CyberData VoIP V2 User manual

CyberData Ceiling Speaker V2
Admin Guide
Schmooze Com Inc.
CyberData
The IP Endpoint Company
Status
Link
RTFM Volume
w
w
w
.
c
y
b
e
r
d
a
t
a
.
n
e
t

How To Find The IP Address
Quick Steps
1. To find this IP address download CyberData’s VoIP Discovery Utility program which allows
you to easily find and configure the default web address of the CyberData VoIP products.
CyberData’s VoIP Discovery Utility program is available at the following website address.
http://www.cyberdata.net/support/voip/discovery_utility.html
.How To Find The MAC Address
Quick Steps
1. Login to the Web GUI of the device by putting the IP address of the device into your browser.
Login to the device when prompted. The factory default username is admin and the
password is also admin.
2. Once logged in scroll to the bottom of the page and you should see the MAC and IP address
© Copyright Schmooze Com, 2012
How To Set The Configuration Server
Quick Steps
1. Login to the Web GUI of the device by putting the IP Address of the device into your browser.
Login to the device when prompted. The factory default username is admin and the
password is also admin.
2. Once logged in click on the “Autoprovisioning” option on the left side.
3. Fill in the following information.
• Enable Autoprovisioning - Check the box
• Get Autoprovisioning from DHCP - Check the box
• Autoprovisioning Server (IP Address) - Define the IP address of your PBX in our
example this is 10.10.0.1
4. Don’t forget to press the save and then reboot button at the bottom of
the page when done.
How To Factory Default
Quick Steps
1. Press and hold the RTFM switch until the button LED starts blinking rapidly (about 10
seconds), then release the RTFM switch.
2. The device announces that it is restoring the factory default settings.
The server http://10.10.0.223:80 requires a username
and password. The site says: CyberData VoIP Strobe.
User Name:
Password:
Cancel Log In
admin
••••

How To Find The IP Address
Quick Steps
1. To find this IP address download CyberData’s VoIP Discovery Utility program which allows
you to easily find and configure the default web address of the CyberData VoIP products.
CyberData’s VoIP Discovery Utility program is available at the following website address.
http://www.cyberdata.net/support/voip/discovery_utility.html
.How To Find The MAC Address
Quick Steps
1. Login to the Web GUI of the device by putting the IP address of the device into your browser.
Login to the device when prompted. The factory default username is admin and the
password is also admin.
2. Once logged in scroll to the bottom of the page and you should see the MAC and IP address
How To Set The Configuration Server
Quick Steps
1. Login to the Web GUI of the device by putting the IP Address of the device into your browser.
Login to the device when prompted. The factory default username is admin and the
password is also admin.
2. Once logged in click on the “Autoprovisioning” option on the left side.
3. Fill in the following information.
• Enable Autoprovisioning - Check the box
• Get Autoprovisioning from DHCP - Check the box
• Autoprovisioning Server (IP Address) - Define the IP address of your PBX in our
example this is 10.10.0.1
© Copyright Schmooze Com, 2012
4. Don’t forget to press the save and then reboot button at the bottom of
the page when done.
How To Factory Default
Quick Steps
1. Press and hold the RTFM switch until the button LED starts blinking rapidly (about 10
seconds), then release the RTFM switch.
2. The device announces that it is restoring the factory default settings.
The server http://10.10.0.223:80 requires a username
and password. The site says: CyberData VoIP Strobe.
User Name:
Password:
Cancel Log In
admin
••••

How To Find The IP Address
Quick Steps
1. To find this IP address download CyberData’s VoIP Discovery Utility program which allows
you to easily find and configure the default web address of the CyberData VoIP products.
CyberData’s VoIP Discovery Utility program is available at the following website address.
http://www.cyberdata.net/support/voip/discovery_utility.html
.How To Find The MAC Address
Quick Steps
1. Login to the Web GUI of the device by putting the IP address of the device into your browser.
Login to the device when prompted. The factory default username is admin and the
password is also admin.
2. Once logged in scroll to the bottom of the page and you should see the MAC and IP address
How To Set The Configuration Server
Quick Steps
1. Login to the Web GUI of the device by putting the IP Address of the device into your browser.
Login to the device when prompted. The factory default username is admin and the
password is also admin.
2. Once logged in click on the “Autoprovisioning” option on the left side.
3. Fill in the following information.
• Enable Autoprovisioning - Check the box
• Get Autoprovisioning from DHCP - Check the box
• Autoprovisioning Server (IP Address) - Define the IP address of your PBX in our
example this is 10.10.0.1
4. Don’t forget to press the save and then reboot button at the bottom of
the page when done.
How To Factory Default
Quick Steps
1. Press and hold the RTFM switch until the button LED starts blinking rapidly (about 10
seconds), then release the RTFM switch.
2. The device announces that it is restoring the factory default settings.
© Copyright Schmooze Com, 2012
