Cypress DCT-9D User manual

Operation Manual
DCT-9D
DCT-9D
Universal Digital / Analog
Audio Converter with
Dolby Digital Decoder

Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer file, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.0 January 2011
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
Manufactured under license from Dolby Laboratories. “Dolby”and
the double-D symbol are trademarks of Dolby Laboratories.

Safety Precautions
Please read all instructions carefully before installing or operating
this product.
 Always follow basic safety precautions to reduce the risk of
fire, electrical shocks and injuries.
 To prevent fires or shocks do not expose this product to rain,
moisture or install it near water.
 Never spill liquid of any kind on or into this product.
 Never push an object into this device through any openings or
empty slots, as this may damage parts.
 Do not attach the power supply to building surfaces.
 Do not allow anything to rest on the power cables or put it in a
place where it might be stepped on .
 To protect the equipment from overheating, do not block the
slots and openings in the casing that provide ventilation.
Revision History
Revision History
Version No Date Summary of Change
RDV1 20110117 Preliminary Release
RDV2 20110802 Add Dolby Logo
RDV3 20110902 Section 6.2
RDV4 20111020 Section 6.2

Table of Contents
1. Introduction ............................................................................................ 1
2. Applications ........................................................................................... 1
3. Package Contents ................................................................................ 1
4. System Requirements ............................................................................ 1
5. Features .................................................................................................. 1
6. Specications ........................................................................................ 2
6.1 Input Audio Reference Level ....................................................... 2
6.2 Input Audio with Output Audio Comparison Chart .................. 2
7. Operation Controls and Functions ...................................................... 3
7.1 Top Panel ........................................................................................ 3
7.2 Right Panel ...................................................................................... 4
7.3 Left Panel ........................................................................................ 4
7.4 Back Panel ...................................................................................... 4
8. Connection and Installation ................................................................. 5
9. Acronyms ............................................................................................... 6

1. Introduction
The Universal Digital/Analog Audio Converter with Dolby Digital Decoder is a
gadget that can convert Optical, Coaxial and L/R audio signals with output
sound guarranty. With the ability to convert digital signals into analog and
analog signals into digital, this gadget supports the simultaneous conversion
of audio formats so when you are converting Optical into L/R audio you
can also convert it into Coaxial and enjoy it without pop sound or suddend
disappear. Therefore, if you find yourself limited by multiple audio formats,
why not consider the Universal Digital/Analog Audio Converter with Dolby
Digital Decoder and find out what pure audio sounds like.
2. Applications

Analog audio to digital audio signal conversion

Digital audio to analog audio signal conversion with Dolby Digital
Decoder

Simultaneously digital and analog audio output
3. Package Contents
 Universal Digital / Analog Audio Converter with Dolby Digital Decoder
 Power Adaptor
 User Manual
4. System Requirements
Input audio source(s) equipments with connection cable(s) and output signal
with connection cables.
5. Features

Dolby Digital Decoder technology embedded

Integrated digital interpolator filter and Digital-to-Analog Converter
(DAC)

Integrated Analog –to-Digital Converter (ADC)

Supports sampling frequencies from 32 to 96kHz

Provides electromagnetic-noise-free transmission

Easy to install and operate

Compact and elegant design
1

Input Ports Optical, Coaxial and L/R
Input Format LPCM 2CH and Dolby Digital from Optical/Coaxial
Sample Frequency 32kHz, 96kHz
Output Ports Coaxial, Optical and L/R
L/R Input Impedance 47KΩ
L/R Output Impedance 600Ω
ESD Protection Human body model: ±10kV (air-gap discharge)
±6kV (contact discharge)
Power Supply 5V / 1A DC (US/EU standard, CE/FCC/UL certified)
Dimensions(mm) 97(W) x 85(D) x 35(H)
Weight(g) 120
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0ºC~40ºC / 32ºF~104ºF
Storage Temperature -20ºC~60ºC / -4ºF~140ºF
Power Consumption 1W
Relative Humidity 20~90% RH (non-condensing)
6.1 Audio Specications
OUT
IN Output Output T.H.D+N (A-Weight)
Frequency
Response SNR Crosstalk
Optical
0dBFS
Optical 0 dBFS <0.00001% 0 dBFS >144 dB <-161 dB
Coaxial 0 dBFS <0.00001% 0 dBFS >144 dB <-161 dB
Line-Out 1.8Vrms+-0.1 <0.01% <0.5 dB >109 dB <-100 dB
Coaxial
0dBFS
Optical 0 dBFS <0.00001% 0 dBFS >144 dB <-161 dB
Coaxial 0 dBFS <0.00001% 0 dBFS >144 dB <-161 dB
Line-Out 1.8Vrms+-0.1 <0.01% <0.5 dB >108 dB <-100 dB
Line 2Vrms
Optical 0 dBFS <0.00001% <0.5 dB >96 dB <-113 dB
Coaxial 0 dBFS <0.00001% <0.5 dB >96 dB <-113 dB
Line-Out 1.8Vrms+-0.1 <0.01% <1 dB >95 dB <-100 dB
6.2 Input Audio to Output Audio Chart
Audio Input Input Format Audio Output
Analog L/R COAXIAL OPTICAL
Analog L/R Analog 2CH Analog 2CH LPCM 2CH
COAXIAL
OPTICAL
LPCM 2CH Analog 2CH LPCM 2CH
Dolby Digital Decoding Lt/Rt Bypass
6. Specications
2

7. Operation Controls and Functions
7.1 Top Panel
POWER L/R COAX OPTICAL
UNIVERSAL
Dolby DIGITAL / ANALOG
AUDIO CONVERTER
D
① ② ③ ④ ⑤
① When the device is turned on the LED is green, and when turned off the
devices LED is red. When the power plug us connected with AC wall
outlet the device will automatically turn on.
② Dolby Digital LED indicator: When the input source is with Dolby Digital
signal the LED will illuminate in red and if its without the LED will not
illuminat.
③Input Analog 2CH LED indicator: When selecting L/R input, the blue LED
will turn on.
④Input Coax LED indicator: When selecting Coaxial input, the blue
LED will switch on.
⑤Input Optical LED indicator: When selecting Optical input, the blue LED
will turn on.
3

7.2 Right Panel
IN
OPTICALCOAXL R
① ② ③
① OPTICAL: The audio sources optical cable connects here.
② COAX: Connect audio sources Coaxial cable in this socket.
③ L/R: This is where you insert the audio sources L/R cable.
7.3 Left Panel
OUT
LRCOAX OPTICAL
③②①
① L/R: Connect to a compatible audio device, such as a TV or amplifier
with an L/R audio cable.
② COAX: Connect to an audio sources (TV or amplifier) coaxial input.
③ OPTICAL: This is used to connect with a TV or amplifiers optical jack.
7.4 Back Panel
POWER
L/ROPTICAL
COAX
INPUT
SELECT
DC 5V
③① ②
① DC 5V Power Jack: Plug the 5V 1A DC power supply into the unit and
connect the adaptor to an AC wall outlet.
② INPUT SELECT: Use this switch to select the current audio source, either
optical, coaxial or L/R.
③ Power Switch: Push the button to turn on or switch off the device.
4

8. Connection and Installation
Set-top-Box
TV
Optical
or
or
or
Amplifier
Blue Ray
DVD
L/R
Coaxial
Coaxial
Optical L/R
5

Acronyms A
Acronym Complete Term
6

20110118 MPM-DCT9D
