cyclotest mySense User manual
Instructions for use
www.cyclotest.de
mySense
EN-2 EN-3
Intended useTable of contents
Intended use
Safety instructions
Operating the device
Technical information
Cleaning and care
Warranty
cyclotest®service hotline
Device description
Display
Initial device setup
Temperature measuring
Recalling saved measurement values
Establishing a data connection to the mySense app
Battery display/changing the battery
Changing devices
Error messages
Technical data
Customer service
Explanation of symbols
Disposal
3
4
6
7
7
9
12
13
14
15
16
17
18
19
19
20
21
22
The cyclotest®mySense is a medical digital thermometer (direct
mode) for the self-measurement of human basal body temperature.
The device transmits the measured values to the cyclotest®mySense
app via a Bluetooth 4.0 interface.
The device is intended exclusively for use with the cyclotest®mySense
app. The device cannot be operated without the cyclotest®mySense
app or with other apps.
EN-4 EN-5
Safety instructions Safety instructions
• The device must be used solely for the purpose described in these
operating instructions. The manufacturer shall not be held liable for
any damages resulting from improper use.
• Protect the device from dirt, dust and strong sunlight and keep the
device away from excessive heat or cold.
• Using the thermometer in a way that does not comply with the in-
tended operating conditions can result in inaccurate measurement
values.
• Before each measurement, check the integrity of the measuring tip.
A damaged measuring tip can cause injuries.
• Do not bite or bend the sensor. This can cause damage and lead to
malfunctions.
• The use of this device near mobile phones, radios or other strong
electromagnetic elds can cause errors and malfunctions. Maintain
a distance of at least 3.3metres from such devices when using the
device.
• The thermometer contains small parts that could be swallowed by
children. Do not leave the device unattended with children.
• If the device is not being used for an extended period of time, re-
move the battery.
• Always store the thermometer in the protective cover.
• Do not open the device (except when changing the battery).
• Do not allow the thermometer to fall on the oor. The thermometer
is not shock-resistant or impact-resistant.
EN-6 EN-7
Operating the device Operating the device
Device description
1
5
2
3
4
1
2
3
4
5
Gold-plated measuring tip
Illuminated display
On/o button
Battery compartmentData transfer and memory
recall button
Display
1 5
26
37
4
46 5
1
2
3
7
Bluetooth data connection
Temperature unit °C/°F
Synchronising
Battery display Time
Date
Memory mode
Initial device setup
You must install the cyclotest®mySense app on your smartphone be-
fore setting up the device for the rst time. The cyclotest®mySense
basal body temperature thermometer cannot be set up without the
cyclotest®mySense app.
Download the cyclotest®mySense app from the Apple App Store or
the Google Play Store onto your smartphone.
EN-8 EN-9
Operating the device Operating the device
Open the cyclotest®mySense app and complete the user registration.
Follow the instructions in the app.
If you already have an account for the cyclotest®mySoul app, you can
use these details to log in to the cyclotest®mySense app. Your data
will then be transferred from the mySoul app.
During the registration process, you will be asked to enter an acti-
vation code for the thermometer. You will nd this activation code
in the packaging of your cyclotest®mySense basal body temperature
thermometer.
Once you have successfully completed user registration, the Blue-
tooth function on your smartphone will be enabled and the app will
search for available devices.
Now switch the thermometer on. To do this,
press and hold the on/o button for at least
1 second.
The device switches on and automatically does
into SET mode, where you can set the date and
time (Figure 1).
The date and time are synchronised automati-
cally from the mySense app. To do this, the de-
vice connects to the app via Bluetooth (Figure 2).
If the connection is successful, the “APP” indicator
appears and the display lights up green (Figure 3).
If the device cannot connect to the app, it switch-
es o after 60 seconds. If this occurs, check
whether Bluetooth is enabled on your smart-
phone and that the mySense app is running. Now
try to establish a connection again.
Once the device is connected successfully, you will be prompted to
perform a test measurement. This test measurement is used to en-
sure that the thermometer and app are functioning correctly and is
not saved.
To perform the test measurement, please follow the instructions in
the app and refer to the instructions for measuring wake-up temper-
ature starting on page 10.
• Switch on the device by pressing and holding the on/o button for
at least 1 second.
• The “On” indicator appears on the display (Fig-
ure 1).
• The device now performs an internal self-test;
all display elements are displayed (Figure 2).
• If measurement values have already been
saved, the most-recently measured value is
shown in the display with an M (memory). The
display switches between the measurement
value and the year, date and time of the meas-
urement (Figure 3).
• The device now checks whether all previ-
ous measurement values have already been
transferred to the mySense app. The device
can temporarily store up to 30 measurements.
Viewing the most-recent measurement value
Checking the transfer status
Temperature measuring
Figure 1
Figure 2
Figure 3
Figure 1
Figure 3
Figure 2
EN-10 EN-11
Operating the device Operating the device
• If you perform more than 30 measurements
without transferring the values to the mySense
app, the oldest value is deleted to make room
for a new measurement.
The device is now ready to perform a new
measurement (Figure 7). Never start the meas-
urement before this indicator appears on the
display. The thermometer must already be in
measurement mode when you start measuring
to be able to correctly record the progress of the
measurement.
Take the measurement within the selected meas-
urement timeframe immediately after waking up. Take the measure-
ment even before you get up.
You should have slept at least 5hours before taking a measurement.
If you have not had enough sleep, skip the measurement.
• Insert the measuring tip under the tongue, to the left or right of
the root of the tongue. The temperature sensor must make good
contact with the tissue.
• During the measurement, the current temper-
ature is shown on the display. You must wait
until the measurement is complete to ensure
the accuracy of the temperature value.
• A long beep indicates that the measurement is
complete. The measurement value is shown
on the display (Figure 9).
• If the thermometer measures a temperature
that is higher than 37.50°C, the display switch-
es between the temperature and HI (fever
warning, Figure 10). This measurement will
not be included in the cyclotest®mySense
app’s cycle calculations.
• The device now tries to establish a Bluetooth
connection to transfer the measured value to
the mySense app. Make sure that the smart-
phone is within range, Bluetooth is enabled
and the mySense app is running.
• If the connection is successful, the “APP” indi-
cator appears and the display lights up green
(Figure 11). Once the data has been trans-
ferred, the thermometer switches o auto-
matically (Figure 12).
• Close your mouth and breathe calmly through your nose so that
the measurement result is not aected by the air that you breathe.
• As long as the measured temperature re-
mains below the measuring range (32.00°C
to 43.99°C), the display shows L (low) (Figure
8). Have a little patience during the measure-
ment. The sensor must rst warm up from
room temperature to body temperature.
Measuring wake-up temperature
Figure 6
Figure 7
Figure 8
Figure 9
Figure 10
Figure 11
• If more than 25 saved measurements have
not been transferred to the mySense App, the
message “APP/FULL” (Figures 5 and 6) appears
on the display to remind you to transfer the
measurement values to the app as soon as
possible.
• The number of measurement values not yet
transferred is shown on the display (Figure 4).
Figure 4
Figure 5
Figure 12
EN-12 EN-13
Operating the device Operating the device
Recalling saved measurement values
The thermometer has a measurement value memory with 30 save
slots. The measurement values are saved automatically together with
the date and time of the measurement. The most recently measured
value is stored in save slot 1; the value measured prior to that is stored
in save slot 2, and so on. If more than 30 measurements are taken,
the oldest value (no. 30) is deleted so that the most recent value (no.
1) can be saved.
The measurement values and lots of additional information are saved
in the mySense app, where they can be analysed with ease.
You can also recall the last 30 readings directly from the mySense ba-
sal body temperature thermometer. To do so, proceed as follows:
• With the device switched o, press and hold the
memory recall button for at least 5 seconds
until the icon appears on the display. The de-
vice switches to memory mode (Figure 1).
• The most recently meas-
ured value, no. 1, is now
displayed (Figure 2, Figure
3). The display switches
between the measure-
ment value and the year,
month/day and time. For
measurement values that have been transferred to the mySense
app, the symbol is displayed.
• By repeatedly pressing the memory recall
key , you can call up the previous measure-
ments (no. 2, no. 3 ...).
• If no measurement values are saved, the fol-
lowing appears on the display (Figure 4):
Figure 3
Figure 2
Figure 1
Figure 4
• If the device cannot establish a connection, the measurement value
is stored on the device to be transferred later. The device can tem-
porarily store up to 30 measurement values. The thermometer then
switches itself o (Figure 12).
Establishing a data connection to the mySense app
The thermometer automatically synchronises the measurement val-
ues, as well as the date and time, to the mySense app after each meas-
urement.
If you want to synchronise the thermometer to the mySense app with-
out performing a temperature measurement, proceed as follows:
• With the device switched o, press and hold the data transfer but-
ton for at least 1 second, but no more than 5 seconds, until the
Bluetooth symbol appears in the display. If
you hold down the button for more than 5
seconds, you will enter memory recall mode.
• The device now connects to the app via Blue-
tooth (Figure 1).
• If the connection is successful, the “APP” indi-
cator appears and the display lights up green
(Figure 2).
Figure 1
Figure 2
If the device cannot connect to the mySense
app, it switches itself o after 60seconds. If this
occurs, check whether Bluetooth is enabled on
your smartphone and that the mySense app is running, then try again.
EN-14 EN-15
Operating the device Operating the device
• Unlock the battery cover by turn-
ing it past the marker to the left.
Then lift the cover o.
• Remove the old battery and insert
a new battery (CR2032) with the
“+” symbol facing up.
• Place the cover back on the bat-
tery compartment and lock it in place.
Battery display/changing the battery
The device is equipped with a CR2032 lithium battery.
If the battery icon ashes on the display while
the thermometer is in use, the battery is low
(Figure 1). You can still perform some tempera-
ture measurements at this point, but you should
have a spare battery ready.
After changing the battery, the thermometer must be connected to
the mySense app so that the date and time can be resynchronised.
Until you have done this, you cannot take any new temperature meas-
urements.
Change the battery if:
– After switching on the device, the “battery
at” indicator (Figure 2) appears on the dis-
play. You must insert a new battery before
you can take any temperature measure-
ments
– Nothing is shown on the display despite
pressing the on/o button.
Figure 1
Figure 2
Battery
compartment
cover locked
Battery com-
partment cov-
er unlocked
Measurement values stored on the device are retained when the bat-
tery is changed.
Changing devices
Each mySense basal body temperature thermometer has a unique
signature assigned to a specic user. Signatures are assigned during
initial setup when the device is synchronised with the mySense app
for the rst time.
If your device is lost or faulty, you can assign a new mySense basal
body temperature thermometer to your user account.
To do this, follow the instructions in the chapter “Initial setup” on page 7.
Please note: If you change device during a cycle, the current cycle be-
comes inactive in the mySense app. For your safety, the mySense app
only accepts measurement data from a single device during a cycle.
EN-16 EN-17
Technical information Technical information
The measured temperature is above 43.99°C and is
therefore outside the measuring range.
The measured temperature is below 32.00°C and is
therefore outside the measuring range.
The ambient temperature is above 40.00°C and is
therefore outside the device’s operating conditions.
The ambient temperature is below 10.00°C and is
therefore outside the device’s operating conditions.
Fever warning. Temperature higher than 37.5°C meas-
ured.
Battery at. Please change the battery.
Device memory is full. Connect the
thermometer to the cyclotest®mySense
app to transfer the measured values to
the app.
Battery low. Have a spare battery ready.
Error messages No display after switching on. Check whether the bat-
tery is positioned correctly and the polarity (+/-) is cor-
rect. If the error persists, change the battery.
Bluetooth connection error
Sensor error. If this occurs repeatedly, please contact
the cyclotest®service hotline.
Calibration error. If this occurs repeatedly, please con-
tact the cyclotest®service hotline.
The device is in technical test mode. Switch it o and
on again after a few seconds to return to normal mode.
Technical data
Type: Maximum thermometer, direct mode
Measuring points/
body reference
points:
rectal, oral, vaginal
Temperature unit: °C/°F
Measuring range: 32.00°C to 43.99°C (89.60°F to 111.18°F)
Measurement
accuracy:
± 0.05°C (0.10°F) between 35.00°C (95.00°F)
and 38.00°C (100.40°F)
± 0.10°C (0.20°F) in other temperature ranges
Memory: 30 measurement values with date and time
can be recalled in memory mode
EN-18 EN-19
Technical information Technical information
Customer service
Device repairs may only be performed by the manufacturer or an ex-
pressly authorised body. Please contact:
We recommend a technical inspection of the device every 5 years. This
inspection can be carried out either by UEBE Medical GmbH or by au-
thorised maintenance services.
UEBE Medical GmbH
Zum Ottersberg 9
97877 Wertheim, Germany
Tel.: +49 (0) 9342/924040
Fax.: +49 (0) 9342/924080
Website: www.uebe.com
Operating condi-
tions:
Ambient temperature 10°C to 40°C, maximum
relative humidity 15% to 95%
Conditions for stor-
age and transport:
-25°C to +55°C, maximum relative humidity
15% to 95%
Battery: 1 x CR2032, 3.0V, mercury-free
Battery life: approx. 400measurements
Data transfer: Bluetooth 4.0 LE (low energy)
IP classication: IP67: dust tight, protection against temporary
submersion
Expected service
life:
5years
Dimensions: 137mm (L) x 32mm (W) x 15mm (H)
Weight: 27g with battery
Explanation of symbols
This product complies with Council Directive 93/42/EEC of 5
September 2007 concerning medical devices and bears the
mark CE 0123 (TÜV SÜD Product Service GmbH).
Degree of protection against electric shock TYPE BF
Consult the instructions for use
Fabricant
Dust tight, protection against temporary submersion
Lot number/Batch number
Reference number = item number
0123
IP 67
Disposal
Technical equipment and batteries do not belong in house-
hold waste. They must be disposed of at appropriate collec-
tion and disposal points.
EN-20 EN-21
WarrantyCleaning and care
• Clean the thermometer with a soft cloth and isopropyl alcohol dilut-
ed with water or cold, soapy water.
• Do not use aggressive cleaning agents, solvents or petroleum spirit
to clean the device.
• The thermometer can be immersed in water or a disinfectant solu-
tion when cleaning. Do not sterilise the device by boiling it, using
gas or placing it in a steam autoclave.
• Make sure that the surface of the measuring sensor and the display
do not get scratched.
• After cleaning the measuring sensor with alcohol, wait 5 minutes
before taking the next temperature measurement so that the ther-
mometer can return to the required operating temperature.
The device has been manufactured and tested with all due care. Nev-
ertheless, in the event of defects upon delivery, we provide a warranty
under the following conditions:
During the warranty period of 2 years from the date of purchase, we
remedy such defects at our discretion and at our expense in our plant
through repair work or replacement delivery of a defect-free device.
The warranty does not cover normal wear and tear of wearing parts or
damage caused by failure to observe the instructions for use, improp-
er handling (e.g. unsuitable power sources, breakage, leaking batter-
ies) and/or disassembly of the device by the buyer. Furthermore, the
warranty does not constitute grounds for asserting claims for damag-
es against us.
UEBE Medical GmbH
Service-Center
Zum Ottersberg 9
97877 Wertheim, Germany
Warranty claims can only be asserted during the warranty period and
upon presentation of the proof of purchase. In the case of a warranty
claim, the device along with the proof of purchase and a description
of the complaint must be sent to:
The cost of returning the device to our factory shall be borne by the
sender. Complaints that are sent back without prepayment will not be
accepted by UEBE.
The statutory claims and rights of the buyer against the seller (for
example, defect claims, producer liability) are not restricted by this
warranty.
Please note: In the case of a warranty claim, please make sure
to enclose the proof of purchase.
EN-22 EN-23
cyclotest®service hotline
You have undoubtedly read our instructions on the use of cyclotest®
mySense carefully and have familiarised yourself with its character-
istics.
If you have any additional questions, you can call our cyclotest®ser-
vice hotline, which is available Monday to Thursday from 8:00am to
5:00pm and Fridays until 4:30pm.
Your cyclotest®advisory team looks forward to speaking with you.
www.cyclotest.de
+ 49 (0) 93 42 / 92 40 40
Se rvice For customers from Switzerland:
www.cyclotest.ch
0 52/ 224 41 47
Service
0640
cyclotest and UEBE are internationally
protected trademarks of:
Subject to technical modications.
Reprinting, including of extracts, is prohibited.
© Copyright 2018 UEBE Medical GmbH
UEBE Medical GmbH
Zum Ottersberg 9
97877 Wertheim, Germany
Phone: + 49 (0) 93 42 / 92 40 40
Fax: + 49 (0) 93 42 / 92 40 80
Website: www.uebe.com
0123
mySense
7 0640 201 AA 2018-09
PZN-14886326
Other manuals for mySense
1
Table of contents
Other cyclotest Thermometer manuals
