CY8CPROTO-062-4343W PSoC®6 Wi-Fi BT PROTOTYPING KIT QUICK START GUIDE
© 2018 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks
referenced herein are the properties of their respective owners. 002-25010 Rev.*A
1) Visit the kit website to download and install the required software.
2) Ensure the jumper J3 is at position 2-3 to select 3.3V.
3) Connect the KitProg3 USB connector (J8) to your PC.
4) Wait for the drivers installation to complete.
5) Open the UART terminal software and connect to the KitProg3
USB-UART COM port with the settings – Baud rate: 115200,
Data: 8 bit, Parity: None, Stop bit: 1 bit, Flow control: None.
6) Press the RESET switch (SW1) on the device.
7) Follow the instructions displayed on the UART terminal to use the
pre-programmed code example.
Refer to the Kit Guide available at the kit website for details.
• PC with USB port and Wi-Fi connectivity
•UART terminal software such as Tera Term or Minicom
•Non-enterprise Wi-Fi network with internet access or a mobile hotspot
Before starting, ensure you have the following.
For more information, please visit: www.cypress.com/CY8CPROTO-062-4343W
KitProg3 USB connector (J8)
Power selection jumper (J3)Reset button (SW1)
Downloaded from Arrow.com.

PSoC Rocks!
Downloaded from Arrow.com.Downloaded from Arrow.com.

Contents under the label
CY8CPROTO-062-4343W PSoC®6
Wi-Fi BT PROTOTYPING KIT
