CYP CPLUS-V11PE8 User manual

4K UHD+ HDMI Audio Extractor
(LPCM 7.1)
CPLUS-V11PE8
Operation Manual
Operation Manual
SOLUTIONS FOR GROWTH n - TECH SOLUTIONS
nT
nT15BX04

DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Cypress Technology assumes no responsibility for any
infringements of patents or other rights of third parties which may result from
its use.
Cypress Technology assumes no responsibility for any inaccuracies that
may be contained in this document. Cypress also makes no commitment to
update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer file, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document are trademarks of
the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for su翿cient space
for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use to
avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2016/11/24 Preliminary release
VS1 2018/02/12 Final technical review
VS2 2020/06/24 Updated default EDID

CONTENTS
1. Introduction ...................................................... 1
2. Applications ..................................................... 1
3. Package Contents ........................................... 1
4. System Requirements ..................................... 2
5. Features............................................................ 2
6. Operation Controls and Functions ................ 3
6.1 Front Panel .................................................. 3
6.2 Rear Panel................................................... 4
6.3 Virtual COM Port Control ............................. 4
6.4 EDID Commander ....................................... 6
6.4.1 EDID Controller Tab ........................... 6
6.4.2 EDID Creator Tab ............................... 7
6.4.3 System Tab ......................................... 8
7. Connection Diagram ....................................... 9
8. Specifications ................................................ 10
8.1 Technical Specifications ............................ 10
8.2 Video Specifications .................................. 11
8.3 Audio Specifications .................................. 12
9. Acronyms ....................................................... 13

1
1. INTRODUCTION
This HDMI Audio Extractor can extract up to 8 channels of LPCM audio from
an HDMI source, allowing the user to convert high quality lossless HDMI
audio into multi-channel analog signals for use with powered speakers or
non-HDMI AV receivers. Bitstream extraction is also supported via an optical
S/PDIF output.
Both the input and output HDMI ports support 4K UHD resolutions up to
4K@60Hz (4:4:4, 8-bit) and are capable of providing high quality audio and
video performance. This unit supports passthrough of HD Bitstream audio
formats, as well as standard Bitstream formats and LPCM 7.1 with audio
sampling rates up to 192kHz. Built-in EDID management support allows the
user select from multiple EDIDs and, with the use of optional PC software, to
upload, download, or edit EDID files.
2. APPLICATIONS
• Audio extraction for use with non-HDMI AV receivers or powered speaker
systems
• AV system integration and home theater installation
• Allows the use of a DVI display, combined with an external speaker
system, with an HDMI source
• HDMI/DVI EDID management
3. PACKAGE CONTENTS
• 1×HDMI Audio Extractor (LPCM 7.1)
• 1×5V/2.6A DC Power Adapter
• 1×Operation Manual

2
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as a media player, video game console or
set-top box.
• HDMI receiving equipment such as an HDTV, monitor or audio amplifier.
• Analog audio receiving equipment such as an audio amplifier or powered
speakers.
• The use of “Premium High Speed HDMI” cables is highly recommended.
5. FEATURES
• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compatible with the use of an HDMI-DVI adaptor
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3840×2160@60 Hz (4:4:4, 8-bit) &
4096×2160@60 Hz (4:4:4, 8-bit)
• Supports 48-bit Deep Color up to 1080p@60Hz
• 2 slots for user-created EDIDs, and EDID bypass support
• Supports CEC passthrough
• Supports passthrough of LPCM 7.1, Bitstream and HD Bitstream audio
formats over HDMI
• Audio extraction of LPCM 7.1 sources to 8 channel analog output and S/
PDIF (S/PDIF output is limited to 2 channel source support)
• Audio extraction of Bitstream sources to S/PDIF output (analog output will
be muted)
• Supports HDMI and S/PDIF audio sampling rates up to 192kHz
• Provides EDID management with EDID bypass and 2 user modifiable
EDIDs
• PC based EDID management tool support
• Supports RS-232 style control via a Virtual COM port over USB

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER POWER LINK
BITSTREAM
LPCM Audio Extractor
4K UHD+ LPCM 7.1 TV LPCM
7.1CH
51 2 3 4
1 POWER Button: Press this button to power the unit on or off.
2 POWER LED: This LED will be lit GREEN when the unit is receiving
power.
Note: Press and hold the Power button for 3 seconds (until the LEDs
begin flashing) to perform a factory reset.
3 LINK LED: This LED will illuminate to indicate that a live source has
been detected on the input port. When no source is detected the LED will
remain off.
4 LPCM LED: This LED will illuminate when LPCM audio has been
detected on the HDMI input.
5 TV/BITSTREAM/LPCM 7.1CH Switch: This switch selects the EDID
that is provided to the input. The “TV” setting passes the EDID from the
connected display without modification. “Bitstream” is the User 1 EDID
and by default has a native resolution of 4K@60Hz with support for
LPCM 2.0 and Bitstream formats. “LPCM 7.1CH” is the User 2 EDID
and by default has a native resolution of 4K@60Hz and limits the audio
support to LPCM 7.1. The two User EDIDs can be modified using the PC
software.

4
6.2 Rear Panel
SERVICE
DC 5V
OPTICAL
AUDIO OUT
FR FL FC LFE RR RL RRC RLC
HDMI IN HDMI OUT
1 2 3 54
1 HDMI IN Port: Connect to HDMI source equipment such as a media
player, game console or set-top box.
2 HDMI OUT Port: Connect to an HDMI TV, monitor or amplifier for digital
video and audio output (LPCM up to 7.1, Bitstream, HD Bitstream).
3 OPTICAL OUT Port: Connect to powered speakers or an amplifier for
digital audio output using an appropriate optical cable (LPCM 2.0 and
Bitstream only).
FR~RLC OUT Ports: Connect to powered speakers or an amplifier for
multi-channel analog audio output (LPCM up to 7.1 only).
4 SERVICE Port: This slot is for EDID management, control and firmware
update use. Connect directly to your PC/laptop using a standard Mini-
USB cable to connect using the PC software or to send commands (via
virtual COM port).
5 DC 5V Port: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.
6.3 Virtual COM Port Control
COM PORT SETTINGS
Baud rate 115200
Data bits 8
Parity None
Stop bits 1
Flow control None

5
COMMAND DESCRIPTION & PARAMETERS
?Show the full command list.
HELP Show the full command list.
P1 Power the unit on.
P0 Power the unit off (Stand-by mode).
P? Show the current power state.
SOURCEDET Show the current input source detection state.
SINKINFO Show information about the currently connected
display.
HDCPIN N1 Set the HDCP handling mode for the HDMI input.
Available values for N1:
1 [Follow Input]
2 [Follow Output]
3 [Apple Mode]
HDCPIN ? Show the current HDCP handling mode.
ECHO N1 Set the console text echo mode behavior.
Available values for N1:
0 [Text echoing is off]
1 [Text echoing is on]
ECHO ? Show the current text echoing mode.
FADEFAULT Reset the unit to the factory defaults.
VER Show the unit’s current firmware version.
REBOOT Reboot the unit.
Note: Commands will not be executed unless followed by a carriage return.
Commands are not case-sensitive.

6
6.4 EDID Commander
(1) This unit uses an EDID Management application which allows the user to
copy the EDID from an attached display, edit an existing EDID file stored
on the PC or create a basic EDID from scratch. The EDID can then be
uploaded to the unit for use.
(2) Please obtain the EDID Management software from your authorized
dealer and save it in a directory where you can easily find it.
(3) Before connecting the unit to your PC, please install the appropriate
Virtual COM Port Driver depending on your Windows version. Next,
install the EDID Management software.
(4) After the installation has successfully completed, an icon for it will appear
on the windows desktop. Launch the software by double-clicking on the
icon and the EDID Management device detection window will open up on
your screen.
(5) After launching the software, power the unit on and then connect it to the
PC/laptop using a USB cable. Click on the “ Search” button and
any detected units will be displayed in the list. Clicking on a detected unit
will open the EDID Commander window.
6.4.1 EDID Controller Tab
• Mode Select: The currently selected EDID is displayed here.
- The “User 1” EDID corresponds to the “Bitstream” setting on the front of
the unit. The “User 2” EDID corresponds to the “LPCM 7.1” setting on
the front of the unit. Both of these EDIDs are user-replaceable.
- To return them to their original values, please perform a factory reset on
the unit.

7
• Save/Upload/Analysis: EDIDs may be saved to a PC, uploaded from a
PC or analyzed.
-
Save: Any EDID from the unit or the connected HDMI display can be
saved to your PC as a *.bin file by selecting the EDID source from the
drop down menu and then clicking the “ Save” icon.
-
Upload: Previously saved EDID files (*.bin format) can be re-uploaded
into the unit by selecting the User EDID to replace from the dropdown
and then clicking the “ Upload” icon. Before accepting the upload, the
software will check and verify that the EDID’s header and checksum
values are acceptable.
-
Analysis: To analyze any EDID stored within the unit, select the EDID
to view from the dropdown and click on the “ Analysis” icon.
6.4.2 EDID Creator Tab
• Select: Click on the EDID Creator tab to begin designing a new EDID from
scratch (select the “ New” icon), to modify an existing EDID stored on
the PC as a .bin file (select the “ Load” icon) or to edit an EDID copied
from the unit via the EDID Analyzer’s edit option.
- Selecting “ New” will automatically populate the various EDID fields
with basic information that can be easily edited to match the user’s
preferences.
- Clicking on the “ Load” icon will open a file load window and after the
*.bin file has been selected and loaded the EDID fields will be populated
with the information from that file. The same will happen when the EDID
is copied from the EDID Analyzer window.

8
• Edit: The following tabs provide access to a wide range of EDID
information which can be edited:
-
Descriptor: This tab allows for the editing of various description and
information fields within the EDID file such as Manufacturer Name,
Monitor Name, etc.
-
PC Timing & SD/HD/UHD: These tabs allow for the selection of the
resolutions and refresh rates that the EDID will report as supported.
-
Audio1 & Audio2: These tabs allow for the selection of which audio
formats, audio frequencies, channels and speaker locations are
supported.
- Color Space: This tab allows for the selection of which color formats
and bit depths are supported, including BT.2020 and HDR support
options.
-
Others: This tab contains options for supporting 3D and defining the
CEC Address.
Once the user is finished editing or creating an EDID it can be saved to a *.bin
file locally or uploaded directly to the unit using the “ Save” and “ Upload”
icons respectively.
6.4.3 System Tab
• Configuration & Firmware: Select the System tab to edit the unit’s
description (select the “ Rename” icon), to reset the unit to factory
defaults (select the “ Reset” icon) and to view the unit’s current hardware
and firmware version information.

9
7. CONNECTION DIAGRAM
SERVICE
DC 5V
OPTICAL
AUDIO OUT
FR FL FC LFE RR RL RRC RLC
HDMI IN HDMI OUT
AV Receiver
Power Supply
HDMI Input
Optical Output
HDMI Output Multichannel Output
USB
Game Console
Virtual COM Port
Enabled PC

10
8. SPECIFICATIONS
8.1 Technical Specifications
HDMI Bandwidth 600MHz/18Gbps
Input Port 1×HDMI
Output Ports 1×HDMI
1×Optical (S/PDIF)
8×RCA (Multichannel)
Control Interface 1×USB Mini-B
HDMI Cable Length 10m (1080p@60Hz, 12-bit)
3m (4K@60Hz, 4:4:4, 8-bit)
Baud Rate Up to 115200bps
Power Supply 5V/2.6A DC
(US/EU standards, CE/FCC/UL certified)
ESD Protection Human Body Model:
±8kV (Air Discharge)
±4kV (Contact Discharge)
Dimensions 231.5m×25mm×108mm (W×H×D)
[Case Only]
231.5mm×25mm×118mm (W×H×D)
[All Inclusive]
Weight 618g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C - 40˚C/32˚F - 104˚F
Storage Temperature −20˚C - 60˚C/−4˚F - 140˚F
Relative Humidity 20 - 90% RH (Non-condensing)
Power Consumption 4.7W

11
8.2 Video Specifications
Standard Resolution Support Input Output
640×480 60, 72, 75, 85  
800×600 56, 60, 72, 75, 85  
1024×768 60, 70, 75, 85  
1280×720 50, 60  
1280×768 60, 75, 85  
1280×800 60  
1280×1024 60  
1360×768 60  
1600×1200 60  
1920×1200 60 (RB)  
720×480p 60  
720×576p 50  
1280×720p 60  
1920×1080i 50, 60  
1920×1080p 24, 25, 30, 50, 60  
3840×2160p (YUV 4:2:0) 50, 60  
4096×2160p (YUV 4:2:0) 50, 60  
3840×2160p 24, 25, 30, 50, 60  
4096×2160p 24, 25, 30, 50, 60  

12
8.3 Audio Specifications
Input/Output Audio Analysis:
Measurement
Input Connector
HDMI
Level 0dBFs
Frequency 1kHz
Measurement
Output Connector
HDMI Optical Analog
Output Level 0~−1dB 2Vrms±10%
THD+N <0.01% <0.01%
Frequency
Response ±1dBFS ±1dBFs
SNR >80dB >80dB
Crosstalk <−80dB <−80dB
Audio Sampling Rates:
HDMI 32, 44.1, 48, 88.2, 96, 176.4, 192kHz (Passthrough)
S/PDIF

13
9. ACRONYMS
ACRONYM COMPLETE TERM
3D Three-Dimensional
ARC Audio Return Channel
CEC Consumer Electronics Control
COM Communication
DAC Digital-to-Analog Converter
DVI Digital Visual Interface
EDID Extended Display Identification Data
FC Front Center
FL Front Left
FR Front Right
HD High-Definition
HDCP High-bandwidth Digital Content Protection
HDMI High-Definition Multimedia Interface
HDR High Dynamic Range
LED Light-Emitting Diode
LFE Low Frequency Effect
LPCM Linear Pulse-Code Modulation
PC Personal Computer
RL Rear Left
RLC Rear Left Center
RR Rear Right
RRC Rear Right Center
S/PDIF Sony/Philips Digital Interface Format
SD Standard-Definition
UHD Ultra-High-Definition
USB Universal Serial Bus

CYPRESS TECHNOLOGY CO., LTD.
www.cypress.com.tw
