CYP PU-507TX-HDVGA User manual

PU-507TX-HDVGA
Switchable HDMI & VGA HDBaseT™ Transmitter with Integrated
Video Scaling (5Play™ inc. PoE & Single LAN, up to 100m)
OPERATION MANUAL

3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 03/03/14 Preliminary release
v1.01 07/04/14 Added RS Protocols and Baud Rate Details
v1.02 21/05/14 Corrected Baud Rate Details

5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions .......8
6.1 Front Panel................................................... 8
6.2 Rear Panel..................................................... 9
6.3 Remote Control........................................10
6.4 RS-232 Pin Denitions ...........................11
6.5 RS-232 Commands .................................12
6.6 OSD Menu..................................................14
6.7 Input Resolution Support.....................17
7. Connection Diagram .......................... 18
8. Specications...................................... 19
9. Acronyms............................................. 20

6
1. INTRODUCTION
The PU-507TX-HDVGA allows VGA and uncompressed HDMI signals to be
transmitted over a Single CAT5e/6/7 cable to lengths of up to 100 metres.
This device features full 5-Play convergence allowing the distribution of
Video, Audio, LAN serving, Power over Ethernet (PoE), RS-232 and 2-way
IR control functionality over the same CAT5e/6/7 cable. This transmitter
allows the user to select and switch between a HDMI or VGA source
whilst the integrated scaler ensures maximum resolution support for the
connected display.
2. APPLICATIONS
Scale low resolution video onto High-Denition display
HDMI/PC signals extension
Lecture room/Showroom/Meeting room/Classroom display and
control
3. PACKAGE CONTENTS
1×PU-507TX-HDVGA
1×IR Extender
1×IR Blaster
24V/2.7 A DC Power Adaptor
Remote control (CR-128)
Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI/PC source equipment such as DVD/Video player or PC/Laptop
and output to HDBaseT compatible Receiver.

7
5. FEATURES
Supports all v1.4 HDMI resolutions plus 4k.
Supports uncompressed video/audio up to 10.2Gbps
Common supported resolutions:
– HDTV: 480p, 576p, 720p, 1080i, 1080p, 1080p24
– PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA
HDMI, HDCP, & DVI compliant
Supports HDCP repeating and CEC functions
Uncompressed data transfer over single CAT cable (100m - CAT6/7;
80m - CAT5e)
Audio support up to 7.1CH & Dolby TrueHD, DTS-HD
5Play™ convergence: HDMI, LAN, POE & Control (IR & RS232)
Supports 3D signals
Note:
1. This system was tested with CAT6/23AWG cables, results may vary with
cables of a dierent specication.
2. The PoE function is designed for powering compatible Receiver units only—
non-PoE Receivers will need their own power supply. Receivers of another
brand may not be compatible.

8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
SERVICE PCHDMIAUDIO XGA
MENU
ENTER
- +
720P
INPUT
HDMI/
PC
INPUT
1 2 3 4 5 6 9
7
8
1SERVICE: This port is reserved for rmware update only.
2IR: IR Receiver window (accepts the remote control signal of this
device only).
3HDMI: Connect to source equipment such as DVD/Video player for
video signal sending.
4PC: Connect with PC/Laptop source equipment for signal input with
D-Sub 15 pin cable.
5AUDIO: Connect to audio source equipment for L/R stereo audio
input with 3.5mm phone jack.
6MENU: Press this button to enter into the OSD menu.
7– INPUT & HDMI/PC LED: Press to select HDMI or PC source input.
When in HDMI mode the LED will illuminate in Red, when in PC mode
the LED will illuminated in Green.
8-/+: Press these buttons to scroll down and up in the OSD selection.
9ENTER: Press this button to conrm the selection. Press this button
together with [–] key to switch output timing to 720p@60 instantly.
Press this button together with [+] key to switch output timing to XGA
(1024x768) instantly.

9
6.2 Rear Panel
IR
Blaster
IR
Extender
CAT5e/6/7 OUT
MODE LINK
LANRS-232 IN
DC 24V
POWER
1 2 3 4 5 6 8 97
1Power LED: This LED will illuminate when the device is connected
with power supply.
2DC 24V: Plug the 24 V DC power supply into the unit and connect the
adaptor to an AC outlet. Only one side of power is needed to activate
both Transmitter and Receiver when both obtain the PoE function.
3RS-232 IN: Connect to a PC or Laptop with D-Sub 9-pin male cable to
bypass RS-232 commands to the Receiver, or for direct RS-232 control
of the PU-507TX-HDVGA.
4LAN: Connect to an active network for LAN sharing of a total
transmission rate up to 100Mbps. Or when a compatible LAN
equipped Receiver is connected to an active network, this allows
the network access (including internet access if available) to be
shared between the Transmitter and Receiver. Connect any Ethernet
equipped device e.g. a Smart TV or games console to the LAN port for
that device to share the network internet access.
Note: DO NOT connect this slot with any of the CAT5e/6/7 port. Doing so
may trigger power shut down and ruin the device.
5IR Blaster: Connect to the supplied IR Blaster cable for IR signal
transmission. Place the IR Blaster in direct line-of-sight of the
equipment to be controlled.
6IR Extender: Connect to the supplied IR Receiver cables for IR signal
reception. Ensure that remote being used is within the direct line-of-
sight of the IR Extender.
7MODE LED: This LED will illuminated when the power is connected.
8Link LED: This LED will illuminate when the slot has been connected
to the Receiver and the Receiver has connected with display that
shows image on screen.
9CAT5e/6/7 Out: Connect to the Receiver unit with a single CAT5e/6/7
cable for transmission of all data signals.

10
6.3 Remote Control
1INPUT: Press this button to switch
HDMI/PC input source instantly.
2EXIT: Press this button to exit
the menu or escape the current
selection under OSD.
3MENU: Press this button to enter
into the OSD menu.
4RESET: Press this button to set the
device back into the factory default
setting.
5AUTO ADJUST: Press this button
to optimise the positioning of the
picture (picture centering) on the
screen.
6ENTER (OK) & ▲▼◄►: Press Enter
to conrm the selection or press the
arrow buttons to scroll in the OSD
selections.
CR-128
OK
INPUT
EXIT MENU
RESET AUTO
ADJUST
1
2
4
6
3
5

11
6.4 RS-232 Pin Denitions
PIN DEFINE TX / RX
1N/C
2TxD/RxD
3RxD/TxD
4NC
5GND
6NC
7NC
8NC
9NC
Baud Rate: 9600 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None

12
6.5 RS-232 Commands
COMMAND DESCRIPTION
S SOURCE 1~2 1=PC
2=HDMI
R SOURCE Reports the numerical equivalent for
SOURCE setting (as above)
S OUTPUT 0~25 0=Native 12=1600×1200
1=640×480 13=1920×1080
2=800×600 16=1920×1200
3=1024×768 17=480p
5=1360×768 18=720p@60
6=1280×720 19=1080p@60
7=1280×800 20=1080i@60
8=1280×1024 22=576p
9=1440×900 23=720p@50
10=1400×1050 24=1080p@50
11=1680×1050 25=1080i@50
R OUTPUT Reports the numerical equivalent for OUTPUT
setting (as above)
S SIZE 0~6 0=OVERSCAN 4=LETTER BOX
1=FULL 5=UNDER 2
2=BEST FIT 6=UNDER 1
3=PAN SCAN
R SIZE Reports the numerical equivalent for SIZE
setting (as above)
S CONTRAST 0~60 Setups the numerical equivalent for
CONTRAST setting (as left)
R CONTRAST Reports the numerical equivalent for
CONTRAST setting
S BRIGHTNESS 0~60 Setups the numerical equivalent for
BRIGHTNESS setting (as left)
R BRIGHTNESS Reports the numerical equivalent for
BRIGHTNESS setting
S HUE 0~60 Setups the numerical equivalent for HUE
setting (as left)

13
R HUE Reports the numerical equivalent for HUE
setting
S SATURATION 0~60 Setups the numerical equivalent for
SATURATION setting (as left)
R SATURATION Reports the numerical equivalent for
SATURATION setting
S SHARPNESS 0~30 Setups the numerical equivalent for
SHARPNESS setting (as left)
R SHARPNESS Reports the numerical equivalent for
SHARPNESS setting
S NR 0~3 0=OFF 2=MIDDLE
1=LOW 3=HIGH
R NR Reports the numerical equivalent for the
NOISE REDUCTION setting (as above)
S AUDIO DELAY 0~3 0=OFF 2=110ms
1=40ms 3=150ms
R AUDIO DELAY Reports the numeric equivalent for AUDIO
DELAY setting (as above)
S AUDIO MUTE 0/1 0=ON 1=MUTE
R AUDIO MUTE Reports the numeric equivalent for AUDIO
MUTE setting (as above)
S KEY LOCK 0/1 0=ENABLE 1=DISABLE
R KEY LOCK Reports the numeric equivalent for KEY
LOCK setting (as above)
FW Checks the FIRMWARE version
S RESET 1 Setups the numerical equivalent for RESET
setting (as left)
Note:
1. RS-232 commands will be not executed unless followed with carriage
return and LF (Line Feed).
2. Commands are not case-sensitive.
3. Resolutions 1~16 are RGB encoded and 17~25 are YUV encoded.

14
6.6 OSD Menu
1st Layer 2nd layer 3rd Layer 4th Layer
DISPLAY OUTPUT Native
640×480 60
800×600 60
1024×768 60
1360×768 60
1280×720 60
1280×800 60
1280×1024 60
1440×900 60
1400×1050 60
1680×1050 60
1600×1200 60
1920×1080 60
1920×1200 60
720×480p 60
1280×720p 60
1920×1080i 60
1920×1080p 60
720×576p 50
1280×720p 50
1920×1080i 50
1920×1080p 50
SIZE OVER SCAN
FULL
ASPECT RATIO
PAN SCAN
LETTER BOX
UNDER 2
UNDER 1

15
1st Layer 2nd layer 3rd Layer 4th Layer
MODE INFO INFO
ON
OFF
PC(PC mode only) AUTO SETUP No
YES
H_POSITION 0~60 (30)
V_POSITION 0~60 (30)
PHASE
CLOCK
WXGA/XGA XGA
WXGA
RESET NO
YES
R
G
COLOUR B
R OFFSET
G OFFSET
B OFFSET
CONTRAST 0~60
COLOUR BRIGHTNESS 0~60
HUE 0~600~60
SATURATION 0~60
SHARPNESS 0~60
OFF
NR. LOW
MIDDLE
HIGH

16
1st Layer 2nd layer 3rd Layer 4th Layer
VOLUME 0~100
DELAY OFF
40mS
AUDIO 110mS
150mS
SOUND ON
MUTE
SETUP FACTORY RESET NO
YES
KEY LOCK OFF
ON
INFORMATION INPUT
OUTPUT
REVISION
Note: Items in Bold are the Factory default settings. Items in ( ) are default
values.

17
6.7 Input Resolution Support
INPUT RESOLUTION HDMI PC
NTSC/PAL - -
VGA@60/72/75 Hz  
SVGA@56/60/72/75 Hz  
XGA@60/70/75 Hz  
SXGA@60/75 Hz  
UXGA@60 Hz  
1280×800@60 Hz  
1680×1050RB@60 Hz  
1920×1080@60 Hz  
480i/576i -
480p/576p -
720p@50/60 Hz -
1080i@50/60 Hz -
1080p@50/60 Hz -

18
7. CONNECTION DIAGRAM
SERVICE PCHDMI AUDIO XGA
MENU
ENTER
- +
720P
INPUT
HDMI/
PC
INPUT
IR
Blaster
IR
Extender
CAT5e/6/7 OUT
MODE LINK
LANRS-232 IN
DC 24V
POWER
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
PC/NB
PC/NB
Router with
Internet
Connection
Compatible
Receiver unit
with PoE
function
HDMI
Video/DVD Player

19
8. SPECIFICATIONS
Output Video Bandwidth 300MHz / 10.2Gbps
Ethernet Speed 100 Mbps
Input Ports 1×HDMI, 1×PC, 1 x 3.5mm Phone Jack (L/R) ,
1×RS-232, 1×LAN, 1×IR Extender
Output Ports 1CAT5e/6, 1×IR Blaster
CAT5e/6/7 Output Cable
Distance
Up to 100 Meters
Supports Resolution HD: 480i~1080p
PC: VGA ~ WUXGA(RB)
CAT5e/6/7 Output Reso-
lution
HD: Up to 1080p@60Hz
PC: Up to WUXGA(RB)
IR Frequency 30~50kHz
ESD Protection Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Dimensions (mm) 145 (W)×192 (D)×30(H)/Jacks Excluded
145 (W)×202 (D)×30(H)/Jacks Included
Weight
608g
Chassis Material Aluminum
Colour Black
Operating Temperature 0 ˚C~40 ˚C / 32 ˚F~104 ˚F
Storage Temperature −20 ˚C ~ 60 ˚C / −4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90 % RH (non-condensing)
Power Consumption 17W

20
9. ACRONYMS
ACRONYM COMPLETE TERM
CAT5e Category 5 Cable
CAT6 Category 6 Cable
CAT7 Category 7 Cable
CV Composite Video
DVI Digital Visual Interface
HDMI High-Definition Multimedia Interface
IR Infrared
WUXGA (RB) Widescreen Ultra Extended Graphics Array (Reduce blanking)
