CYP CPLUS-V2E User manual

CPLUS-V2E
1 by 2 6G HDMI Splitter
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 30/07/15 Preliminary release
RDV2 17/03/16 Add HDMI Cable Spec.
31/05/16 Add texts.

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
7. Connection Diagram ............................ 5
8. Specications ........................................ 6
8.1 Technical Specications .................6
8.2 Supported Resolutions.....................7
9. Acronyms ............................................... 8

1
1. INTRODUCTION
The 1 by 2 HDMI Splitter with HDCP 2.2 is an advanced solution
for splitting a single HDMI input to 2 HDMI outputs. It provides high
performance audio and video output up to 4K2K@60Hz (YUV444)
resolution and is capable of provide high end of audio and video
performance. This unit also support HDR (High Dynamic Range
Imaging) function, which allows giving more luminance radiance
contrasting and colourful pictures for better experience. It supports
high resolution digital audio formats such as LPCM 7.1CH, Dolby
TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio,
audio sampling rate up to 192kHz. There are input and outputs
indications on panel, which will illuminate when detected, system
reset function allows the unit to set the TV to it's default HDMI input.
2. APPLICATIONS
• Entertainment Room / Home Theater
• Lecture Room/Hall Presentation
• Show Room/Demo Room
• Public Commercial Display
3. PACKAGE CONTENTS
• 1×1 by 2 HDMI splitter
• 1×5 V/2.6A DC Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipments such as Blu-ray/DVD/PS3/PS4 player or Set-
Top-Box or any 6G with HDCP2.2 source. And output with 6G HDMI TV/
Display and or audio amplier with connection cables.
Note: To achieve 6G performance will need to collocation with
particular HDMI cable to get the better quality.

2
5. FEATURES
• 4Kx2K 6G supported, HDCP 2.2 , HDMI2.0 and DVI 1.0 compliant.
• System Reset function supported( CEC active source command)
• Displays any of 1 Ultra High-Denition sources on 2 UHDTV displays
simultaneously
• 3D pass-Through
• Supports UHDTV resolutions up to 4Kx2K (3840x2160@24/25/30/50/60
& 4096x2160 @24/25/30/60)
• Supports LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH,
Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
• HDCP 2.2 and HDCP1.4 compliant
• Input port EDID support Standard and TV mode
Note: When displaying HDMI 4Kx2K signal, equivalent source signal,
output display and HDMI cables are required in order to secure the
best image display.
• HDR Pass Through supported.
Note: To active HDR function, input source and output device
should also equip and support HDR function.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
6G IN OUT 1 OUT 2
SYNC
HDCP
EDID
STDTV
SYS-RST
ON OFF
POWER
3G
12 4 6
53
78
1POWER: This LED will illuminate when the device is connected to an
active power supply.
26G/3G: When input source bandwidth is 6G, the 6G LED will
illuminate, when input source detect as 3G, the 3G LED will
illuminate.
3IN SYNC: When input detected, the LED will illuminate, the LED will
icker when detected abnormal, for example, when source signal
not stabled, and when input is not connected, the LED light will off.
4IN HDCP: When Input HDCP has been detected, the LED will
illuminate, the LED will icker when HDCP abnormal, for example
when HDCP version is not supported, and when no HDCP
detected, the LED will off.
5OUT 1~2 SYNC: When output detected, the LED will illuminate,
the LED will icker when detected abnormal, for example, when
output connected but the output sense is off, and when output is
not connected, the LED will off.
6OUT1~2 HDCP: When output HDCP working, the LED will illuminate,
the LED light icker when HDCP abnormal, for example, when
HDCP version is not supported, and when no HDCP detected, the
LED will off.
7EDID: Switch the dip could choose EDID mode to Standard (STD)
mode or TV mode. When on TV mode, the unit will automatically
detect and store output 1 sink EDID data, if switch to STD mode,
the unit will set to standard 1080p and PCM 2 channel.
8SYS-RST: Switch the dip from off to on, the unit will trigger TV to it’s
HDMI input1 immediately, when dip stays in on, the unit will trigger

4
cycle in every 8~10 minutes. (*The purpose of this function is to
guarantee output display the corresponding image, for example,
at the display user use may switch to different HDMI input or other
sources connected to display and this reset function will force the
display to switch back to the HDMI input1 which TV shall support
CEC.)
6.2 Rear Panel
INPUT1 2
OUTPUT
SERVICE
DC 5V
2
13 4
1INPUT: Connect with HDMI source equipment such as DVD/Blue-
ray players and or PC/Laptop devices.
2OUTPUT 1~2: Connect to HDMI TV / display or HD amplier for
output display.
3SERVICE: This is reserved for rmware update use only.
4DC 5V: Connect the adapter which included in the package and
connect to AC wall outlet for power supply.

5
7. CONNECTION DIAGRAM
INPUT 12
OUTPUT
SERVICE
DC 5V
DVD or Blu-ray Player
UHDTVProjector
Power
Supply
Simultaneous
HDMI Outputs
HDMI
Input

6
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 600 MHz/18 Gbps
Input Ports 1×HDMI, 1×USB (Service only)
Output Ports 2×HDMI
HDMI Resolutions VGA~WUXGA (RB), 408i~1080p@24/50/60,
4K@24/25/30, 4K@50/60 (YUV444)
HDMI Cable I/O
Distance
15 m@1080p/8-bit, 10 m@1080p/12-bit,
3 m@4K2K/60_YUV444 5m@4K2K/30
Power Supply 5 V/2.6A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Dimensions 128 mm (W)×108 mm (D)×25 mm (H)/
Jack Excluded
128 mm (W)×117 mm (D)×30 mm (H)/
Jack Included
Weight 358 g
Chassis Material Metal
Color Black
Operating Temperature 0˚C~40˚C/32˚F~104˚F
Storage Temperature −20˚C~60˚C/−4˚F~140˚F
Relative Humidity 20~90% RH (non-condensing)
Power Consumption 4.56 W

7
8.2 Supported Resolutions
Resolution Input Output
640×480@60/72/75/85 √ √
720×400@85 √ √
800×600@56/60/72/75/85 √ √
1024×768@60/70/75/85 √ √
1152×864@75 √ √
1280×720@60 √ √
1280×768@60/75/85 √ √
1280×800@60 √ √
1280×960@60 √ √
1280×1024@60 √ √
1360×768@60 √ √
1366×768@60 √ √
1400×1050@60 √ √
1440×900@60 √ √
1600×900@60 √ √
1600×1200@60 √ √
1680×1050@60 √ √
1920×1080@60 √ √
1920×1200@60 √ √
1920×1440@60 √ √
2560×1600@60 √ √
1440×576i@50 √ √
1440×[email protected]/60 √ √
720×[email protected]/60 √ √
720×576p@50 √ √
1280×720p@50/59.94/60 √ √
1920×1080i@50/59.94/60 √ √

8
Resolution Input Output
1920×[email protected]/24/25/29.97/30/50/59.94/60 √ √
3840×2160@24/25/30/50/60 √ √
4096×2160@24/25/30/50/60 √ √
9. ACRONYMS
ACRONYM COMPLETE TERM
CEC Consumer Electronics Control
DTS Digital Theater System
DVI Digital Visual Interface
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
IR Infrared
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA (RB) Widescreen Ultra Extended Graphics Array (Reduce
Blanking)

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
MPM-CPLUSV2E
