CyberData 011405 Manual

Quick Reference 931979A © 2023, CyberData Corporation, ALL RIGHTS RESERVED
© 2023, CyberData Corporation, ALL RIGHTS RESERVED 931979A Quick Reference
Getting Started
• Download the Operations Guide PDF file from the Documents tab at the following webpage:
https://www.cyberdata.net/products/011405
• Create a plan for the locations of your paging amplifiers.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the
installation instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: The SIP Loudspeaker Amplifier enclosure is not rated for any AC voltages!
Parts
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa
a. Default if there is not a DHCP server present.
192.168.1.23
Web Access Username admin
Web Access Password admin
Subnet Maska255.255.255.0
Default Gatewaya192.168.1.1
(1) Assembly
(1) Wall Mounting Kit
(1) Enclosure
(4) #8 Plastic Anchors (4) #8 x 1-1/4" Pan Head Phillips Self-Tapping Screws
Mounting the Enclosure
IP66 Weatherproofing
Contacting CyberData
To mount the enclosure:
1. Prepare holes for the screws.
2. Plug in the power adapter and use
the Power (PWR) LED to verify that
the power is on.
3. Plug the ethernet cable into the
device. The Link/Activity (Link/
Act.) LED verifies the network
connection.
4. For wall mounting, use the three
#8 x 1-1/4-inch Pan Head Phillips
Self-Tapping Screws.
on the Inside
CG Hex Locknut
CG Sealing Washer
CG Hole Plug
Cord Grip & O-Ring
CG Connector
CG Sealing Grommet
CG End Cap
IP66 Enclosure
Analog Horn Speaker
IP66
Analog Horn Speaker
IP66
Network Cable to
Paging Amplier
Cable Gland (CG)
(Optional Secondary Horn)
Speaker Cable
(Primary)
Sales: 831-373-2601 ext. 334
Support: 831-373-2601 ext. 333
Support Website: https://support.cyberdata.net/
RMA Department Contact and Status: https://support.cyberdata.net/
Warranty Information: https://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
https://www.cyberdata.net/
Installation Quick Reference
SIP Loudspeaker Amplifier
(PoE)
011405
The IP Endpoint Company

Quick Reference 931979A © 2023, CyberData Corporation, ALL RIGHTS RESERVED© 2023, CyberData Corporation, ALL RIGHTS RESERVED 931979A Quick Reference
Dimensions
Mounting Brackets (package of four included)
5.12 [130] 7.87 [200]
11.81 [300]
Notes:
1. Dimensions
are in inches
[millimeters].
2. Projection:
Third Angle
Pull the mounting bracket
outward while tightening the
screw. Do the same to all
four mounting brackets.
Features of the Paging Amplifier
Enclosure Features
The IP Endpoint Company
RTFM Power
Paging
Amplier
Link / Act. Status
Status LED (GREEN)
The GREEN Status LED illuminates
after supplying power to the device.
Link/Network Activity (Link/Act.) LED (GREEN)
The GREEN Link/Network Activity (Link/Act.)
LED blinks to indicate network traffic.
Power (PWR) LED (GREEN/BLUE)
The Power (PWR) LED is:
GREEN in low power mode (802.3af)
BLUE during high power mode (802.3at).
RTFM Switch
To broadcast the device’s current IP address, press and hold the RTFM switch for a couple of seconds and then release it.
To restore the factory defaults, complete the following steps:
1. Press and hold the RTFM switch for several seconds.
2. Release the RTFM switch. The device will be restored to the factory default settings, and will announce "restoring defaults” and
“rebooting.”
*See the Operations Guide for more information about the features in this section.
HINGES
LATCHES
COVER OPEN LEFT
THREE CABLE GLAND WITH
ONE HOLE PLUG

Quick Reference 931979A © 2023, CyberData Corporation, ALL RIGHTS RESERVED© 2023, CyberData Corporation, ALL RIGHTS RESERVED 931979A Quick Reference
8.5 [216]
9.92 [252]
DIMENSIONS ARE IN INCHES [MILLIMETER]
In Order to Assure Size Accuracy,
Make Sure that PAGE SCALING is Select to NONE
Change this Settings by Selecting:
File, Print - PAGE HANDLING - Page Scaling to NONE.
After Printing, Verify that Size is Correct by
Checking Scale on Printed Page.
Prior to Printing this Mounting Template.
Click on "Properties" Tab
Change the Paper Size to 11" x 17" or
A3 (297mm x 420mm)
Mounting Hole (11/64”, 0.172” or 4.4mm)
t #8 Screw or 4mm Screw
Mounting Template
