CyberData 11280 Manual

Installation Quick Reference
Singlewire Paging Adapter
011280
Quick Reference 930730E © 2015, CyberData Corporation, ALL RIGHTS RESERVED© 2015, CyberData Corporation, ALL RIGHTS RESERVED 930730E Quick Reference
The IP Endpoint Company
Mounting
Dimensions
You have the option to use the following mounting template to mark, and then drill two 3/16-inch (0.1875-inch) holes for
the mounting anchors.
To install and mount the Singlewire Paging Adapter:
1. Install the mounting anchors in the holes, and position the Singlewire Paging Adapter mounting holes over the
anchors.
Drill Hole Size for Anchor Installation: 3/16-inch (0.1875-inch)
Dimensions are in Inches [Millimeter]
4.1 [104.0]
6.0 [152.4]
1.2 [29.6]
Dimensions are in Inches [Millimeters]
Getting Started
• Be sure that you have received all the parts described in the Parts List section.
• Download the Operations Guide at the following website:
http://www.cyberdata.net/products/voip/digitalanalog/singlewirepagingadapter/docs.html
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Parts List
Contacting CyberData
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa
a. Default if there is not a DHCP server present.
10.10.10.10
Web Access Username admin
Web Access Password admin
Subnet Maska255.0.0.0
Default Gatewaya10.0.0.1
(1) Mounting Kit
(1) Singlewire Paging Adapter (1) Mounting Template
(2) #6 x1.25-inch, PanHead,
Phillips Sheet Metal Screw
(2) Plastic Anchors
(see the last page)
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: [phone] ext. 136
RMA Email: [email protected]
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/

© 2015, CyberData Corporation, ALL RIGHTS RESERVED 930730E Quick Reference Quick Reference 930730E © 2015, CyberData Corporation, ALL RIGHTS RESERVED
Connections
Typical Paging System Setup Using the Singlewire Paging Adapter
Pin 1 Pin2 Pin 3 Pin 4 Pin 5
Power
Page Port Output Connections
Pin Description
1 Not Used
2 Not Used
3 Positive 600-Ohm Audio Outputa
a. The 600-Ohm audio output of the
page port is also suited for interfaces
with lower input impedances.
4 Negative 600-Ohm Audio Outputa
5 Audio Ground Reference
6 Relay Contact - Commonb
b. 1 Amp at 30 VDC for continuous loads
7 Relay Contact - Normally Openb
Page Port Output
Pin 6 Pin 7
48VDC
Not Used Line Out
RTFM Switch
To restore the factory default settings:
1. Press and hold the RTFM switch while all the indicator
lights turn off.
2. Continue to press the switch until after the indicator lights
turn back on, and then release the switch.
Note: The “Restoring Defaults” announcement can be heard
if a speaker or amplified speaker is connected to the unit.
3. All Singlewire Paging Adapter settings are restored to the
factory defaults, and the unit reboots.
RTFM Switch
To announce the IP address:
1. Briefly press and then quickly release
the RTFM switch.
Note: The IP address announcement
can be heard if a speaker or amplified
speaker is connected to the unit.
IP to Analog Paging
Analog Amplifier
Singlewire Paging Adapter (Back View)
600 Ohm Page Port Out
Page Start Relay Output
Analog Horns/Speakers
RCA HiZ Line Out
10 Ohm 2v PP
PoE Network Cable SIP or Multicast
Analog Audio
Control (Dry Contact)
Analog Horns/Speakers
Analog Amplifier
Verifying Operations and Settings
Setting Up the Singlewire Paging Adapter
When you plug in the Ethernet cable or power supply:
•TheGREEN/BLUE Status LED and the GREEN
Paging LED both blink at a rate of 10 times per
second during the initial network setup.
• The round, GREEN/BLUE Status LED on the
front of the Singlewire Paging Adapter comes on
indicating that the power is on. Once the device
has been initialized, this LED blinks at one
second intervals.
• The square, GREEN/AMBER Link LED above
the Ethernet port indicates that the network
connection has been established. The Link LED
changes color to confirm the auto-negotiated
connection speed:
• The Link LED is GREEN at 10 Mbps.
• The Link LED is AMBER at 100 Mbps.
• The GREEN Paging LED comes on after the
device is booted and initialized. This LED blinks
when a page is in progress. You can disable
Beep on Initialization on the Device
Configuration page.
Status
(GREEN/BLUE LED)
Paging
(GREEN LED)
Link
(GREEN/AMBER LED)
Activity
(GREEN LED)
Chassis ground
Chassis Ground
PoE
Non PoE with 48 VDC Power Supply
To set up the device, connect the device to your network:
Poe
• For PoE, plug one end of an 802.3af Ethernet cable into
the Singlewire Paging Adapter Ethernet port. Plug the
other end of the Ethernet cable into your network. See
the figure on the left.
Non-Poe
• For Non-PoE, connect the Singlewire Paging Adapter to
a 48VDC power supply. See the figure on the left.
•Note: Do not use both PoE and external power.
Chassis Ground
• If required, connect the earth grounding wire to the
Chassis Ground. See the figure on the left.
48VDC
