CYP CPLUS-V32USBC User manual

Operation Manual
Operation Manual
UHD+3×2 Matrix Switcher with USB Ethernet Hub
CPLUS-V32USBC

®
registered trademarks of HDMI licensing Administrator, Inc.

DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Cypress Technology assumes no responsibility for any
infringements of patents or other rights of third parties which may result from
its use.
Cypress Technology assumes no responsibility for any inaccuracies that
may be contained in this document. Cypress also makes no commitment to
update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document are trademarks of
the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for su󰀩cient space
for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use to
avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2020/10/29 Preliminary release

CONTENTS
1. Introduction...................................................................1
2. Applications ..................................................................1
3. Package Contents ........................................................1
4. System Requirements..................................................2
5. Features.........................................................................2
6. Operation Controls And Functions.............................3
6.1 Front Panel...............................................................3
6.2 Rear Panel................................................................4
6.3 RS-232 Pinouts and Defaults ...................................5
6.4 WebGUI Control .......................................................6
6.4.1 AV Switch Tab..................................................8
6.4.2 USB Settings Tab ..........................................10
6.4.3 Automation Tab..............................................11
6.4.4 EDID Tab .......................................................14
6.4.5 Network Tab ..................................................16
6.4.6 System Tab....................................................17
6.5 Telnet Control .........................................................18
6.6 Serial and Telnet Commands .................................18
7. Connection Diagram ..................................................43
8. Specications .............................................................44
8.1 Technical Specications .........................................44
8.2 Video Specications ...............................................45
8.3 Audio Specications ...............................................47
8.3.1 Digital Audio ..................................................47
8.3.2 Analog Audio .................................................47
8.4 Cable Specications...............................................48
9. Acronyms ....................................................................49

1
1. INTRODUCTION
This 3×2 matrix switch is designed for use in environments needing a wide
range of exibility when it comes to inputs, outputs, and control. The two
most common video input interfaces (HDMI, USB-C) are included along with
a pair of HDMI outputs and a single analog audio breakout port, providing
the ultimate in source compatibility and exibility.
All inputs and outputs on this unit are HDCP 2.2 compliant and provide
support for resolutions up to a maximum of 4K@60Hz (4:4:4, 8-bit or 4:2:0,
12-bit HDR). The included USB-C input complies with the USB 3.0 standard
and supports audio/video bypass, and device charging, as well as the ability
to provide a network connection.
This matrix also includes standard USB 3.0 hub functionality with two host
ports (one Type-B and one Type-C), plus two device ports (Type-A) for a
exible KVM conguration. It is ideal for use in meeting rooms or classrooms.
This unit is controllable via front panel controls, WebGUI, Telnet and RS-232.
2. APPLICATIONS
• Home entertainment room
• Lecture hall display and control
• Showroom displays
• Meeting room presentation and control
• Classroom presentations
3. PACKAGE CONTENTS
• 1× UHD+ 3×2 Matrix Switcher with USB Ethernet Hub
• 1× 24V/5A DC Power Adapter
• 1× Shockproof Feet (Set of 4)
• 1× Operation Manual

2
4. SYSTEM REQUIREMENTS
• HDMI or USB-C source equipment such as media players, video game
consoles, laptops, or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors, or audio ampliers.
• The use of Premium High Speed HDMI cables is highly recommended.
5. FEATURES
• HDMI 2.0 and DVI 1.0 compliant
• HDCP 1.x and 2.2 compliant
• 1 USB Type-C and 2 HDMI inputs
• 2 HDMI outputs with independent matrix switching and auto-switch support
• Supports up to 4K UHD (18Gbps, 4K@60Hz 4:4:4, 8-bit) video input and
output
• Supports Deep Color input and output up to 12-bit
• Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
• Supports pass-through of many audio formats including 8 channel LPCM,
Bitstream, and HD Bitstream
• HDMI Output A supports 4K to 1080p downscaling
• USB-C port functionality is switchable between a A/V focused mode
(4K@60Hz) with USB 2.0 data and a mixed media mode with simultaneous
A/V (4K@30Hz), USB 3.0, and Ethernet support
• USB-C port provides up to 20V/3A (60W) power to the connected device
• Supports pass-through of 8 channel LPCM, bitstream & HD bitstream
audio formats
• Analog audio output source audio can be from output A or B (LPCM 2.0
sources only)
• Integrated USB 3.0 hub with one dedicated Type-B host port and two
Type-A device ports (The USB-C port may optionally be used as an
alternate host port)
• Supports basic signal event automation (via RS-232, Ethernet, or CEC)
• Controllable via front panel controls, WebGUI, Telnet and RS-232

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
USB USB
USB
A
B
OUT
OUT
USB 1 USB 2
USB-C USB-CHDMI 1 HDMI A HDMI BHDMI 2
1 2 3 4 5 6 7
1POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
2OUT A & B LEDs: The illuminated LED indicates which source is
currently selected for each output.
3HDMI A & HDMI B Buttons: Press either button to sequentially switch
through the available inputs for the associated HDMI output.
4USB-C & USB LEDs: The illuminated LED indicates which USB host
port is currently active.
5USB Button: Press this button to select which USB host port is currently
active. “USB” selects the USB Type-B port on the front of the unit, “USB-C”
selects the USB Type-C port on the rear of the unit.
6USB 1 & 2 Device Ports (Type-A): Connect directly to standard USB
devices such as a mouse, keyboard or ash drive to extend their USB
functionality to the currently active USB host port.
7USB Host Port (Type-B): Connect directly to a standard USB host
such as a PC or laptop to extend their USB functionality to all currently
connected USB devices.
Note: Only active when the USB mode selection is set to “USB”.

4
6.2 Rear Panel
DC 24VLAN
LINE OUT
OUT
HDMI BHDMI A
IN
HDMI 1 HDMI 2 RS-232
CTL CLI
USB-C
21 3 4 5 6 7
1USB-C IN Port: Connect to USB Type-C host or video source equipment
such as a PC or laptop. When the USB-C port has “Super Speed”
support active, this port can support 4K30 A/V, Ethernet, and USB
simultaneously. When “Super Speed” is disabled, this port will support
full bandwidth 4K60 A/V content but USB data functionality will be limited
to USB 2.0 levels.
Note: Not all devices with USB Type-C ports can support video output.
Please verify that the device supports video output from the USB Type-C
port before attempting to use it as a video source.
2HDMI IN 1 & 2 Ports: Connect to HDMI source equipment such as
media players, game consoles, or set-top boxes. DVI sources are
supported with the use of an HDMI to DVI adapter.
3HDMI OUT A & B Ports: Connect to HDMI TVs, monitors, or ampliers
for digital video and audio output.
4LINE OUT Port: Connect to powered speakers, headphones, or an
amplier for analog stereo audio output extracted from the selected
HDMI output (LPCM 2.0 sources only).
5RS-232 CTL 4-pin Terminal Block: Connect to the device you wish to
control via a 3-pin adapter cable to receive event automation RS-232
commands from the unit.
RS-232 CLI 4-pin Terminal Block: Connect directly to a PC, laptop, or
other serial control device with a 3-pin adapter cable to send RS-232
commands to control the unit.
Note: The 24 volt pins are included to provide power to a dedicated
external control product and should NOT be used when connecting a
standard RS-232 device.
6LAN Port: Connect directly, or through a network switch, to your PC/
laptop to control the unit via Telnet/WebGUI and to extend the network
across the USB Type-B and Type-C ports.
Note: The USB Type-C port must be in “Super Speed” mode to support
Ethernet extension.
7DC 24V Port: Plug the 24V DC power adapter into this port and connect
it to an AC wall outlet for power.

5
6.3 RS-232 Pinouts and Defaults
Serial Port Default Settings
Baud Rate 19200
Data Bits 8
Parity Bits None
Stop Bits 1
Flow Control None
RS-232 Port 1 (CTL) RS-232 Port 2 (CLI)
1
2
3
4
GND
24V
TxD
RxD
4-pin
Terminal Block
1
2
3
4
GN
D
24V
TxD
Rx
D
4-pin
Terminal Block
Note: The 24 volt pins (pin 1) are included to provide power to a dedicated
external control product and should NOT be used when connecting a
standard RS-232 device
