Cyrus PSX-R2 User manual

ENGINEERED
TO ENTERTAIN

Cyrus PSX-R2
User Instructions
IMPORTANT! READ BEFORE OPERATING THIS EQUIPMENT! .. 1
Power supply: ...................................................................... 2
Servicing: ............................................................................. 2
Product service centres: ...................................................... 2
FCC NOTICE.......................................................................... 3
WELCOME TO THE WORLD OF CYRUS!................................. 4
Preparaons for Installaon ................................................ 4
Compability ....................................................................... 4
INSTALLATION......................................................................... 5
Key to the rear panel drawing:........................................ 5
Connecng to the AC Mains Supply .................................... 5
Connecng the PSX-R2to Cyrus Products ............................ 5
Use with early Cyrus products ........................................ 5
OPERATION ............................................................................. 6
Key to the front panel drawing ....................................... 6
Power................................................................................... 6
Addional informaon ........................................................ 6
SPECIFICATIONS...................................................................... 7
Power Supply .................................................................. 7
Enclosure ........................................................................ 7
Output Voltage................................................................ 7
Load Regulaon .............................................................. 7
O/P Noise........................................................................ 7
Ripple Rejecon .............................................................. 7
WARRANTY.............................................................................. 7
WEEE........................................................................................ 7
CONTENTS

Cyrus PSX-R2User Instructions
1
WARNING: To reduce the risk of electrical shock do not
remove any unit covers or panels. There are no user
serviceable parts in this product.
WARNING: To reduce the risk of electric shock, do not
expose this equipment to rain or moisture.
HEED WARNINGS: All warnings on the product and in the
operang instrucons should be adhered to.
READ ALL THE INSTRUCTIONS: All the safety and operang
instrucons should be read before the product is operated.
RETAIN INSTRUCTIONS: The safety and operang
instrucons should be retained for future reference.
FOLLOW INSTRUCTIONS: All operang and use instrucons
should be followed.
CLEANING: Unplug this product from the mains before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
WATER AND MOISTURE: Do not use this product near water
- for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub, in a wet basement; or near a swimming pool
and the like. The product must not be exposed to dripping
or splashing and no objects lled with liquids, such as vases,
shall be placed on the product.
HEAT: The product should be situated away from heat
sources such as radiators, stoves, or any other products
(including ampliers) that produce heat.
VENTILATION: Slots and openings in the cabinet are
provided for venlaon, to ensure reliable operaon of
the product and to protect it from overheang and these
openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed,
sofa, rug or similar surface. This product should not be
placed in a built-in installaon such as a bookcase or rack
unless proper venlaon is provided or the manufacturer’s
instrucons have been adhered to.
OBJECT OR LIQUID ENTRY: Never push objects of any kind
into this product through openings as they may touch
dangerous voltage points or short-out parts that could
result in a re or electric shock.
ACCESSORIES: Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod, bracket
or table recommended by the manufacturer, or sold with
the product. Any mounng of the product should follow
the manufacturer’s instrucons, and should use a mounng
accessory recommended by the manufacturer.
POWER SOURCES: This product should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company.
For products intended to operate from baery power, or
other sources, refer to the operang instrucons.
OVERLOADING: Never overload wall outlets, extension
cords, or integral convenience receptacles. This can result in
an increased risk of re or electric shock.
POWER CORD PROTECTION: Power supply cords should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying parcular
aenon to cords at plugs, convenience receptacles, and
the point where they exit from the product.
NAKED FLAMES: No naked ame sources, such as candles,
must be placed on this product.
LIGHTNING: For added protecon for this product during
a lightning storm, or when it is le unaended or unused
for long periods of me, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
BATTERIES: Warning : Baeries shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION! POLARISED CONNECTOR (CANADA and USA):
To prevent electrical shock, match wide blade of plug to
wide slot, fully insert. Do not alter or remove this plug if it
does not t your mains power socket. Have a suitable socket
installed by a competent electrician.
ACCESS TO THE MAINS PLUG: The means to disconnect this
product from the mains supply is the mains plug. Ensure
that the mains plug is accessible at all mes.
IMPORTANT! READ BEFORE OPERATING THIS EQUIPMENT!
CAUTION: The exclamaon mark is to draw your
aenon to important instrucons and safety
procedures in this manual.
ATTENTION: The lightning ash warns you of the
risk of electrical shock presented by components
inside this product. Unauthorised personnel
must not open this unit.
MOVING THE PRODUCT: A product and cart
combinaon should be moved with care. Sudden
stops, excessive force, and uneven surfaces may
cause the product and cart to overturn.
ATTACHMENTS: Do not use aachments not recommended
by the product manufacturer as they may cause hazards.

Cyrus PSX-R2User Instructions
2
Power supply:
Connect the moulded IEC connector of the AC cord supplied
plugs into the power inlet c on the rear of the unit. The
mains fuse bis on the rear panel next to the power switch.
It must only be replaced as follows:
230V Products: T2AL/250V 20mm
115V Products: T2.5AL/250V 20mm
The mains supply requirement of your power supply is
marked on a label on the rear panel. Before connecng,
check that this voltage is the same as your mains supply.
230V Products: Voltage Range 220V-240V
115V Products: Voltage Range 110V-120V
If you move to an area with a dierent mains voltage,
contact your local Cyrus distributor to have your product
converted.
There are no user replaceable fuses in this unit.
Servicing:
Do not aempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualied service
personnel.
CONDITIONS REQUIRING SERVICE: Unplug this product
from the wall outlet and refer servicing to qualied service
personnel when:
When the power supply cord or plug is damaged.•
If liquid has been spilled, or objects have fallen into the •
product.
If the product has been exposed to rain or water.•
If the product has been dropped or damaged in any •
way.
If the product does not operate normally by following •
the operang instrucons. (Adjust only those controls
that are covered by the operang instrucons. Improper
adjustment of other controls may result in damage
requiring extensive work by a qualied technician to
restore the product to its normal operaon).
When the product exhibits a disnct change in •
performance.
REPLACEMENT PARTS: When replacement parts are
required, be sure the service technician has used
replacements specied by the manufacturer or have the
same characteriscs as the original part. Unauthorised
substuons may result in re, electric shock, or other
hazards.
SAFETY CHECK: Upon compleon of any service or repairs
to this product, ask the service technician to perform safety
checks to determine that the product is in proper operang
condion.
Product service centres:
For product service or technical advice, contact only
authorised Cyrus service centres. Contact details for Cyrus
distributors may be found on the Cyrus website at www.
cyrusaudio.com.

Cyrus PSX-R2User Instructions
3
FCC NOTICE*
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in
a parcular installaon. If this equipment does cause harmful interference to radio
or television recepon, which can be determined by turning the equipment o and
on, the user is encouraged to try and correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.•
Increase the separaon between the equipment and receiver.•
Connect the equipment into an outlet on a circuit dierent from that to which the •
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Any changes or modicaons not expressly approved by the manufacturer could void
the user’s authority to operate the equipment.
*115V products

Cyrus PSX-R2User Instructions
4
WELCOME TO THE WORLD OF CYRUS!
Congratulaons on your choice of Cyrus Hi- products. Our
state-of-the-art design technology and outstanding quality
of manufacture has won countless awards around the
world. We are condent that you will derive great pleasure
from owning a product from one of the most recognised and
respected manufacturers of hi- equipment.
Now is a good me to register your new Cyrus product.
Registraon takes only a few minutes, brings the added
benet of a full two year factory warranty and adds you to
our mailing list for future product updates and upgrades.
To register, visit www.cyrusaudio.com and click the ‘Login/
Register’ link.
Please read these instrucons carefully before commencing
installaon. They provide full guidance to help you install
your power supply safely and correctly.
Preparations for Installation
Before installing your power supply check that the following
items are included in the accessory box.
Power Cable•
Aer removing these items, please retain the packaging.
Install the power supply in a well venlated locaon away
from sources of high temperature, dust or humidity. Never
stand the power supply under another unit or on any surface
likely to obstruct its cooling or venlaon.
Compatibility
The PSX-R2 is compable for connecon to any Cyrus product
equipped with a 5 pin socket marked PSX-R.

Cyrus PSX-R2User Instructions
5
INSTALLATION
Key to the rear panel drawing:
Power switch1.
Mains fuse2.
Power inlet3.
Output cable4.
MADE IN ENGLAND
USE PSX-R WITH
DESIGNATED CYRUS
PRODUCTS ONLY
REGULATED
DC OUTPUT
ab c
d
Connecting to the AC Mains Supply
Connect the socket on the AC Power cable to the Power
inlet c on the rear panel of the PSX-R2. Now connect the
cable to a suitable AC power point.
NOTE: The means to disconnect this product from the
mains supply is the mains plug. Ensure that the mains plug
is accessible at all mes.
Connecting the PSX-R2to Cyrus Products
Only one connecon is necessary from the PSX-R2power
supply to a Cyrus product. The 5 pin connector d ed
to the umbilical cable must be securely connected to the
socket marked PSX-R on the rear of the partnering Cyrus
product. When correctly ed, the connector will latch into
place in the socket. Note that when a PSX-R2 is in use, both
the PSX-R2power supply and the Cyrus product will require
connecon to the mains supply.
Use with early Cyrus products
When used with a Cyrus III, Cyrus IIIi, Cyrus 7 or Cyrus
Power, the amplier must be internally changed to accept
this external power supply. This modicaon should only be
carried out by an appointed Cyrus Dealer. If you decide to
use a modied component without a Cyrus PSX-R2, the unit
must be re-congured.

Cyrus PSX-R2User Instructions
6
Standby Light 1.
OPERATION
Key to the front panel drawing
Power
The mains power switch a is located on the rear panel of
the power supply. This switch should be le on for normal
use, except when le unaended for a long period. In this
case the mains power should be switched o or the product
disconnected from the AC supply.
In normal use, standby operaon of the PSX-R2is controlled
by the partnering Cyrus component. When correctly
installed, the Standby lights on the front panels of the two
products work in unison.
Additional information
Your power supply incorporates electronic protecon to
ensure reliable, long term use. The PSX-R2is designed
to adjust its output DC voltage to that required by the
partnering Cyrus product.
Two levels of regulaon exist in the PSX-R2circuitry in order
to give maximum isolaon from mains borne disturbances
and the voltage ripple due to the charging of the supply
reservoir capacitors, this design has also enhanced the load-
regulaon of the PSX-R2.
Fully regulated intelligent power supply
a
PSX-R
2

Cyrus PSX-R2User Instructions
7
WEEE
This logo means that this product is not to
be disposed of with your household waste.
This product should be handed over to a
designated collecon point to be recycled.
Your cooperaon in the correct disposal of
this product will contribute to the eecve
usage of natural resources. For more
informaon on collecon points, contact
your disposal service or City Hall.
SPECIFICATIONS
Power Supply
Voltage: ........................................... As plate on rear of unit
Power Consumpon (X Power 50W/8Ω).................... 227W
Safety Compliance............................................................CE
EMC (230V).......................................................................CE
EMC (115V).....................................................................FCC
Enclosure
Dimensions (WxHxD).............................. 215 x 75 x 365mm
Weight ......................................................................... 4.6kg
Material Die cast chassis
Output Voltage
High Level ......................................................... +/- 35.5VDC
Low Level............................................................. +/- 21VDC
Variable .......................................................... +/- 18-30VDC
Load Regulation
Amplier, 50W/Ch. 8Ω 1kHz......................................... 0.2%
O/P Noise
@250W ..................................................................... <40μV
Ripple Rejection
@250W ......................................................................>67dB
Cyrus reserves the right to change all specicaons without
noce. E &OE
WARRANTY
The warranty should be registered on-line within eight days
of purchase. No retailer or distributor may vary the terms
of this warranty, which is personal to the original purchaser
and is not transferable.
Please retain the sales receipt as proof of purchase.
Warranty claims must wherever possible be made through
the retailer from whom the equipment was purchased.
This warranty excludes:
Damage caused through neglect, accident, misuse, wear •
and tear, or through incorrect installaon, adjustment
or repair by unauthorised personnel. Any unauthorised
servicing will result in loss of warranty.
Liability for damage or loss occurring in transit to or from •
the purchaser.
Consequenal damage, loss or injury, arising from or in •
conjuncon with this equipment.
Equipment for aenon under warranty should be consigned
return carriage paid. If returned equipment is found to
comply with the published specicaon, CYRUS reserves
the right to raise a charge.
The above condions do not aect your statutory rights as
a consumer.

Cyrus Audio Ltd., Ermine Business Park, Hunngdon, PE29 6XY, U.K.
