CYP CDPS-UA1H10HS User manual

CDPS-UA1H10HS
1 By 10 HDMI UHD Splitter
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
Version 1.0 March 2015
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 18/06/15 Preliminary Release

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
7. Connection Diagram ............................ 5
8. Specications ........................................ 6

1
1. INTRODUCTION
This 1 by 10 HDMI Splitter with HDCP 2.2 is an advanced solution for
splitting a single HDMI input to ten HDMI outputs. It provides high
performance audio and video output through HDMI cables up
to 4K2K@60Hz_YUV420 resolution and is capable of receiving and
transmitting up to 9Gbps of bandwidth with no data loss. Supporting
the latest features you can be assured of reliable and high quality
HDMI distribution.
2. APPLICATIONS
• Home entertainment
• Showroom display
• Educational demo
• Commercial advertisement
3. PACKAGE CONTENTS
• 1 By 10 HDMI Splitter
• 5V/6A Power Adaptor
• Power Cord
• Operational Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as DVD/Blu-ray player and output HD
display/Monitor with HDMI cables.

2
5. FEATURES
• HDMI (with 3D & 4K2K supported) and HDCP2.2/1.4 compliant
• Supports HDTV resolutions up to 4Kx2K (3840x2160@24/25/30,
3840x2160@50/60 YUV_420 & 4096x2160@24/25/30, 4096x2160@50/60
YUV_420) and PC resolutions up to WUXGA@60Hz(RB)
• Supports HDMI data rate up to 9Gbps and ‘Deep Color’ up to
1080p/36-bit
• Supports simultaneous outputs on ten HDMI
• Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby
Digital 2~5.1CH, DTS Surround, Dolby Digital Plus, Dolby TrueHD,
Dolby Atmos and DTS-HD Master Audio
• Supports EDID selection functions
• Supports CEC system reset functions

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER IN 12345678910
SYNC
HDCP 2.2
2.2
HDMI 1x10 SPITTER
2 4 531
1POWER LED: This LED will illuminate in green when the device is
power On.
2SYNC IN: This LED will illuminate when the device is connected with
active source signal.
3HDCP 2.2 IN: This LED will illuminate when the input source signal is
with HDCP 2.2 encrypted.
4SYNC LED 1~10: These LEDs will illuminate when the output detect
Hot-Plug Detection(HPD) from display TV/monitors.
5HDCP 2.2 LED 1~10: These LEDs will illuminate when the output HDMI
display are in the HDCP 2.2 handshaking status.

4
6.2 Rear Panel
HDMI OUT
ON OFF STD TV
EDID SYS.RESET
HDMI IN
12345678910 SERVICE DC 5V
1 2 543 6
1HDMI IN: Connect from source equipment such as Blu-ray/DVD/
PS3 players, Set-Top-Box or any HDMI equipped source device.
2HDMI OUT 1~10: Connect to HDMI TV/display or HD Amplier for
output video and/or audio.
3SERVICE: This slot is reserved for rmware update use only.
4SYS. RESET ON/OFF: Switch this switch to ON allow the device to
reset the output image with the source every 10 minutes.
It will force the connected TV/display to switch its HDMI port to
where the device is connected to ensure image display always.
Reset will be performed in sequence from 1~10 with 1 minute
a port. Default setting is OFF, leave as it is to disable the reset
function.
Note: TV/monitor must obtain CEC function in order to react
accordingly.
5EDID STD/TV: Switch this switch to set HDMI EDID’s setting.
Switch to TV mode allows the device to copy HDMI OUT 1’s EDID.
For example, when input source support 4K2K contents and output
1 also connected with 4K2K display. The device will send 4K2K
contents to output 1~10 however, if output 2~10 are connected to
non-4K2K TV/monitor then port 2~10 may have no image display
therefore, to ensure all outputs obtain image display OUT 2~10’s
EDID must obtain the equivalent EDID to OUT 1.
Switch to STD mode the EDID will support 1080p for video and PCM
2CH for audio.
6DC 5V: Connect the adaptor included in the package and
connect to AC wall outlet for power supply.

5
7. CONNECTION DIAGRAM
HDMI OUT
ON OFF STD TV
EDID SYS.RESET
HDMI IN
12345678910 SERVICE DC 5V
DVD or Blu-ray Player
HD TV or Amplier

6
8. SPECIFICATIONS
Video Bandwidth 300MHz / 9Gbps
Input Ports 1 x HDMI
1 x USB (Service only)
Output ports 10 x HDMI
HDMI I/O Cable 10M/1080p
Length 5M/4K2K
Power Supply DC 5V/6A (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Dimensions 436mm (W) x 160mm (D) x 44mm (H)/Jacks
Excluded
436mm (W) x 165.5mm (D) x 49mm (H)/
Jacks Included
Weight 1856 g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F
Storage temperature -20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (no condensation)
Power Consumption 16w

7
DVI/HDMI Supported Resolutions Input Output
640x480@60/72/75 V V
720x480@60 V V
720x576p@50 V V
800x600@60/72/75 V V
1024x768@60/70/75 V V
1280x720@50/60 V V
1280x720p@60 V V
1280x768@60 V V
1280x800@60 V V
1280x1024@60 V V
1360x768@60 V V
1600x1200@60 V V
1920x1080i@50/60 V V
1920x1080i@60 V V
1920x1080p@24/25/30/50/60 V V
1920x1200@60(RB) V V
3840x2160@24/25/30 V V
3840x2160@50/60_YUV420 V V
4096x2160@24/25/30 V V
4096x2160@50/60_YUV420 V V
