CYP CPLUS-V11PE8 User manual

CPLUS-V11PE8
4K UHD+ LPCM 7.1 Audio Extractor
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 24/11/16 Preliminary release

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 RS-232 Commands...........................5
6.4 EDID Manager ..................................6
7. Connection Diagram .......................... 10
8. Specications ...................................... 11
9. Acronyms ............................................. 12

1
1. INTRODUCTION
This 4K UHD LPCM 7.1 Channel Audio Extractor can extract up to 8
channels of LPCM audio from an HDMI source, allowing the user to
convert high quality lossless HDMI audio into multi-channel analog
signals for use with powered speakers or non-HDMI AV receivers.
Bitstream extraction is also supported via an optical S/PDIF output.
Both the input and output HDMI ports support 4K UHD resolutions
up to 4K@60Hz (YUV4:4:4, 8-bit) and are capable of providing high
quality audio and video performance. This unit supports pass-through
of HD bitstream audio formats, as well as standard bitstream formats
and LPCM 7.1 with audio sampling rates up to 192 kHz. Built in EDID
management support allows the user select from multiple EDIDs and,
with the use of optional PC software, to edit, upload and download
EDID les.
2. APPLICATIONS
• Audio extraction for use with non-HDMI AV receivers or powered
speaker systems
• AV system integration and home theater installation
• Allow use of DVI displays with analog speaker systems with HDMI
sources
• HDMI/DVI EDID management
3. PACKAGE CONTENTS
• 1 x 4K UHD LPCM 7.1 Audio Extractor
• 1 x 5V Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• Analog audio receiving equipment such as audio ampliers or
powered speakers.

2
• The use of “Premium High Speed HDMI” cables is highly
recommended.
5. FEATURES
• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compliant with the use of an HDMI-DVI adaptor
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3940x2160@60 Hz (YUV 4:4:4, 8-bit) &
4096x2160@60 Hz (YUV 4:4:4, 8-bit)
• Supports 48-bit Deep Color up to 1080p60
• 2 slots for user-created EDIDs, and EDID bypass support
• Supports pass-through of LPCM 7.1, bitstream and HD bitstream
audio formats over HDMI
• Audio extraction to 8 channel analog output and optical S/PDIF
output
• Supports HDMI audio sampling rates up to 192 kHz
• Supports S/PDIF audio sampling rates up to 192 kHz
• Provides EDID management with EDID bypass and 2 user modiable
EDIDs
• PC based EDID management tool support
• Supports RS-232 style control via a Virtual COM port over USB
Note: 4K UHD sources or equivalently high-bandwidth signals require
an appropriate compatible display and HDMI cables in order to
achieve the best image quality. The use of “Premium High Speed
HDMI” cables is highly recommended.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
BITSTREAM
TV
LPCM
7.1CH
+
POWER POWER LINK LPCM
4K UHD+ LPCM 7.1 Audio Extractor
1 2 3 4
1POWER/POWER LED: Press this button to power the unit on or off.
The LED will be lit GREEN when the unit is receiving power.
Note: Press and hold the Power button for 3 seconds to perform a
factory reset. Release the button once the LEDs begin ashing.
2LINK: This LED will illuminate to indicate that a live source has been
detected on the input port. When no source is detected the LED
will remain off.
3LPCM: This LED will illuminate when LPCM audio has been detected
on the HDMI input.
4TV/BITSTREAM/LPCM 7.1CH: This switch selects the EDID that is
provided to the input. The “TV” setting passes the EDID from the
connected display without modication. “Bitstream” is the User
1 EDID and by default has a native resolution of 1080p60 with
support for LPCM 2.0 and bitstream formats. “LPCM 7.1CH” is the
User 2 EDID and by default has a native resolution of 1080p60 and
limits the audio support to LCPM 7.1. The two User EDIDs can be
modied using the PC software.

4
6.2 Rear Panel
HDMI IN HDMI OUT
AUDIO OUT
OPTICAL FR FL FC LFE RR RL RRC RLC
SERVICE
DC 5V
1 2 3 4 6
5
1HDMI IN: Connect to HDMI source equipment such as a media
player, game console or set-top box.
2HDMI OUT: Connect to HDMI TVs, monitors or ampliers for digital
video and audio output. (LPCM up to 7.1, bitstream, HD bitstream)
3OPTICAL OUT: Connect to powered speakers or an amplier for
digital audio output using an appropriate optical cable. (LPCM 2.0
and bitstream only)
48 Channel OUT: Connect to powered speakers or an amplier for
multi-channel analog audio output. (LPCM up to 7.1 only)
5SERVICE: This slot is for EDID management, control and rmware
update use. Connect directly to your PC/laptop using a standard
Mini-USB cable to connect using the PC software or to send
commands (via virtual COM port).
6DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.

5
6.3 RS-232 Commands
Command Name Description Parameters
P0 SET UNIT POWER OFF NONE
P1 SET UNIT POWER ON NONE
P? GET POWER STATUS NONE
SOURCEDET SHOW INPUT
INFORMATION
NONE
SINKINFO SHOW SINK
INFORMATION
NONE
HDCPIN SET/SHOW INPUT
HDCP STATUS
HDCPIN N [N=1~3, ?]
1: FOLLOW IN
2: FOLLOW OUT
3: APPLE MODE
?: GET STATUS
Default: FOLLOW OUT
ECHO SET/SHOW CONSOLE
AUTO ECHO MODE
ECHO N [N=0, 1, ?]
0: OFF
1: ON
?: GET STATUS
Default: ON
FADEFAULT SET UNIT TO FACTORY
DEFAULT
NONE
VER SHOW UNIT
FIRMWARE VERSION
NONE
REBOOT SYSTEM REBOOT NONE
? SHOW DESCRIPT OF
COMMAND
NONE
HELP SHOW DESCRIPT OF
COMMAND
NONE
Note: Commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive.

6
6.4 EDID Manager
This unit uses an EDID Management application which allows the
user to copy the EDID from an attached display, edit an existing EDID
le stored on the PC or create a basic EDID from scratch. The EDID
can then be uploaded to the unit for use. Please obtain the EDID
Management software from your authorized dealer and save it in a
directory where you can easily nd it.
Before connecting the unit to your PC, please install the appropriate
Virtual COM Port Driver depending on your Windows version. Next,
install the EDID Management software. After the installation has
successfully completed an icon for it will appears on the windows
desktop. Launch the software by double-clicking on the icon and the
EDID Management device detection window will open up on your
screen.
After launching the software, power the unit on and then connect it
to the PC/laptop using a USB cable. Click on the “Search” button and
any detected units will be displayed in the list. Clicking on a detected
unit will open the EDID Commander window.
EDID Controller Tab
Mode Select: The currently selected EDID is displayed here. The “User
1” EDID corresponds to the “Bitstream” setting on the front of the unit.
The “User 2” EDID corresponds to the “LPCM 7.1” setting on the front
of the unit. Both of these EDIDs are user-replaceable. To return them to
their original values, please perform a factory reset on the unit.

7
Save/Upload/Analysis: EDIDs may also be saved, uploaded or
analyzed.
• Any EDID from the unit or the connected HDMI display can be
saved to your PC as a *.bin le by selecting the EDID source
from the drop down menu and then clicking the “Save” icon.
• Previously saved EDID les (*.bin format) can be re-uploaded
into the unit by selecting the User EDID to replace from the
dropdown and then clicking the “Upload” icon. Before ac-
cepting the upload, the software will check and verify that the
EDID’s header and checksum values are acceptable.
• To analyze any EDID stored within the unit, select the EDID to
view from the dropdown and click on the “Analysis” icon.

8
EDID Creator Tab
Click on the EDID Creator tab to begin designing a new EDID from
scratch (select the “New” icon), to modify an existing EDID stored on
the PC as a .bin le (select the “Load” icon) or to edit an EDID copied
from the unit via the EDID Analyzer’s edit option. Selecting “New” will
automatically populate the various EDID elds with basic information
that can be easily edited to match the user’s preferences. Clicking
on the “Load” icon will open a le load window and after the *.bin le
has been selected and loaded the EDID elds will be populated with
the information from that le. The same will happen when the EDID is
copied from the EDID Analyzer window.

9
The following tabs provide access to a wide range of EDID information
which can be edited:
• Descriptor: This tab allows for the editing of various description
and information elds within the EDID le such as Manufacturer
Name, Monitor Name, etc.
• PC Timing and SD/HD/UHD: These tabs allow for the selection
of the resolutions and refresh rates that the EDID will report as
supported.
• Audio1 and Audio2: These tabs allow for the selection of which
audio formats, audio frequencies, channels and speaker loca-
tions are supported.
• Color Space: This tab allows for the selection of which color
formats and bit depths are supported, including BT.2020 and
HDR support options.
• Others: This tab contains options for supporting 3D and dening
the CEC Address.
Once the user is nished editing or creating an EDID it can be saved
to a *.bin le locally or uploaded directly to the unit using the “Save”
and “Upload” icons respectively.
System Tab
Select the System tab to edit the unit’s description, to reset the unit to
factory defaults and to view the unit’s current hardware and rmware
version information.

10
7. CONNECTION DIAGRAM
HDMI IN HDMI OUT
AUDIO OUT
OPTICAL FR FL FC LFE RR RL RRC RLC
SERVICE
DC 5V
DVD or Blu-ray Player
AV Receiver
Power Supply
HDMI
Input
HDMI
Output
Digital Optical
Audio Output
Multichannel
Audio Output
7.1 Channels
Active Speaker System

11
8. SPECIFICATIONS
Video Bandwidth 600MHz/18Gbps
Input Ports 1 x HDMI
1 x Mini-USB (service & control only)
Output Port 1 x HDMI
1 x Optical S/PDIF (Digital Audio)
HDMI Audio Sampling
Rate
Up to 192 kHz
Optical Audio Sampling
Rate
Up to 192 kHz
HDMI Cable I/O
Distance*
10 meters, 1080p@12-bit
15 meters, 1080p@8-bit
HDMI Audio Format LPCM 2.0/5.1/7.1, Bitstream, HD Bitstream
Optical Audio Format LPCM 2.0, Bitstream
Analog Audio Format 8 Channel
Power Supply 5V / 2.6A DC (US/EU standards, CE/FCC/
UL certied)
ESD Protection Metal
Chassis Material Black
Silkscreen color 213.5mm x 25mm x 108mm (W×H×D)
[Case Only]
Dimensions 213.5mm x 30mm x 116.8mm (W×H×D)
[All Inclusive]
Weight 618g
Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F
Storage temperature -20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (no condensation)
Power Consumption 4.7w
Note: HDMI cable distance might affected by material or design of
cable.
Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)

12
9. ACRONYMS
ACRONYM COMPLETE TERM
CEC Consumer Electronics Control
COAX Coaxial
DTS Digital Theater System
DVI Digital Visual Interface
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
OPT Optical
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA (RB) Widescreen Ultra Extended Graphics Array (Reduce
Blanking)

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
