VoIP V2 Loudspeaker Amplifier
CyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.netCyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.net
VoIP V2 Loudspeaker Amplifier
CyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.net
The IP Endpoint Company
The IP Endpoint Company
Features
 SIP and Simultaneous Multicast
 Dual-speed ethernet 10/100 Mbps
 Web-based configuration
 PoE 802.3at and 802.3af-enabled
 Line-in for background music
 Line-out connector
 DTMF controlled relay
 Direct 8 Ohm speaker drive
 User-uploadable tones and messages
 Digital and manual volume control
 Second SIP endpoint "Night Ringer"
 Autoprovisioning
 Auto-call voice message from input port sense
The new CyberData V2 SIP-enabled VoIP Loudspeaker
Amplifier provides an easy method for implementing an IP-based
overhead paging system for both new and legacy installations.
Now with up to 25 watts output (802.3at)
With up to 25 watts of driving power (802.3at), the Amplifier
provides direct drive of a standard Horn speaker and supports
a line-out connector for connection to an external amplifier.
The interface is compatible with most SIP-based IP PBX
servers that comply with the SIP RFC 3261. For non-SIP
environments, the Loudspeaker Amplifier can be configured to
listen to multicast address and port number combinations to
form paging zones.
Ringer Mode
The VoIP V2 Loudspeaker Amplifier supports two SIP
extensions. One extension can be assigned to a page group for
auto answer paging. The second extension can be assigned to
a “First-to-Answer” ring group with IP phones. An audio ring file
is activated when the second SIP extension of the ceiling
speaker is dialed. If any of the IP phones in the ring group is
answered (or if the caller hangs up), the Loudspeaker Amplifier
stops ringing.
Loudspeaker (part #011068) must be purchased separately.
Specifications
Output 802.3af - up to 8 watts
802.3at - up to 25 watts
Dimensions
Power Input PoE 802.3at or 802.3af
Ethernet I/F 10/100 Mbps
G711Payload Types
2 Years LimitedWarranty
Protocol SIP RFC 3261
Regulatory Compliance FCC Class A


-30 to 55 C (-22 to 131 F) Operating Temperature
14" x 10" x 4"
Boxed Weight 6.5 lbs.
Part Number
Loudspeaker Amplifier, AC 011095
Loudspeaker Amplifier, Wireless
Loudspeaker Amplifier, PoE 011097
011096
Line Out:
Output Signal Amplitudes 2.0 VPP maximum
Output Level +2dBm nominal
Total Harmonic Distortion 0.5% maximum
Output Impedance 10k Ohm
Line In:
Input Signal Amplitudes 2.0 VPP maximum
Input Impedance 10k Ohm
011068Loudspeaker Part Number

VoIP V2 Loudspeaker Amplifier
CyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.netCyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.net
VoIP V2 LoudspeakerAmplifier
930340G/110706
011097
011095
011096
VoIP V2 Loudspeaker Amplifiers – AC Required
Generic Wireless Ethernet Switch
IP-PBX ServerIP Phone
Typical Installation - Wireless 802.11g (Part# 011096)
1 2 3 4 5 6
VoIP V2 Loudspeaker Amplifiers – AC Required
Generic Ethernet Switch
IP-PBX ServerIP Phone
Typical Installation - AC Version (Part# 011095)
1 2 3 4 5 6
VoIP V2 Loudspeaker Amplifiers – No AC Required
802.3af Generic PoE Switch or
802.3at High Power Switch
IP-PBX ServerIP Phone
Typical Installation - PoE 802.3af (Part# 011097)
1 2 3 4 5 6
*For AC wiring, use a qualified electrician.
High Power PoE Injector in Box
High Power PoE Injector in Box

VoIP V2 Loudspeaker Amplifier
CyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.netCyberData Corporation 3 Justin Court, Monterey, CA 93940 831.373.2601 Fax: [phone] www.cyberdata.net
VoIP V2 Loudspeaker Amplifier VoIP V2 LoudspeakerAmplifier
930340G/110706
+
-DC
POWER SUPPLY
30 VDC @ 1A
MAX.
IN
Switching Diode
High PIV UltraFast
Solid State
or
Mechanical
Relay
Controlled Device
Depending Upon
AC or DC rated
Output Contacts
Requirements
Power Source
AC or DC
( )
OUT
IP Phone
Configuring the V2 Loudspeaker Amplifier for Alarm Sensing
When the V2 Loudspeaker
Amplifier is called from a remote
phone, the relay on the paging
amplifier can be programmed to
blink and drive an Alert Strobe.
V2 Loudspeaker Amplifier with Strobe Alert
V2 Loudspeaker Amplifier Connections
Loudspeaker Amplifier
Alert Strobe
1-Sense (+)
2-GND
3-Relay COM
4-Relay NO
5-Line-In(+)
6-Line-In(-)
7-Line-Out(+)
8-Line-Out(-)
9-Spkr Out(+)
10-Spkr Out (-)
CLASS II WIRING
User can upload an audio message
to the Loudspeaker Amplifier.
When the “Sense-In” is activated, the stored
Audio file will play out the local speaker and
repeat until the condition is cleared.
The Loudspeaker Amplifier can also call a
pre-set phone number and when that phone
answers, the stored Audio message will
also be played to the phone. Window Reed Switch
Window Reed switch is connected
to the “Sense-In” connection.
