CyberData DX80 Manual

Quick Reference 931352A © 2017, CyberData Corporation, ALL RIGHTS RESERVED© 2017, CyberData Corporation, ALL RIGHTS RESERVED 931352A Quick Reference
Getting Started
Take the following into consideration before you install this product:
• Due to the size and mass of this product, it is important that the Backbox is safely installed according to these installation
instructions.
• Make sure that the type of wall is capable of supporting the system and use screws that are suitable for that type of wall.
• The system must be installed by qualified personnel in accordance with state and local building regulations.
• Also see the Install the DX80 Phone to Enclosure (on the other page).
• Locate the provided Security Torx Driver Bit (usually taped right next to the Hookswitch on the Faceplate).
• Tool required to remove Security Torx Screws (an Electric Hand Drill or Powered Screwdriver)
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Hookswitch Wires to USB to Analog Audio Module Connections
Contacting CyberData
Black Wire USB - B Plug
on DX80
USB - A to B Cable
1
2
3
4
6
7
8
Plug in to Connector Panel
Plug in to (J1)
USB - A Plug
J4
J1
Red Wire
FACTORY DISCONNECTED
RECONNECT BEFORE FASTEN
FACEPLATE TO BACKBOX
***
ASSEMBLY
HOOKSWITCH
Red Wire to J4 (Position 5)
Black Wire to J4 (Position 9)
5
9
& WIRES TO SOCKET
SOCKET
PLUG
FACTORY PRE-INSTALLED
WIRES TO PLUG
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: [phone] ext. 136
RMA Email: [email protected]
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/
Backbox Mounting Holes Dimensions
Armored Cord Handset to USB to Analog Audio Module
27.559 [700.00]
19.685 [500.00]
9.843 [250.00]
1.969 [50.00]
9.114 [231.50]
6.690 [169.92]
4.016 [102.00]
Approx.
5.118 [130.00]
2.047 [52.00]
2.421 [61.50]
12.567 [319.19]
22.953 [583.00]
9.114 [231.50]
2.047 [52.00]
5.118 [130.00]
16.929 [430.00]
Front
Bottom
Rear
Front
Left
Rear
Rear
Top
Front
Right
Front
Top
Top
Top
ø1.160 [ø29.50]
1.230 [31.25]
Hole Diameter
Typical EMT Fitting
4
Knock Out
Knock Out
ø0.63 [ø16.0]
ø0.41 [ø10.5]
Tool Required to Remove
1) Hammer
2) Screwdriver
Knock Out:
2
One Inch Conduit
EMT Fitting
Conduit Hole Fits
(One on Each Side)
ø1.30 [ø33.0]1
3
Knock Out Knock Out Knock Out
View Shown with
Hole Plug Installed
Open Faceplate
then Remove Fastener
from the Inside
Tool Required to Remove
1) 3/8” Socket / Wrench
or 9mm Socket / Wrench
Nut Behind:
Notes:
1) Dimensions are in Inches [Millimeter]
2) Mounting Holes Fit Up to 1/4" Square Neck Carriage Bolt, 1/4" Self-Tapping or 10 Millimeter Machine Screw
3) 1" EMT Fitting is not provided.
Red Wire to J4 (Position 1)
Green Wire to J4 (Position 3)
Black Wire to J4 (Position 4)
Yellow Wire to J4 (Position 2)
J4
1
2
3
4
5
9
1) #00 size Phillips Screw Driver
Tool Provided for Terminal Block Screw:
6
7
8
Armored Cord Wires End
The IP Endpoint Company
Installation Quick Reference
DX80 Secure Phone
011416

© 2017, CyberData Corporation, ALL RIGHTS RESERVED 931352A Quick Reference Quick Reference 931352A © 2017, CyberData Corporation, ALL RIGHTS RESERVED
Install the DX80 Phone to Enclosure
2) Screwdriver or Nose Plier
1) Hammer
Tool Required to Remove Knockouts (KO):
KO
1/4" Self-Tapping Screw
Up to 1/4" Square Neck Carriage Bolt
Knockouts (KO) & Keyhole Fit:
or 10 Millimeter Machine Screw
KO
KO
KO
KO
KO
Place Phone
Power Supply
inside Holder
Connections
Label
ASSEMBLY
BACKBOX
Plug Power Plug
in to Power Jack
on the Connector Panel
Connector Panel
IEC Power Cord
The Other End
Through Desire
Conduit Hole Exit
to Power Source
Use Provided Security Torx
Driver Bit to Fasten Screws
Use Clean Damp Cloth to Wipe Surface Clean
Screen Cleaning Instruction:
Plexiglass Cleaning Instruction:
Plexiglass Cleaner to Wipe Surface Clean
ASSEMBLY
FACEPLATE
to Backbox
Tool Required:
Electric Hand Drill or
Powered Screwdriver
USB to Analog Audio Module Diagram
See Hookswitch to
for Details Connections
Open Wrench or Box Socket
Use 11/32" or 9mm
To Remove Nut
Connector Cover
Camera
Holder
Foot Stand
CLAMP
CLAMP
Strain Relief Bar Plate
Microphone
Microphone
Stand
Stand
Camera
Front
Behind
Turn to Open Lens Cover
on DX80 Phone
Use a Paper Clip Through Hole
to Access Power Button
Protective Film
from Both Sides
Before Close the Faceplate
*
6" Wire Tie (2x) Wire Tie Mounting
1.5" Square
Base (2x)
Use provided cable management kit
to bundle up cables
#00 size Phillips Screw Driver
Jumper Shunt
Accessory Kits in Ziploc Type Bag Phone Mounting Instruction:
Sightly Push Downward to Engage Locking
5) Place Strain Relief Bar on Top of CLAMPs
1) Lift Connector Cover Up
3) Place Foot Stand Behind Plate,
Microphones on to Stands.
2) Plug in All Neccessary Cables,
Cables Must be Placed Behind Strain Relief Bar
To Remove Phone from Box:
1) Lift Phone Up in Slow Motion then Remove
All Cables from Connector Panel.
JP2
Shunt
Install a Shunt on JP2 to
Enable Auto Answer Mode
