Tighten in pla e with a 5/16 in h washer (I) and 5/16 in h nut
(J). Repeat on the other side.
iii. Pla e the open side of the outer headboard bra ket (E) onto
the exposed square tube of the inner headboard bra ket (D) to
reate a tight fit between (D) and (E). Insert a retainer bolt (G)
fitted with a 5/16 in h washer (I) into the outer headboard
bra ket (E) and through the inner headboard bra ket (D). Hand
tighten using a 5/16 in h washer (I) and a 5/16 in h nut (J).
(Leave loose enough for adjusting.) Repeat on
the other side.
Velcro Leg Straps (Optional: To avoid Base Separation)
5
To help prevent separation when using King Size (2 TXL)
California King Size (2 SCK) or split Queen Size (2 SQ).
Please use the en losed Vel ro Straps.
1. Simply wrap the legs together (Front & Ba k) tightly
using the vel ro straps.
2. Fastening the straps will help prevent movement &
maintain stability.
IMPORTANT NOTES:
Failure to follow the installation steps as they appear in this gui e coul result in amage to your a justable be frame.
Make sure to position the bottom of the hea boar cross member no more than
3 inches (76.2 mm) between the hea boar an the top of the mattress.
Th
DreamStar
World Class Adjustable Bed Base!
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:59 PM Pag 7

1. Lo ate and remove the 9 volt battery over.
3. Repla e the battery over.
2. Install two (2) Alkaline 9 volt batteries.
(Not In luded)
Figure 5: 9 volt battery cover
Your adjustable base is equipped
with an emergen y lowering feature. Follow the steps below in the
event that your base is in the raised position during a power outage.
Figure 6: Install the 9 volt batteries
Figure 7: Replace battery cover
Figure 8: Lower the be using the 9 volt
battery backup system
NOTE:
THE TWO (2) 9 VOLT BATTERIES ARE ONLY RATED FOR SINGLE USE. AFTER
THE EMERGENCY LOWERING, REPLACE WITH NEW ALKALINE BATTERIES.
6
Wir l ss Em rg ncy Pow r Down F atur
Th
DreamStar
World Class Adjustable Bed Base!
4. When the two (2) 9-Volt batteries are installed in
the power supply, and there is a power failure, the
LEARN button on the Power Supply an be used
to move the bed to the flat position.
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:59 PM Pag 8

D ck-on-D ck
Platform D sign
The Deck-on-Deck design gives a
stylish appearance with graceful
flexibility & “Pinch-Free” edges.
Mod rn Styl
“Brush d-St l” L g Supports
The Brushed-Steel Finish adds chic-elegance that
will enhance any bedroom decor.
Und rb d LED Lighting
Safely navigate your way in & out of bed
by simply activating the Underbed
“Night Light” from your remote. The
softly illuminating LED Lamps create a
‘Halo’ effect around your bed so you can
avoid hidden obstacles in the dark.
Dual Body Massag
Enjoy a relaxing body massage with
independent Head & Leg Massage Pods
that you can customize with varying speed,
intensity & WAVE mode options.
Automatic shut-off after full massage cycle.
7
Th
DreamStar
World Class Adjustable Bed Base!
Advanc d F atur Highlights
This Ultra-Premium Adjustable Bed combines style, with more innovative features &
options to totally customize & personalize your sleep experience.
Blu tooth Spak r Sound Syst m
for your List ning Pl asur
Revolutionary Wireless Speakers with
Surround Sound for listening
to music or enhancing game effects.
Advanc d “Ultra-Fr qu ncy”
Op rating Syst m (WiFi R ady)*
The Advanced “UF” wireless remote control system
with “Auto-Jump Signal” provides better performance
& response by always selecting the strongest
frequency. (* An optional WiFi Accessory box can
now be purchased separately allowing you to use
your smart device as a remote with our free app.)
AC
Mount d
Pow r Outl ts
The convenient AC plug oulets
on each side of the base
provides easy electrical access
for today’s high tech devices
NEW Dual “Quick-Slid ”
Mattr ss R tain r Syst m
The new, patent pending “U” shaped mattress Re-
tainer Bars now slide easily into the Head & Fook
deck sections with no screws, bolts or tools needed.
The DUAL system helps in securing the mattress so it
moves smoothly with the frame without bridging.
Custom“Edg -to-Edg “
Lumbar Support Syst m
The patented “Edge-to-Edge” Lumbar
System is independently power driven al-
lowing you to increase or decrease support
to your lower back. It is the ONLY Lumbar
Support System that spans the complete
mattress width.
CAUTION: Ele tri Plug output AC 120V.
Do not ex eed Max Power: 500 W
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 5:59 PM Pag 9

Hea an Foot Position A justments (A, B, C, D)
• Use to raise or lower the head and foot se tions of your adjustable bed. The premium “Wall-Glide”
feature will automati ally syn hronize with all Head & Foot adjustments.
LED Signal Light (E)
• Indi ates signal is being sent for operating fun tion.
Be “Flat” Button (F)
• Press down and hold for 3 se onds to return bed to the flat position.
Pre-Programme Memory Position (G)
• These 3 program fun tion keys allow you to sele t the most popular positions with one tou h.
®
E. LED Signal Light
A. Raises the Head of the Bed
B. Lowers the Head of the Bed
P. Increases Lumbar Support
F. Returns Head & Foot to FLAT
Position (hold 3 seconds)
H. Increases the Intensity
of Vibration (Head)
I. Decreases the Intensity
of Vibration (Head)
M. Full Body Massage
N. Turns on Massage
Wave 1,2 or 3
O. Under
Bed Light
C. Raises the Foot of the Bed
D.Lowers the Foot of the Bed
G. Pre-Programmed
Memory Positions
Q. Decreases
Lumbar Support
J. Increases the Intensity
of Vibration (Foot)
K. Decreases the Intensity
of Vibration (Foot)
L. Stops Massage
FOR YOUR SAFETY, READ THE OWNER’S MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING THIS PRODUCT. ELECTRIC
SHOCK MAY OCCUR IF ELECTRICAL COMPONENTS ARE NOT INSTALLED OR OPERATED ACCORDING TO THESE GUIDELINES.
Exclusiv
“Edge-to-Edge”
Lumbar F atur
For add d
back support
wh n you n d it!
8
Th
DreamStar
World Class Adjustable Bed Base!
Wir l ss Hand R mot Op ration
ALL IN ONE FILE- DREAMSTAR-NEW LAYOUT_Layout 4 8/27/15 6:00 PM Pag 10
