D-Link Conexant HSFi DFM-562IS User manual

1
If you purchased this Modem to make your Internet connection with PC, you must
have an established Internet account from an Internet Service Provider (ISP).
Check Your Package Contents
These are the items included with your D-Link 562IS purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Corporation, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice. D-Link DFM-562IS HSFi PCI Modem
• D-Link DFM-562IS Software Modem Card
• CD-ROM (containing Manual and Q.I.G.)
• Phone Cable
• D-Link DFM-562IS User’s Guide
Using a power
supply with a
different voltage rating
will damage and void
the warranty for this
product.
Before Your Begin
D-Link DFM-562I
S
Software Modem Card

2
Hardware Installation
Please unplug the telephone Line and plug the telephone line into the socket on the
back of the modem marked LINE.
COMPUTER
PHONE
WALL SOCKET
Telephone
LINE
PHONE
LINE

3
Install Drivers
2.1 Windows 98/ME
Click Install Drivers
After system will
auto Install Modem.
Please click Close to
end the window
Click CLOSE
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied.

4
2.1 Windows 98/ME (continue)
Please select Start /
Settings /
Control Panel and
double-click
on the Modems icon.
Check Modem Model No For
D-Link DFM-562IS HSFi PCI
Modem.
If correct the installation is
complete
then click OK to exit.
Click OK
Click Modems

5
2.2 Windows 2K
Click Install Drivers
Click Yes ignore the
message.
Click Yes
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied.

6
After system will
auto Install Modem.
Please click Close to
end the window
Click CLOSE
Click Yes ignore the
message.
Click Yes

7
2.2 Windows 2K(continue)
Please select Start /
Settings/Control Panel
and double-click on the
Phone and Modem
Options icon.
Click Phone and
Modem Options
Check Modem Model No.
For D-Link DFM-562IS HSFi
Modem
If installation is complete
then click OK to exit.
Click OK

8
2.3 Windows XP
Click Install Drivers
Click Continue
Anyway

9
Select the Install the
software automatically
[Recommended] then
click Next to search for
the driver.
Click Next
Click Continue Anyway
to skip the warning
message.
Click Continue
Anyway

10
Please click Close to
end the window
Click CLOSE
Install complete
Click Finish
