Overview
D-Link answers the need for a Broadband VPN Router
with the DIR-130. The DIR-130 is a simple-to-deploy
wired VPN router designed specifically for the Small
Office/Home Office (SOHO) market that demands
superior performance and security in a compact desktop
chassis.
User Configurable Interface
The DIR-130 features an intuitive user interface that
can be easily configured and monitored via the D-Link®
Web-based Management Utility. These configuration
options can be managed through the Administrator rights.
Advanced Hardware Features
The DIR-130 can be connected to a cable or DSL line to
share high-speed Internet access. It also doubles as an
8-port full-duplex 10/100 switch to connect up to eight
Ethernet-enabled devices. Simply add more switches to
expand your wired network. In addition, you can create a
Virtual Private Network (VPN) with the DIR-130 and allow
up to 251off-site or traveling users to securely access your
central network through the Internet simultaneously.
VPN Performance
For optimal VPN configuration, the DIR-130 has an
integrated VPN Server to support almost any required
VPN policy. This device has a hardware VPN engine
to support and manage up to 251VPN configurations.
The DIR-130 can support IPSec, PPTP, and L2TP
protocols, and can handle pass-through traffic as
well. Advanced VPN configuration options include:
DES/3DES/AES/Twofish/Blowfish encryption, IKE/ISAKMP
key management, Main/Aggressive Negotiation modes,
and VPN authentication support using the internal
1501-user database.
Security Features
This VPN router protects your network from online
intruders and potential attacks with Dual Active Firewall
protection using Stateful Packet Inspection (SPI) and
Network Address Translation (NAT).
With small businesses becoming increasingly
network-dependent, the need to invest in a reliable
security solution is crucial. The D-Link NetDefend SOHO
Ethernet VPN Router (DIR-130) offers high return on
investment through robust security features, flexible
configuration, and superb network protection for small
offices and home networks.
NetDefend™ soho Ethernet VPN Router
8-Port 10/100 Switch
DIR-130
Multi-Function Security
+ VPN Server
+ Content Manager
+ Network Access Control
Ports
+ 8 Ethernet LAN
+ 1 Ethernet WAN
Firewall Features
+ Network Address Translation (NAT)
+ Stateful Packet Inspection (SPI)
Embedded VPN Accelerator
+ Up to 251VPN Tunnels
+ IPSec, PPTP, L2TP
+ DES, 3DES, AES, Twofish, Blowfish
Encryption
+ Automated Key Management via
IKE/ISAKMP
+ Main/Aggressive Negotiation
Enhanced Network Services
+ DHCP Server
+ DNS Relay
+ E-mail Alert
+ Network Time Protocol (NTP) Support
+ Dynamic DNS Support

DIR-130
NetDefend™ soho Ethernet VPN Router
8-Port 10/100 Switch
Technical Specifications
Standards + IEEE 802.3 + IEEE 802.3u
Ports + 8 10/100 Mbps LAN + 1 10/100 Mbps WAN
+ 1 USB 1.1
Firewall Mode of Operation + Network Address Translation (NAT) + Port Address Translation (PAT)
VPN Security + VPN Tunnels: 251(IPSec, PPTP, L2TP) + IPSec NAT-Traversal
+ IPSec Site-to-Site/Roaming User + IPSec Dead Peer Detection
+ PPTP/L2TP Server/Client + IPSec/PPTP Pass-through
+ XAUTH (Extended Authentication) for IPSec
Authentication
+ Encryption Transform: DES, 3DES, AES, Twofish,
Blowfish
+ X.509v3 Certificates
Firewall Security + Stateful Packet Inspection (SPI) + Internal User Database (1501Records)
+ Network Address Translation (NAT)
Network Service + Static IP Address + Dynamic DNS
+ PPPoE for xDSL + Big Pond Cable, Telia Compliance
+ DHCP Client for WAN Interface + DNS Resolving of Remote Site-to-Site VPN
Gateway
+ Internal DHCP Server
Device Management Internet Explorer v6 or later; Firefox 1.5 or later
LEDs + Power + LAN
+ Status + WAN
Certifications FCC Class B
Operating Temperature 32°F to 131°F (0°C to 55°C)
Operating Humidity 95% Maximum (Non-condensing)
Dimensions + Item (WxDxH): 4.7” x 7.5” x 1.2” + Packaging (WxDxH): 8.2” x 10.8” x 2.7”
Weight + Item: 0.67 lbs + Packaging: 1.91 lbs
Warranty 1-Year Limited2
Ordering Information
Part Number Description
DIR-130 NetDefend™ SOHO Ethernet VPN Router 8-Port 10/100 Switch
1Feature available on versions 1.10 and later.
21-Year Limited Warranty available only in the USA and Canada.
