1. INTRODUCTION
The 4 by 2 SDI to HDMI Seamless Quad PIP Splitter is a high performance,
high speed zooming/shrinking system that can be easily congure
and control for quad or picture-in-picture video processing. Allowing
4 different SDI input sources to be freely selected and arranged on
to HDMI displays with total of 8 different types of settings. Supporting
resolution up to WUXGA@60RB, 1080p and audio up to 8CH with
sampling rate 48kHz for both inputs and outputs. Screen setting hot
keys, OSD, RS-232 and Telnet allows instant control and switching on
the output displays.
2. APPLICATIONS
• Broadcasting room and control
• Surveillance room and control
• Public advertisement and control
• SDI signal extending
3. PACKAGE CONTENTS
• 1×4 by 2 SDI to HDMI Seamless Splitter
• 1×Remote Control (CR-124)
• 1×12 V/3 A DC Power Adaptor
• 1× Rack Ear Sets
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as SNG camera or SDI signal, PC/Laptop
or RS-232 control devices and output HD TV/monitors with connection
cables.

2
5. FEATURES
• Supports SD-SDI (SMPTE 259M-C, at bitrates of 270 Mbit/s) input
signals up to 250M
• Supports HD-SDI (SMPTE 292M, at bitrates of 1.485Gbit/s and
1.485/1.001 Gbit/s) input signals up to 200M
• Supports 3G-SDI (SMPTE 424M/425M-AB, at bitrates of 2.970 Gbit/s
and 2.9701/1.001 Gbit/s) input signals up to 100M
• HDMI output compatible with DVI
• Combine four SDI inputs single into HDMI and output on to two
synchronize HD screen
• Seamless switching between channels and windows
• Zoom and Shrink 4CH input image and or to overlay them
• Supports PIP, POP and multi-windows display
• Supports OSD, RS-232 Remote and on-panel controls
• Fade-In-Out, Chromakey, Mirror and Rotation (90˚ left & right and
180˚ up & down) functions
• 8 Screen setting hot keys and extra 4 customized favorite screen
setting
• Easily to adjust size, position and setting of 4 input images via
WebGUI, only drag and few clicks can achieve output display
format setting

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWERPOWER
WINDOW
1FAV234
ABCDEFGH
CH 1CHANNEL IN CH 2CH 3CH 4FAV SELECT ENTER
MENU
AUDIO
+
-
INFO
720P/60Hz
A
WINDOW CDEFGH
B
1 2 3 5 6 9 10 487
4 5
1POWER Button & LED: Press this button to power on the device and
the LED will illuminate in green or set it to standby mode and the
LED will illuminate in Red.
2IR Window: Accept IR signal from the device’s remote control
included in the package only.
3CHANNEL IN 1~4: Press these buttons to rotate SDI 1~4 input source
on each channel to be display on screens. All channels can select
the same input or each channel a different input.
4WINDOW A~H & LEDs: Press these hot keys to select the screen
setting where A~D are display a full screen of each channel and
E~H are a different combination of a full screen setting with all 4
channels.
Windows A~D's channel input selection is corresponding to
channel input no. 1~4. That is, to change window A's input channel
must press channel input 1's button. Channel input 2~4's button
will not activate under window A's selection. Windows E~H's size
are adjustable through the OSD menu setting and only window
G & H is PIP(Picture in Picture) where E & F are POP (Picture out Of
picture) settings.
Under window E~H when the size setting is overlapping one
another, channel display sequence is CH4>CH3>CH2 >CH1. That is,
CH4 will cover CH3 and CH3 will cover CH2 and so on. Under some
display the borderline may have interference, adjusting display's
motion setting may resolve the interference issue.
5FAV SELECT & LEDs: Press this button to recall the favor setting from
1~4 and the LED will illuminate accordingly.
6MENU: Press this button to bring up the OSD menu on screen.

4
7ENTER: Press this button to enter into MENU selection and conrm
the selection.
8-/+ Buttons: Press these buttons to scroll down/up the OSD
selections.
9INFO: Press this button to bring up the information section from the
OSD menu.
10 AUDIO: Press this button to select audio channel.
Note:Press the 'INFO & AUDIO' buttons together to switch output
resolution to 720p@60Hz instantly.
6.2 Rear Panel
SDI IN
4321
BA SERVICE
HDMI OUT CONTROL RS232 DC 12V
1 2 3 4 5 6
1SDI IN: Connect with source equipment such as SNG camera or
SDI signal devices.
2HDMI OUT: Connect with HD TV/monitor for output image display.
3SERVICE: This slot is reserved for factory use only.
4CONTROL: Connect from PC/Laptop for Telnet control with RJ-45
cable.
5RS-232: Connect from PC/Laptop/RS-232 equipped device with
D-Sub 9pin cable for RS-232 command sending.
6DC 12V: Plug the 12V DC power supply into the unit and connect
the adaptor to an AC outlet.

5
6.3 Remote Control
1Power: Press this button to switch on
the device or press it again to set it to
standby mode.
2Info: Press this button to show system
information.
3Input CH 1~4: Press these buttons to
rotate SDI 1~4 input source on each
channel to be display on screen
4WA~WH: Press these hot keys to select
the screen setting where WA~WD are
display a full screen of each channel
and WE~WH are a different combination
of a full screen setting with all 4 channels.
5Mute: Press this button to mute the audio
from HDMI output port.
6 ▲/▼/►/◄ & OK Buttons: Press this
buttons to scroll through the OSD selection and press OK to enter
and conrm the setting.
7Menu: Press this button to enter into the OSD menu.
8Exit: Press this button to exit the OSD menu or the OSD settings.
9Fade-In-Out*: Press this button to switch on or off the Fade-in-out
function.
10 Chromakey*: Press this button to enter into Chroma function where
CH 1 is the background and CH 2 is the top image.
11 Mirror*: Press this button to display the screen in mirror image.
12 Rotation*: Press this button to rotate the image 90˚ left and right or
180˚ upside down.
13 Audio 1~4: Press these buttons to select audio from SDI input
source 1~4.
14 FAV. 1~4: Press these buttons to bring up the customized screen
settings.
Note:*Functions only work under Window A to D. The system will
force to switch to Window A when operate under Window E~H.
WA WE CH 1
WB WF CH 2
WC WG CH 3
WD WH CH 4
InputMute
MenuExit
Audio 1Fade In-Out FAV. 1
Audio 2 ChromakeyFAV. 2
Audio 3MirrorFAV. 3
Audio 4 RotationFAV. 4
Info Power
CR-124
OK
1
3
6
7
9
11
2
4
5
8
14
13
12
10

6
6.4 OSD Menu
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
I/O Setup Output
Resolution
480p60
567p50
720p50
720p60
1080p24
1080p25
1080p30
1080p50
1080p60
1024x768
1280x800
1280x1024
1366x768
1440x900
1600x900
1600x1200
1920x1200
NATIVE1
Menu Back
OSD Setting Info Display On/Off
H Offset 0~20 (5)
V Offset 0~20 (5)
OSD Timeout 5~50/Off (10)
Transparent 0~10 (5)
Menu Back
Menu Exit

7
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Adjust
Brightness
Adjust
CH 1 0~100 (50)
CH 2 0~100 (50)
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
Contrast
Adjust
CH 1 0~100 (50)
CH 2 0~100 (50)
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
Saturation
Adjust
CH 1 0~100 (50)
CH 2 0~100 (50)
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
Reset
CH 1 0~100 (50)
CH 2 0~100 (50)
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
Menu Exit

8
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Window
Setup
Channel 1
Select
Size CH1 Wxxx Hxxx
Width Unit
Width Ten
Width Hundred
Height Unit
Height Ten
Height Hundred
Position CH1 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
Priority 1~4
Image Output On/Off
Window Reset
Menu Exit

9
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Window
Setup
Channel 2
Select
Size CH1 Wxxx Hxxx
Width Unit
Width Ten
Width Hundred
Height Unit
Height Ten
Height Hundred
Position CH1 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
Priority 1~4
Image Output On/Off
Window Reset
Menu Exit

10
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Window
Setup
Channel 3
Select
Size CH1 Wxxx Hxxx
Width Unit
Width Ten
Width Hundred
Height Unit
Height Ten
Height Hundred
Position CH1 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
Priority 1~4
Image Output On/Off
Window Reset
Menu Exit

11
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Window
Setup
Channel 4
Select
Size CH1 Wxxx Hxxx
Width Unit
Width Ten
Width Hundred
Height Unit
Height Ten
Height Hundred
Position CH1 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
Priority 1~4
Image Output On/Off
Window Reset
Menu Exit
Label2VIDEO 1
VIDEO 2
VIDEO 3
VIDEO 4
Menu Exit
Favors Store FAV 1 Store Yes/No
FAV 2 Store Yes/No
FAV 3 Store Yes/No
FAV 4 Store Yes/No
Menu Exit
Menu Exit

12
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Window
Convert
Channel 1
Convert
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/Up-Side
Down180/Off
Window Reset
Menu Exit
Channel 2
Convert
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/Up-Side
Down180/Off
Window Reset
Menu Exit
Channel 3
Convert
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/Up-Side
Down180/Off
Window Reset
Menu Exit
Channel 4
Convert
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/Up-Side
Down180/Off
Window Reset
Menu Exit

13
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Chromakey
Setup3
User 1 Minimum For Y 16~240
Maximum For Y 16~240
Minimum For Cb 16~240
Maximum For Cb 16~240
Minimum For Cr 16~240
Maximum For Cr 16~240
Chromakey On/Off
User 2 Minimum For Y 16~240
Maximum For Y 16~240
Minimum For Cb 16~240
Maximum For Cb 16~240
Minimum For Cr 16~240
Maximum For Cr 16~240
Chromakey On/Off
White Minimum For Y 234~235
Maximum For Y 234~235
Minimum For Cb 127~129
Maximum For Cb 127~129
Minimum For Cr 127~129
Maximum For Cr 127~129
Chromakey On/Off
Yellow Minimum For Y 218~220
Maximum For Y 218~220
Minimum For Cb 16~18
Maximum For Cb 16~18
Minimum For Cr 137~139
Maximum For Cr 137~139
Switch On/Off

14
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Chromakey
Setup3
(Cont.)
Cyan Minimum For Y 187~189
Maximum For Y 187~189
Minimum For Cb 152~154
Maximum For Cb 152~154
Minimum For Cr 16~18
Maximum For Cr 16~18
Chromakey On/Off
Green Minimum For Y 171~173
Maximum For Y 171~173
Minimum For Cb 40~42
Maximum For Cb 40~42
Minimum For Cr 25~27
Maximum For Cr 25~27
Chromakey On/Off
Magenta Minimum For Y 77~79
Maximum For Y 77~79
Minimum For Cb 213~215
Maximum For Cb 213~215
Minimum For Cr 228~230
Maximum For Cr 228~230
Chromakey On/Off
Red Minimum For Y 61~63
Maximum For Y 61~63
Minimum For Cb 101~103
Maximum For Cb 101~103
Minimum For Cr 239~240
Maximum For Cr 239~240
Chromakey On/Off

15
MAIN MENU 1ST LAYER 2ND LAYER 3RD LAYER
Chromakey
Setup3
(Cont.)
Blue Minimum For Y 30~32
Maximum For Y 30~32
Minimum For Cb 239~240
Maximum For Cb 239~240
Minimum For Cr 116~118
Maximum For Cr 116~118
Chromakey On/Off
Black Minimum For Y 16~17
Maximum For Y 16~17
Minimum For Cb 127~129
Maximum For Cb 127~129
Minimum For Cr 127~129
Maximum For Cr 127~129
Chromakey On/Off
Exit
Ethernet
Setup
IP Mode Static/DHCP
Time Out 10-~60min/Off
RE-Link Yes/No
Exit
Sys Reset Yes/No
Information Screen
Resolution
F/W Version
F/W
Upgrade
Exit
Menu Exit

16
Note:
1. When in 'NATIVE' resolution, the unit will read the EDID settings of the
display connected to HDMI OUT A.
2. Naming character up to 9 characters.
3. Chromakey Setup only works when CH 1and CH 2 are selected. CH
1 is the background and CH 2 is the top layer to be overlaid. The
RGB setting is for the CH2 video where the minimum setting gures
cannot be greater than the maximum gures and the maximum
gures cannot be lower than the minimum setting gures.
4. Figures in BOLD are default settings.
6.5 RS-232 Protocol
SPLITTER
►
◄
REMOTE CONTROLLER
Pin Assignment Pin Assignment
1 NC 1 NC
2 TX 2 RX
3 RX 3 TX
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 115200bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
