Cypress EZ-PD CY4502 User manual

CY4502
EZ-PD™CCG2 Development Kit Guide
Doc. No. 001-96601 Rev. *B
Cypress Semiconductor
198 Champion Court
San Jose, CA 95134-1709
Phone (USA): +1.800.858.1810
Phone (Intnl): +1.408.943.2600
http://www.cypress.com

Copyrights
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 2
Copyrights
© Cypress Semiconductor Corporation, 2015. The information contained herein is subject to change without notice.
Cypress Semiconductor Corporation assumes no responsibility for the use of any circuitry other than circuitry embodied in
a Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not
warranted nor intended to be used for medical, life support, life saving, critical control or safety applications, unless
pursuant to an express written agreement with Cypress. Furthermore, Cypress does not authorize its products for use as
critical components in life-support systems where a malfunction or failure may reasonably be expected to result in
significant injury to the user. The inclusion of Cypress products in life-support systems application implies that the
manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all charges.
Trademarks
PSoC is a registered trademark of Cypress Semiconductor Corp. All other trademarks or registered trademarks referenced
herein are property of the respective corporations.
Source Code
Any Source Code (software and/or firmware) is owned by Cypress Semiconductor Corporation (Cypress) and is protected
by and subject to worldwide patent protection (United States and foreign), United States copyright laws and international
treaty provisions. Cypress hereby grants to licensee a personal, non-exclusive, non-transferable license to copy, use,
modify, create derivative works of, and compile the Cypress Source Code and derivative works for the sole purpose of
creating custom software and or firmware in support of licensee product to be used only in conjunction with a Cypress
integrated circuit as specified in the applicable agreement. Any reproduction, modification, translation, compilation, or
representation of this Source Code except as specified above is prohibited without the express written permission of
Cypress.
Disclaimer
CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Cypress reserves the right to make changes without further notice to the materials described
herein. Cypress does not assume any liability arising out of the application or use of any product or circuit described
herein. Cypress does not authorize its products for use as critical components in life-support systems where a malfunction
or failure may reasonably be expected to result in significant injury to the user. The inclusion of Cypress’ product in a life-
support systems application implies that the manufacturer assumes all risk of such use and in doing so indemnifies
Cypress against all charges.
Use may be limited by and subject to the applicable Cypress software license agreement.

CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 3
Contents
Safety Information..................................................................................................................................................................5
Regulatory Compliance ...................................................................................................................................................5
General Safety Instructions .............................................................................................................................................5
ESD Protection......................................................................................................................................................5
Handling Boards....................................................................................................................................................5
1. Introduction....................................................................................................................................................................6
1.1 Kit Contents...........................................................................................................................................................6
1.1.1 Software ...................................................................................................................................................6
1.1.2 Tools Not Included....................................................................................................................................7
1.2 Additional Learning Resources..............................................................................................................................7
1.3 Document Conventions.........................................................................................................................................7
1.4 Abbreviations.........................................................................................................................................................8
2. Getting Started.............................................................................................................................................................10
2.1 CY4502 DVK Installation.....................................................................................................................................10
2.2 Install Hardware...................................................................................................................................................12
2.3 Install Software....................................................................................................................................................12
2.4 Uninstall Software................................................................................................................................................12
3. Kit Operation................................................................................................................................................................13
3.1 Theory of Operation.............................................................................................................................................13
3.2 Jumpers...............................................................................................................................................................14
3.3 CCG2 Single-Chip EMCA Application.................................................................................................................15
3.4 CCG2 Two-Chip EMCA Application (One Chip Powered)...................................................................................17
3.5 CCG2 Two-Chip EMCA Application (Both Chips Powered) ................................................................................18
3.6 How to Test CY4502 board .................................................................................................................................19
3.7 Programming the CCG2 Device..........................................................................................................................21
3.7.1 Programming the CCG2 Device Using PSoC Programmer and MiniProg 3...........................................21
3.7.2 Programming the CCG2 Device Using a CCG1 Host Demo Kit over the CC Line .................................23
4. Hardware......................................................................................................................................................................29
4.1 CY4502 Board Details.........................................................................................................................................30
4.2 CCG2 Controller..................................................................................................................................................30
4.3 USB Type-C Plug................................................................................................................................................31
4.4 SWD Connector...................................................................................................................................................33
4.5 20-pin Header......................................................................................................................................................33

Contents
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 4
Appendix A: Troubleshooting Guide..................................................................................................................................34
Appendix B: PCB Layout.....................................................................................................................................................35
B.1 Top Layer................................................................................................................................................................35
B.2 Bottom Layer...........................................................................................................................................................35
B.3 Ground Layer 1.......................................................................................................................................................36
B.4 Ground Layer 2.......................................................................................................................................................36
B.5 Power Layer 1.........................................................................................................................................................37
B.6 Power Layer 2.........................................................................................................................................................37
Revision History...................................................................................................................................................................38
Document Revision History ...........................................................................................................................................38

CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 5
Safety Information
Regulatory Compliance
CY4502 is intended for use as a development platform for hardware or software in a laboratory environment. The board is
an open system design, which does not include a shielded enclosure. Due to this reason, the board may cause
interference to other electrical or electronic devices in close proximity. In a domestic environment, this product may cause
radio interference. In such cases, the user may be required to take adequate preventive measures. Also, this board should
not be used near any medical equipment or RF devices.
Attaching additional wiring to this product or modifying the product operation from the factory default may affect its
performance and cause interference with other apparatus in the immediate vicinity. If such interference is detected,
suitable mitigating measures should be taken.
General Safety Instructions
ESD Protection
ESD can damage boards and associated components. Cypress recommends that the user perform procedures only at an
ESD workstation. If an ESD workstation is not available, use appropriate ESD protection by wearing an antistatic wrist
strap attached to the chassis ground (any unpainted metal surface) on the board when handling parts.
Handling Boards
CY4502 boards are sensitive to ESD. Hold the board only by its edges. After removing the board from its box, place it on a
grounded, static free surface. Use a conductive foam pad if available. Do not slide board over any surface.
CY4502 boards are expected to be handled with care, especially while connecting and disconnecting to other Type-C
receptacles. Careless handling might cause PCB damage.
CY4502 contains electrostatic discharge (ESD) sensitive devices.
Electrostatic charges readily accumulate on the human body and any
equipment, and can discharge without detection. Permanent damage
may occur on devices subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance degradation or loss
of functionality. Store unused CY4502 boards in the protective shipping
package.

CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 6
1. Introduction
Thank you for your interest in the CY4502 EZ-PDTM CCG2 Development Kit (CCG2 DVK). This DVK enables designers to
evaluate the functionality of CCG2 controllers in Electronically Marked Cable Assembly (EMCA) USB Power Delivery (PD)
Type-C cables. It combines hardware and documentation; and showcases the passive EMCA solution with one CCG2 per
cable plug (two-chip solution) and with one CCG2 per cable (one-chip solution).
CCG2 is a USB Type-C cable controller that complies with the latest USB Type-C and USB PD standards. CCG2 provides
a complete USB Type-C and USB PD port control solution for passive cables, active cables, and powered accessories. It
combines an industry-standard, high-performance 32-bit ARM® Cortex™-M0 CPU; communication blocks to support
standard serial communication protocols such as I2C, SPI, UART; and a complete USB Type-C transceiver including the
termination resistors1(RP, RDand RA).
This guide describes the steps to install the software related to the DVK and to operate the development board provided
with the DVK. It documents different types of firmware downloading and debugging methods with detailed instructions. This
guide briefly explains the hardware interfaces available on the development board.
This document assumes that you have the relevant knowledge of USB PD and the Type-C specification and its
applications. It covers the following topics:
Introduction chapter lists the DVK contents and document conventions.
Getting Started chapter on page 10 describes how to use the DVK and install the associated software.
Kit Operation chapter on page 13 explains the DVK operation.
Hardware chapter on page 29 describes the hardware details of the DVK.
1.1 Kit Contents
The CY4502 DVK includes the following:
CY4502 development board
Quick start guide
Visit the DVK web page (www.cypress.com/CY4502) for more information. Inspect the contents of the DVK. If any parts
are missing, contact your nearest Cypress sales office for further assistance.
1.1.1 Software
The CY4502 DVK installer (www.cypress.com/CY4502) package installs documentation, such as a user guide, a quick
start guide, and release notes as well as hardware files, such as a schematic, PCB layout, gerber and cc_flash utility for
programming CCG2.
1 See Type-C specification for more details on termination resistors

Introduction
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 7
1.1.2 Tools Not Included
USB PD–capable/Type-C PC host: The CY4502 board works with a USB PD–capable PC host with a
Type-C receptacle. If a Type-C USB PD–enabled PC is not available, the CCG1 Host Demo board can be used in
conjunction with a standard USB PC.
USB PD–capable/Type-C device: The CY4502 board can work with a USB PD–capable device with a Type-C
interface. If a Type-C USB PD–enabled device is not available, the CCG1 Client Demo board can be used in
conjunction with a standard USB 3.1 (or USB3.0/USB 2.0) device.
1.2 Additional Learning Resources
Visit the CCG2web page for additional learning resources, including a datasheet, a technical reference manual,
application notes, knowledge base articles, and training videos.
Visit the CCG1 web page for additional information on CCG1.
1.3 Document Conventions
Table 1-1. Document Conventions for Guides
Convention
Usage
Courier New
Displays file locations, user-entered text, and source code: C:\ ...cd\icc\
Italics
Displays file names and reference documentation: Read about the sourcefile.hex file in the PSoC Designer
User Guide.
[Bracketed, Bold]
Displays keyboard commands in procedures: [Enter] or [Ctrl] [C]
File > Open
Represents menu paths: File > Open > NewProject
Bold
Displays commands, menu paths, and icon names in procedures: Click the File icon and then click Open.
Times New Roman
Displays an equation: 2 + 2 = 4
Text in gray boxes
Describes cautions or unique functionality of the product.

Introduction
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 8
1.4 Abbreviations
Table 1-2. List of Abbreviations
Definitions and
Acrynoms
Meaning
Active cable
Electronically Marked Cable Assembly with a re-driver to condition USB data signals.
Biphase Mark Code
(BMC)
Modification of Manchester code in which a zero has one transition and a one has two transitions.
Cable plug
Term used to describe a PD-capable element in a multidrop system addressed by SOP’/SOP’’ packets.
Logically, the cable plug is associated with a USB plug at one end of the cable. In a practical
implementation, the electronics may reside anywhere in the cable.
Configuration channel
(CC)
Single wire used by the BMC PHY layer signaling in Type-C.
CRC
Cyclic Redundancy Check - The USB PD packet header and data shall be protected by a 32-bit CRC
DFP
Downstream facing port is a USB Type-C port on a host or a hub to which devices are connected.
DVK
Development kit.
EEPROM
Electrically erasable programmable read-only memory.
Electronically Marked
Cable Assembly
(EMCA)
A USB Type-C cable that uses USB PD to provide the cable’s characteristics
End Of Packet (EOP)
K-code marker used to delineate the end of a packet
I2C
Inter-integrated circuit.
Packet
An entire unit of PD communication, including a preamble, SOP, payload, CRC, and EOP.
Passive cable
Cable with a USB plug on each end, at least one of which is a cable plug supporting SOP’ that does not
incorporate data bus signal conditioning circuits. Supports the Structured VDM to determine its
characteristics. Type-C specification does not discuss passive cables that are not EMCAs.
PC
Personal computer.
SBU
Sideband Use Signals are used in the Alternate Mode supported by the Type-C specification, which
enables multi-purposing of Type-C signals for alternate uses such as DisplayPort
SCL
I2C serial clock line.
SDA
I2C serial data line.
SDK
Software development kit.
Start of packet (SOP)
K-code marker used to delineate the start of a packet. Three SOP sequences are defined: SOP, SOP’,
and SOP’’, with SOP* used to refer to all three.
SOP packet
PD packet that starts with an SOP.
SOP’ packet
PD packet that starts with an SOP’; used to communicate with a cable plug at the near end/host side of
the cable.
SOP’’ packet
PD packet that starts with an SOP’’; used to communicate with a cable plug at the far end/device side of
the cable.

Introduction
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 9
Definitions and
Acrynoms
Meaning
UFP
Upstream facing port is a USB Type-C port on a device or a hub that connects to a host or a hub DFP.
USB
Universal Serial Bus.
USB-IF
Universal Serial Bus Implementers’ Forum.
Vendor Defined
Message (VDM)
PD Data Message defined for vendor/standards usage. These are further partitioned into Structured
VDM messages, where Commands are defined in this specification, and Unstructured VDM messages
which are entirely Vendor Defined.

CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 10
2. Getting Started
This chapter describes how to install and configure the CY4502 DVK.
2.1 CY4502 DVK Installation
To install the DVK software, follow these steps:
1. Download the latest CY4502 DVK software from CY4502 DVK page.Installation package CY4502Setup.exe
contains the kit hardware files, documents, guides and cc_flash utility. Double-click on CY4502Setup.exe to start
the installer. Click Next on the first screen to start the installation as shown in Figure 2-1.
Figure 2-1. CY4502 DVK Installer Screen
2. Select the required Installation Type and click the Next button to start the Installation Wizard (Figure 2-2). For
first-time installation, it is recommended that you select “Typical” as the Installation Type.

Getting Started
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 11
Figure 2-2. Installation Wizard
3. Accept the license agreement for the software components and click Next. The kit will now install on your
machine (Figure 2-3).
Figure 2-3. Installation Progress
4. When installation is complete, you have the option to Launch Cypress Update Manager (Figure 2-4) to ensure
you have the latest DVK.

Getting Started
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 12
Figure 2-4. Cypress Update Manager
Notes:
You can launch the Update Manager from Windows > Start > All Programs > Cypress > Cypress Update
Manager.
After the installation is complete, the contents are available at the following location:
<Install Directory>\CY4502 CCG2 DVK\<version>.
On Windows 32-bit platform, the default <Install Directory> is C:\Program Files\Cypress; on Windows 64-bit
platform, it is C:\Program Files(x86)\Cypress.
2.2 Install Hardware
There is no additional hardware installation required for this kit.
2.3 Install Software
When installing the CY4502 DVK, the installer checks if the required software is installed in the system. If the required
applications are not installed, then it installs them as prerequisites.
The following software programs are installed as part of CY4502 DVK installer:
USB-Serial SDK 1.0.3: Can also be downloaded from http://www.cypress.com/?rID=83110.
PSoC Programmer 3.22.3: Can also be downloaded from www.cypress.com/go/Programmer.
2.4 Uninstall Software
The software can be uninstalled using one of the following methods:
Go to Start > All Programs > Cypress > Cypress Update Manager > Cypress Update Manager; select the Uninstall
button against the CY4502 CCG2 DVK.
Go to Start > Control Panel > Programs and Features; select the Uninstall/Change button against the CY4502
CCG2 DVK.

CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 13
3. Kit Operation
CY4502 includes the CY4502 board shown in Figure 3-1.
Figure 3-1. CY4502 Board
This DVK contains two CCG2 controllers (one in CSP package and the other in DFN package), two SWD connectors, two
USB Type-C plugs, two LEDs, and one 20-pin header. The SWD connectors can be used to update the firmware on the
CYPD2103 devices. Type-C plugs serve as connectors at either end of the cable, providing a way to connect to the Type-
C receptacle at the downstream facing port (DFP) and upstream facing port (UFP). Test points are exposed in the 20-pin
header, which includes CCG2 GPIOs, I2C lines, termination resistor RD, VCONN and the CC lines. LEDs are used to
indicate the powered chip.
The two CYPD2103 devices in the CY4502 board are shipped with factory-installed firmware that demonstrates the
functionality of CCG2 controllers in EMCA USB PD Type-C cables. The CYPD2103 firmware implements a passive EMCA
cable with one CCG2 controller or two CCG2 controllers per cable solution.
3.1 Theory of Operation
This DVK can be used to emulate a general-purpose cable with a USB Type-C plug at each end, as shown in Figure 3-2.
The DVK can be configured to operate in one of three supported passive cable configurations: (1) a chip at only one end of
the cable; (2) a chip at each end of the cable where only one is powered at a time; (3) a chip at each end of the cable
where both are powered simultaneously. The next section covers the jumper settings required to test various
configurations.
Type-C Plugs
20-pin Header
LED2
LED1
SWD Header
SWD Header
CCG2
(CYPD2103-14LHXIT)
CCG2
(CYPD2103-20FNXIT)

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 14
Figure 3-2. CY4502 board as a General Purpose USB Type-C Cable
C
PC
(PD capable) CCG2 CCG2 USB Device
(PD capable)
CY4502 Board
CCC
3.2 Jumpers
The CY4502 board includes five jumpers mounted on the board. Table 3-1 describes the purpose and the default settings
of the jumpers in CY4502 board (depicted in Figure 3-3).
Figure 3-3. CY4502 board Default Jumper Settings
Table 3-1. CY4502 board Jumper Settings
Function
Jumper
Purpose
Default
Configuration
mode selection
J5
Jumper to select both-chip-powered configuration in the two-chip EMCA
solution:
Open; Default jumper position for the one-chip EMCA solution shown in
Figure 3-5 or the two-chip solution with only one of the chips powered
shown in Figure 3-7.
Short: Jumper position for the two-chip EMCA solution with both chips
powered shown in Figure 3-9.
Note: The configuration with both chips powered will work in this DVK
irrespective of which Type-C plug connector, J1 or J2, is connected to the
DFP.
Open
Current
measurement
J6
To measure current, open the jumper and connect multimeter terminals
(set in the current measurement mode) between pins 1 and 2. The
measured current is the total current consumed by the CY4502 board,
including the LEDs, when J1 connector is connected to the host (i.e. when
the DVK is powered using VCONN from Type-C plug, J1).
Short 1–2
Configuration
mode selection
J7
Jumper used to select between the one-chip and two-chip EMCA solution:
Short 2–3: Enables the single-chip solution (with only one CCG2 per
cable).
Short 1–2: Enables the two-chip solution (with two CCG2 controllers per
cable).
Short 1–2
Type-C Plug, J1
20-pin Header
LED2
LED1
SWD Header, J3
SWD Header, J4
Type-C Plug, J2
J6
J8
J7
J5
J13
CCG2, U2
(CYPD2103-14LHXIT)
CCG2, U1
(CYPD2103-20FNXIT)

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 15
Function
Jumper
Purpose
Default
SOP”
response selection
for U1
J8
Jumpers to enable SOP” response for U1 (CYPD2103-20FNXIT):
Short: Enables SOP” response by pulling GPIO (D3) low. CYPD2103
firmware is configured to detect the presence of the VCONN supply in the
VCONN1/VCONN2 pins for determining the responsiveness to SOP
packets. The CCG2 device powered through VCONN1 considers itself to
be the host end of the cable (that is, connected to the DFP) and thus
responds to SOP’. CCG2 powered through VCONN2 considers itself to be
the device end of the cable (that is, connected to the UFP) and thus
responds to SOP”. For the two-chip EMCA solution with both CCG2
controllers powered shown in Figure 3-9, the GPIO (pin D3) must be pulled
low.
Open: Disables SOP” response. CCG2 responds to SOP’ packets only.
For the single-chip EMCA solution shown in Figure 3-5, the GPIO (pin D3)
must be left floating. When the GPIO (pin D3) is left floating, the
CYPD2103 firmware is configured to always respond only to SOP’
packets.
Note: As per the USB PD specification, SOP’ packets are recognized by
the cable controller in one of the cable plugs attached to the DFP and are
not recognized by the UFP or the other cable plug. Similarly, SOP’’
packets are recognized by the cable controller in one of the cable plugs
attached to the UFP and are not recognized by the UFP or the other cable
plug.
Open
SOP”
response selection
for U2
J13
Jumpers to enable SOP”response of U2 (CYPD2103-14LHXIT):
Short: Enables SOP” response by pulling GPIO (D3) low. CYPD2103
firmware is configured to detect the presence of the VCONN supply in the
VCONN1/VCONN2 pins for determining the responsiveness to SOP
packets. The CCG2 device powered through VCONN1 considers itself to
be the host end of the cable (that is, connected to the DFP) and thus
responds to SOP’. CCG2 powered through VCONN2 considers itself to be
the device end of the cable (that is, connected to the UFP) and thus
responds to SOP”. For the two-chip EMCA solution with both CCG2
controllers powered shown in Figure 3-9, the GPIO (pin D3) must be pulled
low.
Open: Disables SOP” response. CCG2 responds to SOP’ packets only.
For the single-chip EMCA solution shown in Figure 3-5, the GPIO (pin D3)
must be left floating. When the GPIO (pin D3) is left floating, the
CYPD2103 firmware is configured to always respond only to SOP’
packets.
Note: As per the USB PD specification, SOP’ packets are recognized by
the cable controller in one of the cable plugs attached to the DFP and are
not recognized by the UFP or the other cable plug. Similarly, SOP’’
packets are recognized by the cable controller in one of the cable plugs
attached to the UFP and are not recognized by the UFP or the other cable
plug.
Open
3.3 CCG2 Single-Chip EMCA Application
The CY4502 board can operate in a single-chip EMCA application, as shown in Figure 3-5. Follow these steps to configure
the board for this mode (depicted in Figure 3-4):
1. Short pins 1 and 2 of jumper J6.
2. Short pins 2 and 3 of jumper J7.
3. Leave jumpers J8 and J13 open.
4. Leave jumper J5 open.
Follow instructions in section 3.6 to test the CY4502 board.

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 16
Figure 3-4. CCG2 Single-Chip EMCA Application Jumper Settings
Figure 3-5. CCG2 Single-Chip EMCA Application Diagram
VCONN 1
VBUS
CC
Type-C
Plug
GND
Type-C
Plug
VCONN 2
SuperSpeed and HighSpeed Lines
0.1uF
CCG2
(CYPD2103-20FNXIT)
VDDD
E3
1uF
A1 VCCD
VSS
C1
XRES
B1
SWD_
IO SWD_
CLK
E2 D1
I2C_0
_SCL I2C_0 _SDA
A3 A2
B4
CC1
GPIO
GPIO D3
C2
CC2 A4
E4 VCONN1 C4
VCONN2
VDDIO
E1
RD1 B3
VSS
D4
GPIO D2
GPIO B2
GPIO
C3
0.1uF
1uF
VDDIO
4.7 k
This EMCA solution contains a CCG2 on only one of its plugs. This solution requires a single VCONN signal to run through
the cable, so that the chip can be powered irrespective of which plug is connected to the host (DFP). In this case, the
CCG2 responds to SOP’ packets only. For more details on this application, refer to AN95615.
LED2
LED1
J6 - Closed
J8 - Open
J7 –Short 2-3
J5 - Open
J13 - Open

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 17
3.4 CCG2 Two-Chip EMCA Application (One Chip Powered)
The CY4502 board can operate in the two-chip EMCA application, with only one of the two CCG2 controllers powered, as
shown in Figure 3-7. Follow these steps to configure the board for this mode (depicted in Figure 3-6):
1. Short pins 1 and 2 of jumper J6.
2. Short pins 1 and 2 of jumper J7.
3. Leave jumpers J8 and J13 open.
4. Leave jumper J5 open.
Follow instructions in section 3.6 to test the CY4502 board.
Figure 3-6. CCG2 Two-Chip EMCA Application (one chip powered) Jumper Settings
Figure 3-7. CCG2 Two-Chip EMCA Application Diagram (One Chip Powered)
VCONN1
VBUS
CC
Type-C
Plug Type-C
Plug
VCONN2
GND
SuperSpeed and HighSpeed Lines
CCG2
(CYPD2103-20FNXIT)
VDDD
E3
A1 VCCD
VSS
C1
XRES
B1
SWD_
IO SWD_
CLK
E2 D1
I2C_0
_SCL I2C_0 _SDA
A3 A2
B4
CC1
GPIO
GPIO D3
C2
CC2 A4
E4 VCONN1 C4
VCONN2
VDDIO
E1
RD1 B3
VSS
D4
GPIO D2
GPIO B2
GPIO
C3
CCG2
(CYPD2103-14LHXIT)
VDDD
7
6VCCD
XRES
12
SWD_
IO SWD_
CLK
89
I2C_0
_SCL I2C_0 _SDA
114
3
CC1
GPIO 13
5VCONN2 4
VCONN1
VSS
2
GPIO 11
GPIO 10
0.1uF
1uF
1uF 1uF
0.1uF
1uF
VDDIO
4.7 k
VDDIO
4.7 k
This EMCA solution contains two CCG2 controllers, one in each plug. In this solution, the VCONN signal does not run
through the cable. Only one CCG2 is powered at a time depending on which is nearer to the DFP that supplies VCONN.
The powered CCG2 responds to SOP’ packets only. For more details on this application, refer to AN95615.
LED2
LED1
J6 - Closed
J8 - Open
J7 –Short 1-2
J5 - Open
J13 - Open

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 18
3.5 CCG2 Two-Chip EMCA Application (Both Chips Powered)
The CY4502 board can operate in the two-chip EMCA application, with both CCG2 controllers powered, as shown in
Figure 3-9. Follow these steps to configure the board for this mode (depicted in Figure 3-8):
1. Short pins 1 and 2 of jumper J6.
2. Short pins 1 and 2 of jumper J7.
3. Short pins 1 and 2 of jumpers J8 and J13.
4. Short pins 1 and 2 of jumper J5.
Follow instructions on section 3.6 to test the CY4502 board.
Figure 3-8. CCG2 Two-Chip EMCA Application (Both Chips Powered) Jumper Settings
Figure 3-9. CCG2 Two-Chip EMCA Application Diagram (Both Chips Powered)
VCONN1
VBUS
CC
Type-C
Plug Type-C
Plug
VCONN2
GND
SuperSpeed and Hi-Speed Lines
CCG2
(CYPD2103-20FNXIT)
VDDD
E3
A1 VCCD
VSS
C1
XRES
B1
SWD_
IO SWD_
CLK
E2 D1
I2C_0
_SCL I2C_0 _SDA
A3 A2
B4
CC1
GPIO
GPIO D3
C2
CC2 A4
E4 VCONN1 C4
VCONN2
VDDIO
E1
1uF
RD1 B3
VSS
D4
GPIO D2
GPIO B2
GPIO
C3
CCG2
(CYPD2103-14LHXIT)
VDDD
7
1uF
6VCCD
XRES
12
SWD_
IO SWD_
CLK
89
I2C_0
_SCL I2C_0 _SDA
114
3
CC1
GPIO
GPIO 13
11
5VCONN2 4
VCONN1
1uF
VSS
2
GPIO 10
C1
VDDIO
4.7 k 4.7 k
VDDIO
0.1uF
1uF
0.1uF
`
This EMCA solution contains two CCG2 controllers, one on each plug, and VCONN is wired across the cable (but not
straight through to the other end of the plug). Even in this solution, the wiring is done such that the cable is reversible. The
LED2
LED1
J6 - Closed
J8 - Closed
J7 –Short 1-2
J5 - Closed
J13 - Closed

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 19
VCONN signal from one cable plug goes to the VCONN1 pin of the CCG2 at that end and also to the VCONN2 pin of the
CCG2 at the other end of the cable. The same applies to the VCONN signal coming from the other end of the cable. Both
CCG2 devices will get powered: one through VCONN1 and the other through VCONN2. For more details on this
application, refer to AN95615.
3.6 How to Test CY4502 board
Follow these steps to test the CY4502 board.
1. Connect CY4502 board between a Type-C enabled host (e.g. Laptop, PC) and a Type-C enabled device with a
Type-C receptacle (e.g. Monitor, USB hard disk). One or two LEDs glow, as listed in Table 3-2, to indicate that the
CCG2 controller(s) and the CY4502 board are powered.
Table 3-2. LED indicators in CY4502
CY4502 Configuration
Reference
Connector
to Host
LED
Description
CCG2 Single-Chip EMCA
Application
Section 3.3
J1
LED1
CCG2 controller, U1 is powered
J2
LED1
CCG2 controller, U1 is powered
CCG2 Two-Chip EMCA
Application (one chip
powered)
Section 3.4
J1
LED1
CCG2 controller, U1 is powered
J2
LED2
CCG2 controller, U2 is powered
CCG2 Two-Chip EMCA
Application (both chips
powered)
Section 3.5
J1
LED1
and
LED2
Both CCG2 controllers, U1 and U2, are
powered
J2
LED1
and
LED2
Both CCG2 controllers, U1 and U2, are
powered
2. If a Type-C enabled host or device is not available, get a CCG1 Host Demo Kit and CCG1 Client Demo Kit and
follow the steps below to test the CY4502 board:
3. Ensure that the CCG1 Host Demo board (Figure 3-10) has the jumper settings listed in Table 3-3.
Figure 3-10. CCG1 Host Demo board
J37 –Short 5-6
J43 –Open
J44 –Closed
J40 –Closed
J35 –Short 5-6
J47 –Closed

Kit Operation
CY4502 EZ-PD™ CCG2 Development Kit Guide, Doc. No. 001-96601 Rev. *B 20
Table 3-3. Jumper Settings for CCG1 Host Demo Kit
Jumper
Position
Comments
J43
Open
Board gets powered from USB 3.0 connector (J16) using jumper J47
J47
Closed
Board gets powered from USB 3.0 connector (J16).
J35
Short 5–6
Advertise Rp value of 10 kfor 3-A current on CC1.
J37
Short 5–6
Advertise Rp value of 10 kfor 3-A current on CC2.
J40
Closed
Enabling VCONN connectivity. Power measurement jumper at VCONN.
J44
Closed
Enabling supply to CCG1. Power measurement jumper.
Note: The other jumpers on CCG1 Host Demo Kit, not listed in Table 3-3, can be retained in any position for testing
CY4502 board. For more details on the CCG1 Host Demo Kit, refer CCG1 Host Demo Kit page.
4. Remove zero ohm resistors R1248, R1249 on the CCG1 Host Demo board.
5. Ensure that the CCG1 Client Demo board (Figure 3-11) has the jumper settings listed in Table 3-4.
Figure 3-11. CCG1 Client Demo board
Table 3-4. Jumper Settings for CCG1 Client Demo board
Jumper
Position
Comments
J11
Short 2–4
Board gets powered from mini USB connector (J8).
J2
Short 5–6
Advertise Rp value of 10 kfor 3-A current on CC1.
J3
Short 5–6
Advertise Rp value of 10 kfor 3-A current on CC2.
J1
Closed
Enabling VCONN connectivity. Power measurement jumper at VCONN.
J44
Closed
Enabling supply to CCG1. Power measurement jumper.
Note: Other jumpers on CCG1 Client Demo board, not listed in Table 3-4, can be retained in any position for testing
CY4502 board. For more details on the CCG1 Client Demo board, refer CCG1 Demo Kit page.
6. Configure the CY4502 board for any of the applications discussed in sections 3.3 to 3.5 .
J11 –Short 2-4
J44 –Closed
J1 –Closed
J3 –Short 5-6
J2 –Short 5-6
