CYP CPLUS-VSE2DD User manual

CPLUS-VSE2DD
HDMI 2.0 with HDCP2.2 Audio Converter with Dolby
Digital and DTS 2.0+ Digital Out Decoder
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
Manufactured under license from Dolby Laboratories. “Dolby” and
the double-D symbol are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent Nos: 5,956,674;
5,974,380; 6,487,535 & other U.S. and worldwide patents issued
& pending. DTS, the Symbol, & DTS and the Symbol together are
registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc.
Product includes software. © DTS, Inc. All Rights Reserved.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 17/07/15 Preliminary release
30/07/15 Updated text
19/08/15 Updated text

CONTENTS
1. Introduction..............................................1
2. Applications.............................................1
3. Package Contents .................................. 1
4. System Requirements.............................. 1
5. Features....................................................2
6. Operation Controls and Functions......... 3
6.1 Front Panel ..........................................3
6.2 Rear Panel...........................................3
7. Connection Diagram .............................. 5
8. Specications .......................................... 6
8.1 Technical Specications ...................6
8.2 Video Resolutions...............................7
8.3 Audio Specications..........................8
8.4 Input to Output Audio Formats ........8
9. Acronyms .................................................9

1
1. INTRODUCTION
With support for the transmission of 6G video (resolutions up to
4K2K@60Hz Ultra HD, and HDCP 2.2) through High Speed HDMI cables,
this HDMI Audio Converter with Dolby®Digital/DTS®2.0+Digital Out
Decoder allows an HDMI audio signal to be de-embedded and
simultaneously split to both digital and analog audio outputs providing
high quality audio and video performance.
This unit allows you to make the most out of your audio signal when
relaying it to external speakers or to further extend the audio pathway
to another location.
2. APPLICATIONS
• Home entertainment installation
• Audio extraction and extension.
• Connect to non-HDMI AV receivers or wider audio systems
3. PACKAGE CONTENTS
• 1 x HDMI 2.0 with HDCP 2.2 Audio Converter with Dolby Digital and
DTS 2.0+ Digital Out Decoder
• 1×5 V/2.6 A Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
HDMI equipped source device and display (TV/monitor) and/or
amplier/active speakers with analog or digital audio connection
cables.

2
5. FEATURES
• HDMI 6G video (resolutions up to 4K2K@60Hz with YUV444) and
HDCP2.2 compliant
• HDMI 1080p video with 12-bit 'Deep Color', 3D video, and HDCP1.4
compliant
• Dolby Digital Decoder technology embedded
• DTS 2.0+Digital Out Decoder technology embedded
• Integrated digital interpolator lter and Digital-to-Analog Converter
(DAC)
• Supports HDTV resolutions up to 4K2K (3840×2160@24/25/30,
4096×2160@24/25/30, 3840×2160@50/60 with YUV444 &
4096×2160@50/60 with YUV444)
• Supports simultaneous audio output on HDMI, analog L/R, Coaxial
and Optical outputs
• Supports Dolby Digital sampling rates up to 48kHz
• Supports DTS sampling rates up to 96kHz
• Supports LPCM input sampling rates up to 96kHz
• Supports coaxial and optical output audio sampling rates up to
96kHz
• Supports de-embedding the audio signal from an HDTV’s ARC
(Audio Return Channel) connection

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER PCM
ARC
+
1 2 3 4 5
1POWER: This LED will illuminate when the unit is connected to an
active power supply.
2PCM LED: This LED will illuminate when the audio source is encoded
in LPCM 2CH audio format.
3DTS LED: This LED will illuminate when the audio source is encoded
in DTS 2.0+Digital Out audio format.
4Dolby LED: This LED will illuminate when the audio source is
encoded in Dolby Digital audio format.
5ARC Button & LED: Use this button to select the HDMI ARC (Audio
Return Channel) function. Push this button to enable the HDMI
ARC function, the LED will turn on; push this button again to disable
the HDMI ARC function, the LED will turn off. When no ARC source
is detected, the unit will automatically switch back to the HDMI
input.
6.2 Rear Panel
HDMI IN HDMI OUT
DC 5V
LRCOAX OPTICAL
SPDIF EDID SERVICE
HDMI
AUDIO
BYPASS/
2CH
BYPASS/
2CH
STD/
TV
AUDIO OUT
1 2 3 4 5 6 87 9 10
1HDMI IN: Connect to an HDMI source device such as a blu-ray
player, set-top box or any HDMI equipped source device.

4
2HDMI OUTPUT: Connect to an HDMI Ultra HD display (TV/monitor) or
UHD AV receiver for video and audio output.
3L/R OUTPUT: Connect to the analog line-level input of an amplier
or active speakers for audio output.
4COAX OUTPUT: Connect to the digital optical input of an AV
receiver for audio output.
5OPTICAL OUTPUT: Connect to the digital coaxial input of an AV
receiver for audio output.
6HDMI AUDIO BYPASS/2CH: Use this switch to select the audio
format of the HDMI output. Switch to 'BYPASS' to allow the audio to
pass-through from the HDMI input port; switch to '2CH' to enable
audio decoding and LPCM 2CH down-mixing of Dolby Digital or
DTS audio signals from the HDMI audio source.
7SPDIF BYPASS/2CH: Use this switch to select the audio format of the
Coaxial and Optical outputs. Switch to 'BYPASS' to allow the audio
to pass-through from the HDMI input port; switch to '2CH' to enable
audio decoding and LPCM 2CH down-mixing of Dolby Digital or
DTS audio signals from the HDMI audio source.
8EDID STD/TV: Use this switch to select the EDID mode, 'STD (Standard)
mode' or 'TV mode'. When in 'TV mode', the unit will automatically
detect and store the EDID settings of the display connected to
the HDMI output. If there is no picture or a distorted image, please
switch to 'STD mode' which will use video up to 1080p at 60Hz and
audio up to LPCM 2CH at 48kHz, Dolby Digital 5.1CH and DTS 5.1CH.
9SERVICE: Manufacturer use only.
10 DC 5V: Connect the adaptor included in the package to an AC
wall outlet for power supply.

5
7. CONNECTION DIAGRAM
HDMI IN HDMI OUT
DC 5V
LRCOAX OPTICAL
SPDIF EDID SERVICE
HDMI
AUDIO
BYPASS/
2CH
BYPASS/
2CH
STD/
TV
AUDIO OUT
DVD or Blu-ray Player
Power
Supply
Coaxial Digital
Audio Output
Analog Stereo
Output
HDMI
Bypass
Active Speakers AV Receiver
HDTV
Optical Digital
Audio Output
HDMI Input

6
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 600 MHz/6 Gbps
Input Ports 1×HDMI, 1×USB (Service only)
Output Ports 1×HDMI, 1×Coaxial, 1×Optical,
1×L/R (2 RCA)
HDMI Cable Length Input: 10m@1080p, 3m@4K2K
Output: 10m@1080p, 3m@4K2K
Power Supply 5 V/2.6 A DC(US/EU standards, CE/FCC/UL
certied)
ESD Protection Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Dimensions 180 mm (W)×104 mm (D)×25mm (H)/Jacks
Excluded
180mm (W)×112.75 mm (D)×25 mm (H)/
Jacks Included
Weight 374 g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0 ˚C~40 ˚C / 32 ˚F ~104 ˚F
Storage Temperature −20 ˚C~60 ˚C / −4 ˚F~140˚F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 5.06W

7
8.2 Video Resolutions
HDMI/DVI RESOLUTIONS INPUT OUTPUT
640×480@60/72/75/85  
720×400@85  
800×600@56/60/72/75/85  
1024×768@60/70/75/85  
1280×720@60  
1280×768@60/75/85  
1280×800@60  
1360×768@60  
1440×900@60  
1600×900@60  
1600×1200@60  
1920×1080@60  
1920×1200@60  
1440×576i@50  
1440×[email protected]/60  
720×[email protected]/60  
720×576p@50  
1280×720p@50/59.94/60  
1920×1080i@50/59.94/60  
1920×[email protected]/24/25/29.97/30/50/59.94/60  
3840×2160@24/25/30/50/60 (YUV444)  
4096×2160@24/25/30/50/60 (YUV444)  
3840×2160@60 (YUV420)  
4096×2160@60 (YUV420)  

8
8.3 Audio Support Specication
Input Level/
Freq. Output
Output Level
Vrms/db±10% THD+N
Frequency
Response SNR >90db
Crosstalk
<-90dB
HDMI
0dB/1kHz
48~96kHz
Analog 2 Vrms < 0.01% ±1 dBFS >104dB <-110dB
Coaxial 0 dB < 0.00001% ±1 dBFS >141dB <-164dB
Optical 0 dB < 0.00001% ±1 dBFS >141dB <-163dB
HDMI 0 dB < 0.00001% ±1 dBFS >141dB <-164dB
8.4 Input to Output Audio Format
Audio
Input
Input
Format
Audio Output
Analog
L/R
HDMI S/PDIF
Switch Status Switch Status
BYPASS 2CH BYPASS 2CH
HDMI
LPCM
2CH
Analog
2CH LPCM 2CH LPCM 2CH LPCM 2CH LPCM 2CH
Dolby
Digital
Decoded
Lt/Rt
Bitstream
Pass-through LPCM Lt/Rt Bitstream Pass-through LPCM Lt/Rt
DTS Decoded
Lo/Ro
Bitstream
Pass-through LPCM Lo/Ro Bitstream Pass-through LPCM Lo/Ro
HDMI
ARC
LPCM
2CH
Analog
2CH
HDMI Pass-through
LPCM 2CH LPCM 2CH
Dolby
Digital
Decoded
Lt/Rt ARC
Bitstream
Pass-through
LPCM Lt/Rt
DTS Decoded
Lo/Ro LPCM Lo/Ro

9
9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
DVI Digital Visual Interface
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protectionl
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA Wide Ultra Extended Graphics Array

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
