Quick Reference 931190A © 2016, CyberData Corporation, ALL RIGHTS RESERVED© 2016, CyberData Corporation, ALL RIGHTS RESERVED 931190A Quick Reference
4.00 [101.6]
120°
VoIP Speaker
Mounting Template
Speaker Hole Diameter:
7.50 [190.5]
Screw Hole Diameter:
0.1875 [4.75]
Dimensions are in inches [millimeter]
Typical System Installation
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following webpage:
http://www.cyberdata.net/voip/011397/
• Create a plan for the locations of your SIP Talk-Back Speakers.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa
a. Default if there is not a DHCP server present.
10.10.10.10
Web Access Username admin
Web Access Password admin
Subnet Maska255.0.0.0
Default Gatewaya10.0.0.1
802.3af/at Compliant Ethernet Switch
IP PhoneSIP Talk-Back Speaker IP PBX ServerSIP Speaker
Optional Remote Call Button
(not included and sold separately)
(3) #8 Nylon Thumb Nuts
(3) #8 Fender Washers
(3) 8-32 x 1 1/4” Mounting
Screws
(1) Speaker Assembly (1) Drop Ceiling Mounting Kit (1) Drywall Mounting Kit
(3) Plastic Ribbed Anchors
(3) #8 Sheet Metal Screws
* See the last page
of this document
(1) Template
The IP Endpoint Company
Installation Quick Reference
SIP Talk-Back Speaker
SIP Compliant
011397*, RAL 9002, Gray White, Standard
011398*, RAL 9003, Signal White, Optional
*Replaces the 011180 and 011181 numbers.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

© 2016, CyberData Corporation, ALL RIGHTS RESERVED 931190A Quick Reference Quick Reference 931190A © 2016, CyberData Corporation, ALL RIGHTS RESERVED
Mounting
Contacting CyberData
*Ceiling Tile or DryWall
VoIP V3 Speaker
Assembly
#8 Fender Washer (3x)
#8 Nylon Thumb Nut (3x)
#6 Screw (3x)
DryWall Mounting Kit
Template
Plastic Ribberd Anchor (3x)
DryWall Mounting Kit
#8-32x1 1/4" (3X)
Ceiling Mounting Screw
*Optional Reinforcement Mount
P/N: 010991A (Sold Seperately)
Tools Required for Installation:
• (1) Sheetrock saw or
(1) Drywall cutter
• (1) #2 Phillips Screwdriver or
(1) #2 Phillips Screwdriver Hex Bit
To mount a speaker:
1. Use the TEMPLATE on the back of this
document to cut a hole in the wall or ceiling,
and prepare holes for the screws.
2. Plug the Ethernet cable into the speaker
assembly. The yellow light verifies the
network connection.
3. For drop ceiling mounting, position the
SPEAKER ASSEMBLY in the ceiling so
that its screw holes align with those you
prepared.
4. For drywall mounting, place the three
PLASTIC RIBBED ANCHORS in the holes
you prepared, and position the SPEAKER
ASSEMBLY over them, aligning the screw
holes in the assembly with the anchors.
5. For drop ceiling mounting*, use the three
8-32 x 1 1/4" MOUNTING SCREWS, #8
NYLON THUMB NUTS, and #8 FENDER
WASHERS to secure the speaker.
For drywall mounting, use the three #8
SHEET METAL SCREWS to secure the
speaker.
* For weak ceiling tile, CyberData offers a
reinforcing mount (CyberData part number
010991A).
Speaker
Assembly
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: [phone] ext. 136
RMA Email: [email protected]
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/
Dimensions and Connections
Connecting Power
Features
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT (-)
LINE OUT (+)
BUTTON LED (-)
BTN SENSE
BUTTON LED (+)
RELAY NO
RELAY COM
AUX POWER (-)
AUX POWER (+)
(+12VDC @ 1A)
J10 J9
CLASS II WIRING
9.000 [228.60] 3.140 [79.75]
DIMENSIONS ARE IN INCHES [MILLIMETER]
9.000 [228.60] 3.140 [79.75]
DIMENSIONS ARE IN INCHES [MILLIMETER]
802.3af Compliant PoE Switch
PoE Injector (part #010867)
Non PoE Switch
RTFM Switch
To broadcast a device’s current IP address, press and
release the RTFM switch within a five second window.
To restore a device’s factory default settings, press and hold
the RTFM switch for more than five seconds.
Speaker Volume
Network Link/Activity LED (yellow)
Speaker Status LED (green)
A solid light confirms that the speaker is operational.
Microphone
