QUICK START GUIDE
CY3643 PROGRAMMING KIT
• Download and install the latest kit software onto
your PC from www.cypress.com/CY364X
• Connect the board to your PC using the provided
USB cable
• The Status LED (Green) turns ON after the kit
driver enumeration is complete
The CY3643 Programming Kit enables quick and easy Programming of Cypress’s
High Performance Programmable Clock Synthesizer (CY29430)
Kit Contents:
1. CY3643 Programming Board
2. USB Standard-A to Mini-B cable
3. Quick Start Guide (this document)
4. IC CY29430FLQXI
(placed inside the socket)
1
Steps to successfully program the clock device using
this Programming kit.
• Ensure default Jumper setting as mentioned in
Table overleaf
• Run the Clock Programmer software tool
1. Select CY294xx from the Device List
2. Select 0x55 for target I2C address
3. Click Connect
4. Open the JEDEC le from <Install_Directory>
\CY364x Programming Kit\<version>\Firmware\
CY3643\CY3643 Kit LVPECL 2.5V 156.25MHz)
5. Click Program
• While eFuse programming is underway you
will notice Power LED (LED2) to glow Amber
2

QUICK START GUIDE
CY3643 PROGRAMMING KIT
© 2017 Cypress Semiconductor Corporation. All rights reserved.
All trademarks or registered trademarks referenced herein are the property of their respective owners.
002-18649 Rev.*A
CY3643 Board Details
Table: Jumper Default Position
Purpose
Power on CY29430
Jumper
J1
Default
Position
1 - 2
Main Power Supply Jumper (J1)
Power LED
USB Mini-B
Connector
Status LED
PSoC 5LP
(CY8C5868LTI-LP039)*
* Component is on the bottom-side of the Programming Board
Socket for 16-pin QFN 3mm x 3mm
Pin-1
