CYP CMPRO-U4H4CVPL User manual

CMPRO-U4H4CVPL
4K2K 4×4 HDMI Matrix over CAT5e/6/7
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2014 by Cypress Technology.
All Rights Reserved.
Version 1.0 April 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 15/05/14 Preliminary Release
RDV2 18/09/14 Add RS-232 Command

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 2
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Remote Control................................5
6.4 IR Cable Pin Assignment..................5
6.5 RS-232 Pin Assignment .....................6
6.6 RS-232 and Telnet Commands .......7
6.7 Telnet Control ...................................9
6.8 Web GUI Control ............................11
7. Connection Diagram .......................... 12
8. Specications ...................................... 13
8.1 CAT5e/6/7 Cable Specication ...13
8.2 CAT5e/6/7 Cable Specication ...14
9. Acronyms ............................................. 15

1
1. INTRODUCTION
The 4K2K 4 by 4 HDMI Matrix over CAT5e/6/7 supports the transmission
of video (resolutions up to 4K2K Full HD), multi-channel digital audio
and control via IR, RS-232, Telnet or Web GUI from four high denition
sources to four outputs over a single CAT5e/6/7 cable (up to 60m) for
each output.
It supports high resolution digital audio formats such as LPCM 7.1CH,
Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio as well as
3D content that can be displayed when connecting a 3D TV and 3D
source.
2. APPLICATIONS
• HDMI Matrix System
• Video/TV wall display and control
• Security surveillance and control
• Commercial advertising, display and control
• University lecture hall, display and control
• Retail sales and demonstration
3. PACKAGE CONTENTS
• 4K2K 4×4 HDMI Matrix over CAT5e/6/7
• 1×IR Extender
• 1×IR Blaster
• 1×24 V/3.75A DC Power Adaptor
• 1×Power Cord
• 1×IR Remote Control with battery
• 1x Right and Left Ear Rack Sets
• Operation Manual

2
4. SYSTEM REQUIREMENTS
• HDMI equipped source devices, connect with HDMI cables or DVI
equipped source, connect with DVI to HDMI cables
• HDMI equipped displays (TVs or monitors) or HDMI equipped AV
receivers, connect with HDMI cables
• Industry standard CAT5e/6/7 cables
• HDBaseT™ Receivers
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Supports HDMI 3D features
• Supports resolutions VGA~WUXGA and 4K2K @50/60(YUV_420)
dependent upon the output display’s EDID settings
• Supports distances up to 60 meters through CAT5e/6/7 cables
• Supports 3D signal display dependent upon the output display EDID
settings
• Supports HDMI input/output up to 10 meters at 8-bit/12-bit resolution
or 5 meters at 4K2K resolution
• Supports bi-directional IR from input and output locations or 5
meters at 4K2K resolution
• Supports RS-232, remote control, on-panel control and IP Control
(Telnet & Web GUI)
• 1U size design
• Supports external and internal EDID settings
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
Note:
Do not connect the LAN/CONTROL port to CAT outputs of this
device, doing so may tigger the device to shoot down.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
4X4 HDMI MATRIX
OVER CAT5e/6/7
POWER LOCK MENU
A/1B/2 C/3D/4
OUT
IN
61 2 3 4 5
1LCM: Displays the setting information of each input and output
setting.
2IR: IR Receiver window (accepts the remote control signal of this
device only).
3POWER: Press this button to power the device on/off. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
4LOCK: Press this button to lock all the buttons on the panel; press
again to unlock. The LED will illuminate when locked.
5MENU: Press this button to access the LCM menu system, from
here EDID settings can be managed and IP system settings are
displayed.
6A~D/1~4 and OUT/IN: Press the OUT or IN button to select the
output or input mode and then press the required number button
to make the selection accordingly.
For example, if outputs A~B need to be set to input 1 and outputs
C~D need to be set to input 2, then the following sequence of
button presses need to be performed:
Press: OUTABIN1MENU,
and then press: OUTCDIN2MENU.
Note: If the MENU button is not pressed the selection will not be
changed.

4
6.2 Rear Panel
IR OUT
IR IN
ALL
RS232
IP
CONTROL
SERVICE
1
IR IN IR OUT
2
IR IN IR OUT
3
IR IN IR OUT
4
IR IN IR OUT
HDMI IN 1HDMI IN 2 HDMI IN 3 HDMI IN 4 DC 24V
1
2
3
4
V+
GND
GND GND
V+
CAT5e/6/7 OUT CAT5e/6/7 OUT CAT5e/6/7 OUT
CBA D
CAT5e/6/7 OUT
2 3 4 4 4 4 9 107
1 85 6 5 6 5 6 5 6
1RS-232: Connect to a PC or control system with D-Sub 9-pin cable
for the transmission of RS-232 commands.
2IP & CONTROL: This port is the link for Telnet or Web GUI controls,
connect to an active Ethernet link with an RJ45 terminated cable (for
further details, please refer to section 6.8 & 6.9).
3SERVICE: Manufacturer use only.
4CAT5e/6/7 OUT A~D: Connect from these CAT outputs to the CAT
input port of the receiver units with a single CAT5e/6/7 cable for HDMI
Audio/Video and IR/RS-232 control signal transmission.
5IR IN 1~4: Connect to the IR extenders for IR signal reception. Ensure
that the remote being used is within the direct line-of-sight of the IR
extender for it will send out the IR signal to the selected receiver's
IR OUT.
6IR OUT 1~4: Connect to the IR blasters for IR signal transmission.
Place the IR blaster in direct line-of-sight of the equipment to be
controlled for it will blaster out the IR signal received from the
receiver side choosen by input selection.
7HDMI IN 1~4: Connect to the HDMI input source devices such as a
DVD player or a Set-top Box with HDMI cable or DVI to HDMI cable.
8ALL IR OUT: Connect to the IR blaster for IR signal transmission to
the source side. Place the IR blaster in direct line-of-sight of the
equipment to be controlled for it will blaster out all signal received
from the IR IN at the receiver sides.
9ALL IR IN: Connect to the IR extender for IR signal reception. Ensure
that remote being used is within the direct line-of-sight of the IR
extender for it will send out the signal to all receiver's IR OUT.
10 DC 24V: Plug the 24 V DC power supply into the unit and connect the
adaptor to an AC outlet.
Warning: Please do not connect the CAT5e/6/7 cable into the
receiver's LAN port.

5
6.3 Remote Control
1
POWER: Press this button to switch
on the device or set it to standby
mode.
2
IN: Input ports selection 1~4.
3
OUT: Output ports selection A~D.
6.4 IR Cable Pin Assignment
3
1
3
1
2
2
Power
IR Blaster Signal
NC
IR Signal
Power
Grounding
IR Extender
IR Blaster
1
23
1A
B
2
C
3
4D
CR-121
IN OUT

6
6.5 RS-232 Pin Assignment
CMPRO-U4H4CVPL Remote Control Console
PIN Assignment PIN Assignment
1 NC 1 NC
2Tx 2Rx
3Rx 3Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None

7
6.6 RS-232 and Telnet Commands
Command Description
help Dipslay all available commands
A1~A4 Switch Output A to 1~4
B1~B4 Switch Output B to 1~4
C1~C4 Switch Output C to 1~4
D1~D4 Switch Output D to 1~4
AB…1~AB…4 Switch Output ABCD to 1~4 at the
same time
SETIP <IP> <SubNet> <GW> Setting IP. SubNet. GateWay<Static IP>
RSTIP IP conguration was reset to factory
defaults<DHCP>
IPCONFIG Display the current IP cong
P0 Power Off
P1 Power On
STORE 01~04 Store current I/O position (01~04)
PRESET 01~04 Recall the store I/O Position (01~04)
SHOW 01~04 Show current port's I/O position (01~04)
NAME N1 N2 Name the stored port N1(01~04)
no more than 8 charactors, N2
(ABCDEFGH)
I1~I4 Switch all the output to 1~4
ST Display the current matrix state and
rmware version
RS System Reset to A1, B1, C2, D2, E3, F3,
G4, H4
EM Setting EDID MODE. 1-STD 2-TV.
?Display all available commands
QUIT Exit (Telnet only)

8
UARTBAUD? Display baud rate setting 1~6
1: 9600bps
2: 14400bps
3: 19200bps
4: 38400bps
5: 57600bps
6: 115200bps
UARTBAUD1 Set output A’s baud rate from 1~6
UARTBAUD2 Set output B’s baud rate from 1~6
UARTBAUD3 Set output C’s baud rate from 1~6
UARTBAUD4 Set output D’s baud rate from 1~6
UARTSW? Display output’s UART status
UARTSW0 Switch to MCU. Allowing Receivers to
send commands to Matrix.
UARTSW1 Switch to output A and allow Matrix
to send commands to Receiver’s
connected device.
UARTSW2 Switch to output B and allow Matrix
to send commands to Receiver’s
connected device.
UARTSW3 Switch to output C and allow Matrix
to send commands to Receiver’s
connected device.
UARTSW4 Switch to output D and allow Matrix
to send commands to Receiver’s
connected device.
Quit Exit (for telnet only)
Note: 1. All the command will be not executed unless followed with a
carriage return. All letters are case-insensitive.
2. Commands are under RS-232 control only.
3. EDID STD@1080p/2CH, EDID TV@Output A.

9
6.7 Telnet Control
Before attempting to use the telnet control, please ensure that both
the Matrix (via the 'LAN /CONTROL' port) and the PC/Laptop are
connected to the active networks.
To access the telnet control in Windows 7, click on the 'Start' menu
and type "cmd" in the Search eld then press enter.
Under Windows XP go to the 'Start' menu and click on "Run", type
"cmd" with then press enter.
Under Mac OS X, go to Go→Applications→Utilities→Terminal
See below for reference.

10
Once in the command line interface (CLI) type "telnet", then the IP
address of the unit and "23", then hit enter.
Note: The IP address of the Matrix can be displayed on the device's
LCM monitor by pressing the Menu button twice.
This will bring us into the device which we wish to control. Type "HELP"
to list the available commands.
Type “IPCONFIG” To show all IP congurations. To reset the IP,
type “RSTIP” and to use a set static IP, type ”SETIP” (For a full list of
commands, see Section 6.7).
Note: Any commands will not be executed unless followed by a
carriage return. Commands are case-insensitive. If the IP is changed
then the IP Address required for Telnet access will also change
accordingly.

11
6.8 Web GUI Control
On a PC/Laptop that is connected to the same active network as the
Matrix, open a web browser and type device's IP address on the web
address entry bar. The browser will display the device's status, control
and User setting pages.
Click on the 'Control' tab to control power, input/output ports, EDID
and reset mode.
Clicking on the 'User Setting' tab allows you to reset the IP
conguration. The system will ask for a reboot of the device every time
any of the settings are changed. The IP address needed to access
the Web GUI control will also need to be changed accordingly on the
web address entry bar.

12
7. CONNECTION DIAGRAM
IR OUT
IR IN
ALL
RS232
IP
CONTROL
SERVICE
1
IR IN IR OUT
2
IR IN IR OUT
3
IR IN IR OUT
4
IR IN IR OUT
HDMI IN 1HDMI IN 2HDMI IN 3HDMI IN 4 DC 24V
1
2
3
4
V+
GND
GND GND
V+
CAT5e/6/7 OUT CAT5e/6/7 OUT CAT5e/6/7 OUT
CBA D
CAT5e/6/7 OUT
IR EMITTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
ZONE A
RX
ZONE C
RX
ZONE D
RX
1 2 3 4
ZONE B
RX
21 3 4
Blu-ray Player
RS-232 Equipped PC
or Control System
CAT5e/6
Output
Power
Supply
Network Router
IR In All
IR Out All
Media Server Satellite Receiver Set-top Box
HDMI
Input
IR In/
Out

13
8. SPECIFICATIONS
Video Bandwidth 340 MHz/10.2 Gbps
Input Ports 4×HDMI, 5×IR Extender, 1×RS-232, 1×RJ-
45(Control), 1×Mini USB Type B (For
rmware updated only)
Output Ports 4×CAT5e/6/7, 5×IR Blaster
ESD Protection Human-body Model:
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
Power Supply 24 V/3.75 A DC (US/EU standards, CE/
FCC/UL certied)
Dimensions 436 mm (W)×249mm (D)×44 mm (H)/
Jacks Excluded
436 mm (W)×256.2mm (D)×48 mm (H)/
Jacks Included
Weight 3352 g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0 ºC~40 ºC/32 ºF~104 ºF
Storage Temperature −20 ºC~60 ºC/−4 ºF~140 ºF
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 66W
8.1 CAT5e/6/7 Cable Specication
Cable
Type
Range Pixel clock
rate
Video Data
Rate
Supported Video
CAT5e/6/
CAT 7
60 m <=225 MHz <=5.3 Gbps
(HD Video)
Up to 1080p, 60 Hz,
36 bits 3D(data rates
lower than 5.3 Gbps
or below 225 MHz
TMDS clock).

14
8.2 CAT5e/6/7 Cable Specication
INPUT OUTPUT
640x480@60/72/75/85 V V
800x600@56/60/72/75/85 V V
1024x768@60/70/75/85 V V
1280x720@60 V V
1280x1024@60 V V
1600x1200@60 V V
1920x1200@60RB V V
3840x2160p@24/25/30 V V
4096x2160p@24 V V
4096x2160p@50/60(YUV_420) V V
480I/576I V V
480P/576P V V
720P@50/60 V V
1080I@50/60 V V
1080P@50/60 V V
1080P@24/25/30 V V

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
MPM-CMPROU4H4CVPL
9. ACRONYMS
ACRONYM COMPLETE TERM
CLI Command Line Interface
DTS Digital Theater System
DVI Digital Visual Interface
EDID Extended Display Identication Data
GUI Graphical User Interface
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
LCM Liquid Crystal Module
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA Widescreen Ultra Extended Graphics Array
