1. INTRODUCTION
The HDMI™ 4Kx2K LPCM Extractor allows you to extract audio signals
from your HDMI source. When connecting to a TV or display you don’t
always get the best audio, or in the case of a PC monitor, no audio
at all. With this Audio Extractor you can take your original HDMI audio
signal and convert it to digital optical or analog multi-channel audio.
This means that you can output your audio signal to external speakers
or extend your audio signal pathway. Meanwhile, when connecting
a 4Kx2K display a true video will be performed without down grading
the resolution.
2. APPLICATIONS
• Game Entertainment on monitor
• Extend your audio signal
• Audio extraction for non-HDMI AV receivers or wider audio systems
3. PACKAGE CONTENTS
• HDMI 4Kx2K LPCM 7.1 Extractor
• 5V Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as Blu-ray/PS3 player and output display
(TV/monitor) and amplier/active speakers with connection cables.

DRAFT
2
5. FEATURES
• Compliant with HDMI, HDCP 1.2 and DVI 1.0
• Supports HDMI audio sampling rate up to 192 kHz
• Supports Optical S/PDIF audio sampling rate up to 192 kHz
• HDMI supports high-bit-rate (HBR) audio
• No HDMI output connection is required to receive audio at the
analog and optical outputs
• Supports 4 x 3.5mm phone jack for analog multi-channel audio
outputs
• Maximum input and output HDMI cable length can run up to
15 meters at 1080p 8-bit resolution or 10 meters at 1080p 12-bit
resolution
• Supports built-in audio EDID switching among LPCM 7.1CH, TV
(external) EDID, and Bitstream audio
• Supports CEC bypass
• Supports 4Kx2K resolution and 3D signal
Note: When displaying HDMI 4Kx2K signal, equivalent source signal,
output display and HDMI cables are required in order to secure the
best image display.

DRAFT
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Top Panel
LinkLPCM Power
HDMI 4Kx2K
LPCM 7.1 Extractor
31 2
1LPCM: This LED will illuminate when the output audio EDID is switch
to LPCM 7.1CH.
2Link: This LED will illuminate when input source is connected with
HDMI signal.
3Power: This LED will illuminate when the unit is connected with
power supply.
6.2 Right Panel
HDMI InService
1 2
1Service: This port is reserved for rmware update only.
2HDMI IN: This slot is to connect with source equipment such as Blu-
ray/PS3 player with HDMI signal sending.

DRAFT
4
6.3 Left Panel
Out
OpticalHDMIFL/FR LFE/FC
1 2 3 4
1HDMI OUT: Connect to the display (TV/monitor) with an HDMI
cable for video and audio signal output. For 4Kx2K or 3D image
display, an equivalent standard display is required. No HDMI
output connection is required to send audio through the analog
and optical outputs.
2Optical OUT: Connect to audio equipment such as an amplier or
Hi-Fi system with an optical cable for digital audio output. Supports
up to bitstream audio 5.1CH and LPCM 2CH.
3FL/FR OUT: Connect to audio equipment such as an amplier or
active speakers with 3.5mm phone jack cable for front left and
front right audio outputs.
4LFE/FC OUT: Connect to audio equipment such as an amplier or
active speakers with 3.5mm phone jack cable for low-frequency
effects/subwoofer and front center audio outputs.
6.4 Front Panel
DC 5V
Bitstream
TV LPCM
7.1CH
Power
1 2 3
1TV/Bitstream/LPCM 7.1CH: This switch allows users to select the
source’s audio EDID.
TV Mode: Switch to TV mode to use the HDMI output port’s EDID,
the audio supports up to LPCM 7.1 channels.
Bitstream Mode: Switch to Bitstream mode to use the HDMI output
port’s EDID, the audio supports up to compressed audio 5.1
channels.
LPCM 7.1CH Mode: Switch to LPCAM 7.1 mode to use the HDMI
output port’s EDID, the audio supports up to LPCM 7.1 channels.

DRAFT
5
Note: Depending on the input audio format, the unit may not
output audio through all output port. For Example, the optical
output port will have no audio when the input audio format is
more than LPCM 7.1CH.
2Power: Press this button to switch on the device or to set it into
standby mode.
3DC 5V: Plug with 5V DC power adaptor from the AC wall outlet for
power supply.
6.5 Rear Panel
Out
RL/RR RLC/RRC
1 2
1RL/RR: Connect to audio equipment such as an amplier or active
speakers with 3.5mm phone jack cable for rear left and rear
right audio outputs.
2RLC/RRC: Connect to audio equipment such as an amplier or
active speakers with 3.5mm phone jack cable for rear left center
and rear right center audio outputs.

DRAFT
6
7. CONNECTION DIAGRAM
HDMI InService
LinkLPCM Power
HDMI 4Kx2K
LPCM 7.1 Extractor
Out
RL/RRRLC/RRC
Out
OpticalHDMI FL/FRLFE/FC
DVD or Blu-ray Player
Amplier
HDMI Output
HDMI Audio Extractor
7.1 Speakers
Digital Audio
Output (Optical)
Display
HDMI Input

DRAFT
7
8. SPECIFICATIONS
Video Bandwidth 300Mbps / 10.2Gbps
Input Ports 1 x HDMI, 1 x Mini-USB (service only)
Output Ports 1 x HDMI, 1 x Optical, 4 x 3.5mm Phone
Jack
HDMI Audio Sampling
Rate
Up to 192 kHz
Optical S/PDIF Audio
Sampling Rate
Up to 192 kHz
HDMI Audio Format LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH,
DTS 2~5.1CH, Dolby Digital Plus, Dolby
TrueHD, and DTS-HD Master Audio
Optical Audio Format LPCM 2CH, Dolby Digital 2~5.1CH, and
DTS 2~5.1CH
L/R Audio Format 4 x Phone Jacks Output Format
7.1 CH Analog Audio
HDMI I/O 4Kx2K Cable
Distance
Power Supply 5V / 1.2A DC ( US/EU standards, CE/FCC/
UL certied)
ESD Protection Human body model:
±8kV (air-gap discharge)
±6kV (contact discharge)
Dimensions (mm) 85 (W) x 87.5 (D) x 34(H)
Weight (g) 102
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0˚C~40˚C / 32˚F~104˚F
Storage Temperature -20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90% RH (non-condensing)
Power Consumption 2.37W

DRAFT
8
8.1Audio Supports Chart
Output
Audio Mode HDMI Optical L/R
2CH V V V
LPCM 5.1 V V V
LPCM 7.1 V V
Bitstream 5.1 V V
Bitstream 7.1 V
