Cygnett iPod Speaker User manual

Quick Start Guide:
Alarm Clock & Radio
Speaker System for iPod
GrooveRise

Warranty
Introduction
Cygnett 12 Month Manufacturers Warranty
Register online at www.cygnett.com to
activate your warranty.
Thank you for purchasing Cygnett's GrooveRise
iPod Alarm Clock & Radio Speaker System. Now
you can experience the freedom to wake up to
your favourite songs while the GrooveRise
recharges your iPod around the clock. With a
feature-packed remote you can command your
iPod & GrooveRise from the comfort of your
bed.
To get the most from your new GrooveRise,
please take a few minutes to read the following
instructions and familiarise yourself with the
operation of the unit.

1
Contents
Getting to know the GrooveRise . . . . . . . . . . . . . . . . .
Connecting the GrooveRise . . . . . . . . . . . . . . . . . .
Operating the GrooveRise
Audio Modes . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the Time . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm & Alarm Mode Setting . . . . . . . . . . . . . . .
Snooze/Nap Mode Setting . . . . . . . . . . . . . . . . .
Sleep Mode Setting . . . . . . . . . . . . . . . . . . . . . . .
Tuning the Radio . . . . . . . . . . . . . . . . . . . . .
Volume Setting . . . . . . . . . . . . . . . . . . . . . . .
Setting the Backlight. . . . . . . . . . . . . . . . . . .
GrooveRise Remote Control . . . . . . . . . . . . . . . . . . . .
2
4
5
5
6
7
7
8
8
8
10

2
Getting to know the GrooveRise
Top View
1234
5678
9
10 11
1. Alarm1/Alarm 2
2. Alarm Mode
3. Alarm Set
4. Time
5. Power
6. Dimmer
7. Sleep
8. Audio
9. Snooze
10. Set +/-
11. Volume +/-

3
Getting to know the GrooveRise
Rear View
AB
A. DC 12V
B. Line In
C. FM Antenna
C

4
Connecting the GrooveRise
Connecting the GrooveRise
Take the AC Power Adaptor and plug it into the Groove
Rise 12v DC IN Port (A) at the back of the unit. Plug the
AC Power Adaptor into the wall socket and switch it on.
Press the Power button (5) located on the top of the
GrooveRise. The unit should now be on and ready for
use.
Please note:
The unit will have default settings of AUX mode, 20dB
volume and display a time of 00:00.

5
Operating the GrooveRise
Operating the GrooveRise
Audio Modes:
When the GrooveRise is turned on it will be in AUX audio
mode.
If you have already docked your iPod, press the Audio
button on the top of the unit and click through
AUX/RADIO/IPOD audio modes until you have reached
the desired audio mode.
If there is not an iPod docked, press the Audio button on
the top of the unit to choose between AUX or RADIO
modes.
Setting the Time:
Press the Time Set button located on the top of the unit
to select the Hour/Minute settings.
Then spin the set +/- wheel to adjust the hour and
minute setting.

6
Operating the GrooveRise cont.
Operating the GrooveRise
Alarm and Alarm Mode Setting:
Press the Al1/Al2 button to enable alarm 1, alarm 2 or
both.
Once you have enabled at least one alarm, press the Al
Set button. Use the Al Set button to switch between the
hours and minutes to set the alarm time.
Then use the Set +/- wheel to adjust the hours or
minutes desired.
Set each alarm separately.
After you have set the alarm(s) press Al Mode to switch
between AUX/RADIO/IPOD as the alarm type.
To set to volume of the alarm – see “Volume Setting”
section.
The alarm will sound every day at the set time(s).
After the alarm has gone off, it can be turned off until
the next day by pushing any button except the
Snooze/Nap button.

7
Operating the GrooveRise cont.
Operating the GrooveRise
Snooze/Nap Mode Setting:
Press the Snooze/Nap button on the top of the unit
after the alarm has gone off. The alarm will turn off
temporarily and will go off again after 9 minutes
approximately. You may use this feature until you turn
the alarm off.
Sleep Mode Setting:
The sleep mode allows you to set the unit to turn off
after a certain amount of time (15/30/45/60 minutes).
Press the Sleep button on the top of the unit and the
display will cycle through 15/30/45/60 minutes time
options. Select the time you desire and the GrooveRise
will turn off after the desired sleep time selected.

8
Operating the GrooveRise cont.
Operating the GrooveRise
Tuning the Radio:
When in Radio mode, use the Set+/- wheel to adjust to
the FM frequency you want.
Volume Setting:
The Default volume setting is 20dB (min volume is 0dB
and max volume is 40dB).
To increase the volume, spin the Volume wheel
clockwise. To decrease the volume spin the Volume
wheel anti-clockwise.
To set the Volume of the alarm, simply adjust the
volume to the desired level using the Volume wheel
before pushing the Power button Off on the unit. The
alarm will sound at the volume level selected prior to
turning the unit off.
Setting the Back light:
The back light has three settings: OFF, DIM and BRIGHT.
The backlight can be switched on when the unit is
powered on or off by pushing the Dimmer button to
cycle through OFF, DIM and BRIGHT modes.

standby mute
source
time set
menu
memory
alm mode
enter
snooze / dimmer
volume– volume+
al1/al2
alm set
sleep
9
GrooveRise Remote Control
Remote Control
standby: power on/off.
mute: Mute or un-mute speaker
source: Ipod/radio/Aux audio source
selection
memory: preset radio station
al1/al2: activates alarms 1 or 2
time set: sets the time, press to cycle
through hour/ minute/ month/ day
alm mode: selects audio source for
alarm
alm set: sets the alarm time, press to
cycle through hour/minute\
menu: press to go back to previous
menu on iPod
enter: selects the chosen function on
ipod
sleep: press and cycle through to turn
unit off in 15/30/45 or 60 minutes

10
GrooveRise Remote Control cont.
snooze/dimmer: press to snooze alarm for 9
minutes, when alarm is not activated press to dim the
LCD screen.
volume –/+: press to decrease and increase the
volume
play/pause: press to start playback, press again
to pause
prev: go to previous song
next: go to next song
up/down: press to scroll up or down through
the iPod menu

N15150
Z385

©2008 Cygnett www.cygnett.com
iPod is a trademark of Apple, Inc.,
registered in the U.S. and other countries.
