CyberPower CP600LCD Manual

IntellIgent lCD SerIeS
The CyberPower Intelligent LCD CP600LCD uninterruptible power supply (UPS) safeguards mid- to high-end computer sys-
tems against surges/spikes and offers battery backup in the event of brownouts or blackouts.
The CP600LCD unit has a capacity of 600VA/340Watts, eight (8) NEMA 5-15R receptacles, including four (4) fail-safe outlets
for critical loads. The intelligent multi-function LCD panel displays real-time UPS vitals for ease of control. This unit offers
connectivity via one (1) HID USB port, as well as protection for phone/network (RJ11/RJ45) and cable/coax (RG-6). It has one
(1) maintenance-free, user-replaceable 12V/7Ah battery and includes EMI/RFI filters to increase the immunity of the load to
disturbances and surges. PowerPanel®Personal Edition UPS Management software automatically closes computer files and
safely shuts down the system in case of a power outage.
PowerPanel®Personal Edition: In event of a power
outage, PowerPanel PE saves open files and “hibernates”
the PC to increase the run-time on the UPS unit. Power-
Panel is easily installed on any Windows-based PC and
uses minimal system resources. Diagnostic screens display
the status of the UPS, including silent operation mode,
configurable system notifications, automatic self tests,
adjustable high/low voltage warnings, event/data logging,
and scheduled shutdowns.
Technical Support: CyberPower assists users with any
product, installation, or warranty concerns – free of charge.
3-Year Warranty: Stringent manufacturing processes and
innovative product design enables CyberPower to offer one
of the strongest warranties in our industry. CyberPower will
repair or replace damaged units within three (3) years of
purchase date.
ISO and Safety Certifications: All CyberPower manufac-
turing facilities are state-of-the-art and ISO-9001 Quality
Tested. Our products are certified by the FCC, cUL, and UL.
Windows Compatibility: Our PowerPanel®power manage-
ment software has been fully tested and is compatible with
Windows 2000, 2003, XP 32/64, Vista 32/64, 7, and
Server 2008.
Intelligent LCD Diagnostic Display: The innovative front
panel displays 9 different UPS vitals: input voltage level,
output voltage level, battery capacity, runtime estimate, load
level, on battery, overload, fault condition, and silent mode.
Transformer-Spaced Outlets; Widely-spaced outlets
accommodate large transformer-based plugs without com-
promising the utility of other outlets.
USB Connectivity: HID compliant USB port enables full
integration with built-in power management and auto shut-
down features of Windows, Linux and Mac OS X.
EMI/RFI Filters: Shielding against electromagnetic interfer-
ence and radio frequency signals prevents line noise (“hum-
ming”) over telephone lines or audio systems.
Audible Alarms: Distinctive tones identify when the unit
is running on battery power, if it is overloaded or when the
battery is low.
Resettable Circuit Breaker: The user may use this
convenient unit reset switch in case of an overload.
CP600LCD
The CP600LCD UPS system offers full-time surge protection and battery backup.
FEATURES & BENEFITS:
KEY FEATURES:
•600VA / 340W Simulated sine wave
•Standby Topology
•Multi-function LCD display
•Compact Desktop Form Factor
•RJ11/RJ45 Protection
•8 Outlets / USB port
•EMI/RFI filters
•PowerPanel®Personal Edition
DESIGNEDS FOR:
•Home Office/Small Office
Networks & Equipment
•Workstations/PCs
•Internetworking Hardware
•Home Theater System Equipment
•Surveillance & Security Systems
•Personal Electronics
•POS Systems
Runtimes:
2 Minutes at Full-load
9 Minutes at Half-load
CyberPower Systems, Inc.
4241 12th Ave. E. Suite 400
Shakopee, MN 55379
Toll-free 877.297.6937
CPSww.com

IntellIgent lCD SerIeS
© 2011 CyberPower Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners. CyberPower reserves the right to modify product information or specifications
without previous notice. The information presented is accurate at the time of publication. 11-2011
CyberPower Systems, Inc. designs and manufactures state-of-the-art power protection and distribution equipment for corporate, business, home, government and edu-
cational markets. CyberPower leads the industry by surpassing customer expectations in the development, design, construction, durability and functionality of uninterrupt-
ible power supply (UPS) products for computers, peripherals and connected devices. CyberPower Systems operates in the Asian Pacific, North American, and European
markets. For additional information, including sales office locations and authorized reseller partners, visit CPSww.com.
Resettable Circuit
Breaker
Phone/Fax/Modem
(RJ11/RJ45) Surge
Protected Ports
USB Communication
Port to PC
Intelligent LCD
Diagnostic Display
On/Off
Power Button
4 Full Time Surge
Protected Outlets
(2 Transformer
Spaced Outlets)
Power On
Indicator Light
4 Full Time Surge
Protected Battery
Backup Outlets
(2 Transformer
Spaced Outlets)
Wiring Fault
Indicator Light
CP600LCD SPECIFICATIONS
GENERAL
UPS Topology Standby
INPUT
Voltage 100Vac - 140Vac
Frequency 60Hz +/- 3Hz
Plug Type NEMA 5-15P
Plug Style Right angle
Cord Length 6’
OUTPUT
VA 600
Watts 340
On Battery Voltage 120Vac +/- 5%
On Battery Frequency 60Hz
On Battery Waveform Simulated Sine Wave
Outlets-Total 8
Outlet Type NEMA 5-15R
Outlets - Battery & Surge Protected 4
Outlets - Surge-Only Protected 4
Outlets - Widely Spaced 4
BATTERY
Runtime at Half Load (min.) 9
Runtime at Full Load (min.) 2
Battery Type Sealed lead acid
Battery Size 12V/7AH
User Replaceable Yes
Typical Recharge Time 8 Hours
Replacement Battery BB Battery - SH1228W
Battery Quantity 1
SURGE PROTECTION & FILTERING
Surge Suppression 1,030 Joules
Phone / Ethernet RJ11 / RJ45 1-In, 1-Out (Combo)
EMI/RFI Filtration Yes
MANAGEMENT & COMMUNICATIONS
Multifunction LCD Display Yes
HID Compliant USB Port Yes
Serial Port No
Management Cable USB cable
LED Indicators Power on, wiring fault
Audible Alarms On battery, low battery, overload
Software PowerPanel®Personal Edition
PHYSICAL
Dimensions (WxHxD) 11” x 6.5” x 3.5”
Weight (lbs.) 14
CERTIFICATIONS
Certifications UL1778, cUL 107.1, FCC DOC Class B
RoHS Compliant Yes
WARRANTY
Product Warranty 3 Years Limited
Connected Equipment Guarantee Lifetime
CEG Amount $175,000
