CYP PU-1107-KIT User manual

OPERATION MANUAL
PU-1107-KIT
Pure Digital v1.3 HDMI over
Single CAT6 Extender Set with
Repeater Function

Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
 Copyright 2009 by Cypress Technology.
All Rights Reserved.
Version 1.0 August 2010
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
 Always follow basic safety precautions to reduce the risk of
re, electrical shock and injury to persons.
 To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
 Never spill liquid of any kind on or into this product.
 Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
 Do not attach the power supply cabling to building surfaces.
 Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
 To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide
ventilation.
Revision History
Version No Date Summary of Change
V1 20100412 Preliminary release

Table of Contents
1. Introduc tion..................................................................................1
2. Ap plic a tions.................................................................................1
3. Pa c ka geContents......................................................................1
4. SystemReq uirem ents..................................................................1
5. Features........................................................................................2
6. Spec ific a tions..............................................................................3
7. Op erationControlsa nd Func tions.............................................4
7.1 Front Panel .................................................................... 4
7.2 Rear Panel .................................................................... 5
8. Connec tiona ndInstallation..................................................... 6
9. Ac ronym s................................................................................... 7

1. Introduction
The HDMI 1.3 transmitter and receiver over ONE CAT 6 is a tool for extending
your HDMI signal over long distances to a compatible display. Instead of
using expensive HDMI cables, your existing CAT 6 cables/sockets can be
utilized to perform advanced functions like transferring Deep Color (12 bits/
color) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio) digital audio, with a bandwidth up to 225MHz. The
HDMI 1.3 Transmitter and receiver, over ONE CAT6 extender is your substantial
HDMI extender tool.
2. Applications
 Distribute HDMI signals over long distances
 Showroom display
 Hypermarket display
 Lecture room display
3. Package Contents
 HDMI v1.3 Transmitter x 1
 HDMI v1.3 Receiver x 1
 5V DC Power Supply adaptor x 2
 Operation Manual x 1
4. System Requirements
Input HDMI source equipment and output HDMI display with connection
cables and one CAT6 cable.
1

5. Features
 HDMI 1.3, HDCP 1.1 and DVI1.1 compliant.
 Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/
color) and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and
DTS-HD Master Audio) Digital audio .
 Uses one CAT-6 cable for data/DDC transmission.
 Equalizes and recovers incoming TMDS data before re-transmitting it in
optimal quality regardless of the incoming signal quality.
 Cable testing showed that with 1080p 8bit or 12bit resolution the HDMI
input source can be 20meters away.
 Cable testing showed that with 1080p 8bit resolution the HDMI output
device can be 15meters away and with 1080p 12bit resolution it can be
10 meters away.
 When transmitting a signal in 1080p 8bit resolution the CAT6 operating
distance is 45 meters, and when the signal is in 12bit resolution the CAT6
operating distance is 10meters.
 Supports xvYCC
2

6. Specications
Frequency Bandwidth 2.25Gbps (single link)
Transmitter
Input/Output Ports 1 x HDMI Female port/1 x CAT6
Receiver
Output/Input Ports 1 x HDMI Female port/1 x CAT6
Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certied)
ESD Protection Human Body Model:  8kV (air-gap discharge)
 4kV (contact discharge)
Dimensions (mm) 78.5 (W) X 102 (d) X 30 (H) / Tx
78.5 (W) x 72 (D) x 30 (H) / Rx
Weight(g) 182 / Tx
90 / Rx
Chassis Material Aluminum
Silkscreen Color Silver
Power Consumption TX: 3.5W RX:2W
Operating Temperature 0C ~ 40C / 32F ~ 104F
Storage Temperature -20C ~ 60C / -4F ~ 140F
Relative Humidity 20~90% RH (non-condensing)
3

7. Operation Controls and Functions
7.1FrontPanel
CH-1107TX CH-107RX
① ②
DC 5V
HDMI INPUT
② ③
DC 5V HDMI OUT
①HDMI INPUT: This slot is where you connect the HDMI or DVI output
port of your source equipment such as DVD/Blu Ray players or Set-top-
boxes with an HDMI cable or link up with another receiver unit from the
same family to extend a signal over long distances.
②DC 5V: This is where you plug the 5V DC power supply into the unit
and connect the adaptor to an AC outlet.
③HDMI OUTPUT: This slot is where you connect the HDMI or DVI input port of
your display such as an HDTV or HD monitor or link up with another
receiver unit from the same family to extend a signal over long distances.
4

7.2RearPa nel
CH-1107TX CH-107RX
②
CAT6 IN
②①
TV/STD 10 Bit
CAT6 OUT
EDID
8 Bit 12 Bit
①EDID Control Switcher: Switch the EDID between STD and TV. Switch to
STD to use the built-in EDID or switch to TV to use the TV’s EDID. The default
factory setting is TV, leave as is when the display is working properly.
Note: 1. When EDID is switched to STD the unit will use its built-in EDID which
supports:
Video → 1080p 8-bit, 10-bit or 12-bit (max)
Audio → PCM 2CH
2. The EDID selection will only be activated when the unit is re-plugged
and powered on.
②CAT6 OUT/IN: Connect the CAT6 output of the transmitter with the CAT6
input of the receiver.
Note: A. This system was tested with CAT-6E/23AWG cables, so if using cables
of another type, results may vary.
B. Cable distance tested with PS3 120G & 40" Samsung LED 12 bit LCD
TV.
C.The gures provided in this manual are for reference only; actual
performance may depend on the source and display used along
with the type cable.
5

8. Connection and Installation
DVD
HDMI
Cable HDMI Cable
CAT6
Cable
LCD TV
CH-1107TX CH-107RX
HDMI
HDMI
HDMI
HDMI
6

Acronyms A
Acronym Complete Term
CAT6 Category 6 Cable
EDID Extended display identication data
HDMI High-Denition Multimedia Interface
7
