2D-Link DFE-530TX+ Quick Install Guide
System Requirements
• AcomputerwithanavailablePCIslot
• Windows®7,Vista®,XPor2000,Linux2.2.xandabove,
 Netware5.x/6.x,orMacOS10.2.x
• 300MHzprocessorandatleast64MBofRAM
• 32MBfreeharddrivespace
• CD-ROMDrive
Package Contents
•D-LinkDFE-530TX+EthernetDesktopAdapter
•ManualandSoftwareonCD
•WOLCable
•StandardandLowProleBrackets
•QuickInstallGuide
System Requirements
If any of the above items are missing, please contact your reseller.

3 D-Link DFE-530TX+ Quick Install Guide
Hardware Overview
Hardware Overview
• AcomputerwithanavailablePCIslot
• Windows®7,Vista®,XPor2000,Linux2.2.xandabove,
 Netware5.x/6.x,orMacOS10.2.x
• 300MHzprocessorandatleast64MBofRAM
• 32MBfreeharddrivespace
• CD-ROMDrive
Link/Activity
Asteadygreenlightindicatesagoodconnectionto
yourethernetdevice.Ablinkinglightindicatesdatais
beingtransmitted(sendingorreceiving).
Speed
When lit, the device speed is
100Mbps.Ifthelightisnotlit,the
devicespeedis10Mbps.

4D-Link DFE-530TX+ Quick Install Guide
Software Installation
Warning: Do NOT install the DFE-530TX+ PCI Fast Ethernet
Adapter into your computer before installing the driver software
from the D-Link CD.
TurnonyourcomputerandInserttheD-LinkDFE-530TX+DriverCD
intheCD-ROMdrive.Thestep-by-stepinstructionsthatfolloware
showninWindows®XP.Thestepsandscreensaresimilarforthe
otherWindowsoperatingsystems.
IftheCDAutorunfunctiondoesnotautomaticallystartonyourcomputer,
gotoStart>Run.IntheRuncommandboxtype“D:\DFE530TX+.
exe”(whereD:representsthedriveletterofyourCD-ROMdrive).
Drivers for non-Windows® operating systems are located on the
D-LinkCD.
Installation
Software Installation
Whentheautorunscreenappears,clickInstall Drivers.

5 D-Link DFE-530TX+ Quick Install Guide
Software Installation
Shutdownyourcomputer.GotoStart>Shut Down>selectShut
DownandclickOK.
Once your computer is turned off, remove the power cable from
thecomputer.OpenthecaseandinserttheD-Linkadapterintoan
availablePCIslot.
If you are familiar with Wake-On-
LAN, attach the cable to your
motherboardandtheadapter.Ifyou
arenotusingtheWOLfeature,do
notattachthecable.
Note: Write down the serial number
and hardware revision (e.g. A1)
before installing the adapter. If you
contact technical support, you will
need this information.
Replace the case, plug in the power cable, and power on your
computer.
Thedriverswillinstall.Oncetheinstallationiscomplete,clickOK.

6D-Link DFE-530TX+ Quick Install Guide
Software Installation
Onceyou boot yourcomputer, Windows® will automaticallyinstall
thedrivers.
Windows 2000 users: If you receive the Found New Hardware
Wizard, please refer to page 10 of the manual to finish your
installation.
Windows XP users:YouwillreceiveabubblestatingthatWindows
foundtheDFE-530TX+adapter.
Windows Vista® and Windows® 7 users:Youwillreceiveabubble
statingthatWindowshasinstalledthedevicedriver.
Youmaynowverifyyourinstallation.

7 D-Link DFE-530TX+ Quick Install Guide
Verify Installation
Toverifythatthedriversareinstalled,youmayviewDeviceManager.
Toviewthedevicemanager,pleasefollowthestepsbelow:
Step 1:
Windows®2000:ClickonStart>Settings>Control Panel
WindowsXP:ClickonStart>Control Panel
WindowsVista®:ClickonStart>Control Panel
Windows®7:Click on Start > Control Panel
Step 2:
Windows2000/XP:ClickontheSystemicon.ClicktheHardware
tabandthenclickDevice Manager.
Windows Vista: Click on the System and Maintenance icon and
thenclickonDevice Manager.
Windows®7:Clickonthe System and Securityiconandthenclick
onDevice ManagerunderSystem.
Step 3:
Scrolldownandclicktheplus(+)signnexttoNetwork Adapters.The
D-Link DFE-530TX+ PCI Fast Ethernet Adapter (rev.F)willbelisted.
Verify Installation

8D-Link DFE-530TX+ Quick Install Guide
Configure your Adapter
Configure your Adapter
After you install your new D-Link adapter, by default, the TCP/IP
settingsshouldbesettoobtainanIPaddressfromaDHCPserver
(i.e.router)automatically.ToverifyyourIPaddress,pleasefollow
thestepsbelow.
Windows®2000/XP:ClickonStart > Run.Intherunboxtypecmd
andclickOK.
Windows Vista®/ Windows® 7: Click on Start > All Programs >
Accessories > Command Prompt.
Attheprompt,typeipconfig
andpressEnter.
This will display the IP
address,subnetmask,and
thedefaultgatewayofyour
adapter.
If the address is 0.0.0.0, check your adapter installation, security
settings, and the settings on your router. Some rewall software
programsmayblockaDHCPrequestonnewlyinstalledadapters.
Ifyouareconnectingtoawirelessnetworkatahotspot(e.g.hotel,
coffeeshop,airport),pleasecontactanemployeeoradministrator
toverifytheirwirelessnetworksettings.

FormoreinformationonsettingyourIPaddress,pleaserefertothe
manual.

9 D-Link DFE-530TX+ Quick Install Guide
Configure your Adapter
IfyouarenotusingaDHCPcapablegateway/router,oryouneedto
assignastaticIPaddress,pleasefollowthestepsbelow.
Step 1:
Windows® 2000: Click on Start>Settings>Control Panel >
Network Connections
WindowsXP:ClickonStart>Control Panel > Network Connections
WindowsVista®: Click on Start>Control Panel > Network and
Internet > Network and Sharing Center > Manage network
connections
Windows®7:ClickonStart > Control Panel > Network and Internet
> Network and Sharing Center > Change Adapter Settings
Step 2:
Right-clickontheLocal Area Connection,whichrepresentsyour
D-Linknetworkadapter,andselectProperties.
Step 3:
HighlightInternet Protocol (TCP/IP)andclickProperties.
Step 4:
ClickUse the following IP addressandenteranIPaddressthat
isonthesamesubnetasyournetworkortheLANIPaddresson
yourrouter.
Example:Iftherouter’sLANIPaddressis192.168.0.1,makeyour
IP address 192.168.0.X where X is a number between 2 and 99.
Makesurethatthenumberyouchooseisnotinuseonthenetwork.
SetDefaultGatewaythesameastheLANIPaddressofyourrouter
(192.168.0.1).
SetPrimaryDNSthesameastheLANIPaddressofyourrouter
(192.168.0.1).TheSecondaryDNSisnotneededoryoumayenter
aDNSserverfromyourISP.

10D-Link DFE-530TX+ Quick Install Guide
Configure your Adapter
Step 5:
ClickOKtwicetosaveyoursettings.

11 D-Link DFE-530TX+ Quick Install Guide
Notes
Notes

12D-Link DFE-530TX+ Quick Install Guide
Technical Support
Technical Support
D-Link’swebsitecontainsthelatestuserdocumentationandsoftware
updatesforD-Linkproducts.
U.S.andCanadiancustomerscancontactD-LinkTechnicalSupport
throughourwebsiteorbyphone.
United States
Telephone
(877)453-5465
World Wide Web
http://support.dlink.com
Canada
Telephone
(800)361-5265
World Wide Web
http://support.dlink.ca
Version6.4
January12,2010
6FE530TXQB02G
